IEI Technology NANO-QM871 User manual

NANO-QM871 EPIC SBC
Page i
User Manual
EPIC SBC with 4th Generation 22nm Intel
®
Mobile Core™
i7/i5/i3 or Celeron® Processor, Dual HDMI, LVDS, VGA,
Dual GbE, SATA 6Gb/s, USB 3.0, PCIe Mini, PCIe/104,
Intel® AMT 9.0
,
Audio and RoHS
MODEL:
NANO-QM871
Rev. 1.01 – 24 April, 2014

NANO-QM871 EPIC SBC
Page ii
Revision
Date Version Changes
24 April, 2014 1.01 Modified LAN pinouts
24 December, 2013 1.00 Initial release

NANO-QM871 EPIC SBC
Page iii
Copyright
COPYRIGHT NOTICE
The information in this document is subject to change without prior notice in order to
improve reliability, design and function and does not represent a commitment on the part
of the manufacturer.
In no event will the manufacturer be liable for direct, indirect, special, incidental, or
consequential damages arising out of the use or inability to use the product or
documentation, even if advised of the possibility of such damages.
This document contains proprietary information protected by copyright. All rights are
reserved. No part of this manual may be reproduced by any mechanical, electronic, or
other means in any form without prior written permission of the manufacturer.
TRADEMARKS
All registered trademarks and product names mentioned herein are used for identification
purposes only and may be trademarks and/or registered trademarks of their respective
owners.

NANO-QM871 EPIC SBC
Page iv
Table of Contents
1 INTRODUCTION.......................................................................................................... 1
1.1 INTRODUCTION........................................................................................................... 2
1.2 FEATURES................................................................................................................... 3
1.3 CONNECTORS ............................................................................................................. 4
1.4 DIMENSIONS............................................................................................................... 5
1.5 DATA FLOW................................................................................................................ 6
1.6 TECHNICAL SPECIFICATIONS ...................................................................................... 7
2 PACKING LIST............................................................................................................. 9
2.1ANTI-STATIC PRECAUTIONS...................................................................................... 10
2.2 UNPACKING PRECAUTIONS....................................................................................... 10
2.3 PACKING LIST............................................................................................................11
2.4 OPTIONAL ITEMS...................................................................................................... 12
3 CONNECTOR PINOUTS........................................................................................... 14
3.1 PERIPHERAL INTERFACE CONNECTORS..................................................................... 15
3.1.1 Layout .............................................................................................................. 15
3.1.2 Peripheral Interface Connectors ..................................................................... 16
3.1.3 External Interface Panel Connectors............................................................... 17
3.2 INTERNAL PERIPHERAL CONNECTORS...................................................................... 17
3.2.1 Audio Connector .............................................................................................. 17
3.2.2 Battery Connector............................................................................................ 18
3.2.3 Digital I/O Connector...................................................................................... 19
3.2.4 EC Debug Port................................................................................................. 20
3.2.5 Fan Connector (CPU)...................................................................................... 21
3.2.6 Fan Connector (System) .................................................................................. 22
3.2.7 Keyboard and Mouse Connector ..................................................................... 23
3.2.8 LAN Active LED Connector............................................................................. 24
3.2.9 LVDS Connector.............................................................................................. 24
3.2.10 LVDS Backlight Connector............................................................................ 25
3.2.11 PCIe Mini Card Slot....................................................................................... 26

NANO-QM871 EPIC SBC
Page v
3.2.12 PCIe/104 Slot................................................................................................. 28
3.2.13 Power Button Connector................................................................................ 31
3.2.14 Power Connector (12V)................................................................................. 32
3.2.15 Power LED and HDD LED Connector ......................................................... 32
3.2.16 Reset Button Connector ................................................................................. 33
3.2.17 RS-232 Serial Port Connectors...................................................................... 34
3.2.18 RS-422/485 Serial Port Connector (COM3).................................................. 35
3.2.19 SATA 6Gb/s Drive Connectors....................................................................... 36
3.2.20 SATA Power Connectors................................................................................ 37
3.2.21 SMBus Connector .......................................................................................... 38
3.2.22 SO-DIMM Connector..................................................................................... 38
3.2.23 SPI Flash Connector...................................................................................... 39
3.2.24 SPI Flash Connector (EC)............................................................................. 40
3.2.25 TPM Connector.............................................................................................. 41
3.2.26 USB 2.0 Connector ........................................................................................ 42
3.3 EXTERNAL INTERFACE CONNECTORS....................................................................... 43
3.3.1 Ethernet Connectors ........................................................................................ 43
3.3.2 HDMI Connectors............................................................................................ 44
3.3.3 USB 2.0 Connector .......................................................................................... 45
3.3.4 USB 3.0 Connector .......................................................................................... 45
3.3.5 VGA Connector................................................................................................ 46
4 INSTALLATION ......................................................................................................... 47
4.1ANTI-STATIC PRECAUTIONS...................................................................................... 48
4.2 INSTALLATION CONSIDERATIONS.............................................................................. 48
4.3 COOLING KIT INSTALLATION.................................................................................... 50
4.4 SO-DIMM INSTALLATION ....................................................................................... 52
4.5 PCIE MINI CARD INSTALLATION .............................................................................. 53
4.6 JUMPER SETTINGS .................................................................................................... 54
4.6.1 AT/ATX Mode Selection................................................................................... 55
4.6.2 Clear CMOS..................................................................................................... 55
4.6.3 LVDS Voltage Selection.................................................................................... 56
4.6.4 LVDS Resolution Selection .............................................................................. 57
4.7 CHASSIS INSTALLATION............................................................................................ 58
4.7.1 Airflow.............................................................................................................. 58

NANO-QM871 EPIC SBC
Page vi
4.7.2 Motherboard Installation................................................................................. 59
4.8 INTERNAL PERIPHERAL DEVICE CONNECTIONS........................................................ 59
4.8.1 AT/ATX Power Connection.............................................................................. 59
4.8.2 Audio Kit Installation....................................................................................... 61
4.8.3 LVDS LCD Installation.................................................................................... 62
4.8.4 SATA Drive Connection ................................................................................... 64
4.8.5 Single RS-232 Cable........................................................................................ 65
4.9 EXTERNAL PERIPHERAL INTERFACE CONNECTION ................................................... 66
4.9.1 HDMI Display Device Connection.................................................................. 66
4.9.2 LAN Connection............................................................................................... 67
4.9.3 USB Connection (Dual Connector)................................................................. 68
4.9.4 VGA Monitor Connection ................................................................................ 69
4.10 INTEL®AMTSETUP PROCEDURE........................................................................... 70
5 BIOS.............................................................................................................................. 72
5.1 INTRODUCTION......................................................................................................... 73
5.1.1 Starting Setup................................................................................................... 73
5.1.2 Using Setup...................................................................................................... 73
5.1.3 Getting Help..................................................................................................... 74
5.1.4 Unable to Reboot after Configuration Changes.............................................. 74
5.1.5 BIOS Menu Bar................................................................................................ 74
5.2 MAIN........................................................................................................................ 76
5.3ADVANCED............................................................................................................... 77
5.3.1 ACPI Settings................................................................................................... 78
5.3.2 RTC Wake Settings........................................................................................... 79
5.3.3 Trusted Computing........................................................................................... 80
5.3.4 CPU Configuration.......................................................................................... 82
5.3.5 SATA Configuration ......................................................................................... 84
5.3.6 Intel(R) Rapid Start Technology....................................................................... 85
5.3.7 AMT Configuration.......................................................................................... 86
5.3.8 USB Configuration........................................................................................... 87
5.3.9 iWDD H/W Monitor......................................................................................... 88
5.3.9.1 Smart Fan Mode Configuration................................................................ 88
5.3.10 F81866 Super IO Configuration.................................................................... 90
5.3.10.1 Serial Port n Configuration..................................................................... 90

NANO-QM871 EPIC SBC
Page vii
5.3.11 F81866 H/W Monitor..................................................................................... 93
5.3.12 Serial Port Console Redirection.................................................................... 94
5.3.13 iEi Feature ..................................................................................................... 97
5.3.14 ICP Board ...................................................................................................... 98
5.4 CHIPSET ................................................................................................................... 99
5.4.1 System Agent (SA) Configuration .................................................................. 100
5.4.1.1 Graphics Configuration........................................................................... 100
5.4.1.2 NB PCIe Configuration........................................................................... 103
5.4.1.3 Memory Configuration ........................................................................... 104
5.4.2 PCH-IO Configuration .................................................................................. 105
5.4.2.1 PCI Express Configuration..................................................................... 106
5.5 BOOT...................................................................................................................... 107
5.6 SECURITY............................................................................................................... 109
5.7 SAVE &EXIT...........................................................................................................110
6 SOFTWARE DRIVERS.............................................................................................111
6.1AVAILABLE SOFTWARE DRIVERS .............................................................................112
6.2 STARTING THE DRIVER PROGRAM ...........................................................................112
6.3 CHIPSET DRIVER INSTALLATION..............................................................................114
6.4 GRAPHICS DRIVER INSTALLATION...........................................................................117
6.5 LAN DRIVER INSTALLATION.................................................................................. 120
6.6 USB 3.0 DRIVER INSTALLATION ............................................................................ 125
6.7AUDIO DRIVER INSTALLATION ............................................................................... 128
6.8 INTEL®AMTDRIVER INSTALLATION .................................................................... 130
A BIOS OPTIONS ........................................................................................................ 133
B ONE KEY RECOVERY........................................................................................... 136
B.1 ONE KEY RECOVERY INTRODUCTION .................................................................... 137
B.1.1 System Requirement....................................................................................... 138
B.1.2 Supported Operating System......................................................................... 139
B.2 SETUP PROCEDURE FOR WINDOWS........................................................................ 140
B.2.1 Hardware and BIOS Setup ............................................................................ 141
B.2.2 Create Partitions ........................................................................................... 141
B.2.3 Install Operating System, Drivers and Applications..................................... 145
B.2.4 Building the Recovery Partition.................................................................... 146

NANO-QM871 EPIC SBC
Page viii
B.2.5 Create Factory Default Image....................................................................... 148
B.3AUTO RECOVERY SETUP PROCEDURE.................................................................... 153
B.4 SETUP PROCEDURE FOR LINUX.............................................................................. 158
B.5 RECOVERY TOOL FUNCTIONS ................................................................................ 161
B.5.1 Factory Restore ............................................................................................. 163
B.5.2 Backup System............................................................................................... 164
B.5.3 Restore Your Last Backup.............................................................................. 165
B.5.4 Manual........................................................................................................... 166
B.6 RESTORE SYSTEMS FROM A LINUX SERVER THROUGH LAN.................................. 167
B.6.1 Configure DHCP Server Settings.................................................................. 168
B.6.2 Configure TFTP Settings............................................................................... 169
B.6.3 Configure One Key Recovery Server Settings............................................... 170
B.6.4 Start the DHCP, TFTP and HTTP................................................................. 171
B.6.5 Create Shared Directory................................................................................ 171
B.6.6 Setup a Client System for Auto Recovery...................................................... 172
B.7 OTHER INFORMATION............................................................................................ 175
B.7.1 Using AHCI Mode or ALi M5283 / VIA VT6421A Controller....................... 175
B.7.2 System Memory Requirement ........................................................................ 177
C TERMINOLOGY ..................................................................................................... 178
D DIGITAL I/O INTERFACE..................................................................................... 182
D.1 INTRODUCTION...................................................................................................... 183
D.2 DIO CONNECTOR PINOUTS ................................................................................... 183
D.3ASSEMBLY LANGUAGE SAMPLES........................................................................... 184
D.3.1 Enable the DIO Input Function .................................................................... 184
D.3.2 Enable the DIO Output Function.................................................................. 184
E HAZARDOUS MATERIALS DISCLOSURE ....................................................... 185
E.1 HAZARDOUS MATERIALS DISCLOSURE TABLE FOR IPB PRODUCTS CERTIFIED AS
ROHS COMPLIANT UNDER 2002/95/EC WITHOUT MERCURY ..................................... 186

NANO-QM871 EPIC SBC
Page ix
List of Figures
Figure 1-1: NANO-QM871...............................................................................................................2
Figure 1-2: Connectors ..................................................................................................................4
Figure 1-3: NANO-QM871 Dimensions (mm) ...............................................................................5
Figure 1-4: Data Flow Diagram......................................................................................................6
Figure 3-1: Connector and Jumper Locations...........................................................................15
Figure 3-2: Audio Connector Location.......................................................................................18
Figure 3-3: Battery Connector Location.....................................................................................19
Figure 3-4: Digital I/O Connector Location ................................................................................20
Figure 3-5: EC Debug Port Location...........................................................................................21
Figure 3-6: CPU Fan Connector Location..................................................................................22
Figure 3-7: System Fan Connector Location.............................................................................22
Figure 3-8: Keyboard/Mouse Connector Location....................................................................23
Figure 3-9: LAN Active LED Connector Location......................................................................24
Figure 3-10: LVDS Connector Location......................................................................................25
Figure 3-11: LVDS Backlight Inverter Connector......................................................................26
Figure 3-12: PCIe Mini Card Slot Location.................................................................................27
Figure 3-13: PCIe/104 Slot Location ...........................................................................................28
Figure 3-14: Power Button Connector Location........................................................................31
Figure 3-15: Power Connector Location ....................................................................................32
Figure 3-16: Power LED and HDD LED Connector Location ...................................................33
Figure 3-17: Reset Button Connector Location.........................................................................34
Figure 3-18: RS-232 Serial Port Connector Location................................................................34
Figure 3-19: RS-422/485 Serial Port Connector Location.........................................................35
Figure 3-20: SATA 6Gb/s Drive Connector Locations..............................................................36
Figure 3-21: SATA Power Connector Locations .......................................................................37
Figure 3-22: SMBus Connector Location...................................................................................38
Figure 3-23: SO-DIMM Connector Locations.............................................................................39
Figure 3-24: SPI Flash Connector Location...............................................................................39
Figure 3-25: EC SPI Flash Connector Location.........................................................................40
Figure 3-26: TPM Connector Location........................................................................................41

NANO-QM871 EPIC SBC
Page x
Figure 3-27: USB Connector Locations......................................................................................42
Figure 3-28: External Interface Connectors...............................................................................43
Figure 3-29: Ethernet Connector.................................................................................................43
Figure 3-30: HDMI Connector......................................................................................................44
Figure 3-31: VGA Connector .......................................................................................................46
Figure 4-1: Install Support Bracket.............................................................................................50
Figure 4-2: Align the Cooling Kit.................................................................................................51
Figure 4-3: Secure the Cooling Kit..............................................................................................52
Figure 4-4: SO-DIMM Installation................................................................................................53
Figure 4-5: PCIe Mini Card Installation.......................................................................................53
Figure 4-6: AT/ATX Mode Selection Jumper Location..............................................................55
Figure 4-7: Clear CMOS Jumper Location .................................................................................56
Figure 4-8: LVDS Voltage Selection Jumper Location .............................................................57
Figure 4-9: LVDS Resolution Selection Jumper Location........................................................58
Figure 4-10: Power Cable to Motherboard Connection............................................................60
Figure 4-11: Connect Power Cable to Power Supply................................................................61
Figure 4-12: Audio Kit Cable Connection ..................................................................................62
Figure 4-13: LVDS Connector......................................................................................................63
Figure 4-14: Backlight Inverter Connection...............................................................................64
Figure 4-15: SATA Drive Cable Connection...............................................................................65
Figure 4-16: Single RS-232 Cable Installation ...........................................................................66
Figure 4-17: HDMI Connection....................................................................................................67
Figure 4-18: LAN Connection......................................................................................................68
Figure 4-19: USB Connector........................................................................................................69
Figure 4-20: VGA Connector .......................................................................................................70
Figure 6-1: Start Up Screen ...................................................................................................... 113
Figure 6-2: Drivers..................................................................................................................... 113
Figure 6-3: Chipset Driver Welcome Screen........................................................................... 114
Figure 6-4: Chipset Driver License Agreement...................................................................... 115
Figure 6-5: Chipset Driver Read Me File ................................................................................. 115
Figure 6-6: Chipset Driver Setup Operations ......................................................................... 116
Figure 6-7: Chipset Driver Installation Finish Screen............................................................ 117
Figure 6-8: Graphics Driver Welcome Screen........................................................................ 118
Figure 6-9: Graphics Driver License Agreement.................................................................... 118
Figure 6-10: Graphics Driver Read Me File............................................................................. 119

NANO-QM871 EPIC SBC
Page xi
Figure 6-11: Graphics Driver Setup Operations..................................................................... 119
Figure 6-12: Graphics Driver Installation Finish Screen ....................................................... 120
Figure 6-13: Windows Control Panel....................................................................................... 121
Figure 6-14: System Control Panel.......................................................................................... 121
Figure 6-15: Device Manager List ............................................................................................ 122
Figure 6-16: Update Driver Software Window ........................................................................ 123
Figure 6-17: Locate Driver Files............................................................................................... 123
Figure 6-18: LAN Driver Installation ........................................................................................ 124
Figure 6-19: LAN Driver Installation Complete....................................................................... 124
Figure 6-20: USB 3.0 Driver Welcome Screen........................................................................ 125
Figure 6-21: USB 3.0 Driver License Agreement.................................................................... 126
Figure 6-22: USB 3.0 Driver Read Me File............................................................................... 126
Figure 6-23: USB 3.0 Driver Setup Operations....................................................................... 127
Figure 6-24: USB 3.0 Driver Installation Finish Screen ......................................................... 127
Figure 6-25: Audio Driver Welcome Screen............................................................................ 128
Figure 6-26: Audio Driver Installation...................................................................................... 129
Figure 6-27: Audio Driver Installation Complete.................................................................... 129
Figure 6-28: Intel® ME Driver Welcome Screen ..................................................................... 130
Figure 6-29: Intel® ME Driver License Agreement................................................................. 131
Figure 6-30: Intel® ME Driver Setup Operations.................................................................... 131
Figure 6-31: Intel® ME Driver Installation Finish Screen ...................................................... 132
Figure B-1: IEI One Key Recovery Tool Menu ........................................................................ 137
Figure B-2: Launching the Recovery Tool.............................................................................. 142
Figure B-3: Recovery Tool Setup Menu .................................................................................. 142
Figure B-4: Command Prompt ................................................................................................. 143
Figure B-5: Partition Creation Commands.............................................................................. 144
Figure B-6: Launching the Recovery Tool.............................................................................. 146
Figure B-7: Manual Recovery Environment for Windows..................................................... 146
Figure B-8: Building the Recovery Partition........................................................................... 147
Figure B-9: Press Any Key to Continue .................................................................................. 147
Figure B-10: Press F3 to Boot into Recovery Mode............................................................... 148
Figure B-11: Recovery Tool Menu ........................................................................................... 148
Figure B-12: About Symantec Ghost Window........................................................................ 149
Figure B-13: Symantec Ghost Path ......................................................................................... 149
Figure B-14: Select a Local Source Drive ............................................................................... 150

NANO-QM871 EPIC SBC
Page xii
Figure B-15: Select a Source Partition from Basic Drive ...................................................... 150
Figure B-16: File Name to Copy Image to ............................................................................... 151
Figure B-17: Compress Image.................................................................................................. 151
Figure B-18: Image Creation Confirmation............................................................................. 152
Figure B-19: Image Creation Complete................................................................................... 152
Figure B-20: Image Creation Complete................................................................................... 152
Figure B-21: Press Any Key to Continue ................................................................................ 153
Figure B-22: Auto Recovery Utility.......................................................................................... 154
Figure B-23: Disable Automatically Restart............................................................................ 154
Figure B-24: Launching the Recovery Tool............................................................................ 155
Figure B-25: Auto Recovery Environment for Windows ....................................................... 155
Figure B-26: Building the Auto Recovery Partition................................................................ 156
Figure B-27: Factory Default Image Confirmation ................................................................. 156
Figure B-28: Image Creation Complete................................................................................... 157
Figure B-29: Press any key to continue.................................................................................. 157
Figure B-30: IEI Feature ............................................................................................................ 158
Figure B-31: Partitions for Linux.............................................................................................. 159
Figure B-32: Manual Recovery Environment for Linux ......................................................... 160
Figure B-33: Access menu.lst in Linux (Text Mode).............................................................. 160
Figure B-34: Recovery Tool Menu ........................................................................................... 161
Figure B-35: Recovery Tool Main Menu.................................................................................. 162
Figure B-36: Restore Factory Default...................................................................................... 163
Figure B-37: Recovery Complete Window.............................................................................. 163
Figure B-38: Backup System.................................................................................................... 164
Figure B-39: System Backup Complete Window ................................................................... 164
Figure B-40: Restore Backup ................................................................................................... 165
Figure B-41: Restore System Backup Complete Window..................................................... 165
Figure B-42: Symantec Ghost Window ................................................................................... 166
Figure B-43: Disable Automatically Restart............................................................................ 173

NANO-QM871 EPIC SBC
Page xiii
List of Tables
Table 1-1: Technical Specifications..............................................................................................8
Table 2-1: Packing List.................................................................................................................12
Table 2-2: Optional Items.............................................................................................................13
Table 3-1: Peripheral Interface Connectors...............................................................................17
Table 3-2: Rear Panel Connectors..............................................................................................17
Table 3-3: Audio Connector Pinouts ..........................................................................................18
Table 3-4: Battery Connector Pinouts........................................................................................19
Table 3-5: Digital I/O Connector Pinouts....................................................................................20
Table 3-6: EC Debug Port Pinouts..............................................................................................21
Table 3-7: CPU Fan Connector Pinouts......................................................................................22
Table 3-8: System Fan Connector Pinouts ................................................................................23
Table 3-9: Keyboard/Mouse Connector Pinouts .......................................................................23
Table 3-10: LAN Active LED Connector Pinouts.......................................................................24
Table 3-11: LVDS Connector Pinouts.........................................................................................25
Table 3-12: Backlight Inverter Connector Pinouts....................................................................26
Table 3-13: PCIe Mini Card Slot Pinouts ....................................................................................28
Table 3-14: PCIe/104 Slot Pinouts...............................................................................................31
Table 3-15: Power Button Connector Pinouts...........................................................................31
Table 3-16: Power Connector Pinouts........................................................................................32
Table 3-17: Power LED and HDD LED Connector Pinouts.......................................................33
Table 3-18: Reset Button Connector Pinouts............................................................................34
Table 3-19: RS-232 Serial Port Connector Pinouts...................................................................35
Table 3-20: RS-422/485 Serial Port Connector Pinouts............................................................35
Table 3-21: DB-9 RS-422/485 Pinouts.........................................................................................36
Table 3-22: SATA 6Gb/s Drive Connector Pinouts....................................................................37
Table 3-23: SATA Power Connector Pinouts.............................................................................37
Table 3-24: SMBus Connector Pinouts ......................................................................................38
Table 3-25: SPI Flash Connector Pinouts ..................................................................................40
Table 3-26: EC SPI Flash Connector Pinouts ............................................................................40
Table 3-27: TPM Connector Pinouts...........................................................................................41

NANO-QM871 EPIC SBC
Page xiv
Table 3-28: USB Port Connector Pinouts...................................................................................42
Table 3-29: LAN Pinouts ..............................................................................................................43
Table 3-30: Connector LEDs........................................................................................................44
Table 3-31: HDMI Connector Pinouts .........................................................................................44
Table 3-32: External USB 2.0 Port Pinouts ................................................................................45
Table 3-33: External USB 3.0 Port Pinouts ................................................................................46
Table 3-34: VGA Connector Pinouts...........................................................................................46
Table 4-1: Jumpers.......................................................................................................................54
Table 4-2: LVDS Voltage Selection Jumper Settings................................................................56
Table 4-3: LVDS Resolution Selection Jumper Settings..........................................................58
Table 5-1: BIOS Navigation Keys................................................................................................74

NANO-QM871 EPIC SBC
Page xv
BIOS Menus
BIOS Menu 1: Main.......................................................................................................................76
BIOS Menu 2: Advanced..............................................................................................................78
BIOS Menu 3: ACPI Settings .......................................................................................................78
BIOS Menu 4: RTC Wake Settings..............................................................................................79
BIOS Menu 5: Trusted Computing..............................................................................................81
BIOS Menu 6: CPU Configuration...............................................................................................82
BIOS Menu 7: SATA Configuration.............................................................................................84
BIOS Menu 8: Intel(R) Rapid Start Technology .........................................................................85
BIOS Menu 9: AMT Configuration...............................................................................................86
BIOS Menu 10: USB Configuration.............................................................................................87
BIOS Menu 11: iWDD H/W Monitor .............................................................................................88
BIOS Menu 12: Smar Fan Mode Configuration..........................................................................89
BIOS Menu 13: F81866 Super IO Configuration........................................................................90
BIOS Menu 14: Serial Port n Configuration Menu.....................................................................90
BIOS Menu 15: F81866 H/W Monitor...........................................................................................93
BIOS Menu 16: Serial Port Console Redirection.......................................................................94
BIOS Menu 17: iEi Feature...........................................................................................................97
BIOS Menu 18: ICP Board............................................................................................................98
BIOS Menu 19: Chipset................................................................................................................99
BIOS Menu 20: System Agent (SA) Configuration................................................................. 100
BIOS Menu 21: Graphics Configuration.................................................................................. 101
BIOS Menu 22: NB PCIe Configuration ................................................................................... 103
BIOS Menu 23: Memory Configuration.................................................................................... 104
BIOS Menu 24: PCH-IO Configuration..................................................................................... 105
BIOS Menu 25: PCI Express Configuration ............................................................................ 106
BIOS Menu 26: Boot.................................................................................................................. 107
BIOS Menu 27: Security............................................................................................................ 109
BIOS Menu 28: Save & Exit.......................................................................................................110
NANO-QM871

NANO-QM871 EPIC SBC
Page 1
Chapter
1
1 Introduction

NANO-QM871 EPIC SBC
Page 2
1.1 Introduction
Figure 1-1: NANO-QM871
The NANO-QM871 is an EPIC SBC with a 4th generation 22nm Intel® mobile Core™
i7/i5/i3 or Celeron® processor and Intel® QM87 Express Chipset. Storage on the board is
handled by two SATA 6Gb/s ports and one PCIe Mini socket for connecting a hard drive,
optical drive or SSD.
The board has three types of graphics outputs that support triple independent display. A
VGA output connects to a VGA monitor. One LVDS connector supports 18/24-bit
dual-channel display. Two HDMI connectors support HDMI 1.4a specification.
Other slots and connectors include PCIe/104 Type 2 slot, RS-232 ports, RS-422/485 port,
Gigabit Ethernet, USB 3.0 ports, USB 2.0 ports, TPM, SMBus and digital I/O.

NANO-QM871 EPIC SBC
Page 3
1.2 Features
Some of the NANO-QM871 motherboard features are listed below:
EPIC form factor
4th generation 22nm Intel® mobile Core™ i7/i5/i3 or Celeron® processor
One 204-pin 1600/1333 MHz DDR3/DDR3L (1.35V) SO-DIMM supported
(system max. 8.0 GB)
Dual GbE
Intel® AMT 9.0 support
Supports triple independent display with dual HDMI+VGA/dual
HDMI+LVDS/HDMI+VGA+LVDS
One PCIe Mini card slot with mSATA support
One PCIe/104 Type 2 slot
Complete I/O with six USB (two USB 3.0, four USB 2.0), two SATA 6Gb/s,
three COM (two RS-232, one RS-422/485) and audio
RoHS compliant

NANO-QM871 EPIC SBC
Page 4
1.3 Connectors
The connectors on the NANO-QM871 are shown in the figure below.
Figure 1-2: Connectors

NANO-QM871 EPIC SBC
Page 5
1.4 Dimensions
The main dimensions of the NANO-QM871 are shown in the diagram below.
Figure 1-3: NANO-QM871 Dimensions (mm)
