IEI Technology PICO-8522 User manual

1
Half-size PCI CPU Card supports Intel® Pentium® M/ Celeron® M with
a 400MHz FSB with VGA/LVDS, Dual GbE, and USB 2.0
PICO-8522
Quick Installation Guide
Version 2.0
Dec.09, 2008
Package List
PICO-8522 package includes the following items:
1 x PICO-8522 Single Board Computer
1 x Mini Jumper Pack
1 x ATA flat cable
1 x PS/2 KB/MS Y cable
1 x Dual RS-232 cable with bracket
1 x SATA cable
1 x Dual ports USB cable with bracket
1 x Utility CD
1 x QIG (Quick Installation Guide)
©2006 Copyright by IEI Technology corp.
All rights reserved.

2
Specifications
CPU
Socket 479 Intel® Pentium® M/ Celeron® M with 400 MHz FSB
System Chipset: Intel® 852GM + ICH4M
BIOS: AMI BIOS
System memory: 1x 184-pin DIMM DDR 266/200MHz up to 1GB
Ethernet

Dual PCI interface Realtek RTL8110SC GbE
controllers
I/O
2 x RS-232
5 x USB 2.0 (1 on bracket, 4 on board)
1 x 40 pin IDE
2 x SATA
1 x FDD
1 x LPT
1 x PS/2 KB/MS
1 x 6-pin header for KB/MS
Expansion (By Backplane Support): 4 PCI Master
Digital I/O: 8 bit digital l/O, 4 input/ 4 output
Super I/O: Winbond W83627EHG
Audio: 5.1 Channel Audio Kit with Realtek ALC655 AC’97 Codec
Display
CRT integrated in Intel® 852GM
LVDS: Dual-Channel 18/24-bit LVDS
WDT: Software programmable supports 1-255 sec. System reset
Power supply: 5V/12V, AT/ATX support
Power Consumption
[email protected], [email protected] (Celeron® M 1GZ/DDR400 1G);
[email protected],[email protected](Pentium® M 1.6G/DDR400 1G);
Temperature: Operation:0~60°C(32~140°F)
Humidity: Operation:5%~95% non-condensing
Dimension: 185mm x 122mm
Weight: GW: 1.0Kg

3
Ordering Information
PICO-8522-R20
Half-size PCI CPU Card supports Intel® Pentium® M/ Celeron® M with
a 400MHz FSB with VGA/LVDS, Dual GbE, and USB 2.0
PICO-8522-1GZ-R20
Half-size PCI CPU Card supports Intel® Celeron® M 1GHz/ zero cache
with a 400MHz FSB with VGA/LVDS, Dual GbE, and USB 2.0
PICO-8522-600-R20
Half-size PCI CPU Card supports Intel® Celeron® M 600MHz/ 512K
cache with a 400MHz FSB with VGA/LVDS, Dual GbE, and USB 2.0
AC-KIT08R-R10: 5.1 Channel Audio Kit with Realtek ALC655 AC’97 Codec
CF-479B-RS: CPU cooler
32100-088600-RS: SATA power cable
19800-000049-RS: LPT cable
32200-000017-RS: FDD cable

4
Jumpers setting and Connectors
LABEL FUNCTION
J_CMOS1 Clear CMOS setup jumper
J_VLVDS1 LVDS Voltage Selection jumper
J_CF1 CF Card Master/Slave jumper
JP2 LVDS1 Panel Resolution Selection jumper
KB_MS1 PS/2 MOUSE & KEYBOARD Connector
USB_C4 USB Port Connector
LAN1
LAN2 LAN RJ-45 Connectors
VGA1 VGA 15-pin Female Connector
LPT1 Parallel Port Connector
IDE1 IDE Connector
CF1 CF Card Slot
FDD1 FDC Connector
COM1
COM2 Internal Serial Port Connectors
USB01
USB23 Internal 4 Port USB Connectors
CPU_FAN1
CPU Fan Connector
ATXCTL1 
DIO1 Digital I/O Connector
F_PANEL1
PWR & RST Buttons 
KB_MS2 External 6-pin Header Keyboard/ Mouse Connector
J_AUDIO1 AC’97 Connector
INVERTER1
Panel Backlight +12V Power Source
LVDS1 Dual Link LVDS
SATA1
SATA2 Serial ATA Connectors
BAT1 Battery connector
DIMM1 DDR2 slot

5
J_CMOS1 : Clear CMOS Setup
J_CMOS1
DESCRIPTION
1-2
(Default)
Keep CMOS Setup
(Normal Operation)
2-3 Clear CMOS Setup
J_VLVDS1 :LVDS Voltage Selection
J_VLVDS
DESCRIPTION
1-2
(Default)
Set The Voltage Level Of
Panel To 3.3V
2-3 Set The Voltage Level Of
Panel To 5V
J
P
2
:
LVDS Panel Resolution Selection
JP2 DESCRIPTION
Open 640 X 480 (18-bit)
1-2
(Default) 800 X 600 (18-bit)
3-4 1024 X 768 (18-bit)
1-2 & 3-4 1280 X 1024 (48-bit)
5-6 1400X1050 (36-bit)
1-2 & 5-6 1400X1050 (48-bit)
3-4 & 5-6 1600X1200 (48-bit)
1-2 & 3-4 & 5-6
1440 X 900 (18-bit)
7-8 1440 X 900 (48-bit)
1-2 & 7-8 1280 X 800 (18-bit)
J
_
CF1
:
configure CF Card type
J_CF1 DESCRIPTION
Open
(Default) Slave
Short 1-2
Master
ATXCTL1:
BP to Mainboard Connector
PIN
DESCRIPTION
1 GND
2 PS_ON#
3 5VSB
ATXCTL1
BP to Mainboard Connector
Power
DESCRIPTION
AT
(Default) Short 1-2.
ATX Connect "PS_ON# &
5VSB Cable".

6
CPU_FAN1 : CPU Fan Connector
PIN NO.
DESCRIPTION
1 GND
2 +12V
3 Sense
4 Rotation Signal
DIO1 : Digital Input / Output Connector
PIN NO.
DESCRIPTION
PIN NO.
DESCRIPTION
1 Ground 2 +5V
3 Output 3 4 Output 2
5 Output 1 6 Output 0
7 Input 3 8 Input 2
9 Input 1 10 Input 0
F_PANEL1
:
PWR & RST Buttons
and Indicators
panel
PIN
DESCRIPTION
PIN
DESCRIPTION
1 PWR_BTN+ 2
PWR_LED+
PWRBTN
3 PWR_BTN- 4
PWR_LED- Power
LED
5 HDD_LED+ 6
RESET+HDD
LED 7 HDD_LED- 8
RESET- RESET
J_AUDIO1: AC’97 Connector
PIN NO.
DESCRIPTION
PIN NO.
DESCRIPTION
1 SYNC 2 BITCLK
3 SDOUT 4 PCBEEP
5 SDIN 6 RST#
7 +5V 8 GND
9 +12V
COM1, COM2: Internal Serial Port Connector
PIN NO.
DESCRIPTION PIN NO.
DESCRIPTION
1 DCD# 6 DSR#
2 RXD 7 RTS#
3 TXD 8 CTS#
4 DTR# 9 RI#
5 GND 10 NC

7
INVERTER1 : 5-pin Header Inverter
Connector
PIN NO.
DESCRIPTION
1 LCD Adjust
2 GROUND
3 +12V
4 GROUND
5 BACKLIGHT ENABLE
USB01

 

USB23: Internal USB Connector
USB1

 

USB2
PIN
DESCRIPTION
PIN
DESCRIPTION
1 +5V 2 GROUND
3 DATA- 4 DATA+
5 DATA+ 6 DATA-
7 GROUND 8 +5V
LVDS1: LVDS
Connector
PIN NO.
DESCRIPTION
PIN NO.
DESCRIPTION
1 GND1 2 GND2
3 A_Y0 4 A_Y0#
5 A_Y1 6 A_Y1#
7 A_Y2 8 A_Y2#
9 A_CK 10 A_CK#
11 A_Y3 12 A_Y3#
13 GND3 14 GND4
15 B_Y0 16 B_Y0#
17 B_Y1 18 B_Y1#
19 B_Y2 20 B_Y2#
21 B_CK 22 B_CK#
23 B_Y3 24 B_Y3#
25 GND5 26 GND6
27 VCC1 28 VCC2
29 VCC3 30 VCC4

8
BAT1 :
Battery Connector
PIN
DESCRIPTION
1 BAT+ (+3.3V)
2 BAT- (GND)
KB_MS2:
6-pin Header KB/MS Connector
PIN
DESCRIPTION
1
VCC(+5V)
2
MOUSE DATA
3
MOUSE CLOCK
4
KB DATA
5
KB CLOCK
6
GND
LPT
1
: Parallel Port Connector
PIN
DESCRIPTION PIN
DESCRIPTION
1 RSTROBE# 14
AUTO FORM FEED #
2 DATA0 15
ERROR#
3 DATA1 16
INITIALIZE#
4 DATA2 17
PRINTER SELECT IN#
5 DATA3 18
GND
6 DATA4 19
GND
7 DATA5 20
GND
8 DATA6 21
GND
9 DATA7 22
GND
10
ACKNOWLEDGE# 23
GND
11
BUSY 24
GND
12
PAPER EMPTY 25
GND
13
PRINTER SELECT 26
N/C

9
Board Layout: Jumper and Connector Locations

10
