IEI Technology KINO-9453 User manual

KINO-9453 Mini-ITX Motherboard
Page I
KINO-9453 Motherboard User Manual

KINO-9453 Mini-ITX Motherboard
Page II
Revision
Date Version Changes
2008-07 v2.00 -Changed Northbridge chipset from Intel® 945GM to Intel® 945GME
-Added system fan connector (SYS_FAN1) information
-Added three jumper information:
 AT/ATX power mode select jumpers
 LVDS screen resolution select jumper

COM3 mode select jumpers
 RS-422/485 terminal resister jumpers
2007-04 v1.00 Initial Release

KINO-9453 Mini-ITX Motherboard
Page III
Copyright
COPYRIGHT NOTICE
The information in this document is subject to change without prior notice in order to
improve reliability, design and function and does not represent a commitment on the part
of the manufacturer.
In no event will the manufacturer be liable for direct, indirect, special, incidental, or
consequential damages arising out of the use or inability to use the product or
documentation, even if advised of the possibility of such damages.
This document contains proprietary information protected by copyright. All rights are
reserved. No part of this manual may be reproduced by any mechanical, electronic, or
other means in any form without prior written permission of the manufacturer.
TRADEMARKS
All registered trademarks and product names mentioned herein are used for identification
purposes only and may be trademarks and/or registered trademarks of their respective
owners.

KINO-9453 Mini-ITX Motherboard
Page IV
Manual Conventions
WARNING!
Warnings appear where overlooked details may cause damage to the equipment or result
in personal injury. Warnings should be taken seriously. Warnings are easy to recognize.
The word “warning” is written as “WARNING,” both capitalized and bold and is followed by
text. The text is the warning message. A warning message is shown below:
WARNING:
This is an example of a warning message. Failure to adhere to warning
messages may result in permanent damage to the KINO-9453 or
personal injury to the user. Please take warning messages seriously.
CAUTION!
Cautionary messages should also be heeded to help reduce the chance of losing data or
damaging the KINO-9453. Cautions are easy to recognize. The word “caution” is written
as “CAUTION,” both capitalized and bold and is followed. The italicized text is the
cautionary message.Acaution message is shown below:

KINO-9453 Mini-ITX Motherboard
Page
V
CAUTION:
This is an example of a caution message. Failure to adhere to cautions
messages may result in permanent damage to the KINO-9453. Please
take caution messages seriously.
NOTE:
These messages inform the reader of essential but non-critical information. These
messages should be read carefully as any directions or instructions contained therein can
help avoid making mistakes. Notes are easy to recognize. The word “note” is written as
“NOTE,” both capitalized and bold and is followed by text. The text is the cautionary
message. A note message is shown below:
NOTE:
This is an example of a note message. Notes should always be read.
Notes contain critical information about the KINO-9453. Please take
note messages seriously.

KINO-9453 Mini-ITX Motherboard
Page VI
Packing List
NOTE:
If any of the components listed in the checklist below are missing,
please do not proceed with the installation. Contact the IEI reseller or
vendor you purchased the KINO-9453 from or contact an IEI sales
representative directly. To contact an IEI sales representative, please
send an email to [email protected].
The items listed below should all be included in the KINO-9453 package.
 1 x KINO-9453 single board computer
 1 x IDE cable
 1 x SATA power cable
 2 x SATA cables
 1 x Dual RS-232 cable
 1 x I/O shielding
 1 x Mini jumper pack
 1 x Utility CD
 1 x QIG (quick installation guide)
Images of the above items are shown in Chapter 3.

KINO-9453 Mini-ITX Motherboard
Page
V
II
Table of Contents
1INTRODUCTION..................................................................................................... 1
1.1 INTRODUCTION .......................................................................................................... 2
1.1.1 KINO-9453 Benefits........................................................................................... 3
1.1.2 KINO-9453 Features.......................................................................................... 3
1.2 KINO-9453 OVERVIEW............................................................................................. 3
1.2.1 KINO-9453 Overview Photo.............................................................................. 3
1.2.2 KINO-9453 Peripheral Connectors and Jumpers ............................................. 4
1.2.3 Technical Specifications..................................................................................... 5
2DETAILED SPECIFICATIONS ............................................................................. 8
2.1 OVERVIEW ................................................................................................................. 9
2.2 DIMENSIONS .............................................................................................................. 9
2.2.1 Board Dimensions.............................................................................................. 9
2.2.2 External Interface Panel Dimensions.............................................................. 10
2.3 DATA FLOW...............................................................................................................11
2.4 COMPATIBLE PROCESSORS ....................................................................................... 12
2.4.1 Compatible Processor Overview ..................................................................... 12
2.4.2 Supported Processors ...................................................................................... 12
2.5 INTEL®945GME NORTHBRIDGE CHIPSET ............................................................... 13
2.5.1 Intel®945GME Overview................................................................................ 13
2.5.2 Intel®945GME Memory Support..................................................................... 13
2.5.3 Intel®945GME Integrated Graphics............................................................... 14
2.5.3.1 Intel®945GME Analog CRT Support....................................................... 15
2.5.3.2 Intel®945GME LVDS Support................................................................. 15
2.5.3.3 Intel®945GME SDVO Support................................................................ 15
2.5.4 Intel®945GME Direct Media Interface (DMI)................................................ 15
2.6 INTEL®ICH7-M SOUTHBRIDGE CHIPSET................................................................. 16
2.6.1 Intel®ICH7-M Overview ................................................................................. 16
2.6.2 Intel®ICH7-M Audio Codec ’97 Controller.................................................... 16
2.6.3 Intel®ICH7-M IDE Interface........................................................................... 17
2.6.4 Intel®ICH7-M Low Pin Count (LPC) Interface.............................................. 17

KINO-9453 Mini-ITX Motherboard
Page VIII
2.6.5 Intel®ICH7-M PCI Interface........................................................................... 18
2.6.6 Intel®ICH7-M Real Time Clock ...................................................................... 18
2.6.7 Intel®ICH7-M SATA Controller ...................................................................... 18
2.6.8 Intel®ICH7-M USB Controller........................................................................ 18
2.7 PCIE BUS COMPONENTS .......................................................................................... 19
2.7.1 PCIe Bus Overview.......................................................................................... 19
2.7.2 Broadcom PCI Express GbE interface............................................................. 19
2.8 LPC BUS COMPONENTS........................................................................................... 19
2.8.1 LPC Bus Overview........................................................................................... 19
2.8.2 BIOS Chipset.................................................................................................... 20
2.8.3 Super I/O chipset.............................................................................................. 20
2.8.3.1 Super I/O LPC Interface ........................................................................... 21
2.8.3.2 Super I/O 16C550 UARTs ........................................................................ 21
2.8.3.3 Super I/O Enhanced Hardware Monitor................................................... 21
2.8.3.4 Super I/O Fan Speed Controller................................................................ 21
2.8.3.5 Super I/O Keyboard Controller................................................................. 21
2.9 ENVIRONMENTALAND POWER SPECIFICATIONS ....................................................... 22
2.9.1 System Monitoring ........................................................................................... 22
2.9.2 Operating Temperature and Temperature Control........................................... 23
2.9.3 Power Consumption......................................................................................... 23
3UNPACKING .......................................................................................................... 24
3.1 ANTI-STATIC PRECAUTIONS...................................................................................... 25
3.2 UNPACKING.............................................................................................................. 25
3.2.1 Unpacking Precautions.................................................................................... 25
3.3 UNPACKING CHECKLIST........................................................................................... 26
3.3.1 Package Contents............................................................................................. 26
3.3.2 Optional Items.................................................................................................. 27
4CONNECTOR PINOUTS...................................................................................... 29
4.1 PERIPHERAL INTERFACE CONNECTORS .................................................................... 30
4.1.1 KINO-9453 Layout........................................................................................... 30
4.1.2 Peripheral Interface Connectors ..................................................................... 31
4.1.3 External Interface Panel Connectors............................................................... 32
4.2 INTERNAL PERIPHERAL CONNECTORS...................................................................... 32

KINO-9453 Mini-ITX Motherboard
Page I
X
4.2.1 Fan Connectors................................................................................................ 32
4.2.2 Front Panel Connector .................................................................................... 33
4.2.3 Digital Input/Output Connector....................................................................... 34
4.2.4 IDE Connector................................................................................................. 35
4.2.5 LCD Backlight Connector................................................................................ 37
4.2.6 LVDS LCD connector ...................................................................................... 38
4.2.7 Mini PCI Slot ................................................................................................... 40
4.2.8 Power Connector............................................................................................. 41
4.2.9 14-Pin Serial Port Connectors......................................................................... 42
4.2.10 10-Pin Serial Port Connectors....................................................................... 43
4.2.11 SATA Drive Connectors.................................................................................. 44
4.2.12 SPDIF Connector........................................................................................... 45
4.2.13 Internal USB Connectors............................................................................... 46
4.3 EXTERNAL INTERFACE CONNECTORS....................................................................... 47
4.3.1 Audio Connectors............................................................................................. 48
4.3.2 CRT Connector ................................................................................................ 48
4.3.3 DVI Connector................................................................................................. 49
4.3.4 Ethernet Connectors ........................................................................................ 50
4.3.5 Keyboard/Mouse Connector ............................................................................ 51
4.3.6 Serial Port Connectors .................................................................................... 52
4.3.7 USB Connector ................................................................................................ 53
5INSTALLATION .................................................................................................... 55
5.1 ANTI-STATIC PRECAUTIONS...................................................................................... 56
5.2 INSTALLATION CONSIDERATIONS ............................................................................. 57
5.2.1 Installation Notices.......................................................................................... 57
5.2.2 Installation Checklist....................................................................................... 58
5.3 CPU, CPU COOLING KITAND DIMM INSTALLATION ............................................. 59
5.3.1 Socket 479 CPU Installation............................................................................ 59
5.3.2 Cooling Kit CF-479B-RS Installation.............................................................. 62
5.3.3 DIMM Installation........................................................................................... 64
5.4 JUMPER SETTINGS.................................................................................................... 65
5.4.1 AT/ATX Power Select Jumper Settings ............................................................ 66
5.4.2 Clear CMOS Jumper........................................................................................ 67
5.4.3 COM 3 Function Select Jumper....................................................................... 69

KINO-9453 Mini-ITX Motherboard
Page X
5.4.4 RS-422 or RS-486 Termination Resister.......................................................... 70
5.4.5 LVDS Screen Resolution Selection................................................................... 71
5.4.6 LVDS Voltage Selection.................................................................................... 73
5.5 CHASSIS INSTALLATION ........................................................................................... 75
5.5.1 Airflow.............................................................................................................. 75
5.5.2 Motherboard Installation................................................................................. 75
5.6 INTERNAL PERIPHERAL DEVICE CONNECTIONS........................................................ 76
5.6.1 Peripheral Device Cables................................................................................ 76
5.6.2 IDE Cable Connection..................................................................................... 76
5.6.3 Dual RS-232 Cable Connection....................................................................... 77
5.6.4 SATA Drive Connection ................................................................................... 78
5.7 EXTERNAL PERIPHERAL INTERFACE CONNECTION................................................... 80
5.7.1 Audio Connection............................................................................................. 80
5.7.2 RJ-45 Ethernet Connection.............................................................................. 81
5.7.3 USB Connection............................................................................................... 82
5.7.4 VGA Monitor Connection ................................................................................ 83
5.7.5 Serial Device Connection ................................................................................ 84
5.7.6 PS/2 Keyboard/Mouse Connection.................................................................. 85
6AMI BIOS................................................................................................................ 87
6.1 INTRODUCTION ........................................................................................................ 88
6.1.1 Starting Setup................................................................................................... 88
6.1.2 Using Setup...................................................................................................... 88
6.1.3 Getting Help..................................................................................................... 89
6.1.4 Unable to Reboot After Configuration Changes.............................................. 89
6.1.5 BIOS Menu Bar................................................................................................ 89
6.2 MAIN ....................................................................................................................... 90
6.3 ADVANCED............................................................................................................... 91
6.3.1 CPU Configuration.......................................................................................... 92
6.3.2 IDE Configuration........................................................................................... 93
6.3.2.1 IDE Master, IDE Slave ............................................................................. 96
6.3.3 Super IO Configuration.................................................................................. 100
6.3.4 Hardware Health Configuration.................................................................... 104
6.3.5 ACPI Configuration ....................................................................................... 109
6.3.5.1 General ACPI Configuration................................................................... 109

KINO-9453 Mini-ITX Motherboard
Page
X
I
6.3.6 APM Configuration.........................................................................................111
6.3.7 Remote Access Configuration.........................................................................113
6.3.8 USB Configuration..........................................................................................117
6.3.8.1 USB Mass Storage Device Configuration............................................... 120
6.4 PCI/PNP ................................................................................................................ 122
6.5 BOOT ..................................................................................................................... 128
6.5.1 Boot Settings Configuration........................................................................... 129
6.5.2 Boot Device Priority...................................................................................... 131
6.5.3 Removable Drives.......................................................................................... 133
6.6 SECURITY............................................................................................................... 134
6.7 CHIPSET ................................................................................................................. 135
6.7.1 NorthBridge Configuration............................................................................ 136
6.7.1.1 Video Function Configuration ................................................................ 137
6.7.2 SouthBridge Chipset Configuration............................................................... 140
6.8 EXIT....................................................................................................................... 142
7DRIVER INSTALLATION.................................................................................. 144
7.1 AVAILABLE SOFTWARE DRIVERS ............................................................................ 145
7.2 DRIVER CD AUTO-RUN.......................................................................................... 145
7.3 CHIPSET DRIVER INSTALLATION............................................................................. 146
7.4 INTEL GRAPHICS MEDIAACCELERATOR DRIVER ................................................... 151
7.5 BROADCOM LAN DRIVER (FOR GBE LAN) INSTALLATION .................................. 157
7.6 REALTEK HD AUDIO DRIVER (ALC883) INSTALLATION ....................................... 163
7.6.1 BIOS Setup..................................................................................................... 163
7.6.2 Driver Installation ......................................................................................... 163
7.7 REALTEK AC`97 AUDIO DRIVER (ALC665) INSTALLATION .................................. 167
7.7.1 BIOS Setup..................................................................................................... 167
7.7.2 Driver Installation ......................................................................................... 167
7.8 INTEL MATRIX STORAGE MANAGER INSTALLATION............................................... 174
ABIOS OPTIONS.................................................................................................... 180
BDIO INTERFACE................................................................................................. 184
B.1 DIO INTERFACE INTRODUCTION ........................................................................... 185
B.2 DIO CONNECTOR PINOUTS ................................................................................... 185
B.3 ASSEMBLY LANGUAGE SAMPLES........................................................................... 186

KINO-9453 Mini-ITX Motherboard
Page XII
B.3.1 Enable the DIO Input Function..................................................................... 186
B.3.2 Enable the DIO Output Function.................................................................. 186
CWATCHDOG TIMER .......................................................................................... 187
DADDRESS MAPPING.......................................................................................... 190
D.1 ADDRESS MAP ...................................................................................................... 191
D.2 1ST MB MEMORYADDRESS MAP ......................................................................... 191
D.3 IRQ MAPPING TABLE............................................................................................ 192
D.4 DMA CHANNELASSIGNMENTS............................................................................. 192
EINTEL®MATRIX STORAGE MANAGER...................................................... 193
E.1 INTRODUCTION...................................................................................................... 194
E.1.1 Precautions.................................................................................................... 194
E.2 FEATURES AND BENEFITS ...................................................................................... 195
E.3 ACCESSING THE INTEL®MATRIX STORAGE MANAGER.......................................... 195
E.4 RAID CONFIGURATION ......................................................................................... 196
E.4.1 Creating a RAID Volume............................................................................... 196
E.4.2 Deleting a RAID Volume................................................................................ 201
E.4.3 Resetting a Disk to Non-RAID....................................................................... 203
E.4.4 Exiting the Matrix Storage Manager............................................................. 206
FINDEX.................................................................................................................... 207

KINO-9453 Mini-ITX Motherboard
Page
X
III
List of Figures
Figure 1-1: KINO-9453 Embedded SBC........................................................................................2
Figure 1-2: KINO-9453 Overview...................................................................................................4
Figure 2-1: KINO-9453 Dimensions (mm).....................................................................................9
Figure 2-2: External Interface Panel Dimensions (mm)............................................................10
Figure 2-3: Data Flow Block Diagram.........................................................................................11
Figure 2-4: 240-pin DIMM Sockets ..............................................................................................14
Figure 4-1: Connector and Jumper Locations...........................................................................30
Figure 4-2: Fan Connector Locations.........................................................................................33
Figure 4-3: Front Panel Connector Location .............................................................................34
Figure 4-4: GPIO Connector Location........................................................................................35
Figure 4-5: IDE Device Connector Location ..............................................................................36
Figure 4-6: LCD Backlight Connector Location ........................................................................38
Figure 4-7: LVDS LCD Connector Location ...............................................................................39
Figure 4-8: Mini PCI Slot Location..............................................................................................40
Figure 4-9: Power Connector Location ......................................................................................42
Figure 4-10: 14-Pin Serial Port Connector Locations...............................................................43
Figure 4-11: 10-Pin Serial Port Connector Locations ...............................................................44
Figure 4-12: SATA Drive Connector Locations..........................................................................45
Figure 4-13: SPDIF Connector Locations ..................................................................................46
Figure 4-14: Internal USB Connector Locations .......................................................................47
Figure 4-15: KINO-9453 External Interface Connectors............................................................48
Figure 4-16: Audio Connectors...................................................................................................48
Figure 4-17: VGA Connector........................................................................................................49
Figure 4-18 DVI-I Connector Pinout Locations..........................................................................50
Figure 4-19: RJ-45 Ethernet Connector......................................................................................51
Figure 4-20: PS/2 Pinouts ............................................................................................................52
Figure 4-21: External Serial Port Connector..............................................................................53
Figure 5-1: Make sure the CPU socket retention screw is unlocked ......................................60
Figure 5-2: Lock the CPU Socket Retention Screw...................................................................61
Figure 5-3: IEI CF-479B-RS Cooling Kit......................................................................................62
Figure 5-4: Cooling Kit Support Bracket....................................................................................63

KINO-9453 Mini-ITX Motherboard
Page XIV
Figure 5-5: Connect the cooling fan cable.................................................................................63
Figure 5-6: Installing a DIMM.......................................................................................................64
Figure 5-7: Jumper Locations.....................................................................................................65
Figure 5-8: AT/ATX Power Select Jumper Location ..................................................................67
Figure 5-9: Clear CMOS Jumper .................................................................................................68
Figure 5-10: COM 3 Function Select Jumper Locations...........................................................70
Figure 5-11: RS-422 and RS-485 Termination Resister Jumper Locations.............................71
Figure 5-12: LVDS Screen Resolution Selection Jumper Pinout Locations...........................73
Figure 5-13: LVDS Voltage Selection Jumper Pinout Locations..............................................74
Figure 5-14: IDE Cable Connection.............................................................................................77
Figure 5-15: Dual RS-232 Cable Installation ..............................................................................78
Figure 5-16: SATA Drive Cable Connection ...............................................................................79
Figure 5-17: SATA Power Drive Connection ..............................................................................79
Figure 5-18: Audio Connectors...................................................................................................81
Figure 5-19: RJ-45 Ethernet Connector......................................................................................82
Figure 5-20: USB Connector........................................................................................................83
Figure 5-21: VGA Connector........................................................................................................84
Figure 5-22: Serial Device Connector.........................................................................................85
Figure 5-23: PS/2 Keyboard/Mouse Connector.........................................................................86
Figure 6-1: Video Function Configuration............................................................................... 138
Figure 7-1: Available Drivers .................................................................................................... 146
Figure 7-2: Chipset Driver Installation Program..................................................................... 147
Figure 7-3: Chipset Driver Installation Welcome Screen....................................................... 148
Figure 7-4: Chipset Driver Installation License Agreement .................................................. 149
Figure 7-5: Chipset Driver Readme File Information ............................................................. 150
Figure 7-6: Chipset Driver Installation Complete................................................................... 151
Figure 7-7: Select the Operating System ................................................................................ 152
Figure 7-8: VGA Driver .............................................................................................................. 153
Figure 7-9: GMA Driver Readme File ....................................................................................... 154
Figure 7-10: GMA Driver File Extraction.................................................................................. 154
Figure 7-11: GMA Driver Installation Welcome Screen.......................................................... 155
Figure 7-12: GMA Driver License Agreement ......................................................................... 156
Figure 7-13: GMA Driver Installing Notice............................................................................... 156
Figure 7-14: GMA Driver Installation Complete...................................................................... 157
Figure 7-15: Access Windows Control Panel ......................................................................... 158

KINO-9453 Mini-ITX Motherboard
Page
XV
Figure 7-16: Double Click the System Icon............................................................................. 159
Figure 7-17: Double Click the Device Manager Tab ............................................................... 159
Figure 7-18: Device Manager List ............................................................................................ 160
Figure 7-19: Search for Suitable Driver................................................................................... 161
Figure 7-20: Locate Driver Files............................................................................................... 162
Figure 7-21: Location Browsing Window................................................................................ 162
Figure 7-22: 4-AUDIO\AC-KIT883HD\Windows Folder........................................................... 163
Figure 7-23: HD Audio Driver Setup Extracting Files............................................................. 164
Figure 7-24: HD Audio Driver Setup Welcome Screen........................................................... 165
Figure 7-25: HD Audio Driver Installation Complete.............................................................. 166
Figure 7-26: CD 4-AUDIO\AC-KIT08R\Windows Folder ......................................................... 168
Figure 7-27: AC`97 Audio Driver Install Shield Wizard Starting............................................ 168
Figure 7-28: AC`97 Audio Driver Setup Preparation .............................................................. 169
Figure 7-29: AC`97 Audio Driver Welcome Screen................................................................. 169
Figure 7-30: AC`97 Audio Driver Software Configuration ..................................................... 170
Figure 7-31: AC`97 Audio Driver Digital Signal....................................................................... 171
Figure 7-32: AC`97 Audio Driver Installation Begins ............................................................. 172
Figure 7-33: AC`97 Audio Driver Installation Complete......................................................... 173
Figure 7-34: SATA RAID Driver Installation Program............................................................. 174
Figure 7-35: SATA RAID Setup Program Icon......................................................................... 175
Figure 7-36: InstallShield Wizard Setup Screen..................................................................... 175
Figure 7-37: Matrix Storage Manager Setup Screen .............................................................. 176
Figure 7-38: Matrix Storage Manager Welcome Screen ........................................................ 176
Figure 7-39: Matrix Storage Manager Warning Screen.......................................................... 177
Figure 7-40: Matrix Storage Manager License Agreement.................................................... 177
Figure 7-41: Matrix Storage Manager Readme File................................................................ 178
Figure 7-42: Matrix Storage Manager Setup Complete.......................................................... 179

KINO-9453 Mini-ITX Motherboard
Page XVI
List of Tables
Table 1-1: Technical Specifications ..............................................................................................7
Table 2-1: Processor Features ....................................................................................................12
Table 2-2: Supported Processors ...............................................................................................13
Table 2-3: Supported HDD Specifications..................................................................................17
Table 2-4: Power Consumption...................................................................................................23
Table 2-5: Power Consumption...................................................................................................23
Table 3-1: Package List Contents................................................................................................27
Table 3-2: Optional Items.............................................................................................................28
Table 4-1: Peripheral Interface Connectors ...............................................................................31
Table 4-2: Rear Panel Connectors ..............................................................................................32
Table 4-3: Fan Connector Pinouts...............................................................................................33
Table 4-4: Front Panel Connector Pinouts.................................................................................34
Table 4-5: GPIO Connector Pinouts............................................................................................35
Table 4-6: IDE Connector Pinouts...............................................................................................37
Table 4-7: LCD Backlight Connector Pinouts............................................................................38
Table 4-8: LVDS LCD Connector Pinouts...................................................................................39
Table 4-9: Mini PCI Slot Pinouts..................................................................................................41
Table 4-10: Power Connector Pinouts........................................................................................42
Table 4-11: COM2 Pinouts............................................................................................................43
Table 4-12: COM4 Pinouts............................................................................................................44
Table 4-13: SATA Drive Connector Pinouts................................................................................45
Table 4-14: SPDIF Pinouts ...........................................................................................................46
Table 4-15: USB3 and USB4 Pinouts..........................................................................................47
Table 4-16: VGA Connector Pinouts ...........................................................................................49
Table 4-17: DVI-I Connector Pinouts...........................................................................................50
Table 4-18: LAN1 and LAN2 Pinouts...........................................................................................51
Table 4-19: RJ-45 Ethernet Connector LEDs .............................................................................51
Table 4-20: PS/2 Connector Pinouts...........................................................................................52
Table 4-21: External Serial Port Pinouts.....................................................................................53
Table 4-22: External USB Connector Pinouts............................................................................54

KINO-9453 Mini-ITX Motherboard
Page
X
VII
Table 5-1: Jumpers .......................................................................................................................66
Table 5-2: AT/ATX Power Select Jumper Settings.....................................................................66
Table 5-3: Clear CMOS Jumper Settings....................................................................................68
Table 5-4: COM 3 Function Select Jumper Settings .................................................................69
Table 5-5: RS-422 Termination Resister Jumper Settings........................................................70
Table 5-6: RS-485 Termination Resister Jumper Settings........................................................71
Table 5-7: LVDS Screen Resolution Selection Jumper Settings..............................................72
Table 5-8: LVDS Voltage Selection Jumper Settings.................................................................74
Table 5-9: IEI Provided Cables ....................................................................................................76
Table 6-1: BIOS Navigation Keys ................................................................................................89

KINO-9453 Mini-ITX Motherboard
Page XVIII
BIOS Menus
Menu 1: Main.................................................................................................................................90
Menu 2: Advanced........................................................................................................................92
Menu 3: CPU Configuration.........................................................................................................93
Menu 4: IDE Configuration ..........................................................................................................94
Menu 5: IDE Master and IDE Slave Configuration.....................................................................96
Menu 6: Super IO Configuration .............................................................................................. 101
Menu 7: Hardware Health Configuration................................................................................. 104
Menu 8: ACPI Configuration..................................................................................................... 109
Menu 9: General ACPI Configuration [Advanced\ ACPI Configuration] ...............................110
Menu 10:Advanced Power Management Configuration.........................................................111
Menu 11: Remote Access Configuration [Advanced].............................................................114
Menu 12: USB Configuration.....................................................................................................118
Menu 13: USB Mass Storage Device Configuration............................................................... 120
Menu 14: PCI/PnP Configuration ............................................................................................. 123
Menu 15: Boot............................................................................................................................ 128
Menu 16: Boot Settings Configuration.................................................................................... 129
Menu 17: Boot Device Priority Settings .................................................................................. 132
Menu 18: Removable Drives..................................................................................................... 133
Menu 19: Security...................................................................................................................... 134
Menu 20: Chipset....................................................................................................................... 135
Menu 21:NorthBridge Chipset Configuration......................................................................... 136
Menu 22:SouthBridge Chipset Configuration......................................................................... 140
Menu 23:Exit............................................................................................................................... 142

KINO-9453 Mini-ITX Motherboard
Page 1
1 Introduction
Chapter
1

KINO-9453 Mini-ITX Motherboard
Page 2
1.1 Introduction
Figure 1-1: KINO-9453 Embedded SBC
The KINO-9453 Mini-ITX form factor motherboard is an Intel® dual-core CPU platform.
Intel® Core™2 Duo, Core Duo and Core Solo CPU are all supported to enhance the
system processing speed. The KINO-9452 has a maximum front side bus (FSB)
frequency of 667 MHz and contains two DDR2 SDRAM DIMM sockets that support up to
4 GB system memory.
The KINO-9453 supports diverse displays including one VGA display, one DVI display and
one LVDS display. These multimedia features make the KINO-9453 a best choice for
integrating into point-of-sale (POS), kiosk or digital signage applications.
The KINO-9453 supports up to two serial ATA (SATA) hard disk drives (HDD) with
maximum transfer rates of 1.5 Gb/s and up to eight USB 2.0 devices. The dual PCI
Express (PCIe) Gigabit Ethernet (GbE) controllers provide GbE connectivity for network
communication. The KINO-9453 also has a PCI socket and a Mini PCI socket for system
expansion. Three RS-232, one RS-232/422/485 and one digital input/output (DIO) port
offer system integrators more choices of peripheral devices for the targeted application.
