IFB MAXIDRY 550 User manual

IFB Industries Limited, Plot No. IND - 5, Sector - 1, East Calcutta Township, Kolkatta - 700 078
Visit us at www.ifbappliances.com
ALSO FROM IFB
OPERATING MANUAL
Maxidry 550 / Easydry 550
MICROWAVE OVEN
CAPACITY - 17 to 30 LITERS
DISHWASHER
CAPACITY - 12 PLACE SETTING
1860 425 5678 -
3900 4321 -
BSNL & MTNL Callers
Other Callers
USE ONLY GENUINE IFB SPARES & ACCESSORIES
* Company shall not be responsible for defects arising
due to usage of spurious parts and accessories

3
Dear Customer,
Congralution, you are now the proud owner of
international range of tumble dry clothes dryer from
IFB
Your clothes dryer, is truely going to be your freedom
machine. It requires just 30 seconds of your time in
loading the fabrics and setting the time. Thereafter,
you are totally free to do what you please. No more
hassles of pin drying your clothes outside anymore. No
more wet clothes nor the fear of your clothes being blown
away.
This clothes dryer is modelled on the unique
‘Tumble Dry’ concept for superior fabric care and
100% clothes drying. What more, its unique” reversible”
tumble actions render your clothes totally wrinkle free.
As you read this manual you will understand what
this clothes dryer can do for you.
For any futher information, please contact your
nearest dealers or IFB service Centre.

528

27
MODEL : MAXIDRY 550 / EASYDRY 550 SR. NO. CD 550A/CD550B
DEALER’S NAME :
CUSTOMER’S NAME :
ADDRESS :
PIN CODE :
TEL. NO. (Resi.) (Off.)
E-MAIL :
MOTOR SR. NO. :
DATE OF PURCHASE :
MODEL : MAXIDRY 550 / EASYDRY 550 SR. NO. CD 550A/CD550B
DEALER’S NAME :
CUSTOMER’S NAME :
ADDRESS :
PIN CODE :
TEL. NO. (Resi.) (Off.)
E-MAIL :
MOTOR SR. NO. :
DATE OF PURCHASE :
SERVICE STATION COPY
6
MAXIDRY 550
Programme
Selector Knob
Reversible badge
Reversible badge
Safety Reset
Switch
Door
Switch
Lint Filter
& Filter Guard
Porthole
door
Special Powder
Coated Steel
Cabinet
Adjustable feet
for Levelling
(other mounting
options ref page
no.9,10)
Stainless Steel
Drum
Maxidry 550
Maxidry 550
EASYDRY 550
Programme
Selector Knob
Reversible badge
Reversible badge
Safety Reset
Switch
Door
Switch
Lint Filter
& Filter Guard
Porthole
door
Special Powder
Coated Steel
Cabinet
Adjustable feet
for Levelling
(other mounting
options ref page
no. 9, 10)
Powder Coated
Drum
Easydry 550
Easydry 550

TRANSIT TAPE
726
220-240 V Single Phase, 50 Hz

258
Bracket
Washers
Screws
Adjustable Legs

924
( See page 10 &25)

2310
MOUNTING OF VENT KIT
Replace the existing exhaust air director on the back of dryer
with the adapter. Mount vent kit in sideways or upward position
on the back of dryer using the same fasteners (Fig.-4). Direct
other end of hose outside the window.
Fig -4
A vent kit is supplied along with accessories which consist of
adapter - A, hose - B, and two connectors - C (Fig -1)
Fig -1
Assemble connectors on both ends of hose by rotating
clockwise direction. (Fig. 2)
Fig -2
Insert one end of hose assembly into the adapter slot and
lock it (Fig. - 3)
Fig -3

1122

12 21
qThis dryer has been designed for domestic use of drying clothes and garments. It
should not be used for any other purpose.
This appliance is not intended for use by persons (Including children’s) with reduced
physical, sensory or mental capabilities or Lack of Experience and Knowledge, unless
they have given supervision or instruction concerning use of the appliance by person
responsible for their safety.
Items that have ben soiled with substances such as cooking oil, acetone, alcohol,
petrol, kerosene, spot removers, turpentine, waxes and wax removers should be
washed in hot water with an extra amount of detergent before being dried in the
tumble dryer.
Items such as foam rubber (latex foam), shower caps, waterproof textiles, rubber
backed articles and cloths or pillows fitted with foam rubber pads should not be dried
in the tumble dryer.
Fabrics softness, or similar products, should be used as specified by the fabric softener
instructions.
Never stop a tumble dryer before the end of the drying cycle unless all items
are quickly removed and spread out so that the heat is dissipated.
The appliance must not be installed behind a lockable door, a sliding door or a door
with a hinge on the opposite side to that of the tumble dryer.
“AIRING” : The final part of the tumble dryer cycle occurs without heat ( cool down ) to
ensure that the items are left at a temperature that ensures that the items will not be
damaged.
q
q
q
q
q
q
Warning :
Take these precautions for safe efficient operation
of your dryer.
1. “Read the Instructions “
2. Check that electrical line can take the rquired
load.
3. Connect to a 220V, 50 Hz single phase AC
supply.
4. Appliance must be earthed properly before
operation. This can be done by using a 3 pin
plug and properly earthed socket of 15 amp.
with a 12 amp. fuse.
5. No double adaptors or extension cords to be
used.
6. Make sure the lint filter and filter guard are
properly fitted. ( Refer page 19 )

COTTONS CupboardDry 140 - 160min
IronDry 120 - 140min
RefreshCycle 20min
SYNTHETICS CupboardDry 65 - 75min
IronDry 40- 50min
MIXEDLOAD Cupboard Dry 110 - 120 min
IronDry 80 - 90min
20 13
Maxidry 550 Easydry 550
Maxidry 550
Maxidry 550
Similarly, the “anticrease” badge can be reversed.

1914
Normal
Easy
ANTICREASE

1518
A

16
The above indicated value are under standard test conditions only.
Normal
Normal
Normal
Normal
Normal
Easy
Easy
Easy
Easy
Easy
Easy
Easy
REFRESH
Refresh Cycle
IRON DRY CUPBOARD DRY
