IEI Technology IKARPC-07A User manual

IKARPC-07A-A8 In-vehicle Panel PC
Page I
User Manual
MODEL:
IKARPC-07A
7” Android-Based In-
V
ehicle Panel PC with Touch Screen
TI AM3715 ARM Cortex™ A8 CPU, OBD-II, CAN, USB, Audio,
RS-232, RoHS Compliant, IP 54 Front Panel
Rev. 1.02 – December 24, 2014

IKARPC-07A-A8 In-vehicle Panel PC
Page II
Revision
Date Version Changes
December 24, 2014 1.02 Modified power input voltage range
October 7, 2013 1.01 Updated for new Android version 4.1.2
December 5, 2012 1.00 Initial release

IKARPC-07A-A8 In-vehicle Panel PC
Page III
Copyright
COPYRIGHT NOTICE
The information in this document is subject to change without prior notice in order to
improve reliability, design and function and does not represent a commitment on the part
of the manufacturer.
In no event will the manufacturer be liable for direct, indirect, special, incidental, or
consequential damages arising out of the use or inability to use the product or
documentation, even if advised of the possibility of such damages.
This document contains proprietary information protected by copyright. All rights are
reserved. No part of this manual may be reproduced by any mechanical, electronic, or
other means in any form without prior written permission of the manufacturer.
TRADEMARKS
All registered trademarks and product names mentioned herein are used for identification
purposes only and may be trademarks and/or registered trademarks of their respective
owners.

IKARPC-07A-A8 In-vehicle Panel PC
Page IV
Table of Contents
1 INTRODUCTION.......................................................................................................... 1
1.1 OVERVIEW.................................................................................................................. 2
1.2 FEATURES................................................................................................................... 2
1.3 FRONT PANEL............................................................................................................. 3
1.3.1 Function Keys .................................................................................................... 4
1.3.2 LED Indicators................................................................................................... 4
1.4 REAR PANEL............................................................................................................... 5
1.5 SIDE PANELS .............................................................................................................. 6
1.6 TOP PANEL ................................................................................................................. 7
1.7 BOTTOM PANEL.......................................................................................................... 7
1.8 SYSTEM SPECIFICATIONS............................................................................................ 7
1.9 DIMENSIONS............................................................................................................. 10
2 UNPACKING................................................................................................................11
2.1 PACKING LIST........................................................................................................... 12
2.2 OPTIONAL ITEMS...................................................................................................... 13
3 INSTALLATION ......................................................................................................... 15
3.1ANTI-STATIC PRECAUTIONS...................................................................................... 16
3.2 INSTALLATION PRECAUTIONS................................................................................... 16
3.3 INSTALLATION AND CONFIGURATION STEPS ............................................................. 17
3.4 SD CARD INSTALLATION.......................................................................................... 17
3.5 SIM CARD INSTALLATION........................................................................................ 18
3.6 MOUNTING THE SYSTEM .......................................................................................... 21
3.7 EXTERNAL I/O CONNECTORS ................................................................................... 22
3.7.1 I/O Connector 1 (20-pin)................................................................................. 22
3.7.2 I/O Connector 2 (24-pin)................................................................................. 23
3.7.3 Power Input Connection.................................................................................. 24
3.7.4 USB Connectors............................................................................................... 26
3.8 SYSTEM MAINTENANCE........................................................................................... 26
4 USING THE IKARPC-07A-A8 .................................................................................. 27

IKARPC-07A-A8 In-vehicle Panel PC
Page V
4.1 POWER-ON/OFF PROCEDURE ................................................................................... 28
4.1.1 Installation Checklist....................................................................................... 28
4.1.2 Power-on Procedure ........................................................................................ 28
4.1.3 Power-off Procedure........................................................................................ 30
4.2 FUNCTION BUTTONS ................................................................................................ 31
4.3 HOME SCREEN ......................................................................................................... 32
4.3.1 Multiple Home Screens.................................................................................... 32
4.3.2 Add Shortcut..................................................................................................... 32
4.3.3 Arrange the Home Screen................................................................................ 33
4.3.4 Function Menu................................................................................................. 34
4.4 SETTINGS ................................................................................................................. 34
4.4.1 WIRELESS & NETWORKS.............................................................................. 35
4.4.1.1 More Settings............................................................................................ 36
4.4.2 Sound................................................................................................................ 37
4.4.3 Display............................................................................................................. 38
4.4.4 Storage............................................................................................................. 39
4.4.5 Apps.................................................................................................................. 40
4.4.6 Location Access................................................................................................ 40
4.4.7 Security ............................................................................................................ 41
4.4.8 Language & Input............................................................................................ 42
4.4.9 Backup & Reset................................................................................................ 43
4.4.10 Add account.................................................................................................... 44
4.4.11 Date & Time ................................................................................................... 44
4.4.12 Accessibility ................................................................................................... 45
4.4.13 Developer Options......................................................................................... 46
4.4.14 About Tablet................................................................................................... 47
4.5 FILE MANAGER........................................................................................................ 48
4.6 CAMERA................................................................................................................... 49
4.7 RFID READER.......................................................................................................... 50
4.8 GPS ......................................................................................................................... 52
4.8.1 Satellite Location and Signal Strength............................................................. 52
4.8.2 Main Satellite Information in Cockpit View..................................................... 53
4.8.3 Current Location in World Map View.............................................................. 53
4.8.4 NMEA Messages from the GPS Receiver......................................................... 54
4.8.5 Basic Information from Each Satellite............................................................. 55

IKARPC-07A-A8 In-vehicle Panel PC
Page VI
4.8.6 Preferences Menu............................................................................................. 55
4.9 SYSTEM UPDATE ...................................................................................................... 57
5 INTERFACE CONNECTORS................................................................................... 61
5.1 PERIPHERAL INTERFACE CONNECTORS..................................................................... 62
5.2 INTERNAL PERIPHERAL CONNECTORS...................................................................... 63
5.2.1 Camera Connector (CAMERA1) ..................................................................... 64
5.2.2 LVDS Connector (LVDS1)............................................................................... 64
5.2.3 Microphone Connector (MIC2)....................................................................... 65
5.2.4 Programming Connector (CN7, CN8)............................................................. 65
5.2.5 Programming Connector (MCU1, JP2)........................................................... 65
5.2.6 Speaker Connector (SPK2).............................................................................. 66
5.2.7 Touch Panel Connector (TS1).......................................................................... 66
A OBD-II READER COMMAND................................................................................. 67
A.1 SELECT A CHIP INITIAL MODE:UPDATE F/W OR RUN F/W.................................... 68
A.2 BOOT MODE............................................................................................................ 68
A.3 RUN MODE.............................................................................................................. 68
A.4 INTO CAN_STANDARD V2.2.B (CAN STANDARD) ................................................. 70
A.5 INTO TELEMATICS (VEHICEL INFORMATION)........................................................... 72
B WATCHDOG TIMER................................................................................................. 76
C HAZARDOUS MATERIALS DISCLOSURE......................................................... 79
C.1 HAZARDOUS MATERIALS DISCLOSURE TABLE FOR IPB PRODUCTS CERTIFIED AS
ROHS COMPLIANT UNDER 2002/95/EC WITHOUT MERCURY ....................................... 80

IKARPC-07A-A8 In-vehicle Panel PC
Page VII
List of Figures
Figure 1-1: IKARPC-07A-A8 Panel PC..........................................................................................2
Figure 1-2: Front View....................................................................................................................3
Figure 1-3: Function Keys .............................................................................................................4
Figure 1-4: LED Indicators.............................................................................................................4
Figure 1-5: Rear View.....................................................................................................................6
Figure 1-6: Side Panels..................................................................................................................6
Figure 1-7: Top Panel.....................................................................................................................7
Figure 1-8: Bottom Panel...............................................................................................................7
Figure 1-9: Dimensions (unit: mm).............................................................................................10
Figure 3-1: SD Card Slot Access Panel Retention Screw.........................................................17
Figure 3-2: Install the SD Card....................................................................................................18
Figure 3-3: SIM Card Slot Access Panel Retention Screw.......................................................18
Figure 3-4: Unlock the SIM Card Slot Cover..............................................................................19
Figure 3-5: Open the SIM Card Slot Cover.................................................................................19
Figure 3-6: Place a SIM Card.......................................................................................................20
Figure 3-7: Lock the SIM Card Slot Cover..................................................................................20
Figure 3-8: VESA Mount Retention Screw Holes ......................................................................21
Figure 3-9: I/O Connector 1 Pinouts Location...........................................................................22
Figure 3-10: I/O Connector 2 Pinouts Location.........................................................................23
Figure 3-11: Power Input Connector...........................................................................................24
Figure 3-12: ACC Power Cable....................................................................................................25
Figure 3-13: Optional Cigarette Lighter Cable...........................................................................25
Figure 3-14: USB Connector........................................................................................................26
Figure 4-1: Power Connector and Power Button ......................................................................29
Figure 4-2: Power-off Confirmation Screen...............................................................................30
Figure 4-3: Function Buttons ......................................................................................................31
Figure 4-4: Multiple Home Screens.............................................................................................32
Figure 4-5: Launcher Page ..........................................................................................................33
Figure 4-6: Move and Trash Item on Home Screen...................................................................33
Figure 4-7: Home Screen Function Menu ..................................................................................34

IKARPC-07A-A8 In-vehicle Panel PC
Page VIII
Figure 4-8: Wireless and Networks Settings .............................................................................35
Figure 4-9: More Settings Menu..................................................................................................36
Figure 4-10: Sound Menu.............................................................................................................37
Figure 4-11: Display Menu...........................................................................................................38
Figure 4-12: Storage Menu ..........................................................................................................39
Figure 4-13: Apps Menu...............................................................................................................40
Figure 4-14: Location Access Menu...........................................................................................40
Figure 4-15: Security Menu..........................................................................................................41
Figure 4-16: Language & Input Menu .........................................................................................42
Figure 4-17: Backup & Reset Menu ............................................................................................43
Figure 4-18: Add Account Menu .................................................................................................44
Figure 4-19: Date & Time Menu...................................................................................................44
Figure 4-20: Accessibility Menu..................................................................................................45
Figure 4-21: Developer Options Menu........................................................................................46
Figure 4-22: About Tablet Menu..................................................................................................47
Figure 4-23: OI File Manager .......................................................................................................48
Figure 4-24: Possible Storage Devices ......................................................................................49
Figure 4-25: Camera Application ................................................................................................50
Figure 4-26: RFID Application .....................................................................................................51
Figure 4-27: Tag Information.......................................................................................................51
Figure 4-28: Satellite Location and Signal Strength.................................................................52
Figure 4-29: Main Satellite Information in Cockpit View...........................................................53
Figure 4-30: Current Location in World Map View....................................................................54
Figure 4-31: NMEA Messages .....................................................................................................54
Figure 4-32: Basic Information from Each Satellite..................................................................55
Figure 4-33: Preferences Menu...................................................................................................56
Figure 4-34: System Update Icon................................................................................................58
Figure 4-35: System Update-Browse Storage ...........................................................................58
Figure 4-36: System Update-Select SD Card.............................................................................59
Figure 4-37: System Update-Select File.....................................................................................59
Figure 4-38: System Update-Update...........................................................................................60
Figure 5-1: Main Board Layout Diagram (Front Side)...............................................................62
Figure 5-2: Main Board Layout Diagram (Solder Side).............................................................62

IKARPC-07A-A8 In-vehicle Panel PC
Page IX
List of Tables
Table 1-1: Technical Specifications..............................................................................................9
Table 2-1: Packing List.................................................................................................................13
Table 2-2: Optional Items.............................................................................................................14
Table 3-1: I/O Connector 1 Pinouts.............................................................................................22
Table 3-2: I/O Connector 2 Pinouts.............................................................................................23
Table 3-3: Power Input Connector Pinouts................................................................................24
Table 4-1: Power Sate and Ignition System...............................................................................29
Table 4-2: Function Buttons........................................................................................................31
Table 4-3: Function Buttons........................................................................................................34
Table 4-4: Satellite Color Coding................................................................................................53
Table 5-1: Peripheral Interface Connectors...............................................................................63
Table 5-2: Camera Connector (CAMERA1) Pinouts..................................................................64
Table 5-3: LVDS Connector (LVDS1) Pinouts............................................................................65
Table 5-4: Microphone Connector (MIC2) Pinouts....................................................................65
Table 5-5: Programming Connector (CN7, CN8) Pinouts.........................................................65
Table 5-6: Programming Connector (MCU1, JP2) Pinouts.......................................................65
Table 5-7: Speaker Connector (SPK2) Pinouts..........................................................................66
Table 5-8: Touch Panel Connector (TS1) Pinouts.....................................................................66

IKARPC-07A-A8 In-vehicle Panel PC
Page 1
Chapter
1
1 Introduction

IKARPC-07A-A8 In-vehicle Panel PC
Page 2
1.1 Overview
Figure 1-1: IKARPC-07A-A8 Panel PC
The IKARPC-07A-A8 is a 7” Android-based panel PC designed for in-car use.
At the heart of the system is the Texas Instruments (TI) AM3715 ARM Cortex™ A8
processor, offering low power in a powerful package. The system also offers a multimedia
experience with a built-in camera, microphone and speakers. Other peripherals include
two USB ports and two I/O connectors which support RS-232, OBD-II, CAN 2.0 B, digital
I/O, video input and audio input/output. Wireless networking capabilities include
Bluetooth 2.1 and 802.11b/g/n.
1.2 Features
The IKARPC-07A-A8 features the following:
TI AM3715 ARM Cortex™ A8 processor
On-board 1.0 GB 533 MHz DDR2 memory
Pre-installed Android 4.1.2 operating system
802.11b/g/n wireless
Bluetooth 2.1 + EDR Class 1
Two USB 2.0 ports
3.75G connectivity with external antenna

IKARPC-07A-A8 In-vehicle Panel PC
Page 3
Support OBD-II, CAN 2.0 B, digital I/O and RS-232
GPS antenna connector
2-megapixel front-facing camera, speaker, microphone
Touch screen
IP 54 compliant front panel
RoHS compliance
1.3 Front Panel
The front of the IKARPC-07A-A8 is a flat panel screen with a plastic frame. The
components on the front panel are listed below:
2-megapixel camera
Ambient light sensor
Four Function key (refer to Section 1.3.1)
LED indicators (see Section 1.3.2)
Microphone
RFID reader
Figure 1-2: Front View

IKARPC-07A-A8 In-vehicle Panel PC
Page 4
1.3.1 Function Keys
There are four function keys on the front panel of the IKARPC-07A-A8 as shown in the
figure below.
Figure 1-3: Function Keys
1.3.2 LED Indicators
The LED indicators on the front panel show the status of power, Bluetooth, Wi-Fi and
GPRS/HSUPA connection.
Figure 1-4: LED Indicators

IKARPC-07A-A8 In-vehicle Panel PC
Page 5
1.4 Rear Panel
The rear panel has VESA mounting screw holes and an access panel for SD card and SIM
card. The following I/O connectors can also be found on the rear panel.
1 x 9 V~ 30 V DC input connector
20-pin connector:
o1 x 10/100 Mbps LAN
o1 x CAN 2.0 B
o1 x OBD-II
o1 x USB
24-pin Connector:
o1 x Audio line-out (R+L)
o1 x Audio mic-in
o1 x RS-232
o1 x Video in
o2-bit digital input
o2-bit digital output
1 x 3.75G antenna connector
1 x GPS antenna connector

IKARPC-07A-A8 In-vehicle Panel PC
Page 6
Figure 1-5: Rear View
1.5 Side Panels
Each side panel has one USB host port.
Right Panel Left Panel
Figure 1-6: Side Panels

IKARPC-07A-A8 In-vehicle Panel PC
Page 7
1.6 Top Panel
The top panel has a power button. Press the power button for 4~6 seconds to power on
the system.
Figure 1-7: Top Panel
1.7 Bottom Panel
The bottom panel has a 1 W speaker.
Figure 1-8: Bottom Panel
1.8 System Specifications
The technical specifications for the IKARPC-07A-A8 systems are listed in Table 1-1.
System
CPU TI AM3715 ARM Cortex™ A8 processor
Memory On-board 512 MB DDR memory
Boot Flash 4 GB iNAND e.MMC Flash
OS Android 4.1.2
Storage One SD card slot (SD 2.0 compatible, max. 32 GB)
Audio 1 x Speaker (1 W)
1 x Microphone

IKARPC-07A-A8 In-vehicle Panel PC
Page 8
Camera Front-facing 2-megapixel camera
Watchdog Timer Software programmable supports 1~255 sec. system reset
Real-time Clock Battery backup RTC
Display
LCD 7” TFT LCD with LED backlight
Max. Resolution 800 x 480 (WVGA)
Brightness (cd/m2) 500
Viewing Angle (H-V) 130/140
Touchscreen 5-wire projective capacitive touchscreen
Auto-dimming Yes
Communication
LAN 1 x 10/100 Mbps RJ-45
Wireless LAN 802.11b/g/n
Bluetooth Bluetooth 2.1 + EDR Class 1
WWAN Built-in u-blox LISA-U200-00S 3.75G UMTS/HSPA+ module supports:
HSPA/UMTS-800/850/1900/2100 MHz
Quad-band EDGE/GPRS/GSM-850/900/1800/1900MHz
GPS Built-in u-blox MAX-6Q GPS module with external antenna
RFID On-board RFID antenna
13.56MHz protocols supported:
ISO/IEC 14443A, ISO/IEC 14443B PCD 106 kbit/s to 848 kbit/s
ISO/IEC 14443A, ISO/IEC 14443B PICC 106 kbit/s to 424 kbit/s
Power
Power Input 4-pin (2x2) Molex power connector supports DC or ACC power
Optional 40 W power adapter with transfer cable
DC Power 9 V ~ 30 V DC input via cigarette lighter power cable
ACC Power ACC power on/off mode with software configurable delay time
Physical Character
Construction Material ABS + PC plastic front frame
Mounting VESA 75 mm x 75 mm
Dimensions (W x H x D) 210.0 mm x 154.0 mm x 28.1 mm
Operation Temperature -20ºC ~ 60ºC
Storage Temperature -30ºC ~ 70ºC
Humidity 5% ~ 95%, non-condensing

IKARPC-07A-A8 In-vehicle Panel PC
Page 9
Net weight 0.8 kg
IP level IP 54 compliant front panel
Drop Survival 1 m
Safety CE, FCC, e-MARK, ISO7637
Connectors and Buttons
Antenna Connectors 1 x 3.75G antenna SMA female connector
1 x GPS antenna SMA female connector
Expansion Slot 1 x SIM card slot
I/O Ports 1 x 9 V~ 30 V DC input connector
2 x USB Host ports
20-pin Connector:
1 x 10/100 Mbps LAN
1 x CAN 2.0 B
1 x OBD-II
1 x USB
24-pin Connector:
1 x Audio line-out (R+L)
1 x Audio mic-in
1 x RS-232
1 x Video in
2-bit digital input
2-bit digital output
Front Panel Buttons 1 x Power button
4 x Function buttons (Home, Menu, Back, Search)
LED Indicators 1 x Power LED
1 x Bluetooth status LED
1 x Wi-Fi connection LED
1 x 3G connection LED
Table 1-1: Technical Specifications

IKARPC-07A-A8 In-vehicle Panel PC
Page 10
1.9 Dimensions
The dimensions are shown below.
Figure 1-9: Dimensions (unit: mm)
