IEI Technology iQ7-BT User manual

iQ7-BT Qseven Module
Page i
User Manual
Qseven® Rev. 2.0 Module with
22nm Intel® Atom™/Celeron® Processor,
2 GB/4 GB DDR3L, and RoHS Compliant
MODEL:
iQ7-BT
Rev. 1.01 – June 29, 2017

iQ7-BT Qseven Module
Page ii
Revision
Date Version Changes
June 29, 2017 1.01 Clarified BIOS specifications
March 23, 2015 1.00 Initial release

iQ7-BT Qseven Module
Page iii
Copyright
COPYRIGHT NOTICE
The information in this document is subject to change without prior notice in order to
improve reliability, design and function and does not represent a commitment on the part
of the manufacturer.
In no event will the manufacturer be liable for direct, indirect, special, incidental, or
consequential damages arising out of the use or inability to use the product or
documentation, even if advised of the possibility of such damages.
This document contains proprietary information protected by copyright. All rights are
reserved. No part of this manual may be reproduced by any mechanical, electronic, or
other means in any form without prior written permission of the manufacturer.
TRADEMARKS
All registered trademarks and product names mentioned herein are used for identification
purposes only and may be trademarks and/or registered trademarks of their respective
owners.

iQ7-BT Qseven Module
Page iv
Table of Contents
1 INTRODUCTION.......................................................................................................... 1
1.1 INTRODUCTION........................................................................................................... 2
1.2 FEATURES................................................................................................................... 2
1.3 MODEL VARIATIONS................................................................................................... 3
1.4 BOARD OVERVIEW ..................................................................................................... 4
1.5 DIMENSIONS............................................................................................................... 5
1.6 DATA FLOW................................................................................................................ 6
1.7 TECHNICAL SPECIFICATIONS ...................................................................................... 7
2 PACKING LIST............................................................................................................. 9
2.1ANTI-STATIC PRECAUTIONS...................................................................................... 10
2.2 UNPACKING PRECAUTIONS....................................................................................... 10
2.3 PACKING LIST............................................................................................................11
2.4 OPTIONAL ITEMS...................................................................................................... 12
3 INSTALLATION ......................................................................................................... 13
3.1ANTI-STATIC PRECAUTIONS...................................................................................... 14
3.2 INSTALLATION CONSIDERATIONS.............................................................................. 14
3.3 QSEVEN CONNECTOR PINOUTS ................................................................................ 16
3.4MOUNTING IQ7-BTTO BASEBOARD .......................................................................... 20
3.5 SOFTWARE INSTALLATION ........................................................................................ 22
3.5.1 Starting the Driver Program............................................................................ 22
3.5.2 Available Software Drivers.............................................................................. 24
4 BIOS.............................................................................................................................. 26
4.1 INTRODUCTION......................................................................................................... 27
4.1.1 Starting Setup................................................................................................... 27
4.1.2 Using Setup...................................................................................................... 27
4.1.3 Getting Help..................................................................................................... 28
4.1.4 Unable to Reboot after Configuration Changes.............................................. 28
4.1.5 BIOS Menu Bar................................................................................................ 28

iQ7-BT Qseven Module
Page v
4.2 MAIN........................................................................................................................ 29
4.3ADVANCED............................................................................................................... 30
4.3.1 ACPI Settings................................................................................................... 31
4.3.2 IT8528 Super IO Configuration....................................................................... 32
4.3.2.1 Serial Port n Configuration....................................................................... 32
4.3.3 iWDD H/W Monitor......................................................................................... 34
4.3.3.1 Smart Fan Mode Configuration................................................................ 35
4.3.4 RTC Wake Settings........................................................................................... 36
4.3.5 Serial Port Console Redirection ...................................................................... 37
4.3.6 CPU Configuration.......................................................................................... 40
4.3.7 IDE Configuration........................................................................................... 42
4.3.8 Trusted Computing........................................................................................... 43
4.3.9 USB Configuration........................................................................................... 44
4.3.10 Security Configuration................................................................................... 45
4.4 CHIPSET ................................................................................................................... 46
4.4.1 North Bridge .................................................................................................... 47
4.4.1.1 Intel IGD Configuration............................................................................ 47
4.4.2 South Bridge Configuration............................................................................. 50
4.4.2.1 PCI Express Configuration....................................................................... 52
4.5 SECURITY................................................................................................................. 53
4.6 BOOT........................................................................................................................ 54
4.7 SAVE &EXIT............................................................................................................ 56
A REGULATORY COMPLIANCE.............................................................................. 58
B PRODUCT DISPOSAL.............................................................................................. 60
C BIOS OPTIONS.......................................................................................................... 62
D TERMINOLOGY ....................................................................................................... 65
E WATCHDOG TIMER................................................................................................. 69
F HAZARDOUS MATERIALS DISCLOSURE.......................................................... 72

iQ7-BT Qseven Module
Page vi
List of Figures
Figure 1-1: iQ7-BT...........................................................................................................................2
Figure 1-2: On-board Components and Connectors ..................................................................4
Figure 1-3: iQ7-BT Dimensions (mm)...........................................................................................5
Figure 1-4: iQ7-BT Dimensions with Heatsink (mm)...................................................................5
Figure 1-5: Data Flow Diagram......................................................................................................6
Figure 3-1: Qseven Connector Location....................................................................................16
Figure 3-2: Connect the Qseven Connectors............................................................................21
Figure 3-3: Secure the Heatsink..................................................................................................22
Figure 3-4: Start Up Screen .........................................................................................................23
Figure 3-5: Drivers........................................................................................................................23

iQ7-BT Qseven Module
Page vii
List of Tables
Table 1-1: Model Variations...........................................................................................................3
Table 1-2: iQ7-BT Specifications...................................................................................................8
Table 2-1: Packing List.................................................................................................................11
Table 2-2: Optional Items.............................................................................................................12
Table 3-1: Qseven Connector Pin Definitions ...........................................................................20
Table 4-1: BIOS Navigation Keys................................................................................................28

iQ7-BT Qseven Module
Page viii
BIOS Menus
BIOS Menu 1: Main.......................................................................................................................29
BIOS Menu 2: Advanced..............................................................................................................30
BIOS Menu 3: ACPI Settings .......................................................................................................31
BIOS Menu 4: IT8528 Super IO Configuration...........................................................................32
BIOS Menu 5: Serial Port n Configuration Menu.......................................................................32
BIOS Menu 6: iWDD H/W Monitor ...............................................................................................34
BIOS Menu 7: Smar Fan Mode Configuration............................................................................35
BIOS Menu 8: RTC Wake Settings..............................................................................................36
BIOS Menu 9: Serial Port Console Redirection.........................................................................37
BIOS Menu 10: CPU Configuration.............................................................................................40
BIOS Menu 11: IDE Configuration...............................................................................................42
BIOS Menu 12: Trusted Computing............................................................................................43
BIOS Menu 13: USB Configuration.............................................................................................44
BIOS Menu 14: Security Configuration ......................................................................................45
BIOS Menu 15: Chipset................................................................................................................46
BIOS Menu 16: North Bridge .......................................................................................................47
BIOS Menu 17: Intel IGD Configuration......................................................................................47
BIOS Menu 18: South Bridge.......................................................................................................50
BIOS Menu 19: PCI Express Configuration ...............................................................................52
BIOS Menu 20: Security...............................................................................................................53
BIOS Menu 21: Boot.....................................................................................................................54
BIOS Menu 22: Save & Exit..........................................................................................................56
iQ7-BT

iQ7-BT Qseven Module
Page 1
Chapter
1
1 Introduction

iQ7-BT Qseven Module
Page 2
1.1 Introduction
Figure 1-1: iQ7-BT
The iQ7-BT Qseven® module provides the main processing chips and is connected to a
compatible Qseven® baseboard. The iQ7-BT is preinstalled with 4th generation Intel®
Atom or Celeron® processor. The Qseven® standard allows the Qseven® baseboard
to be designed, while leaving the choice of processor till the later stages of design. The
iQ7-BT provides a low power option with the full range of modern I/O options. The iQ7-BT
embedded module is designed for flexible integration by system developers into
customized platform devices.
1.2 Features
Some of the iQ7-BT Qseven module features are listed below:
 Complies with Qseven® Rev. 2.0 form factor
 Supports 22nm Intel® Atom or Celeron® processor
 2 GB/4 GB 1066/1333 MHz DDR3L soldered memory
 Optional 2 GB–64 GB soldered SSD
 Supports dual independent display via LVDS, DisplayPort or HDMI
 Supports USB 3.0, SATA 3Gb/s and GbE
 Supports wide operating temperature (-40ºC ~ 85ºC)
 RoHS compliant

iQ7-BT Qseven Module
Page 3
1.3 Model Variations
There are several models of the iQ7-BT series. The model variations are listed in
Table 1-1.
Model On-board SoC Operating Temp.
Standard
iQ7-BT-E38251 Intel® Atom™ processor E3825
(1.33 GHz, dual-core, 1 MB cache, 6 W TDP)
-20ºC ~ 60ºC
iQ7-BT-E38251W2 Intel® Atom™ processor E3825
(1.33 GHz, dual-core, 1 MB cache, 6 W TDP)
-40°C–85°C
iQ7-BT-E38451 Intel® Atom™ processor E3845
(1.91 GHz, quad-core, 2 MB cache, 10 W TDP)
-20ºC ~ 60ºC
iQ7-BT-E38451W2 Intel® Atom™ processor E3845
(1.91 GHz, quad-core, 2 MB cache, 10 W TDP)
-40°C–85°C
By Request (MOQ: 100 pcs/lot)
iQ7-BT-E38151 -20ºC ~ 60ºC
iQ7-BT-E38151W2
Intel® Atom™ processor E3815
(1.46 GHz, single-core, 512 KB cache, 5 W TDP) -40°C–85°C
iQ7-BT-E38261 -20ºC ~ 60ºC
iQ7-BT-E38261W2
Intel® Atom™ processor E3826
(1.46 GHz, dual-core, 1 MB cache, 7 W TDP) -40°C–85°C
iQ7-BT-E38271 -20ºC ~ 60ºC
iQ7-BT-E38271W2
Intel® Atom™ processor E3827
(1.75 GHz, dual-core, 1 MB cache, 8 W TDP) -40°C–85°C
iQ7-BT-J19001 Intel® Celeron® processor J1900
(2 GHz, quad-core, 2 MB cache, 10 W TDP)
-20ºC ~ 60ºC
iQ7-BT-N28071 Intel® Celeron® processor N2807
(1.58 GHz, dual-core, 2 MB cache, 4.3 W TDP)
-20ºC ~ 60ºC
iQ7-BT-N29301 Intel® Celeron® processor N2930
(1.83 GHz, quad-core, 2 MB cache, 7.5 W TDP)
-20ºC ~ 60ºC
Table 1-1: Model Variations

iQ7-BT Qseven Module
Page 4
1.4 Board Overview
The on-board components and connector of the iQ7-BT are shown in the figures below.
Figure 1-2: On-board Components and Connectors

iQ7-BT Qseven Module
Page 5
1.5 Dimensions
The main dimensions of the iQ7-BT are shown in the diagram below.
Figure 1-3: iQ7-BT Dimensions (mm)
Figure 1-4: iQ7-BT Dimensions with Heatsink (mm)

iQ7-BT Qseven Module
Page 6
1.6 Data Flow
Figure 1-5 shows the data flow between the system chipset, the CPU and other
components installed on the motherboard.
Figure 1-5: Data Flow Diagram

iQ7-BT Qseven Module
Page 7
1.7 Technical Specifications
The iQ7-BT technical specifications are listed below.
iQ7-BT
Form Factor Qseven® Rev. 2.0
On-board SoC
 Standard
o Intel® Atom™ processor E3825
(1.33 GHz, dual-core, 1 MB cache, 6 W TDP)
o Intel® Atom™ processor E3845
(1.91 GHz, quad-core, 2 MB cache, 10 W TDP)
 By request (MOQ: 100 pcs/lot)
o Intel® Atom™ processor E3815
(1.46 GHz, single-core, 512 KB cache, 5 W TDP)
o Intel® Atom™ processor E3826
(1.46 GHz, dual-core, 1 MB cache, 7 W TDP)
o Intel® Atom™ processor E3827
(1.75 GHz, dual-core, 1 MB cache, 8 W TDP)
o Celeron® processor J1900
(2 GHz, quad-core, 2 MB cache, 10 W TDP)
o Intel® Celeron® processor N2930
(1.83 GHz, quad-core, 2 MB cache, 7.5 W TDP)
o Intel® Celeron® processor N2807
(1.58 GHz, dual-core, 2 MB cache, 4.5 W TDP)
Memory 2 GB 1066/1333 MHz DDR3L soldered memory (up to 4 GB)
Graphics Engine Intel® HD Graphics Gen 7 with four execution units
Supports DirectX 11.1, OpenGL 4.2 and OpenCL 1.2
Ethernet Intel® I210 Ethernet Controller
BIOS
UEFI BIOS
 $,[[%,26YHUVLRQLVIRU%D\7UDLO,PRGHO&38([[
 AMxx BIOS version is for Bay Trail M/D model (CPU: J1900/
N2930/N2807)
Embedded Controller ITE IT8528E/FX

iQ7-BT Qseven Module
Page 8
iQ7-BT
Watchdog Timer Software programmable supports 1~255 sec. system reset
Storage Two SATA 3Gb/s (signal to baseboard)
Optional 2 GB–64 GB soldered SSD (SATA port 2)
Display
(signal to baseboard)
Supports dual independent display
One 18/24-bit dual-channel LVDS by CH7511B DP to LVDS
converter (up to 1920x1200@60 Hz)
One DDI (DP: up to 2560 x 1600; HDMI: up to 1920 x 1080)
Expansions
(signal to baseboard) Three PCIe x1
I/O Interfaces
(signal to baseboard)
Six USB 2.0
One USB 3.0
One RS-232
HD Audio
8-bit SDIO 2.0
SMBus
I2C
LPC
SPI
Power Consumption
3.3 V @ 0.1 A, 5 V @ 0.13 A, 12 V @ 1.35 A, 5 VSB @ 0.12 A
(1.91 GHz Intel® Atom™ E3845 CPU with 2 GB 1333 MHz DDR3L
memory)
Operating Temperature -20ºC ~ 60ºC
-40ºC ~ 85ºC (W2 models)
Storage Temperature -30ºC ~ 70ºC
Operating Humidity 5% ~ 95% (non-condensing)
Dimensions 70 mm x 70 mm
Weight (GW/NW) 300 g/150 g
Table 1-2: iQ7-BT Specifications

iQ7-BT Qseven Module
Page 9
Chapter
2
2 Packing List

iQ7-BT Qseven Module
Page 10
2.1 Anti-static Precautions
WARNING!
Static electricity can destroy certain electronics. Make sure to follow the
ESD precautions to prevent damage to the product, and injury to the
user.
Make sure to adhere to the following guidelines:
 Wear an anti-static wristband: Wearing an anti-static wristband can prevent
electrostatic discharge.
 Self-grounding: Touch a grounded conductor every few minutes to discharge
any excess static buildup.
 Use an anti-static pad: When configuring any circuit board, place it on an
anti-static mat.
 Only handle the edges of the PCB: Don't touch the surface of the
motherboard. Hold the motherboard by the edges when handling.
2.2 Unpacking Precautions
When the iQ7-BT is unpacked, please do the following:
 Follow the antistatic guidelines above.
 Make sure the packing box is facing upwards when opening.
 Make sure all the packing list items are present.

iQ7-BT Qseven Module
Page 11
2.3 Packing List
NOTE:
If any of the components listed in the checklist below are missing, do
not proceed with the installation. Contact the IEI reseller or vendor the
iQ7-BT was purchased from or contact an IEI sales representative
directly by sending an email to 39[email protected].
The iQ7-BT is shipped with the following components:
Quantity Item and Part Number Image
1 iQ7-BT Qseven Module
1 Heatsink
1 Utility CD
1 Quick Installation Guide
Table 2-1: Packing List

iQ7-BT Qseven Module
Page 12
2.4 Optional Items
The following are optional components which may be separately purchased:
Item and Part Number Image
Baseboard for Qseven modules
(P/N: iQ7-DB-MATX)
Table 2-2: Optional Items
