IEI Technology HYPER-BW User manual

HYPER-BW
Page I
User Manual
HYP E R -BW
MODEL:
P ICO-ITX SBC supports Intel® 14nm Pentium®/Celeron® on-board SoC,
d u a l Min i HDMI, M.2 2242, GbE, USB 3.0, SATA 6Gb/s , COM,
Audio and RoHS
Rev. 1.02 - 13 December, 2017

HYPER-BW
Page II
Re vis io n
Date Version Changes
13 December, 2017 1.02 Updated Section 1.5: Dimensions
6 July, 2017 1.01 Updated Section 1.2: Model Variations
Updated Section 1.7: Technical Specifications
27 June, 2016 1.00 Initial release

HYPER-BW
Page III
Copyright
COPYRIGHT NOTICE
The information in this document is subject to change without prior notice in order to
improve reliability, design and function and does not represent a commitment on the part
of the manufacturer.
In no event will the manufacturer be liable for direct, indirect, special, incidental, or
consequential damages arising out of the use or inability to use the product or
documentation, even if advised of the possibility of such damages.
This document contains proprietary information protected by copyright. All rights are
reserved. No part of this manual may be reproduced by any mechanical, electronic, or
other means in any form without prior written permission of the manufacturer.
TRADEMARKS
All registered trademarks and product names mentioned herein are used for identification
purposes only and may be trademarks and/or registered trademarks of their respective
owners.

HYPER-BW
Page IV
Manual Conventions
WARNING
Warnings appear where overlooked details may cause damage to the
equipment or result in personal injury. Warnings should be taken
seriously.
C AUTIO N
Cautionary messages should be heeded to help reduce the chance of
losing data or damaging the product.
NOTE
These messages inform the reader of essential but non-critical
information. These messages should be read carefully as any directions
or instructions contained therein can help avoid making mistakes.
HOT S URFACE
This symbol indicates a hot surface that should not be touched without
taking care.

HYPER-BW
Page V
Table of Contents
1 INTRODUCTION.......................................................................................................... 1
1.1 INTRODUCTION........................................................................................................... 2
1.2 MODEL VARIATIONS ................................................................................................... 2
1.3 FEATURES................................................................................................................... 3
1.4 CONNECTORS ............................................................................................................. 4
1.5 DIMENSIONS............................................................................................................... 6
1.6 DATA FLOW ................................................................................................................ 8
1.7 TECHNICAL SPECIFICATIONS ...................................................................................... 9
2 UNPACKING ................................................................................................................11
2.1 ANTI-S TAT IC PRECAUTIONS ...................................................................................... 12
2.2 UNPACKING PRECAUTIONS....................................................................................... 12
2.3 PACKING LIST........................................................................................................... 13
2.4 OPTIONAL ITEMS ...................................................................................................... 14
3 CONNECTORS ........................................................................................................... 15
3.1 PERIPHERAL INTERFACE CONNECTORS..................................................................... 16
3.1.1 HYPER-BW Layout .......................................................................................... 16
3.1.2 Peripheral Interface Connectors ..................................................................... 17
3.1.3 External Interface Panel Connectors............................................................... 18
3.2 INTERNAL PERIPHERAL CONNECTORS ...................................................................... 18
3.2.1 AT/ATX Mode Select Switch............................................................................. 18
3.2.2 Audio Connector .............................................................................................. 19
3.2.3 Battery Connector............................................................................................ 20
3.2.4 BIOS FW Connector ........................................................................................ 21
3.2.5 Buzzer Connector............................................................................................. 21
3.2.6 Clear CMOS Button......................................................................................... 22
3.2.7 CPU Fan Connector ........................................................................................ 23
3.2.8 DDR3L SO-DIMM Slot.................................................................................... 24
3.2.9 Debug Connector ............................................................................................. 24
3.2.10 EC FW Connector.......................................................................................... 25

HYPER-BW
Page VI
3.2.11 Front Panel Connector................................................................................... 26
3.2.12 LAN LED Connector...................................................................................... 27
3.2.13 M.2 2242 (B key) Socket ................................................................................ 28
3.2.14 RS-232 Serial Port Connector ....................................................................... 28
3.2.15 SATA 6Gb/s Drive Connector ........................................................................ 29
3.2.16 SATA Power Connector.................................................................................. 30
3.2.17 SMBus Connector .......................................................................................... 31
3.2.18 USB Connector .............................................................................................. 31
3.3 EXTERNAL PERIPHERAL INTERFACE CONNECTOR PANEL ......................................... 32
3.3.1 HDMI Connectors............................................................................................ 33
3.3.2 LAN Connector ................................................................................................ 34
3.3.3 Power Connector ............................................................................................. 34
3.3.4 USB Connectors............................................................................................... 35
4 INSTALLATION ......................................................................................................... 36
4.1 ANTI-S TAT IC PRECAUTIONS ...................................................................................... 37
4.2 INSTALLATION CONSIDERATIONS.............................................................................. 37
4.3 SO-DIMM INSTALLATION ....................................................................................... 39
4.4 INTERNAL PERIPHERAL DEVICE CONNECTIONS........................................................ 40
4.4.1 SATA Drive Connection ................................................................................... 40
4.4.2 Single RS-232 Cable ........................................................................................ 41
4.5 HEAT SINK ENCLOSURE............................................................................................ 42
5 BIOS .............................................................................................................................. 43
5.1 INTRODUCTION......................................................................................................... 44
5.1.1 Starting Setup................................................................................................... 44
5.1.2 Using Setup ...................................................................................................... 44
5.1.3 Getting Help..................................................................................................... 45
5.1.4 Unable to Reboot after Configuration Changes .............................................. 45
5.1.5 BIOS Menu Bar................................................................................................ 45
5.2 MAIN........................................................................................................................ 46
5.3 ADVANCED ............................................................................................................... 47
5.3.1 ACPI Settings ................................................................................................... 48
5.3.2 IT8528 Super IO Configuration ....................................................................... 49
5.3.2.1 Serial Port 1 Configuration ....................................................................... 49

HYPER-BW
Page VII
5.3.3 iWDD H/W Monitor ......................................................................................... 51
5.3.3.1 Smart Fan Mode Configuration ................................................................ 52
5.3.4 RTC Wake Settings ........................................................................................... 55
5.3.5 Serial Port Console Redirection ...................................................................... 56
5.3.5.1 Console Redirection Settings.................................................................... 57
5.3.6 iEi Feature ....................................................................................................... 59
5.3.7 CPU Configuration.......................................................................................... 60
5.3.8 SATA Configuration ......................................................................................... 61
5.3.9 USB Configuration........................................................................................... 62
5.4 CHIPSET ................................................................................................................... 63
5.4.1 North Bridge Configuration............................................................................. 64
5.4.1.1 Intel IGD Configuration............................................................................ 64
5.4.2 Southbridge Configuration .............................................................................. 67
5.4.2.1 PCI Express Configuration ....................................................................... 68
5.4.2.2 M.2 Socket PCIEx1 .................................................................................. 69
5.5 SECURITY................................................................................................................. 70
5.6 BOOT........................................................................................................................ 71
5.7 EXIT ......................................................................................................................... 73
A REGULATORY COMPLIANCE .............................................................................. 75
B PRODUCT DISPOSAL .............................................................................................. 77
C BIOS OPTIONS .......................................................................................................... 79
D TERMINOLOGY....................................................................................................... 82
E WATCHDOG TIMER................................................................................................. 86
F HAZARDOUS MATERIALS DISCLOSURE.......................................................... 89

HYPER-BW
Page VIII
Lis t of Figu re s
Figure 1-1: HYPER-BW...................................................................................................................2
Figure 1-2: Connectors (Front Side).............................................................................................4
Figure 1-3: Connectors (Solder Side)...........................................................................................5
Figure 1-4: Dimensions (mm) ........................................................................................................7
Figure 1-5: Data Flow Diagram......................................................................................................8
Figure 3-1: Connector and Jumper Locations (Front) ..............................................................16
Figure 3-2: Connector and Jumper Locations (Rear) ...............................................................16
Figure 3-3: AT/ATX Mode Select Switch Location ....................................................................19
Figure 3-4: Audio Connector Location .......................................................................................19
Figure 3-5: Battery Connector Location.....................................................................................20
Figure 3-6: BIOS FW Connector Location..................................................................................21
Figure 3-7: Buzzer Connector Location .....................................................................................22
Figure 3-8: Clear CMOS Button Location...................................................................................23
Figure 3-9: CPU Fan Connector Location ..................................................................................23
Figure 3-10: DDR3L SO-DIMM Slot Location .............................................................................24
Figure 3-11: Debug Port Connector Location............................................................................25
Figure 3-12: EC FW Connector Location....................................................................................26
Figure 3-13: Front Panel Connector Location ...........................................................................26
Figure 3-14: LAN LED Connector Locations .............................................................................27
Figure 3-15: M.2 2242 (B key) Socket Location .........................................................................28
Figure 3-16: RS-232 Serial Port Connector Location................................................................29
Figure 3-17: SATA 6Gb/s Drive Connector Location ................................................................30
Figure 3-18: SATA Power Connector Location .........................................................................30
Figure 3-19: SMBus Connector Location ...................................................................................31
Figure 3-20: USB Connector Location........................................................................................32
Figure 3-21: External Peripheral Interface Connector ..............................................................33
Figure 3-22: HDMI Connector ......................................................................................................33
Figure 3-23: LAN Connector........................................................................................................34
Figure 4-1: SO-DIMM Installation ................................................................................................39
Figure 4-2: SATA Drive Cable Connection.................................................................................40
Figure 4-3: Single RS-232 Cable Installation .............................................................................41

HYPER-BW
Page IX
Figure 4-4: Heat Sink Retention Screws.....................................................................................42

HYPER-BW
Page X
Lis t of Ta b le s
Table 1-1: HYPER-BW Model Variations......................................................................................2
Table 1-2: Technical Specifications............................................................................................10
Table 3-1: Peripheral Interface Connectors ...............................................................................17
Table 3-2: Rear Panel Connectors ..............................................................................................18
Table 3-3: AT/ATX Mode Select Switch Settings.......................................................................18
Table 3-4: Audio Connector Pinouts ..........................................................................................20
Table 3-5: Battery Connector Pinouts ........................................................................................20
Table 3-6: BIOS FW Connector Pinouts .....................................................................................21
Table 3-7: Buzzer Connector Pinouts.........................................................................................22
Table 3-8: Clear CMOS Button Settings .....................................................................................22
Table 3-9: CPU Fan Connector Pinouts .....................................................................................23
Table 3-10: Debug Port Connector Pinouts ...............................................................................25
Table 3-11: EC FW Connector Pinouts .......................................................................................26
Table 3-12: Front Panel Connector Pinouts...............................................................................27
Table 3-13: LAN LED Connector Pinouts...................................................................................27
Table 3-14: RS-232 Serial Port Connector Pinouts ...................................................................29
Table 3-15: SATA Power Connector Pinouts.............................................................................30
Table 3-16: SMBus Connector Pinouts ......................................................................................31
Table 3-17: USB Connector Pinouts ...........................................................................................32
Table 3-18: HDMI Connector Pinouts .........................................................................................33
Table 3-19: LAN Pinouts ..............................................................................................................34
Table 3-20: Connector LEDs........................................................................................................34
Table 3-21: Power Connector Pinouts........................................................................................35
Table 3-22: USB 2.0 & USB 3.0 Port Pinouts .............................................................................35
Table 5-1: BIOS Navigation Keys ................................................................................................45

HYPER-BW
Page XI
BIOS Me n u s
BIOS Menu 1: Main .......................................................................................................................46
BIOS Menu 2: Advanced ..............................................................................................................47
BIOS Menu 3: ACPI Configuration ..............................................................................................48
BIOS Menu 4: Super IO Configuration........................................................................................49
BIOS Menu 5: Serial Port 1 Configuration Menu .......................................................................49
BIOS Menu 6: Hardware Monitor.................................................................................................51
BIOS Menu 7: Smart Fan Mode Configuration ..........................................................................52
BIOS Menu 8: RTC Wake Settings ..............................................................................................55
BIOS Menu 9: Serial Port Console Redirection .........................................................................56
BIOS Menu 10: Console Redirection Settings...........................................................................57
BIOS Menu 11: IEI Feature...........................................................................................................59
BIOS Menu 12: CPU Configuration .............................................................................................60
BIOS Menu 13: IDE Configuration...............................................................................................61
BIOS Menu 14: USB Configuration .............................................................................................62
BIOS Menu 15: Chipset ................................................................................................................63
BIOS Menu 16: Northbridge Chipset Configuration..................................................................64
BIOS Menu 17: Integrated Graphics ...........................................................................................65
BIOS Menu 18: Southbridge Chipset Configuration .................................................................67
BIOS Menu 19: PCI Express Configuration ...............................................................................68
BIOS Menu 20: PCI Express Configuration ...............................................................................69
BIOS Menu 21: Security ...............................................................................................................70
BIOS Menu 22: Boot .....................................................................................................................71
BIOS Menu 23:Exit........................................................................................................................73

HYPER-BW
Page 1
1Introduction
Chapter
1

HYPER-BW
Page 2
1.1 Introduction
Figure 1-1: HYPER-BW
The HYPER-BW is a PICO-ITX motherboard. It accepts an Intel® Pentium®/Celeron®
on-board SoC and supports one 204-pin 1333/1600 MHz single-channel DDR3L SDRAM
unbuffered SO-DIMM module up to 8 GB.
The HYPER-BW includes two mini HDMI ports. Expansion and I/O include one USB 2.0
connector and one USB 3.0 connector on the rear panel, two USB 2.0 connectors by pin
header and one SATA 6Gb/s connector. Serial device connectivity is provided by one
internal RS-232 connector. One RJ-45 Ethernet connector provides the system with
smooth connections to an external LAN.
1.2 Model Variations
The model variations of the HYPER-BW Series are listed below.
Model No. SoC
HYPER-BW-N4 Intel® Pentium® 14nm quad-core N3710 up to 2.56GHz (6W)
HYPER-BW-N3 Intel® Celeron® 14nm quad-core N3160 up to 2.24GHz (6W)
HYPER-BW-N2 Intel® Celeron® 14nm dual-core N3060 up to 2.48GHz (6W)
HYPER-BW-N1 Intel® Celeron® 14nm dual-core N3010 up to 2.24GHz (4W)
HYPER-BW-E8-ECO Intel® Celeron® 14nm quad-core x5-E8000 up to 2.00GHz (5W)
Table 1-1: HYPER-BW Model Variations

HYPER-BW
Page 3
1.3 Features
Some of the HYPER-BW motherboard features are listed below:
Pico-ITX SBC supports Intel® 14nm Pentium®/Celeron® on-board SoC
IEI jumper-less function
Dual independent display support
1333/1600 MHz 1.35V DDR3L SDRAM up to 8 GB supported
COM, USB 3.0, SATA 6Gb/s and Audio support
1 x M.2 2242 B key slot for expansion possibility
IEI One Key Recovery solution allows you to create rapid OS backup and
recovery

HYPER-BW
Page 4
1.4 Connectors
The connectors on the HYPER-BW are shown in the figure below.
Figure 1-2: Connectors (Front Side)

HYPER-BW
Page 5
Figure 1-3: Connectors (Solder Side)

HYPER-BW
Page 6
1.5 Dimensions
The dimensions of the board are listed below:

HYPER-BW
Page 7
Figure 1-4: Dimensions (mm)

HYPER-BW
Page 8
1.6 Data Flow
Figure 1-5 shows the data flow between the system chipset, the CPU and other
components installed on the motherboard.
Figure 1-5: Data Flow Diagram

HYPER-BW
Page 9
1.7 Technical Specifications
HYPER-BW technical specifications are listed below.
Specification HYP ER-BW
SoC Intel® Pentium® N3710 on-board SoC (up to 2.56GHz,
quad-core, 2MB cache, TDP=6W)
Intel® Celeron® N3160 on-board SoC (up to 2.24GHz,
quad-core, 2MB cache, TDP=6W)
Intel® Celeron® N3060 on-board SoC (up to 2.48GHz,
dual-core, 2MB cache, TDP=6W)
Intel® Celeron® N3010 on-board SoC (up to 2.24GHz,
dual-core, 2MB cache, TDP=4W)
Intel® Celeron® x5-E8000 on-board SoC (up to 2.00GHz,
quad-core, 2MB cache, TDP=5W)
B IO S AMI UEFI BIOS
Me m o ry One 204-pin 1333/1600 MHz single-channel DDR3L SDRAM
unbuffered SO-DIMM slot support up to 8 GB
Graphics Intel® HD Graphics Gen 8 Engine with 16 low-power
execution units, supporting DX11.1, OpenGL 4.2 and
OpenCL1.2
Display Output Dual independent display
2 x Mini HDMI (up to 3840x2160@30Hz)
Ethernet LAN1: Realtek RTL8111 controller
EC IT8587
Watchdog Timer Software programmable support 1~255 sec. system reset
I/O In t e rfa c e
Audio Connector 1 x HD Audio by 10-pin (2x5) header
Ethernet One RJ-45 port
Seria l P o rts 1 x RS-232 (by pin header)
