IEI Technology KINO-QM670 User manual

KINO-QM670 Mini-ITX SBC
Page I
User Manual
KINO-QM670
MODEL:
Mini-ITX Motherboard Supports Socket G2 for
Intel® Mobile Core™i7/i5 CPU, VGA/LVDS/HDMI
Dual GbE, USB 3.0, PCIe Mini, SATA 6Gb/s and Audio
Rev. 2.01 – 24 April, 2014
KINO-QM670 CPU Card

KINO-QM670 Mini-ITX SBC
Page II
Revision
Date Version Changes
24 April, 2014 2.01 Modified LAN pinouts
Updated Chapter 2: Unpacking
24 December, 2013 2.00 Updated for R20 version
7 February, 2013 1.04 Updated LAN port pinouts
3 May, 2012 1.03 Updated Section 3.2.20 SPI Flash Connector
Updated Appendix C One Key Recovery
15 December, 2011 1.02 Minor update to Section 3.2.13 12V Power Connector and Section 3.2.14
SATADrive Connectors
10 August, 2011 1.01 Minor update to COM3 pin definition
7 July, 2011 1.00 Initial release

KINO-QM670 Mini-ITX SBC
Page III
Copyright
COPYRIGHT NOTICE
The information in this document is subject to change without prior notice in order to
improve reliability, design and function and does not represent a commitment on the part
of the manufacturer.
In no event will the manufacturer be liable for direct, indirect, special, incidental, or
consequential damages arising out of the use or inability to use the product or
documentation, even if advised of the possibility of such damages.
This document contains proprietary information protected by copyright. All rights are
reserved. No part of this manual may be reproduced by any mechanical, electronic, or
other means in any form without prior written permission of the manufacturer.
TRADEMARKS
All registered trademarks and product names mentioned herein are used for identification
purposes only and may be trademarks and/or registered trademarks of their respective
owners.

KINO-QM670 Mini-ITX SBC
Page IV
Table of Contents
1 INTRODUCTION.......................................................................................................... 1
1.1 INTRODUCTION........................................................................................................... 2
1.2 CONNECTORS ............................................................................................................. 3
1.3 DIMENSIONS............................................................................................................... 4
1.3.1 Board Dimensions.............................................................................................. 4
1.3.2 External Interface Panel Dimensions................................................................ 5
1.4 DATA FLOW................................................................................................................ 6
1.5 TECHNICAL SPECIFICATIONS ...................................................................................... 7
2 UNPACKING................................................................................................................. 9
2.1ANTI-STATIC PRECAUTIONS...................................................................................... 10
2.2 UNPACKING PRECAUTIONS....................................................................................... 10
2.3 PACKING LIST............................................................................................................11
2.3.1 Optional Items.................................................................................................. 12
3 CONNECTORS ........................................................................................................... 13
3.1 PERIPHERAL INTERFACE CONNECTORS..................................................................... 14
3.1.1 KINO-QM670 Layout ...................................................................................... 14
3.1.2 Peripheral Interface Connectors ..................................................................... 15
3.1.3 External Interface Panel Connectors............................................................... 16
3.2 INTERNAL PERIPHERAL CONNECTORS...................................................................... 17
3.2.1 Audio Connector .............................................................................................. 17
3.2.2 Battery Connector............................................................................................ 18
3.2.3 Backlight Inverter Connector .......................................................................... 19
3.2.4 Digital I/O Connector...................................................................................... 20
3.2.5 EC Debug Port................................................................................................. 21
3.2.6 Fan Connector (CPU)...................................................................................... 22
3.2.7 Fan Connector (System) .................................................................................. 22
3.2.8 Front Panel Connector .................................................................................... 23
3.2.9 Infrared Interface Connector........................................................................... 24
3.2.10 Keyboard/Mouse Connector .......................................................................... 25

KINO-QM670 Mini-ITX SBC
Page V
3.2.11 LVDS Connector............................................................................................. 26
3.2.12 PCIe Mini Card Slot ...................................................................................... 28
3.2.13 12V Power Connector.................................................................................... 29
3.2.14 SATA Drive Connectors ................................................................................. 30
3.2.15 SATA Power Connector.................................................................................. 31
3.2.16 Serial Port Connector (RS-232)..................................................................... 32
3.2.17 Serial Port Connectors (RS-422/485)............................................................ 33
3.2.18 SMBus Connector .......................................................................................... 34
3.2.19 SPDIF Connector........................................................................................... 35
3.2.20 SPI Flash Connector...................................................................................... 36
3.2.21 TPM Connector.............................................................................................. 37
3.2.22 USB Connectors............................................................................................. 38
3.3 EXTERNAL PERIPHERAL INTERFACE CONNECTOR PANEL ......................................... 39
3.3.1 Audio Connector .............................................................................................. 40
3.3.2 Ethernet and USB 2.0 Connector..................................................................... 41
3.3.3 Ethernet and USB 3.0 Connector..................................................................... 42
3.3.4 HDMI Connectors............................................................................................ 43
3.3.5 Power Connector (12 V, Power Adapter) ........................................................ 43
3.3.6 Serial Port Connector (COM1) ....................................................................... 44
3.3.7 VGA Connector................................................................................................ 45
4 INSTALLATION ......................................................................................................... 46
4.1ANTI-STATIC PRECAUTIONS...................................................................................... 47
4.2 INSTALLATION CONSIDERATIONS.............................................................................. 48
4.2.1 Installation Notices.......................................................................................... 48
4.3 UNPACKING.............................................................................................................. 49
4.4 CPU, CPU COOLING KIT AND SO-DIMM INSTALLATION........................................ 49
4.4.1 Socket G2 CPU Installation............................................................................. 50
4.4.2 Socket G2 Cooling Kit Installation.................................................................. 52
4.4.3 SO-DIMM Installation..................................................................................... 54
4.5 JUMPER SETTINGS .................................................................................................... 54
4.5.1 AT/ATX Power Mode Jumper Settings............................................................. 55
4.5.2 Clear CMOS Jumper........................................................................................ 56
4.5.3 LVDS Panel Resolution Jumper....................................................................... 57
4.5.4 LVDS Voltage Selection.................................................................................... 59

KINO-QM670 Mini-ITX SBC
Page VI
4.5.5 ME RTC Register Jumper................................................................................ 60
4.5.6 Flash Security Override Jumper...................................................................... 61
4.5.7 MPC Switch Control (Reserved)...................................................................... 62
4.6 CHASSIS INSTALLATION............................................................................................ 63
4.6.1 Airflow.............................................................................................................. 63
4.6.2 Motherboard Installation................................................................................. 63
4.7 INTERNAL PERIPHERAL DEVICE CONNECTIONS........................................................ 63
4.7.1 SATA Drive Connection ................................................................................... 64
4.7.2 Dual RS-232 Cable with Slot Bracket.............................................................. 65
4.8 EXTERNAL PERIPHERAL INTERFACE CONNECTION ................................................... 66
4.8.1 Audio Connector .............................................................................................. 67
4.8.2 LAN and USB Connection ............................................................................... 67
4.8.3 Serial Device Connection ................................................................................ 69
4.8.4 VGA Monitor Connection ................................................................................ 70
4.9 SOFTWARE INSTALLATION ........................................................................................ 71
5 BIOS SCREENS........................................................................................................... 73
5.1 INTRODUCTION......................................................................................................... 74
5.1.1 Starting Setup................................................................................................... 74
5.1.2 Using Setup...................................................................................................... 74
5.1.3 Getting Help..................................................................................................... 75
5.1.4 Unable to Reboot After Configuration Changes.............................................. 75
5.1.5 BIOS Menu Bar................................................................................................ 75
5.2 MAIN........................................................................................................................ 76
5.3ADVANCED............................................................................................................... 77
5.3.1 ACPI Settings................................................................................................... 78
5.3.2 Trusted Computing........................................................................................... 79
5.3.3 CPU Configuration.......................................................................................... 80
5.3.4 SATA Configuration ......................................................................................... 81
5.3.5 USB Configuration........................................................................................... 82
5.3.6 Super IO Configuration ................................................................................... 84
5.3.6.1 Serial Port n Configuration....................................................................... 84
5.3.7 H/W Monitor.................................................................................................... 89
5.3.7.1 FAN 1 Configuration ................................................................................ 90
5.3.7.2 FAN 2 Configuration ................................................................................ 91

KINO-QM670 Mini-ITX SBC
Page VII
5.3.8 Serial Port Console Redirection ...................................................................... 92
5.3.9 iEi Feature........................................................................................................ 95
5.4 CHIPSET ................................................................................................................... 95
5.4.1 Northbridge Configuration.............................................................................. 97
5.4.1.1 Graphics Configuration............................................................................. 98
5.4.2 Southbridge Configuration ............................................................................ 101
5.4.3 ME Configuration.......................................................................................... 103
5.5 BOOT...................................................................................................................... 104
5.6 SECURITY............................................................................................................... 105
5.7 SAVE &EXIT.......................................................................................................... 106
A INTEL® AMT CONFIGURATION........................................................................ 108
A.1 INTEL®AMTSETUP PROCEDURE .......................................................................... 109
A.2 INTEL®MANAGEMENT ENGINE BIOS EXTENSION................................................ 109
A.3 IEI EASY MANAGER APPLICATION .........................................................................114
B BIOS MENU OPTIONS............................................................................................115
C ONE KEY RECOVERY............................................................................................118
C.1 ONE KEY RECOVERY INTRODUCTION .....................................................................119
C.1.1 System Requirement ...................................................................................... 120
C.1.2 Supported Operating System......................................................................... 121
C.2 SETUP PROCEDURE FOR WINDOWS........................................................................ 122
C.2.1 Hardware and BIOS Setup............................................................................ 123
C.2.2 Create Partitions........................................................................................... 123
C.2.3 Install Operating System, Drivers and Applications..................................... 127
C.2.4 Build-up Recovery Partition.......................................................................... 128
C.2.5 Create Factory Default Image ...................................................................... 130
C.3AUTO RECOVERY SETUP PROCEDURE.................................................................... 135
C.4 SETUP PROCEDURE FOR LINUX.............................................................................. 140
C.5 RECOVERY TOOL FUNCTIONS ................................................................................ 143
C.5.1 Factory Restore............................................................................................. 145
C.5.2 Backup System............................................................................................... 146
C.5.3 Restore Your Last Backup.............................................................................. 147
C.5.4 Manual .......................................................................................................... 148
C.6 RESTORE SYSTEMS FROM A LINUX SERVER THROUGH LAN.................................. 149

KINO-QM670 Mini-ITX SBC
Page VIII
C.6.1 Configure DHCP Server Settings.................................................................. 150
C.6.2 Configure TFTP Settings............................................................................... 151
C.6.3 Configure One Key Recovery Server Settings............................................... 152
C.6.4 Start the DHCP, TFTP and HTTP................................................................. 153
C.6.5 Create Shared Directory................................................................................ 153
C.6.6 Setup a Client System for Auto Recovery...................................................... 154
C.7 OTHER INFORMATION ............................................................................................ 157
C.7.1 Using AHCI Mode or ALi M5283 / VIA VT6421A Controller ...................... 157
C.7.2 System Memory Requirement........................................................................ 159
D TERMINOLOGY ..................................................................................................... 160
E WATCHDOG TIMER............................................................................................... 165
F HAZARDOUS MATERIALS DISCLOSURE........................................................ 168
F.1 HAZARDOUS MATERIALS DISCLOSURE TABLE FOR IPB PRODUCTS CERTIFIED AS
ROHS COMPLIANT UNDER 2002/95/EC WITHOUT MERCURY..................................... 169

KINO-QM670 Mini-ITX SBC
Page IX
List of Figures
Figure 1-1: KINO-QM670 ................................................................................................................2
Figure 1-2: Connectors ..................................................................................................................3
Figure 1-3: KINO-QM670 Dimensions (mm).................................................................................4
Figure 1-4: External Interface Panel Dimensions (mm)..............................................................5
Figure 1-5: Data Flow Block Diagram...........................................................................................6
Figure 3-1: Connector and Jumper Locations...........................................................................14
Figure 3-2: Audio Connector Location.......................................................................................17
Figure 3-3: Battery Connector Location.....................................................................................18
Figure 3-4: Panel Backlight Connector Pinout Location..........................................................19
Figure 3-5: Digital I/O Connector Location ................................................................................20
Figure 3-6: BIOS Debug Port Location.......................................................................................21
Figure 3-7: CPU Fan Connector Location..................................................................................22
Figure 3-8: +12V Fan Connector Location.................................................................................23
Figure 3-9: Front Panel Connector Location .............................................................................24
Figure 3-10: Infrared Connector Location..................................................................................25
Figure 3-11: Keyboard/Mouse Connector Location..................................................................26
Figure 3-12: LVDS LCD Connector Pinout Location.................................................................27
Figure 3-13: PCIe Mini Card Slot Location.................................................................................28
Figure 3-14: CPU 12V Power Connector Location....................................................................30
Figure 3-15: SATA Drive Connector Location ...........................................................................31
Figure 3-16: SATA Power Connector Location .........................................................................32
Figure 3-17: Serial Port Connector Location.............................................................................33
Figure 3-18: Serial Port Connector (RS-422/485) Location ......................................................34
Figure 3-19: SMBus Connector Location...................................................................................35
Figure 3-20: SPDIF Connector Location ....................................................................................36
Figure 3-21: SPI Flash Connector Location...............................................................................37
Figure 3-22: TPM Connector Pinout Location ...........................................................................38
Figure 3-23: USB Connector Pinout Location ...........................................................................39
Figure 3-24: KINO-QM670 External Peripheral Interface Connector.......................................40
Figure 3-25: Audio Jacks.............................................................................................................40
Figure 3-26: Ethernet Connector.................................................................................................41

KINO-QM670 Mini-ITX SBC
Page X
Figure 3-27: 4-pin Power Mini-DIN Connection .........................................................................44
Figure 3-28: Serial Port Pinouts..................................................................................................44
Figure 3-29: VGA Connector .......................................................................................................45
Figure 4-1: Unlock CPU socket retention screw .......................................................................51
Figure 4-2: Lock the CPU Socket Retention Screw...................................................................52
Figure 4-3: Cooling Kit Support Bracket....................................................................................53
Figure 4-4: SO-DIMM Installation................................................................................................54
Figure 4-5: Jumper Locations.....................................................................................................54
Figure 4-6: AT/ATX Power Mode Jumper Location...................................................................56
Figure 4-7: Clear CMOS Jumper .................................................................................................57
Figure 4-8: LVDS Panel Resolution Jumper Pinout Locations................................................58
Figure 4-9: LVDS Voltage Selection Jumper Pinout Locations...............................................60
Figure 4-10: ME RTC Register Jumper Location.......................................................................61
Figure 4-11: Flash Security Override Jumper Location............................................................62
Figure 4-12: MPC Switch Control Jumper Location..................................................................63
Figure 4-13: SATA Drive Cable Connection...............................................................................64
Figure 4-14: SATA Power Drive Connection..............................................................................65
Figure 4-15: Dual RS-232 Cable Installation ..............................................................................66
Figure 4-16: Audio Connector.....................................................................................................67
Figure 4-17: LAN Connection......................................................................................................68
Figure 4-18: Serial Device Connector.........................................................................................69
Figure 4-19: VGA Connector .......................................................................................................70
Figure 4-20: Introduction Screen................................................................................................71
Figure 4-21: Available Drivers.....................................................................................................72
Figure A-1: Intel® Active Management Technology Status Dialog...................................... 109
Figure A-2: Intel® Current ME Password................................................................................ 110
Figure A-3: Intel® ME New Password...................................................................................... 110
Figure A-4: Intel® AMT Configuration..................................................................................... 111
Figure A-5: Select KVM Configuration .................................................................................... 111
Figure A-6: KVM Configuration................................................................................................ 112
Figure A-7: KVM User Opt-in.................................................................................................... 112
Figure A-8: Exit.......................................................................................................................... 113
Figure C-1: IEI One Key Recovery Tool Menu ........................................................................ 119
Figure C-2: Launching the Recovery Tool.............................................................................. 124
Figure C-3: Recovery Tool Setup Menu .................................................................................. 124

KINO-QM670 Mini-ITX SBC
Page XI
Figure C-4: Command Mode..................................................................................................... 125
Figure C-5: Partition Creation Commands.............................................................................. 126
Figure C-6: Launching the Recovery Tool.............................................................................. 128
Figure C-7: Manual Recovery Environment for Windows..................................................... 128
Figure C-8: Building the Recovery Partition........................................................................... 129
Figure C-9: Press Any Key to Continue .................................................................................. 129
Figure C-10: Press F3 to Boot into Recovery Mode............................................................... 130
Figure C-11: Recovery Tool Menu ........................................................................................... 130
Figure C-12: About Symantec Ghost Window........................................................................ 131
Figure C-13: Symantec Ghost Path ......................................................................................... 131
Figure C-14: Select a Local Source Drive ............................................................................... 132
Figure C-15: Select a Source Partition from Basic Drive ...................................................... 132
Figure C-16: File Name to Copy Image to ............................................................................... 133
Figure C-17: Compress Image.................................................................................................. 133
Figure C-18: Image Creation Confirmation............................................................................. 134
Figure C-19: Image Creation Complete................................................................................... 134
Figure C-20: Image Creation Complete................................................................................... 134
Figure C-21: Press Any Key to Continue ................................................................................ 135
Figure C-22: Auto Recovery Utility.......................................................................................... 136
Figure C-23: Disable Automatically Restart............................................................................ 136
Figure C-24: Launching the Recovery Tool............................................................................ 137
Figure C-25: Auto Recovery Environment for Windows ....................................................... 137
Figure C-26: Building the Auto Recovery Partition................................................................ 138
Figure C-27: Factory Default Image Confirmation ................................................................. 138
Figure C-28: Image Creation Complete................................................................................... 139
Figure C-29: Press any key to continue.................................................................................. 139
Figure C-30: Partitions for Linux.............................................................................................. 141
Figure C-31: System Configuration for Linux......................................................................... 142
Figure C-32: Access menu.lst in Linux (Text Mode).............................................................. 142
Figure C-33: Recovery Tool Menu ........................................................................................... 143
Figure C-34: Recovery Tool Main Menu.................................................................................. 144
Figure C-35: Restore Factory Default...................................................................................... 145
Figure C-36: Recovery Complete Window.............................................................................. 145
Figure C-37: Backup System.................................................................................................... 146
Figure C-38: System Backup Complete Window ................................................................... 146

KINO-QM670 Mini-ITX SBC
Page XII
Figure C-39: Restore Backup ................................................................................................... 147
Figure C-40: Restore System Backup Complete Window..................................................... 147
Figure C-41: Symantec Ghost Window ................................................................................... 148
Figure C-42: Disable Automatically Restart............................................................................ 155

KINO-QM670 Mini-ITX SBC
Page XIII
List of Tables
Table 1-1: Technical Specifications..............................................................................................8
Table 3-1: Peripheral Interface Connectors...............................................................................16
Table 3-2: Rear Panel Connectors..............................................................................................16
Table 3-3: Audio Connector Pinouts ..........................................................................................17
Table 3-4: Battery Connector Pinouts........................................................................................18
Table 3-5: Panel Backlight Connector Pinouts..........................................................................19
Table 3-6: Digital I/O Connector Pinouts....................................................................................20
Table 3-7: EC Debug Port Pinouts..............................................................................................21
Table 3-8: CPU Fan Connector Pinouts......................................................................................22
Table 3-9: +12V Fan Connector Pinouts.....................................................................................23
Table 3-10: Front Panel Connector Pinouts...............................................................................24
Table 3-11: Infrared Connector Pinouts.....................................................................................25
Table 3-12: Keyboard/Mouse Connector Pinouts .....................................................................26
Table 3-13: LVDS LCD Port Connector Pinouts........................................................................27
Table 3-14: PCIe Mini Card Slot Pinouts ....................................................................................29
Table 3-15: CPU 12V Power Connector Pinouts........................................................................30
Table 3-16: SATA Drive Connector Pinouts...............................................................................31
Table 3-17: SATA Power Connector Pinouts.............................................................................32
Table 3-18: Serial Port Connector Pinouts ................................................................................33
Table 3-19: Serial Port Connector (RS-422/485) Pinouts..........................................................34
Table 3-20: DB-9 RS-422/485 Pinouts.........................................................................................34
Table 3-21: SMBus Connector Pinouts ......................................................................................35
Table 3-22: SPDIF Connector Pinouts........................................................................................36
Table 3-23: JSPI1 Flash Connector Pinouts..............................................................................37
Table 3-24: JSPI2 Flash Connector Pinouts..............................................................................37
Table 3-25: TPM Connector Pinouts...........................................................................................38
Table 3-26: USB Port Connector Pinouts...................................................................................39
Table 3-27: LAN Pinouts ..............................................................................................................41
Table 3-28: Ethernet Connector LEDs........................................................................................41
Table 3-29: USB 2.0 Port Pinouts................................................................................................42
Table 3-30: USB 3.0 Port Pinouts................................................................................................42

KINO-QM670 Mini-ITX SBC
Page XIV
Table 3-31: HDMI Connector Pinouts .........................................................................................43
Table 3-32: Serial Port Pinouts....................................................................................................44
Table 3-33: VGA Connector Pinouts...........................................................................................45
Table 4-1: Jumpers.......................................................................................................................55
Table 4-2: AT/ATX Power Mode Jumper Settings.....................................................................55
Table 4-3: Clear CMOS Jumper Settings....................................................................................57
Table 4-4: LVDS Panel Resolution Jumper Settings.................................................................58
Table 4-5: LVDS Voltage Selection Jumper Settings................................................................59
Table 4-6: ME RTC Register Jumper Settings ...........................................................................60
Table 4-7: Flash Security Override Jumper Settings................................................................61
Table 4-8: MPC Switch Control Jumper Settings (Reserved) ..................................................62
Table 5-1: BIOS Navigation Keys................................................................................................75

KINO-QM670 Mini-ITX SBC
Page XV
List of BIOS Menus
BIOS Menu 1: Main.......................................................................................................................76
BIOS Menu 2: Advanced..............................................................................................................78
BIOS Menu 3: ACPI Configuration..............................................................................................78
BIOS Menu 4: TPM Configuration...............................................................................................79
BIOS Menu 5: CPU Configuration...............................................................................................80
BIOS Menu 6: SATA Configuration.............................................................................................81
BIOS Menu 7: USB Configuration...............................................................................................82
BIOS Menu 8: Super IO Configuration........................................................................................84
BIOS Menu 9: Serial Port n Configuration Menu.......................................................................84
BIOS Menu 10: H/W Monitor........................................................................................................89
BIOS Menu 11: FAN 1 Configuration..........................................................................................90
BIOS Menu 12: FAN 2 Configuration..........................................................................................91
BIOS Menu 13: Serial Port Console Redirection.......................................................................93
BIOS Menu 14: iEi Feature...........................................................................................................95
BIOS Menu 15: Chipset................................................................................................................96
BIOS Menu 16: Northbridge Chipset Configuration..................................................................97
BIOS Menu 17: Northbridge Chipset Configuration..................................................................98
BIOS Menu 18: Southbridge Chipset Configuration.............................................................. 101
BIOS Menu 19: ME Subsystem................................................................................................. 103
BIOS Menu 20: Boot.................................................................................................................. 104
BIOS Menu 21: Security............................................................................................................ 106
BIOS Menu 22:Exit..................................................................................................................... 107
BIOS Menu 23: IEI Feature........................................................................................................ 140

KINO-QM670 Mini-ITX SBC
Page 1
1 Introduction
Chapter
1

KINO-QM670 Mini-ITX SBC
Page 2
1.1 Introduction
Figure 1-1: KINO-QM670
The KINO-QM670 Mini-ITX motherboard is a Socket G 32nm Intel® Core™ i5
and Core™ i7 processor (Arrandale) platform. Up to two 4.0 GB 1066 MHz or 1333 MHz
DDR3 SDRAM SO-DIMM are supported by the Intel® Arrandale processor. The processor
also supports a PCIe x16 slot.
The integrated Intel® QM67 Express Chipset supports two GbE LAN: one through the
Intel® 82579 Ethernet controller (with iAMT 7.0 support) and another through the Intel®
82583V Ethernet controller. The Intel® QM67 also supports two SATA 3Gb/s drives, two
SATA 6Gb/s drives, and provides 12 V or 5 V SATA power.
The KINO-QM670 supports multiple display devices, including 18-bit or 24-bit
dual-channel LVDS, analog CRT, and dual HDMI. Six USB 2.0 channels, two USB 3.0
channels and one expansion PCIe Mini socket provide flexible expansion options. High
Definition Audio (HDA) support ensures HDA devices can be easily implemented on the
KINO-QM670.

KINO-QM670 Mini-ITX SBC
Page 3
1.2 Connectors
The connectors on the KINO-QM670 are shown in the figure below.
Figure 1-2: Connectors

KINO-QM670 Mini-ITX SBC
Page 4
1.3 Dimensions
1.3.1 Board Dimensions
The dimensions of the board are listed below:
Length: 170 mm
Width: 170 mm
Figure 1-3: KINO-QM670 Dimensions (mm)

KINO-QM670 Mini-ITX SBC
Page 5
1.3.2 External Interface Panel Dimensions
External peripheral interface connector panel dimensions are shown in 6Figure 1-4.
Figure 1-4: External Interface Panel Dimensions (mm)
