IECHO BK4 Series User manual

FOREWORD
Dear customer：
Hello!
BK4 series high-precision digital cutting system can automatically and accurately complete the processes of
full cutting, half cutting, engraving, punching, crease, marking, etc. at the same time, it is equipped with or
equipped with receiving and automatic feeding system to quickly complete blanking and cleaning. It is
suitable for the production of advertising signs, printing and packaging, automobile interior decoration,
furniture sofa, composite materials and other industries, Is the real all-round champion of material cutting.
Thank you for choosing to use IECHO high-speed digital cutting system!
When compiling this manual, we strive to be comprehensive and easy to understand. In order to facilitate
your better use of the equipment, please read the user manual carefully, operate according to the steps, and
keep it properly after reading. From the beginning to the end, IECHO's "star service" will accompany you. No
matter what problems you have, please contact us according to the telephone and address on the user
manual. We are always waiting to serve you.
Thank you again for choosing IECHO products, if there is any change for the manual contents due to product
improvement, we apologize in advance that we won’t make another notice

● Please read the product manual carefully before using the product.
● To ensure production safety, please read the "safety instructions".
Safety instructions
note
In principle, all installation, putting into use and maintenance
work should only be completed by qualified professionals !
note
There is a risk of serious injury to personnel and property under the following
circumstances：
Remove the housing without authorization
Incorrect installation and use
note
Internal or external changes to the equipment can only be made after
prior consultation with Hangzhou IECHO Technology Co., Ltd
note
The company shall not be liable for safety injuries caused by the use of
accessories not authorized by Hangzhou IECHO Technology Co., Ltd

目录
1. Equipment Overview ..................................................................................................................................................................... 1
1.1. Features.............................................................................................................................................................................. 1
1.2. Composition ..................................................................................................................................................................... 1
1.3. Working Principles .......................................................................................................................................................... 1
1.4. Technical Parameters...................................................................................................................................................... 2
1.5. Cutting head ..................................................................................................................................................................... 3
1.6. Cutting tools ..................................................................................................................................................................... 4
1.7. Circuit Boards introductions.......................................................................................................................................... 7
2. Installation ....................................................................................................................................................................................... 8
2.1. Installation of complete machine................................................................................................................................. 8
2.1.1. Loading and unloading ..................................................................................................................................... 8
2.1.2. Disassembly and assembly of the cover ........................................................................................................ 9
2.1.3. Remove the packing batten ............................................................................................................................. 9
2.1.4. Move the machine............................................................................................................................................ 10
2.1.5. Initial leveling of the base frame ................................................................................................................... 10
Leveling methods：........................................................................................................................................................ 10
2.2. Power supply .................................................................................................................................................................. 11
2.3. Air supply......................................................................................................................................................................... 12
2.4. Cutting head installation.............................................................................................................................................. 12
2.5. Cutting tools installation.............................................................................................................................................. 16
2.5.2. EOT installation.................................................................................................................................................. 17
2.5.4. Creasing tool installation ................................................................................................................................ 20
3. Operation....................................................................................................................................................................................... 20
3.1. Preparation...................................................................................................................................................................... 20
3.2. Steps ................................................................................................................................................................................. 20
4. Electrical wiring instructions ...................................................................................................................................................... 21
4.1. BK4 Circuit diagram of Machine................................................................................................................................. 21
4.2. BK4 Gas circuit diagram ............................................................................................................................................... 22
5. Common Error and Troubleshooting ...................................................................................................................................... 23
6. Safety Attentions.......................................................................................................................................................................... 24

1. Equipment Overview
1.1. Features
BK4 series cutting machine adopts the overall frame structure layout and brand-new appearance
design. Adhering to the design concept of efficient, accurate cutting and intelligent processing of IECHO
equipment, it takes a higher level in cutting efficiency, operation stability and noise reduction.
Efficient motion control system, high-speed motion and smooth operation;
The circulating air pump cooling system solves the contradiction between sound insulation and
heat dissipation, and the noise reduction effect is obvious;
High mechanical strength for high load work;
High precision CCD positioning to ensure cutting accuracy;
Vacuum area control;
Energy saving vortex vacuum control;
Cutting head processing technology.
1.2. Composition
BK4 series cutting machine is composed of electrical control cabinet, cutting machin, vacuum pump
and other auxiliary equipment. It can be equipped with automatic feeding system, computer rack, CCD,
automatic knife initialization and other functional modules; The software part consists of data
processing software and cutting machine control software. (please refer to the corresponding software
manual for software use)
According to user requirements, one or more of the following tools can be configured: UCT, EOT,
milling tool, V-CUT, Creasing tool, PRT, punching tool, general drawing pen, etc. (please refer to 1.6 tool
introduction for details)
1.3. Working Principles
Import the files into SmartCut/iBrightCut, the user can process the files (editing and nesting) and
send the processed cutting files to CutterServer. According to the cutting files, the controlling system will
create motion control signals. With the signals, servo motors execute the tools lift/down and modules
movement. Thereby, the machine achieves the high- speed and high-precision

1.4. Technical Parameters
Definition
Parameter
Model
BK4-2516
Cutting Area
2500mm×1600mm
Machine Dimension
3380mm×2200mm×1330mm
Area covered
According to the configuration, it’s around 10-15 ㎡
Weight
880KG
Max Speed
1800mm/s
Max Cutting Thickness
50mm
Accuracy
0.1 mm
Modules
Can be installed up to 2 cutting heads
File formats
DXF 、 PLT 、 PDF 、 HPG 、 HPGL 、 TSK 、
BRG 、 XML 、 CUT 、 OXF 、 ISO 、 AI 、 PS 、
EPS
Interface
Serial port/USB/
Adsorption
Vacuum Pump
Air supply Requirement
0.6~0.8MPa，Dry compressed air
Power Requirement
Three-phase 380V/single phase 220V 50Hz
Rated power
13KW
Storage Temperature
Temperature0 ℃ -40 ℃ ， Humidity 20%-80%RH

1.5. Cutting head
Universal
cutting head
All tools can be installed in
(Except for milling tools over
450W)
Cutting thickness ：
50mm
Punch head
Two punches are set.
It can punch round holes or
slotted and V-shaped knife
holes.
Punching Max: 10mm
thick material

1.6. Cutting tools
Illustration
Name
Ab.
Feature
Material
Tangent
Tool
CUT
Universal Cutting Tool for
materials up to 5mm thick.
Fast speed and low cost.
Cardboard, Chevron board, ABS
board, Gasket, Carbon fiber
prepreg, PVC tarpaulin, PE, XPE,
Label, e
Electric
Oscillating
Tool
EOT
High-frequency electric-driven
tool with 80W power options.
Max cutting speed 1m/s for
soft and medium-density
materials.
Chevron board, Corrugated
board, Gasket board, Gray
cardboard, PE, XPE, EPE, PU
leather composite sponge, Coil
car mat
Pneumati
c
Oscillating
Tool
POT
Powerful air-driven tool
with extended stroke for
dense materials up to
50mm thick.
Composites, Honeycomb
board, Asbestos gasket,
Graphite gasket, Sponge, EPE,
etc.
Kiss-Cut
Tool
KCT
By adjusting the position of
the tool tip, the material can
be accurately positioned and
processed, and the upper
material can be accurately
cut through without
damaging the bottom lining
material of the lower layer. It
is mainly suitable for cutting
vinyl material.
Vinyl, sticker, reflective film,
etc.

Driven
Rotary
Tool
DRT
Cutting tool with driven
rotary blade for fabrics and
technical textiles with high
processing speed.
Fabrics, carbon fiber, glass
fiber, aramid, carpet, etc.

Illustration
Name
Ab
Feature
Material
V-CUT
Tool
V-CUT
Tool with 5 cutting angles
(0°,15°,22.5°, 30°, 45°).
Create 3D structural
design
Honeycomb board,
sandwich board, KT board,
Gray board, etc
Powerful
Rotary
Tool
PRT
The cutting speed is fast
and it is not easy to burn
wire. With the hair
splitter, it can directly cut
wool materials. Wool
separator can be added.
textiles, carbon fiber, glass
fiber, carpet, fur, etc.。
Creasing
Tool
CTT
Creasing wheels for
carton box making
Corrugated board, carton
board, etc
CNC
Router
URT
Standard material suction
device, compressed air
cooling.
power ： 450W ；
RPM ： 60000rpm ；
Max thickness ：
16mm。
Acrylic, Di-bond, aluminum
composite, MDF, et

1.7. Circuit Boards introductions
Location diagram of circuit board of electrical box

2. Installation
2.1. Installation of complete machine
2.1.1. Loading and unloading
Use a forklift (the arm length of the forklift shall not be less than 2.3m) to operate from the side of
the machine, and pay attention to the center of gravity of the machine. Since the center of gravity

of the equipment is biased towards the front end, the cross beam is usually moved to the rear end
for fixation.
Use lifting device: four lifting ring mounting holes are provided on both sides of the equipment table to
facilitate lifting with lifting rings.
Two sleepers are installed at the bottom of the factory equipment, which can be directly placed on the
flat ground。
2.1.2. Disassembly and assembly of the cover
Before installation, remove 4 middle side covers on both sides. The middle side cover is fixed on
the machine with two 3M Velcro stickers on the left and right. Pull up the left and right sides of the
upper part of the middle side cover to separate the bonding surface, and then remove the middle side
cover。
2.1.3. Remove the packing batten
Remove the fixing bolts of the packing wooden strip with an 8mm wrench, lift the equipment and take

out the packing wooden strip. (forklift or "lengthening" foot can be used to lift the machine)
2.1.4. Move the machine
The equipment is equipped with casters, which can be used to move the machine on a flat site.
Before pushing the equipment, be sure to "shorten" the anchor to make the casters fall to the
ground.
2.1.5. Initial leveling of the base frame
After the equipment is moved to the installation site, adjust the base frame height to make the
casters of the equipment completely suspended, and then start to adjust the table level. Note:
the weight of BK4 2516 equipment is 880Kg, and the ground flatness of the equipment
installation position shall not be greater than 2cm.
Leveling methods：
(1) Turn on the power and air supply, and open the air pump and air valve.
(2) Place the level on the felt at position 1 (Y direction) as shown in the figure, and adjust anchor a

and anchor B to center the bubble of the level. Note that the felt at the place where the level ruler
is placed shall be clean and avoid the felt joint.
(3) Place the level on the felt at position 2 (x direction) as shown in the figure, and adjust the anchor
C to center the bubble of the level. Note that the felt at the place where the level ruler is placed
shall be clean and avoid the felt joint.
(4) Tighten the lock nut on the base frame
2.2. Power supply
Users need to provide 3-phase 5-wire power supply (3 phase lines / 1 zero line / 1 ground wire),
and connect the power supply to the main input terminal of the power supply with 5-core cable.
The power access terminal of the equipment electrical box is shown in the figure.
The power output terminal of the equipment electrical box is shown in the figure. The electrical
box is provided with a 380V three-phase power socket and several 220V power sockets, which can

后前腰型槽 圆柱销
provide power for computer console, vacuum cleaner, milling cutter, feeding rack, etc.
2.3. Air supply
An air source interface is set at the back of the equipment electrical box, and a 12mm diameter air
pipe needs to be used to connect the "main air source inlet". Note: if the equipment is equipped with
additional functions such as milling cutter and pneumatic vibrating cutter, the corresponding air source
interface of the electrical box can be used; If there is no additional configuration, be sure to keep the
interface closed to avoid air leakage affecting the normal use of the equipment.
2.4. Cutting head installation
Tilt the machine head to the support plate on the beam, and the bottom of the machine head is close
to the mounting surface of the support plate. Make sure that the waist groove on the back of the head

slides into the cylindrical pin on the support plate. 
Rotate the nose forward with the bottom of the nose as the rotating shaft. Make sure that the stepped
cylindrical pin on the support plate slides into the hoist block on the back of the head.
Push the head down to the bottom (about 15mm), and insert the female flat plug on the head into the
male flat plug on the support plate.


Note: the limit slot on the back of the head must fit the clamping step on the support plate.
After installation in place, tighten two M5 fixing screws with 4mm Allen wrench.

2.5. Cutting tools installation
2.5.1. UCT installation
Put the sharp knife tool into the machine head, and the red dot in the UCT corresponds to the red dot
on the machine head.
After the UCT is completely put into the machine head, tighten it clockwise to complete the installation.

2.5.2. EOT installation
Put the EOT into the machine head, and the red dot in the EOT corresponds to the red dot on the
machine head
After the EOT is completely put into the machine head, tighten it clockwise, lock the fixing block, and
the installation is completed.
