Midea FP-91LFD070GMTM-N User manual

Clothes Dryer
20140107
Customer Care
(02) 863-55-22
Landline:
[phone]
Mobile:
Toll free: 1-800-10-863-5522
• Monday - Sunday / 8:00am - 8:00pm
A quality product of
Before using this product, please read this manual carefully and keep it for future reference.

Safety information
1) This appliance is not intended for use by persons (including children) with
reduced physical, sensory or mental capabilities, and those who lack knowledge
and experience unless they have been given supervision or instruction concerning
use of the appliance, by a person responsible for their safety.
2) Children should be supervised to ensure that they do not play with the
appliance.
3) This dryer is not to be used if industrial chemicals were used with washing
the clothes.
4) Clean the filter frequently.
5) Lint must not to be allowed to accumulate in the drum.
6) Adequate ventilation has to be provided to avoid the back flow of gases into
the room.
7) Do not dry unwashed items in the dryer.
8) Items that have been contaminated with substances such as cooking oil, acetone,
alcohol, petrol, kerosene, spot removers, turpentine, waxes and wax removers
should be washed in hot water with a extra amount of detergent before being
dried in the tumble dryer.
9) Items such as foam rubber (latex form), shower caps, waterproof textiles,
rubber backed articles and clothes or pillows fitted with foam rubber pads
should not be dried in this product.
10) Fabric softeners, or similar products, should be used as specified by the fabric
softener instructions.
11) The final part of a dryer cycle occurs without heat (cool down cycle) to
ensure that items are left at a temperature the ensures that the items will not
be damaged.
12) The exhaust air must not be discharged into a vent which is used for
exhausting fumes from appliances that burn gas or other fuels.
13) The appliance must not be installed behind a lockable door, a sliding door or
a door with a hinge on the opposite side to that of the dryer. This is to
make sure that a full opening of the dryer door is not restricted.
Safety information..................................................................................
Installation .............................................................................................
Part name.............................................................................................
Notes before use.................................................................................
Simple installation.................................................................................
Control panel..........................................................................................
Operation................................................................................................
Drying clothes instructions.....................................................................
Cleaning and routine maintenance.......................................................
Safety reset.............................................................................................
Precautions.............................................................................................
Technical specifications........................................................................
1
4
4
4
5
6
7
7
9
10
11
12
Table of Contents

15) Do not lay the appliance on any side, except on its bottom, during use and
maintenance.
16) Remove all objects from pockets especially lighters and matches.
17) Carpets must not obstruct the ventilation holes at the base of this appliance
(if applicable).
19) This appliance is for indoor use only.
18) If power cord is damaged, only the manufacturer, service agent or qualified
person should repair it.
14) Items that have oil on it can ignite spontaneously, especially when exposed to
heat sources such as that in a clothes dryer. When the items become warm,
oxidation occurs in the oil, creating heat. If the heat cannot escape, the items
can become hot enough to catch fire. Piling, stocking, or storing items with oil
on it can prevent heat from escaping and this creates a fire hazard.
Install or store in places not exposed to
water and the weather, which can cause
permanent damage to the unit and
invalidate the warranty.
Keep areas around the exhaust openings
and adjacent surrounding areas free
from the accumulation of lint, dust and
dirt. An obstructed port might reduce
the airflow.
Thoroughly spin the laundry in a washing
machine, before putting it in the dryer.
High spin speed can a reduce the drying
time and save energy consumption.
Do not wash or dry articles that have been
cleaned in, washed in, soaked in or spotted
with combustible or explosive substances
(such as wax,oil,paint,gasoline,degreasers,
dry-cleaning solvent, kerosene, etc.).
Never attempt to operate this appliance
if it is damaged, malfunctioning, partially
disassembled, or has missing or broken
parts, including a damaged cord or plug.
Do not allow children to climb on or go in
the appliance. Close supervision of children
is necessary when the appliance is used
near children.
Do not use the machine when your
feet or hands are wet with water.
Do not store plastic, paper or clothing that
may burn or melt on top of the dryer during
operation.
Do not dry articles containing rubber,
plastic or similar materials such as
padded bras, tennis shoes, boots, bath
mats, rugs, bibs, baby pants,raincoats,
plastic bags or pillows that may melt or
burn. Some rubber materials, when heated,
can under certain circustances produce fire
through spontaneous combustion.
The exhaust air must not be discharged
into a flue which is used for exhausting
fumes from an appliance an appliance
that burn gas or other fuels.
The door can be opened only after the
program of the dryer is completed. Do
not open the door before the program
is finished to avoid the skin from being
scalded by hot steam or the overheated
dryer.
Safety information Safety Information
Precautions
Make sure that combustible sprays are
placed far from the dryer when it is in
operation. If there is a gas leak, do not
touch the plug or the Start/Pause button.

1. Top board
2. Control panel
3. Door
4. Front panel 5. Side panel
6. Filter
7. Flexible duct
8. Power plug
9. Switch
10. Drum
• The dryer uses alternative current with a rated voltage and frequency. When
the voltage fluctuates between 6% of the rated voltage, the dryer can work normally.
• Connect the power plug to a socket that is properly installed and earthed.
• Power plug must match the socket and NEVER USE PLUG ADAPTORS!
• Do not use extension cords.
• Do not connect or pull the plug, with wet hands.
• When connectiong and pulling the plug, hold the plug tightly and then pull it out.
Do not pull the power cord itself.
Step 1:
Dryer should be placed in a ventilated area with not
less than 10 cm distance from the wall. If placed in a room
such as bathroom, it is suggested that there are no obstacles
within 1.5m infront of the dryer.
Step 2: Horizontal Adjustment
Tie a heavy object on a string and hang it in front and
at the two sides of the dryer. Refer to the figures below.
If A=A and B=B, this means that the dryer is already level.
Note:
It the installation of the dryer is not level, the
unbalance sensor will work and the dryer will
stop working at times.
Notes when installing:
• Do not install the dryer in open air or places that are open to rain.
• Do not place the back of the dryer near curtains.
• Do not place the dryer near gas or flammable substances.
Step 3: Flexible duct installation
• Connect one end of the flexible duct (with spiral thread)
to the vent at the back of the dryer. Rotate the duct until
it is tightly secure in place.
• The other end of the flexible duct will be extended toward the outdoor area.
Refer to the following illustrations for the proper installation method.
Installation Simple installation
Installation
Notes before use
Power source and grounding
Notes
Part name
Please take note of the following safety advice:
1. For home electrical wiring that is buried underground, make sure that these are
not in contact with gas pipes and water pipes and are distinguishable as electrical
in nature.
2. Use a socket with current rating of 10 A and is compliant to national electrical
standards.
The socket and the ground wire must be installed by an electician to prevent
incorrect installation or socket selection and to guarantee the electrical safety.
The power cord of the dryer employs a Y connection. If the supply cord is
damaged, it must be replaced by the manufacturer, its service agent or similar
qualified persons in order to avoid hazards.
Heavy object

1. Rotate the program knob clockwise to select the desired program.
2. Press "Heat Intensity" button to select the heat level.
3. Press "Start" button to start the dry cycle.
140-155min
110-130min
110-120min
85-105min
100-120min
80-100min
110-140min
90-100min
The following are instructions for operating your new dryer. Refer to specific sections
of this manual, for more detailed information.
Program knob
Heat Intensity (Max/Mid)
Start
Ironing not intended
Ironing not intended
Ironing not intended
Ironing not intended
Ironing intended
Ironing intended
Ironing intended
Ironing intended
6.5kg
3kg
3.5kg
2.5kg
Mid
Max
Max
Mid
Cotton
Cotton fiber
Fiber
Wool These are not commonly dried in this appliance. Examples are
sweaters, bicycle covers, raincoats, etc.
Operation
Control Panel
7
Reference Dry Weight of Clothes
Dry Program
Weight of
Dry Clothes
Heating
Intensity
Clothes
Material
Control Panel Operation
1. Before drying, thoroughly spin the laundry in a washing machine. High spin speed
can reduce the drying time and save energy consumption.
2. For a uniform drying result, sort the laundry according to fabric type and drying
program.
3. Before drying, close zippers, hooks and eyelets, buttons, tie fabric belts, etc.
4. Do not over dry the clothes because these can easily get creases.
5. Do not dry articles containing rubber or similar elastic materials.
6. The door can be opened only after the drying program is over, to avoid
overheating and/or getting scalded by hot steam.
7. Clean the filter and empty the container after each use, to avoid prolonged
drying time and increase in energy use.
8. Do not dry clothes that have just been dry-cleaned.
Briefs
(about 70g cotton)
Clothes Drying Instructions
1
40'
OFF
80'
15'
60
'
140 '
100 '
120'
55'
START
Legend:
Max
Mid
Heat Intensity
Timer (minutes)
Timer Setting Guide
- Cotton
- Fiber
- If intended for ironing
- If not intended for ironing
6.5kg
6.5kg
:140-1 55 min
min
min
min
min
min
min
min
:110-130
3kg :110-1 20
3kg :85-105
3.5 kg:100-120
3.5 kg:80-100
2.5 kg:110-14 0
2.5 kg:90-100
6.5kg Clothes Dryer
FP-91LFD070GMTM-N

Note:
1) Clean the filter before each use.
Remove by pulling straight up.
2) Use a cloth to wipe the filter.
3) Installing the Filter
If the filter is cleaned using a damp cloth or
with water, let the filter dry in the sun before
installing it back to the machine.
Use a soft damp cloth to clean the
cabinet and drum.
1. Do not rinse with water directly.
2. Do not use scouring pads.
3. Do not use gasoline and alcohol for wiping.
Make sure to open the front door after cleaning
the drum, for it to dry naturally.
Operation Cleaning and routine maintenance
Cleaning the cabinet and Drum
Filter
899
Be cautious, if the clothes to be dried have labels containing the following
symbols:
Dry Normal Do not tumble dry Do not dry
Line dry / hang to dry Drip dry Drip flat Keep in the shade
Dry clean Do not dry clean Dry clean normal cycle
with any solvent
Dry clean normal cycle,
petroleum solvent only
1. At the last 15 minutes of the program, cool air will be used and there will be
no more heating. This is done to avoid wrinkling of clothes and to make it
comfortable for you to take the clothes out of the dryer.
2. Room temperature and humidity will not affect drying time.
3. Check the labels attached to the clothes and choose the appropriate setting
based on it.

• The clothes in the machine are
too many.
• Clothes are not immediately taken
out of the drum after the drying
process and left in the drum for
a long period of time.
• Clothes are not properly sorted.
• The temperature is setting is too high.
The cut out switch may operate for the following reasons:
1. Lint filter is clogged.
2. Exhaust outlets are blocked at the back of the dryer.
3. Poor ventilation in the laundry room (open a window or door)
4. A piece of lightweight garment (e.g.: handkerchief) covers the filter.
Unit does
not start
• Power is cut.
• The power plug is not insered tightly
• Dry weight of clothes exceed
the rated capacity.
• The temperature fuse is cut.
• The filter is dirty.
• The air intake area or
flexible duct is dirty.
• Take out some clothes, make sure the
drum is not too full.
• Take out the clothes immediately when
drying is finished.
• See page 7.
• Follow the fabric care label on the
clothes.
• Follow the fabric care label on the clothes.
Take out the clothes when it is still a little
damp and then hang it until it becomes
fully dry.
• Wait for electrical supply to resume.
• Check the power socket, make sure the
plug is tightly secure in place.
• Dry weight must not exceed 6.5kg.
• Call for service.
• Clean the filter after each use.
• Clean the air intake or flexible duct.
• Too dry
• Use fabric softener. Turn the clothes
inside-out to reduce friction. Spray starch
solution on cuffs and necklines when
ironing clothes.
• It is normal for synthetic fiber and
permanent press fiber to form lumps.
External surfaces
are hot or there is
presence of burnt
smell
Clothes are
too dry
Clothes shrink
Fiber ball on
clothes
When in operation, the dryer can cause:
• Vibration noise: This occurs when the wet clothes turn and bump against
one another.
• Bumping sound: When drying, steam is generated, comes out of the pipe
and bumps against the bottom of the drum.
Safety reset Precautions
Trouble Cause Solution
10 11
These dryers have a safety cut out switch which is activated by temperature.
It will only be necessary to press the safety reset button if the dryer is not heating.
Allow the dryer at least 10 minutes to cool down before pressing the button. Press
the white button until you feel the reset switch click. The most common reason for
the dryer to overheat is a clogged filter. Cleaning the filter after each load will
avoid repetitive operation of the safety cut out switch.

12
Note: The rated capacity is the maximum capacity. Make sure that the dry weight of the clothes that are loaded
in the appliance do not exceed the rated capacity.
Dimensions
Rated input
power
Rated voltage
595x550x840(mm) Product weight
1760 W
220 V~
Rated capacity
Rated frequency
33kg
6.5kg
60Hz
Technical specifications
Specifications
13
