IEI Technology KINO-SE-i2 User manual

KINO-SE-i2
Page I
User Manual
KINO-SE-i2
MODEL:
Mini-ITXSBC with AMD®Embedded G-Series SoC with VGA/Dual
HDMI, Dual GbE, Dual PCIe Mini, USB 3.0, SATA6GB/s,
Audio, iRIS-2400 and RoHS
Rev. 1.00 - 27 January, 2015
KINO-SE-i2 CPU Card

KINO-SE-i2
Page II
Revision
Date Version Changes
27 January, 2015 1.00 Initial release

KINO-SE-i2
Page III
Copyright
COPYRIGHT NOTICE
The information in this document is subject to change without prior notice in order to
improve reliability, design and function and does not represent a commitment on the part
of the manufacturer.
In no event will the manufacturer be liable for direct, indirect, special, incidental, or
consequential damages arising out of the use or inability to use the product or
documentation, even if advised of the possibility of such damages.
This document contains proprietary information protected by copyright. All rights are
reserved. No part of this manual may be reproduced by any mechanical, electronic, or
other means in any form without prior written permission of the manufacturer.
TRADEMARKS
All registered trademarks and product names mentioned herein are used for identification
purposes only and may be trademarks and/or registered trademarks of their respective
owners.

KINO-SE-i2
Page IV
Table ofContents
1 INTRODUCTION.......................................................................................................... 1
1.1 INTRODUCTION........................................................................................................... 2
1.2 MODEL VARIATIONS ................................................................................................... 2
1.3 FEATURES................................................................................................................... 3
1.4 CONNECTORS ............................................................................................................. 4
1.5 DIMENSIONS............................................................................................................... 5
1.6 DATA FLOW................................................................................................................ 6
1.7 TECHNICAL SPECIFICATIONS ...................................................................................... 7
2 UNPACKING............................................................................................................... 10
2.1ANTI-STATIC PRECAUTIONS.......................................................................................11
2.2 UNPACKING PRECAUTIONS........................................................................................11
2.3 PACKING LIST........................................................................................................... 12
2.4 OPTIONAL ITEMS...................................................................................................... 13
3 CONNECTORS ........................................................................................................... 14
3.1 PERIPHERAL INTERFACE CONNECTORS..................................................................... 15
3.1.1 KINO-SE-i2 Layout.......................................................................................... 15
3.1.2 Peripheral Interface Connectors ..................................................................... 15
3.1.3 External Interface Panel Connectors............................................................... 17
3.2 INTERNAL PERIPHERAL CONNECTORS...................................................................... 17
3.2.1 AT/ATX Mode Select Switch............................................................................. 17
3.2.2 Battery Connector............................................................................................ 18
3.2.3 Clear CMOS Button......................................................................................... 19
3.2.4 CPU Fan Connector........................................................................................ 20
3.2.5 CPU Power Connector .................................................................................... 21
3.2.6 DDR3 SO-DIMM Slots .................................................................................... 22
3.2.7 Digital I/O Connector...................................................................................... 23
3.2.8 EC Debug Connector....................................................................................... 24
3.2.9 Front Panel Connector .................................................................................... 25
3.2.10 IPMI Slot........................................................................................................ 26

KINO-SE-i2
Page V
3.2.11 Keyboard/Mouse Connector........................................................................... 29
3.2.12 LAN LED Connector...................................................................................... 30
3.2.13 PCIe x4 Slot ................................................................................................... 31
3.2.14 PCIe Mini Card Slot ...................................................................................... 33
3.2.15 RS-232 Serial Port Connector....................................................................... 36
3.2.16 RS-422/485 Serial Port Connector................................................................ 37
3.2.17 SATA 6Gb/s Drive Connector ........................................................................ 37
3.2.18 SATA Power Connector.................................................................................. 38
3.2.19 SD Card Slot .................................................................................................. 39
3.2.20 SMBUS Connector......................................................................................... 40
3.2.21 SPDIF Connector........................................................................................... 41
3.2.22 SPI Flash Connector...................................................................................... 42
3.2.23 System Fan Connector................................................................................... 43
3.2.24 TPM Connector.............................................................................................. 44
3.2.25 USB Connector .............................................................................................. 45
3.3 EXTERNAL PERIPHERAL INTERFACE CONNECTOR PANEL ......................................... 47
3.3.1 Audio Connector.............................................................................................. 47
3.3.2 Ethernet and USB Connectors......................................................................... 48
3.3.3 HDMI Connector ............................................................................................. 49
3.3.4 Power Connector............................................................................................. 50
3.3.5 Serial Port Connector (COM1) ....................................................................... 51
3.3.6 VGA Connector................................................................................................ 51
4 INSTALLATION ......................................................................................................... 53
4.1ANTI-STATIC PRECAUTIONS...................................................................................... 54
4.2 INSTALLATION CONSIDERATIONS.............................................................................. 54
4.2.1 SO-DIMM Installation..................................................................................... 55
4.3 INTERNAL PERIPHERAL DEVICE CONNECTIONS........................................................ 57
4.3.1 SATA Drive Connection ................................................................................... 57
4.3.2 Single RS-232 Cable........................................................................................ 58
4.4 EXTERNAL PERIPHERAL INTERFACE CONNECTION ................................................... 59
4.4.1 Audio Connection............................................................................................. 59
4.4.2 HDMI Display Device Connection.................................................................. 60
4.4.3 LAN Connection............................................................................................... 61
4.4.4 Serial Device Connection ................................................................................ 62

KINO-SE-i2
Page VI
4.4.5 USB Connection............................................................................................... 63
4.4.6 VGA Monitor Connection ................................................................................ 64
5 BIOS.............................................................................................................................. 66
5.1 INTRODUCTION......................................................................................................... 67
5.1.1 Starting Setup................................................................................................... 67
5.1.2 Using Setup...................................................................................................... 67
5.1.3 Getting Help..................................................................................................... 68
5.1.4 Unable to Reboot after Configuration Changes.............................................. 68
5.1.5 BIOS Menu Bar................................................................................................ 68
5.2 MAIN........................................................................................................................ 69
5.3ADVANCED............................................................................................................... 70
5.3.1 ACPI Settings................................................................................................... 70
5.3.2 Trusted Computing........................................................................................... 71
5.3.3 RTC Wake Settings........................................................................................... 72
5.3.4 CPU Configuration.......................................................................................... 74
5.3.5 IDE Configuration ........................................................................................... 75
5.3.6 USB Configuration........................................................................................... 76
5.3.7 F81866 Super IO Configuration...................................................................... 77
5.3.7.1 Serial Port n Configuration....................................................................... 78
5.3.8 F81866 H/W Monitor....................................................................................... 83
5.3.8.1 Smart Fan Mode Configuration................................................................ 84
5.3.9 Serial Port Console Redirection ...................................................................... 85
5.3.9.1 Console Redirection Settings.................................................................... 86
5.4 CHIPSET ................................................................................................................... 89
5.4.1 South Bridge Configuration............................................................................. 89
5.4.2 North Bridge Configuration............................................................................. 91
5.5 BOOT........................................................................................................................ 91
5.6 SECURITY................................................................................................................. 94
5.7 SAVE &EXIT............................................................................................................ 94
5.8 SERVER MGMT......................................................................................................... 96
5.8.1.1 System Event Log..................................................................................... 97
5.8.1.2 BMC network configuration..................................................................... 98
ABIOS MENU OPTIONS............................................................................................. 99

KINO-SE-i2
Page VII
B TERMINOLOGY...................................................................................................... 102
C WATCHDOGTIMER .............................................................................................. 107
D HAZARDOUS MATERIALS DISCLOSURE........................................................110
D.1 HAZARDOUS MATERIAL DISCLOSURE TABLE FOR IPB PRODUCTS CERTIFIED AS
ROHS COMPLIANT UNDER 2002/95/EC WITHOUT MERCURY......................................111

KINO-SE-i2
Page VIII
List of Figures
Figure 1-1: KINO-SE-i2...................................................................................................................2
Figure 1-2: Connectors ..................................................................................................................4
Figure 1-3: Dimensions (mm)........................................................................................................5
Figure 1-4: Data Flow Diagram......................................................................................................6
Figure 3-1: Connector and Jumper Locations...........................................................................15
Figure 3-2: AT/ATX Mode Select Switch Location ....................................................................18
Figure 3-3: Battery Connector Location.....................................................................................19
Figure 3-4: Clear CMOS Button Location...................................................................................20
Figure 3-5: CPU Fan Connector Locations................................................................................21
Figure 3-6: CPU Power Connector Location..............................................................................22
Figure 3-7: DDR3 SO-DIMM Slot Location..................................................................................23
Figure 3-8: Digital I/O Connector Location ................................................................................24
Figure 3-9: EC Debug Connector Location................................................................................25
Figure 3-10: Front Panel Connector Location ...........................................................................26
Figure 3-11: IPMI Slot Location...................................................................................................27
Figure 3-12: Keyboard/Mouse Connector Location..................................................................30
Figure 3-13: LAN LED Connector Location ...............................................................................31
Figure 3-14: PCIe x4 Slot Location .............................................................................................32
Figure 3-15: PCIe Mini Card Slot Location.................................................................................34
Figure 3-16: RS-232 Serial Port Connector Location................................................................36
Figure 3-17: RS-422/485 Connector Location............................................................................37
Figure 3-18: SATA 6Gb/s Drive Connector Location................................................................38
Figure 3-19: SATA Power Connector Location .........................................................................39
Figure 3-20: SD Card Slot Location............................................................................................40
Figure 3-21: SMBus Connector Location...................................................................................41
Figure 3-22: SPDIF Connector Location.....................................................................................42
Figure 3-23: SPI Flash Connector Location...............................................................................43
Figure 3-24: System Fan Connector Locations.........................................................................44
Figure 3-25: TPM Connector Location........................................................................................45
Figure 3-26: USB Connector Locations......................................................................................46
Figure 3-27: External Peripheral Interface Connector..............................................................47

KINO-SE-i2
Page IX
Figure 3-28: Audio Connector.....................................................................................................47
Figure 3-29: LAN Connector........................................................................................................48
Figure 3-30: Serial Port Pinout Locations..................................................................................51
Figure 3-31: VGA Connector .......................................................................................................52
Figure 4-1: SO-DIMM Installation ................................................................................................56
Figure 4-2: SATA Drive Cable Connection.................................................................................57
Figure 4-3: Single RS-232 Cable Installation .............................................................................58
Figure 4-4: Audio Connector.......................................................................................................60
Figure 4-5: HDMI Connection......................................................................................................61
Figure 4-6: LAN Connection........................................................................................................62
Figure 4-7: Serial Device Connector...........................................................................................63
Figure 4-8: USB Connector..........................................................................................................64
Figure 4-9: VGA Connector .........................................................................................................65

KINO-SE-i2
Page X
List of Tables
Table 1-1: KINO-SE-i2 Model Variations.......................................................................................2
Table 1-2: Technical Specifications..............................................................................................9
Table 3-1: Peripheral Interface Connectors...............................................................................17
Table 3-2: Rear Panel Connectors ..............................................................................................17
Table 3-3: AT/ATX Mode Select Switch Settings.......................................................................18
Table 3-4: Battery Connector Pinouts........................................................................................19
Table 3-5: Clear CMOS Button Settings.....................................................................................20
Table 3-6: CPU Fan Connector Pinouts .....................................................................................21
Table 3-7: CPU Power Connector Pinouts.................................................................................22
Table 3-8: Digital I/O Connector Pinouts....................................................................................24
Table 3-9: EC Debug Connector Pinouts ...................................................................................25
Table 3-10: Front Panel Connector Pinouts...............................................................................26
Table 3-11: IPMI Slot Pinouts ......................................................................................................29
Table 3-12: Keyboard/Mouse Connector Pinouts .....................................................................30
Table 3-13: LAN LED Connector Pinouts...................................................................................31
Table 3-14: PCIe x4 Slot Pinouts.................................................................................................33
Table 3-15: PCIe Mini Card Slot Pinouts (M_PCIE1) .................................................................35
Table 3-16: PCIe Mini Card Slot Pinouts (M_PCIE2) .................................................................36
Table 3-17: RS-232 Serial Port Connector Pinouts ...................................................................37
Table 3-18: RS-422/485 Connector Pinouts ...............................................................................37
Table 3-19: SATA Power Connector Pinouts.............................................................................39
Table 3-20: SMBus Connector Pinouts ......................................................................................41
Table 3-21: SPDIF Connector Pinouts........................................................................................42
Table 3-22: SPI Flash Connector Pinouts (SPI1).......................................................................43
Table 3-23: SPI Flash Connector Pinouts (SPI2).......................................................................43
Table 3-24: System Fan Connector Pinouts ..............................................................................44
Table 3-25: TPM Connector Pinouts...........................................................................................45
Table 3-26: USB Connector Pinouts...........................................................................................46
Table 3-27: LAN1_USB2 Connector Pinouts .............................................................................49
Table 3-28: LAN2_USB2 Connector Pinouts .............................................................................49
Table 3-29: HDMI Connector Pinouts .........................................................................................50

KINO-SE-i2
Page XI
Table 3-30: Power Connector Pinouts........................................................................................51
Table 3-31: Serial Port Pinouts....................................................................................................51
Table 3-32: VGA Connector Pinouts...........................................................................................52
Table 5-1: BIOS Navigation Keys................................................................................................68

KINO-SE-i2
Page XII
List ofBIOS Menus
BIOS Menu 1: Main.......................................................................................................................69
BIOS Menu 2: Advanced..............................................................................................................70
BIOS Menu 3: ACPI Configuration..............................................................................................71
BIOS Menu 4: Trusted Computing..............................................................................................72
BIOS Menu 5: RTC Wake Settings ..............................................................................................73
BIOS Menu 6: CPU Configuration...............................................................................................74
BIOS Menu 7: IDE Configuration.................................................................................................75
BIOS Menu 8: USB Configuration...............................................................................................76
BIOS Menu 9: Super IO Configuration........................................................................................77
BIOS Menu 10: Serial Port n Configuration Menu.....................................................................78
BIOS Menu 11: Hardware Health Configuration........................................................................83
BIOS Menu 12: FAN 1 Configuration..........................................................................................84
BIOS Menu 13: Serial Port Console Redirection.......................................................................86
BIOS Menu 14: Console Redirection Settings...........................................................................87
BIOS Menu 15: Chipset................................................................................................................89
BIOS Menu 17: South Bridge Configuration..............................................................................90
BIOS Menu 18: North Bridge Configuration ..............................................................................91
BIOS Menu 19: Boot.....................................................................................................................91
BIOS Menu 20: Security...............................................................................................................94
BIOS Menu 21:Exit........................................................................................................................95
BIOS Menu 21: IDE Configuration...............................................................................................96
BIOS Menu 22: PCH Azalia Configuration Menu.......................................................................97
BIOS Menu 23: PCH Azalia Configuration Menu.......................................................................98

KINO-SE-i2
Page 1
1Introduction
Chapter
1

KINO-SE-i2
Page 2
1.1 Introduction
Figure 1-1: KINO-SE-i2
The KINO-SE-i2 PICO-ITX motherboard is an AMD® G-Series SoC processor platform. It
supports two 1600/1333 MHz DDR3 & DDR3L SO-DIMM modules up to 8.0 GB.
The KINO-SE-i2 includes a VGA connector and two HDMI connectors. Expansion and I/O
include two USB 3.0 connectors on the rear panel, two USB 2.0 connectors on the rear
panel, two USB 2.0 connectors by pin header and two SATA 6Gb/s connectors. Serial
device connectivity is provided by three internal RS-232 connectors, one external RS-232
connector and one internal RS-422/485 connector. Two RJ-45 Ethernet connectors
provide the system with smooth connections to an external LAN.
1.2 Model Variations
The model variations of the KINO-SE-i2 Series are listed below.
ModelNo. SoC
KINO-SE-i2-4241-R10 AMD® 28nm quad core GX-424CC 2.4GHz (25W)
KINO-SE-i2-4121-R10 AMD® 28nm quad core GX-412HC 1.2GHz (7W)
KINO-SE-i2-2121-R10 AMD® 28nm dual core GX-212JC 1.2GHz (6W)
KINO-SE-i2-2091-R10 AMD® 28nm dual core GX-209HA 1.0GHz (9W)
KINO-SE-i2-4111-R10 AMD® 28nm quad core GX-411GA 1.0GHz (15W)
Table 1-1: KINO-SE-i2 Model Variations

KINO-SE-i2
Page 3
1.3 Features
Some of the KINO-SE-i2 motherboard features are listed below:
Mini-ITX form factor with AMD® Embedded G-Series SoC
12V only single voltage design for AT/ATX power
Dual independent display by VGA, dual HDMI
Supporting Dual PCIe Mini card slot with mSATA, wireless card, DOM
capabilities
Support IPMI 2.0 with with iRIS module
IEI One Key Recovery solution allows you to create rapid OS backup and
recovery

KINO-SE-i2
Page 4
1.4 Connectors
The connectors on the KINO-SE-i2 are shown in the figure below.
Figure 1-2: Connectors

KINO-SE-i2
Page 5
1.5 Dimensions
The dimensions of the board are listed below:
Figure 1-3: Dimensions (mm)

KINO-SE-i2
Page 6
1.6 Data Flow
Figure 1-4 shows the data flow between the system chipset, the CPU and other
components installed on the motherboard.
Figure 1-4: Data Flow Diagram

KINO-SE-i2
Page 7
1.7 TechnicalSpecifications
KINO-SE-i2 technical specifications are listed below.
Specification KINO-SE-i2
SoC AMD® Embedded G-Series G-Series SoC
GX-424CC on-board Soc (2.4GHz, quad-core, 2MB cache,
TDP=25W)
GX-412HC on-board Soc (1.2GHz, quad-core, 2MB cache,
TDP=7W) (by request)
GX-212JC on-board Soc (1.2GHz, dual-core, 1MB cache,
TDP=6W) (by request)
GX-209HA on-board Soc (1.0GHz, dual-core, 1MB cache,
TDP=9W) (by request)
GX-411GA on-board Soc (1.0GHz, quad-core, 2MB cache,
TDP=15W)
BIOS UEFI BIOS
Memory Two 204-pin 1600/1333 MHz dual-channel DDR3 & DDR3L
SDRAM unbuffered DIMMs support up to 8GB
Graphics Engine GPU frequency 497MHz for GX-424CC
GPU frequency 300MHz for GX-412HC
GPU frequency 300MHz for GX-212JC
GPU frequency 225MHz for GX-209HA
GPU frequency 300MHz for GX-411GA
Support DX11.1, OpenGL 4.1 and OpenCL1.2
UVD4.2 decode for H.264, MPEG2/4, VC1, MVC
VCE 2.0 encode for H.264, VCE
Display Output 2 x HDMI (up to 3840x2160@60Hz)
1 x VGA (up to 2048x1536@60Hz)
Ethernet LAN1: Intel® I210-AT PCIe controller with NCSI support
LAN2: Intel® I211-AT PCIe controller
Super IO Fintek F81866

KINO-SE-i2
Page 8
Specification KINO-SE-i2
I/O Interfaces 1 x RS-422/485
4 x RS-232 (1 on rear I/O, 3 by pin header)
1 x SD card
2 x SATA 6Gb/s with SATA power connector
2 x USB 3.0 (2 on rear I/O)
4 x USB 2.0 (2 on rear I/O, 2 by pin header)
1 x mSATA (colay SATA port 2)
1 x 6-pin wafer for PS/2 KB/MS
iRIS Remote Management
Module
1 x iRIS-2400 slot
SMBus 2 x 4-pin (1x4) wafer
Audio Realtek AL892 HD Audio codec
1 x S/PID by 4-pin (1x4) header for digital audio
1 x Line-out / Mic-in audio jack on rear IO
Front Panel 1 x Front panel
(Power LED, HDD LED, Power Button, Reset Button)
LAN LED 2 x 2-pin headers for LAN1 Link LED, LAN2 Link LED
Expansion 1 x Half-size PCIe Mini card slot
1 x PCIe x4 slot
Digital I/O 8-bit digital I/O (4-bit input / 4-bit output)
Fan Connector 1 x 4-pin system fan connector
Watchdog Timer Software programmable supports 1~255 sec. system reset
Environmentaland Power Specifications
Power Supply 12V only DC input
1 x Internal 4-pin (2x2) power connector
1 x External DC jack (4-pin DIN)
Support AT/ATX mode
