SENZ SDC320 User manual

SDC320
Condenser Dryer

SENZ CONDENSER DRYER.
4 - 29
SENZ KONDENSATORTØRKETROMMEL.
SENZ KONDENSAATIOKUIVAUSRUMMUN.
KONDENSATOR TØRRETUMBLER FRA SENZ.
SENZ KONDENSTORKTUMLARE
注意：这些标识只印在说明书右侧页面
30 - 55
56 - 81
82 - 107
108 - 133
32

4
Safety Instructions
Warning!
！
To prevent any damages to your and others' life
or property, you have to follow the safety notes.
SAFETY INSTRUCTIONS
• This product belongs to CategoryⅠelectrical appliances, and
only for drying textiles which have been washed with water in
the household. Please pay attention to the safety of power
use during the operation!
• The power source with reliable earthing must be used. Its
earth wire must be buried under the ground and shall not be
connected with the public utilities such as city water pipe or
gas pipe etc. The earth wire and null wire shall be
distinguished and shall not be connected together.
• The power wire shall be met IEC and must be able to
withstand the current above 16A. To ensure your and your
family's safety, please make improvement immediately if any
power use at your home does not meet the above-mentioned
requirements.
• Do not put more load than recommended. Obey the maximum
load volume. See the related chapter in the user manual.
• That the tumble dryer is not to be used if industrial chemicals
have been used for cleaning.
• Do not dry unwashed items in the tumble dryer.
• Items that have been soiled with substances such as cooking
oil, acetone, alcohol, petrol, kerosene, spot removers,
turpentine, waxes and wax removers should be washed in hot
water with an extra amount of detergent before being dried in
the tumble dryer.
• Fabric softeners, or similar products, should be used as specified
by the fabric softener instructions.
• Items such as foam rubber (latex foam), shower caps,
waterproof textiles, rubber backed articles and clothes or
pillows fitted with foam rubber pads should not be dried
in the tumble dryer.
• The final part of a tumble dryer cycle occurs without heat
(cool down cycle) to ensure that the items are left at a
temperature that ensures that the items will not be damaged.
• The lint trap has to be cleaned frequently.
• The lint must not to be allowed to accumulate around
the tumble dryer.
• Adequate ventilation has to be provided to avoid the
back flow of gases into the room from product burning
other fuels, including open fires.
5

6 7
• The exhaust air must not be discharged into a flue which
is used for exhausting fumes from product burning gas
or other fuels.
• The product must not be install behind a lockable door,
a sliding door or a door with a hinge on the opposite side
to that of the tumble dryer. In such a way that a full
opening of the tumble dryer door is restricted.
• Oil-affected items can ignite spontaneously, especially
when exposed to heat sources such as in a tumble dryer.
The items become warm, causing an oxidation reaction in
the oil. Oxidation creates heat. If the heat cannot escape,
the items can become hot enough to catch fire. Piling,
stacking or storing oil-affected items can prevent heat
from escaping and so create a fire hazard.
• If it is unavoidable that fabrics that contain vegetable
or cooking oil or have been contaminated by hair care
products be placed in a tumble dryer they should first be
washed in hot water with extra detergent-this will reduce,
but not eliminate, the hazard.
• The product should not be overturned during normal use
or maintenance.
• Remove all objects from pockets such as lighters and
matches.
• This product can be used by children aged from 8 years
and above and persons with reduced physical, sensory or
mental capabilities or lack of experience and knowledge
if they have been given supervision or instruction
concerning use of the product in a safe way and
understand the hazards involved. Children shall not play
with the product. Cleaning and user maintenance shall
not be made by children without supervision.
• The product is not intended for use by persons (including
children) with reduced physical, sensory or mental
capabilities, or lack of experience and knowledge, unless
they have been given supervision or instruction concerning
use of the product by a person responsible for their safety.
• Children should be supervised to ensure that they do not
play with the product.
SAFETY INSTRUCTIONSSAFETY INSTRUCTIONS

Never stop a tumble dryer before the end of the
drying cycle otherwise too much heat will diffuse
and may cause harm.
Warning!
！
• If the power cable is damaged, it must be replaced by
the manufacturer, its service agent or similarly qualified
persons in order to avoid a hazard.
• This appliance is for indoor use only.
• The openings must not be obstructed by a carpet.
• Children of less than 3 years should be kept away unless
continuously supervised.
• If the appliance appear high temperature abnormally ,
please draw the mail plug immediately.
• Warning: The appliance must not be supplied through an
external switching device, such as a timer, or connected to
a circuit that is regularly switched on and off by a utility.
• Remove all packages before using the product.
Otherwise,serious damage may result.
8 9
Damage danger
Explosion danger
Injury danger
Electric shock hazard
• Do not pull out the mains power plug forcefully.
• Do not plug/draw the mains power plug with wet hands.
• Do not damage the mains power cable and plug.
• Do not disassemble and install the dryer without instruction
or supervision.
• Do not stack this dryer on a washing machine without stacking
kit.(If you want to stack on a washing machine, purchase
the independent parts and it must be installed by the
manufacturer, its service agent or similarly qualified persons
in order to avoid a hazard.)
• Do not lean on the open door of the dryer.
• Do not put any pyrotoxin on the dryer, such as a candle,
or electric cooker.
• Do not dry over the rated capacity.
• Do not operate the dryer without the filter door and filter base.
• Do not dry clothes before being spun.
• Do not expose the dryer directly under the sun, and only
use indoors.
• Do not install the dryer in humid or damp environment.
• While cleaning or performing maintenance, remember to
pull out the mains power plug and do not directly wash the
dryer with water.
Do not dry clothes with flammable substances such as coal oil,
alcohol or there will be an explosion.

Accessories
The following parts are optional for specific models.
If your dryer has any of the following parts, wear gloves and
them following the instructions below .
install
Hose holder (optional)
Condensing drain
hose (optional)
Use pliers to
remove the drain
hose from the
hose connector.
Insert the
external
drainage
hose.
Product Overview
Max.120cm
200cm
Put the hose holder on the
basin or any other sink.washing
Installation
Installation Position
Transport
Move cautiously. Do not grasp any salient parts of the machine. The
machine be used as the handle for delivery. If the dryer door cannot
can’t be transported horizontally, it can be slanted up to 30 degrees.
Level Adjusting
Once in its permanent operating position,
check that the dryer is absolutely level with
of a spirit level. If it is not, adjust the
feet with a tool.
the aid
Power Supply Connection
1.It is recommended that, for your convenience, the machine is
your washing machine.
2.The tumble dryer must be installed in a clean dry place, where
Air must be able to circulate freely all round
front air inlet or the air intake
3.To keep vibration and noise to a minimum when the dryer is in use,
placed on a firm and level surface.
4.The feet must never be removed. Do not restrict the floor
deep pile carpets, strips of wood or similar.
would interfere with the
operation of the product.
positioned close to
dirt does not build up.
the product. Do not obstruct the
grilles at the back of the machine.
it should be
clearance through
This might cause heat built-up which
1.Make sure that the voltage of the power supply is the same as the
2.Do not connect the dryer with the power connection board, the
electric specification of the dryer.
Mains power
cable
Filter door
Container
Door
Control panel
Air inlet
Filter base
Maintenance cover
Drum
Top board
Note: Diagram is for reference. Your model may differ slightly. The product you purchased will prevail.
universal plug or socket. do not use multi-plug adapters and
extension cables.
10 11

After Drying
Drying
Buzzer beep or " :00"on display.0
1 2 3 4 5
open the door
and take out
laundry
pull out the
container
pour out
condensate
water
clean the filter power off
Quick Start
Before using, make sure it's installed properly.
Note!
1
plug in
2
load
3
close door
start
on select program select function
or default
If you are using a mains power socket with a switch,
press the switch to turn off the power directly.
Note!
OPERATIONS
1.Before drying, thoroughly spin the laundry in your washing machine.
High spin speed can the drying time and save energy
consumption.
2.For uniform drying result, sort the laundry according to fabric type
and drying programme.
3.Before drying, close zips, hooks and eyelets, button up, tie fabric
belts, etc.
4.Do not over dry clothes, because over dried clothes can easily get
creases.
5.Do not dry the articles containing rubber or similar elastic materials.
6.The door can be opened only after the programme of the drying
machine finishes to from being scalded by hot
steam or over heated drying machine.
7.Clean the lint filter and empty container after each use to avoid
extension of drying time and energy consumption.
8.Do not dry clothes after dry-clean process.
9.
reduce
prevent human skin
Choose the related programme when dryinng wool material clothes,
to make the cloth more fresh and fluffy.
Before Each Drying
Leave it to stand for 2 hours after transporting.
Before first use, use a soft
fabric cloth to clean the inside drum..
1.
2. .
3.
.
4.
Put some clean rags into the drum.
Plug in to the mains power, press 【On/Off 】
Select the 【Refresh】 Programme, press
【Start/Pause】 button
After finishing this programme, follow the
“Cleaning And Care” (refer to page 18) to clean
the filter door.
During drying, the compressor
and the water pump generate some noise
which is entirely normal.
Note!
12 13

Pay attention to use the drying machine if the materials of your clothes
by it or contains the symbols as follows:cannot be dried
Dry
Dry clean
Line dry / hang to dry Drip dry
Do not dry clean
Normal Do not dry
In the shade
Dry flat
Not tumble dry normal
Dry clean normal cycle
with any solvent
Dry clean normal cycle
petroleum solvent only
Never overload.
Not for textile with condensation. The dryer could
be damaged, even fire.
Note!
Mixed-fabric clothes
(about 800g)
Jacket
(about 800g cotton)
Jeans
(about 800g)
Towel quilt
(about 900g cotton)
Single bedsheet
(about 600g cotton)
Short sleeve shirt
(about 180g cotton)
Work clothes
(about 1120g)
Short pants
(about 70g cotton)
Sleepwear
(about 200g)
Socks
(about 50g
mixed-weave)
Long sleeve shirt
(about 300g cotton)
1415
The reference weight of dry clothes (each) Control Panel
Product is switched on or off.
On/Off
the button to start or
pause the drying cycle.
Press
Start/Pause
Working state LED
Function LED
Specialty function
Programmes
Different Dryer cycle can be
selected according to the
user's needs to make the
clothes have more effective
drying result.
3h,6h,9h,12h,Child lock,Filer
Full and Anti-Crease
These buttons are used for
setting additional functions
(Delay, Anti-Crease,Childlock).

1617
Programme selector
1. When the LED display screen
brightens up, rotate the programme control to select the desired
programme.
2.Select the【Delay】or【Anti-Crease】functions for additional
option.
3.Press the【Start/Pause】key.
Press the 【On/Off】button.
Programme start
Programme end
1.The drum will stop running after the programme ends, the
working state LED will stay light and buzzer will ring.The “Filter”
and”Full”LED will remind user to clean the filters and container.
The dryer will start Anti-crease function if user doesn’t
remove the load in time (refer to page 15). Press
key to cut off the mains power and pull the plug out.
2.Deal with any problems according to the “Malfunction display
and solutions , if there is an unexpected stop during the
drying procedure and the dryer shows information (refer to page 18 ).
【 】
【On/Off】
”section
The drum will keep rotating after the programme starts, the state
light in the display area will flash in sequence, the remaining time
displayed will change automatically.
Instructions of the 【Delay】function
This function is used for delaying clothes drying time within 24
hours. The delay time means the programme will start after x hours.
When the delay programme starts, the time starts to decrease on
the display and the delay icon blinks.Steps in details:
1.Load your laundry and make sure the machine door is closed.
2.Press the 【On/Off】button,then to turn the programme selector
control and select your desired programme.
3.You can select the 【Anti-Crease】functions according to your need.
4.To delay, press the【Delay】 key.
5.Continue to press the 【Delay】to select the delay time.
Instructions of the Anti-Crease function【 】
At the end of the drying cycle,the anti-crease phase time is 30
minutes (default ) or 120 minutes (selected).
This function prevents the laundry from creases. The laundry can
be removed during the anti-crease phase. Except 【Cool】,
【Refresh】, all the other programmes have this function.
Instructions of the Child Lock function【 】
1.This machine incorporates a special child safety lock, which can
prevent children from carelessly pressing keys or making a
faulty operation.
2.When the dryer is in the operation state, press the【Anti-Crease】
and 【Signal】buttons at the same time for over 3 seconds to
start child lock function. When child lock function is set, the
display will show Child lock icon and no key can effect the dryer
except 【On/Off】button. Under the start state of the child lock,
the【Anti-Crease】and 【Signal】buttons should be pressed at the
same time for over 3 seconds to release the child lock function.
6.After the 【Start/Pause】 key is pushed, the Dryer is in the run
condition. The drying procedure will be automatically performed
when the delay time is over.
7.If you push the【Start/Pause】button again, the delay function
will be paused.
8.If you want to cancel the “Delay” function, press the 【On/Off】
button.
Other Functions

Drying Programmes Table
This symbol means the energy efficiency test
programme “standard cotton programme”, which
is accordance with the applicable EN 61121
standard and most suitable to dry normal cotton
loads at rated load capacity.
Thick or multi-layered fabrics,e.g. bedlinen,
jeans, jackets etc, are not easy to dry. You'd
better choose Cotton Extra programme.
As the uneven material, thick and multi-layered
clothes are not easy to dry, it is better to choose
the appropriate time drying programme to dry
them if some parts of the clothes are still damp
after the programme has finished.
Note!
1819
Iron
For non-iron washing made of synthetic and blended fabrics,cotton.
Standard
Synthetics Extra
Extra
To warm clothes with hot air in 60 min.
To dry thin synthetic fabrics which are not ironed, such as easy care
shirts, table linen, baby clothes, socks.
To dry thick or multi-layered synthetic fabrics. Drying level: extra dry.
To dry cotton pieces of clothing. Drying level: applicable to iron.
To dry cotton pieces of clothing. Drying level: cupboard dry.
To dry cotton pieces of clothing. Drying level: extra dry.
Application/Properties
To dry delicate laundry that is suitable for drying or laundry which is
advised to be hand-washed at a lower temperature.
To air clothes without blowing hot air from in 10 min.
To dry jeans or leisure clothes that are spun at high speeds in the
washing machine.
If you cannot determine what the clothing's material is, please
choose Mix.
To dry sportswear, thin fabrics, polyester,which are not ironed.
For refreshing or gently cleaning textiles with commercially available
Auto
Sports
Baby Care
Cool
Refresh
Rapid 45'
Warm 60'
Warm 30'
Programme
Auto
Cotton
For cottons and coloureds made of cotton or linen.
(max)
Weight
Sports
Baby Care
Cool
Refresh
Rapid 45'
Warm 60'
Warm 30'
5.0kg
8.0kg
8.0kg
8.0kg
3.5kg
Standard 3.5kg
Jeans Jeans 5.0kg
Mixed Mixed 3.5kg
3.0kg
Delicate Delicate 1.0kg
1.0kg
0.6kg
To dry unknown material clothes automatically.
To dry small amount of baby clothing.
To dry at most 3 shirts in 45 min.
To warm clothes with hot air in 30 min.
dry cleaning products.
8.0kg

20
MAINTENANCE
21
Empty the water container
Clean filter base
Filter door
Locking
lever
Maintenance cover
Filter
base
1. Hold and pull out the water container
with two hands.
2. Tilt the water container, pour out the
condensate water into the basin.
3. Install the water container.
Clean the scrap threads
Cleaning And Care
Empty the water container after each use, the
programme will be paused and the Full LED icon
wil illuminate if the water container is full during
the drying process. After the container is
emptied, the dryer can be restarted by pressing
【Start/Pause】button.
Do not drink the condensate water.
Do not use the dryer without the water container.
Warning!
！
1.
2.
3.
Open the door.
Take out the lint filter,pull
upward to take it out.
Clean the lint filter, clean the inner
ring and door gasket;wipe off the
scrap threads with your hand orrinse
with water and dry thoroughly.
4.Reinstall the filter door.
1.
2.
3.
Open the cover.
Unscrew both locking levers
towards each other.
Clean the filter base completely.
4.Re-insert the filter base!
5.Screw both locking levers.
6.Close the cover until it locks into
position.
Leave the dryer to cool down.
circulation, which will cause an extension of the
drying time and use more energy consumption.
Do disconnect the mains power cable before cleaning!
Do not operate the dryer without the filter!
Clean the filter after each use to prevent lint
accumulation inside the dryer.
The fluff accumulated on the filter will block the air
Note!

Trouble Shooting
Only authorised technicans can carry out repairs.
Before you call service, please check if you have
dealt with the fault yourself or if you have
followed the user instructions.
A technician will charge you for advice, even
during the warranty period.
Warning!
！
As necessary, approx. once every 2 months,
remove the fluff from the heat exchanger
using a sponge or soft brush.
When doing this, use gloves.
Clean heat exchanger
dampened.
The fluff can be removed more easily if it is first
Note!
22 23
Wash air condenser
Leave the dryer to cool down.
Residual water may leak, place an absorbent
cloth under the maintenance cover.
1.Unlock the maintenance cover.
2.Completely open maintenance cover.
3.Screw both locking levers towards each other.
4.Pool out the air condenser.
5.Clean the air condenser completely,drain
thoroughly.
6.Clean the seals.
7.Re-insert the air condenser, handle at the button!
8.Unscrew both lockinglevers.
9.Cloth the maintenance cover until it locks into
position.Plaese clean the air condenser approx,
once every 3 months if frequently used.
Do not damage the air condenser!
Clean with water only; do not use hard/sharp-
edged objects! Do not operate the dryer without
the air condenser!
Warning!
！
During drying,water may collect between the
window and the seal, but this does not affect
the function of your dryer!
Empty container
Dispiay Reason Solutions
Container is full
Water pump failure or water
level sensor failure P lease contact your
local service center
if the problem
persists
Humidity sensor error
“Full” LED on
permanently
Child Lock + 9h
Child Lock + 6h
Temperature sensor error
Child Lock + 3h Heating problem

2425
Technical Specifications
Contains fluorinated greenhouse gases covered by the Kyoto Protocol.Hermetically sealed.
The rated capacity is the maximum capacity,
make sure that the dry clothes which are
loaded in to the product do not exceed the
rated capacity each time.
Do not install the tumble dryer in a room when
there is a risk of frost occurring. At temperatures
around freezing point the tumble dryer may not
be able to operate properly.
There is a risk of damage if the condensate
water is allowed to freeze in the pump, hoses
and / or condensate water container.
Note!
If you cannot deal with the fault by yourself and
need help:
Press the 【On/Off】button.
Pull out the mains power plug and call for service.
Warning!
！
SDC320
•Clean lint filter and wash condenser.
•Empty container.
•Check water outlet.
•Dryer installation too restricted.
•Clean the moisture sensors.
•Use next higher drying programme or using
Timer programme.
•Check the clothes is over load .
Problem Solution
•Working state LED
not on
•The mains plug is inserted.
•Check the programme selected.
•Check fuse in the house.
•Empty condensation container.
•If failure, check hose for condensation outlet.
•Dryer does not start
•Check the has selected
•Check the the door has closed.
•Check the programme has set.
start button .
•Water is running out •Align dryer horizontally.
•Clear air condenser and door seals.
•Door is open by itself •Press door until it “clicks”into position.
•Degree of dryness was
reached or drying time too
long
not
•Humidity in the room is
increase significantly
•Ventilate room adequately.
•Clean the cool grille.
•Ensure that the air condenser has been inserted.
•“Full” LED on permanently
Rated capacity
Rated frequency
Dimension(L*W*H)
Rated input power
Rated voltage
Weight of product
Model
Parameter
Ambient temperature
+5°c ~ +35°c
220-240V~
615*595*845(mm)
2700W
41kg
8.0kg
50Hz
Refrigerant
GWP
CO - eq
2
Quantity of refrigerant

SDC320
8kg
Condenser
B
560.9kWh / year
Automatic
N/A
3.50kWh
4.74kWh
2.57kWh
0.1 W
0.8 W
10 min
111min
140min
90min
B
81%
81%
81%
69dB
Model
Rated Capacity
Dryer Type
Energy efficiency class
Weighted annual energy consumption (AE )
Automatic or non-automatic
EU Ecolabel
Energy consumption of the standard cotton programme
Weighted energy consumption of the standard cotton programme at full and partial load
Energy consumption of the standard cotton programme at full load
Energy consumption of the standard cotton programme at partial load
Power consumption of the off-mode (Po)
Power consumption of the left-on mode (Pl)
Duration of the left-on mode
Programme time of the 'standard cotton programme'
Weighted programme time of the standard cotton programme at full and partial load
Programme time of the standard cotton programme at full load
Programme time of the standard cotton programme at partial load
Condensation efficiency class A (most efficient) to G (least efficient)
Average condensation efficiency of the standard cotton programme at full load
Average condensation efficiency of the standard cotton programme at partial load
Weighted condensation efficiency for the standard cotton programme at full and partial load
Sound power level for the standard cotton programme at full load
❶
c
2627
Product Fiches
❶Energy consumption per year, based on 160 drying cycles of
the standard cotton programme at full and partial load, and
the consumption of the low-power modes. Actual energy
consumption per cycle will depend on how the product is
used.The 'standard cotton programme' used at full and
partial load is the standard drying programme to which the
information in the label and the fiche relates, that this
programme is suitable for drying normal wet cotton laundry
and that it is the most efficient programme in terms of energy
consumption for cotton.
Remarks:

Correct Disposal of this product:
This marking indicates that this product should not
be disposed with other household wastes throughout
the EU. To prevent possible harm to the environment
or human health from uncontrolled waste disposal,
recycle it responsibly to promote the sustainable
reuse of material resources. To return your used
device, please use the return and collection systems
or contact the retailer where the product was
purchased. They can take this product for
environmental safe recycling.
2829
SDC320
2700W
SPECIFICATION Imported and Exclusively marketed by:
Power International AS,
PO Box 523, N-1471 Lørenskog, Norway
Power Norge:
https://www.power.no/kundeservice/
T: 21 00 40 00
Expert Danmark:
https://www.expert.dk/kundeservice/
T: 70 70 17 07
Power Danmark:
https://www.power.dk/kundeservice/
T: 70 33 80 80
Punkt 1 Danmark:
https://www.punkt1.dk/kundeservice/
T: 70 70 17 07
Expert Finland:
https://www.expert.fi/tuki/asiakaspalvelu/
T: 020 7100 670
Power Finland:
https://www.power.fi/tuki/asiakaspalvelu/
T: 0305 0305
Power Sverige:
https://www.power.se/kundservice/
T: 08 517 66 000


•
•
•
•
•

•
•
•
•
•
•
•
•

•
•
•
•

•
•
•
•
•

•
•
•
•
•
•
•
