IEI Technology ICE-BT-T10 User manual

COM Express Rev 2.1 Mini Size Type 6 Module, Intel® 4th Generation
Atom™ Processor, VGA, DDI, GbE, SATA 3Gb/s, USB and Audio,
-40°C to +85°C and RoHS
ICE-BT-T10
Quick Installation
Guide
Version 1.0
Jan 12, 2015.
Package List
ICE-BT-T10 package includes the following items:
1 x ICE-BT-T10 single board computer
1 x Heatsink
1 x QIG (Quick Installation Guide)
1 x Utility CD
©2006 Copyright by IEI Integration
corp.
All rights reserved.
1
COM Express Rev 2.1 Mini Size Type 6 Module, Intel® 4th Generation
Atom™ Processor, VGA, DDI, GbE, SATA 3Gb/s, USB and Audio,
Guide
corp.

2
Specifications
CPU:
Intel® Atom™ E3845 on-board SoC (1.91GHz, quad-core,
2MB cache, TDP=10W)
Intel® Atom™ E3827 on-board SoC (1.75GHz, dual-core, 1MB
cache, TDP=8W)
Intel® Atom™ E3826 on-board SoC (1.46GHz, dual-core, 1MB
cache, TDP=7W)
Intel® Atom™ E3825 on-board SoC (1.33GHz, dual-core, 1MB
cache, TDP=6W)
Intel® Atom™ E3815 on-board SoC (1.46GHz, single-core,
512KB cache, TDP=5W)
Intel® Celeron® J1900 on-board SoC (2GHz, quad-core, 2MB
cache, TDP=10W)
Intel® Celeron® N2930 on-board SoC (1.83GHz, quad-core,
2MB cache, TDP=7.5W)
Intel® Celeron® N2807 on-board SoC (1.58GHz, dual-core,
2MB cache, TDP=4.3W)
BIOS:
UEFI BIOS
Memory

2GB soldered down 1066/1333 MHz DDR3L memory
(4GB optional)
Graphics Engine:
Intel® HD Graphics Gen 7 Engines with 4 execution units,
supports DX11.1, OpenGL 4.2 and OpenCL1.2
Display Output:
1 x VGA (2560x1600) (via reserved pin)
1 x DDI (DP/HDMI, max. resolution 2560x1600/1920x1080)
1 x eDP
Ethernet: Intel® I210 GbE Ethernet
Embedded Controller: IT8587VG-FX
Storage:
2 x SATA 3Gb/s signal to baseboard
Optional soldered down 4GB SSD (SATA port 1)

3
I/O Interface:
4 x USB 2.0 signal to baseboard
1 x USB 3.0 signal to baseboard
Audio: High definition audio interface to baseboard
GPIO: Yes, to baseboard
SMBus: Yes, to baseboard
I2C: Yes, to baseboard
LPC: Yes, to baseboard
SDIO: Yes, to baseboard
SPI: Yes, to baseboard
Internal Storage:
The device shall have the capacity of at least 2 kbits, and shall
have three address inputs. Suitable devices include the Atmel
AT24C32C, ST M24C32 and other compatible devices.
Serial Port:
2 serial ports to baseboard (TX & RX from EC )
Expansion: 3 x PCIe x1 signal to baseboard
Watchdog Timer:
Software programmable supports 1~255 sec. system reset
(from EC)
Power Consumption:
+12V@0.43A, Vcore_12V@0.9 A (Intel® Atom™ E3845 CPU,
2GB 1333 MHz DDR3L memory)
Operating Temperature:
-20°C ~ 60°C
Storage Temperature:
-30°C ~ 70°C
Operation Humidity: 5% ~ 95%, non-condensing
Dimensions: 84 mm x 55 mm (mini size)
Weight(GW/ NW): 300g / 150g

4
Ordering Information
ICE-BT-T10-E38451-R10:
COM Express Basic Type 10 module with Intel® Atom™ quad-
core processor E3845 (10W), VGA, DDI, GbE, SATA, USB 3.0
and HD Audio, RoHS
ICE-BT-T10-E38251-R10:
COM Express Basic Type 10 module with Intel® Atom™ dual-
core processor E3825 (6W), VGA, DDI, GbE, SATA, USB 3.0
and HD Audio, RoHS
ICE-BT-T10-E38151-R10:
COM Express Basic Type 10 module with Intel® Atom™ single-
core processor E3815 (5W), VGA, DDI, GbE, SATA, USB 3.0
and HD Audio, RoHS
ICE-BT-T10-E38451W2-R10:
COM Express Basic Type 10 module with Intel® Atom™ quad-
core processor E3845 (10W), VGA, DDI, GbE, SATA, USB 3.0
and HD Audio, -40°C ~ 85°C and RoHS
ICE-BT-T10-E38251W2-R10:
COM Express Basic Type 10 module with Intel® Atom™ dual-
core processor E3825 (6W), VGA, DDI, GbE, SATA, USB 3.0
and HD Audio, -40°C ~ 85°C and RoHS

5
ICE-BT-T10-E38271 / E38261-R10:
COM Express Basic Type 10 module with Intel® Atom™ processor
E3827 (8W) / E3826 (7W), VGA, DDI, GbE, SATA, USB 3.0 and HD
Audio, RoHS (by request MOQ: 100pcs/lot)
ICE-BT-T10-J19001 / N29301/N28071-R10:
COM Express Basic Type 10 module with Intel® Celeron® processor
J1900 (10W) / N2930 (7.5W) / N2807 (4.3W), VGA, DDI, GbE, SATA,
USB 3.0 and HD Audio, RoHS (by request MOQ: 100pcs/lot)
ICE-BT-T10-E38271W2 / E38261W2/ E38151W2-R10:
COM Express Basic Type 10 module with Intel® Atom™ processor
E3827 (8W) / E3826 (7W) / E3815 (5W), VGA, DDI, GbE, SATA,
USB 3.0 and HD Audio, -40°C ~ 85°C and RoHS (by request MOQ:
100pcs/lot)
ICE-DB-T10-R10:
Baseboard for COM Express Type 10 Module COM.0 Rev. 2.1,
supports PICMG EAPI R1.0

6
Connector
COM Express Connector AB1 : COM Express Connector AB
Pin DESCRIPTION Pin DESCRIPTION
A1 GND B1 GND15
A2 GBE0_MDI3- B2 GBE0_ACT#
A3 GBE0_MDI3+ B3 LPC_FRAME#
A4 GBE0_LINK100# B4 LPC_AD0
A5 GBE0_LINK1000#
B5 LPC_AD1
A6 GBE0_MDI2- B6 LPC_AD2
A7 GBE0_MDI2+ B7 LPC_AD3
A8 GBE0_LINK# B8 RSVD
A9 GBE0_MDI1- B9 RSVD
A10
GBE0_MDI1+ B10
LPC_CLK
A11
GND1 B11
GND16
A12
GBE0_MDI0- B12
PWRBTN#
A13
GBE0_MDI0+ B13
SMB_CK
A14
GBE0_CTREF B14
SMB_DAT
A15
SUS_S3# B15
SMB_ALERT#
A16
SATA0_TX+ B16
SATA1_TX+
A17
SATA0_TX- B17
SATA1_TX-
A18
SUS_S4# B18
SUS_STAT#
A19
SATA0_RX+ B19
SATA1_RX+
A20
SATA0_RX- B20
SATA1_RX-
A21
GND2 B21
GND17
A22
USB_SSRX0- B22
USB_SSTX0-
A23
USB_SSRX0+ B23
USB_SSTX0-
A24
RSVD B24
RSVD
A25
RSVD B25
RSVD
A26
RSVD B26
RSVD
A27
BATLOW# B27
WDT
A28
ATA_ACT# B28
RSVD
A29
AC_SYNC B29
AC_SDIN1
A30
AC_RST# B30
AC_SDIN0
A31
GND3 B31
GND18
A32
AC_BITCLK B32
SPKR
A33
AC_SDOUT B33
I2C_CK
A34
BIOS_DISABLE# B34
I2C_DAT

7
A35 RSVD B35
RSVD
A36
RSVD B36
RSVD
A37
RSVD B37
RSVD
A38
RSVD B38
RSVD
A39
RSVD B39
RSVD
A40
RSVD B40
RSVD
A41
GND4 B41
GND
A42
USB2- B42
USB3-
A43
USB2+ B43
USB3+
A44
USB_2_3_OC# B44
USB_0_1_OC#
A45
USB0- B45
USB1-
A46
USB0+ B46
USB1+
A47
VCC_RTC B47
RSVD
A48
RSVD B48
RSVD
A49
RSVD B49
SYS_RESET#
A50
LPC_SERIRQ B50
CB_RESET#
A51
GND5 B51
GND20
A52
VGA_HSYNC B52
RSVD
A53
VGA_VSYNC B53
VGA_RED
A54
GPI0 B54
GPO1
A55
VGA_I2C_CK B55 VGA_GRN
A56
VGA_I2C_DAT B56
VGA_BLU
A57
GND6 B57
GPO2
A58
RSVD B58
RSVD
A59
RSVD B59
RSVD
A60
GND7 B60
GND
A61
PCIE_TX2+ B61
PCIE_RX2+
A62
PCIE_TX2- B62
PCIE_RX2-
A63
GPI1 B63
GPO3
A64
PCIE_TX1+ B64
PCIE_RX1+
A65
PCIE_TX1- B65
PCIE_RX1-
A66
GND8 B66
WAKE0#
A67
GPI2 B67
RSVD
A68
PCIE_TX0+ B68
PCIE_RX0+
A69
PCIE_TX0- B69
PCIE_RX0-
A70
GND9 B70
GND22
A71
DDI0_TXP2(eDP) B71
DDI1_TXP0
A72
DDI0_TXN2(eDP) B72
DDI1_TXN0
A73
DDI0_TXP1(eDP) B73
DDI1_TXP1

8
A74
DDI0_TXN1(eDP) B74
DDI1_TXN1
A75
DDI0_TXP0(eDP) B75
DDI1_TXP0
A76
DDI0_TXN0(eDP) B76
DDI1_TXN0
A77
DDI0_ENVDD(eDP)
B77
RSVD
A78
RSVD B78
RSVD
A79
RSVD B79
DDI0_ENBKL
A80
GND10 B80
GND23
A81
DDI0_TXP3(eDP) B81
DDI1_TXP3
A82
DDI0_TXN3(eDP) B82
DDI1_TXN3
A83
DDI0_AUXP(eDP) B83
DDI0_PWM(eDP)
A84
DDI0_AUXN(eDP) B84
VCC5SBY
A85
GPI3 B85
VCC5SBY
A86
RSVD B86
VCC5SBY
A87
eDP_HPD B87
VCC5SBY
A88
PCIE0_CK_REF+ B88
BIOS_DIS1#
A89
PCIE0_CK_REF- B89
DDI0_HPD
A90
GND11 B90
GND24
A91
SPI_VCC B91
RSVD
A92
SPI_MISO B92
RSVD
A93
GPO0 B93
RSVD
A94
SPI_CLK B94
RSVD
A95
SPI_MOSI B95
DDI1_DDC_AUX_SEL
A96
RSVD B96
RSVD
A97
TYPE10# B97
SPI_CS#
A98
RS1_TX B98
DDI1_CTRLCLK_AUXP
A99
RS1_RX B99
DDI1_CTRLDATA_AUXN
A100
GND13 B100
GND25
A101
RS2_TX B101
FAN_PWMOUT
A102
RS2_RX B102
FAN_TACHIN
A103
LID# B103
SLEEP#
A104
VCC_12V B104
VCC_12V
A105
VCC_12V B105
VCC_12V
A106
VCC_12V B106
VCC_12V
A107
VCC_12V B107
VCC_12V
A108
VCC_12V B108
VCC_12V
A109
VCC_12V B109
VCC_12V
A110
GND14 B110
GND26

9
Board Layout: Jumper and Connector Locations
(Unit: mm)
