IFM Electronic ANT805 User manual

Operating instructions
RFID UHF antennas
Low range / ultra-low range
Mid range / short mid range
Wide range
ANT805
ANT810
ANT815
ANT820
ANT830
ANT910
ANT920
ANT930
706385 / 00 11 / 2014
UK

RFID UHF antennas
2
Content
1 Preliminary note � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � 3
1�1 Symbols used� � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � 3
2 Safety instructions � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � 3
2�1 General� � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � 3
2�2 Target group � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � 3
2�3 Electrical connection � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � 4
2�4 Tampering with the device � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � 4
2�5 Environmental conditions � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � 4
3 Product description� � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � 5
3�1 Low-range antennas� � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � 5
3�2 Mid-range antennas � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � 5
3�3 Wide-range antennas � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � 6
3�4 Antenna type according to reading range and transponder shape� � � � � � � 7
4 Reading range and selectivity� � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � 9
4�1 Antenna allocation according to tag types � � � � � � � � � � � � � � � � � � � � � � � � � 9
4�2 Reading range � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � 9
4�3 Selectivity � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � 10
4�4 Selectivity and reading range of the low-range antennas � � � � � � � � � � � � 10
5 Conformity with standards � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � 10
6 Installation� � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � 13
6�1 Installation location� � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � 13
6�2 Laying of cables � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � 14
7 Typical applications� � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � 15
7�1 Pharmaceutical industry � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � 15
7�2 Access systems � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � 15
7�3 Automation industry � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � 15
7�4 Other applications for mid-range antennas � � � � � � � � � � � � � � � � � � � � � � � 15
8 Abbreviations � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � 16
9 Approvals � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � 16
10 Maintenance, repair and disposal� � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � 16

UK
RFID UHF antennas
3
1 Preliminary note
This document is intended for specialists� These specialists are people who are
qualified by their appropriate training and their experience to see risks and to
avoid possible hazards that may be caused during operation or maintenance of
the device� The document contains information about the correct handling of the
device�
Read this document before use to familiarise yourself with operating conditions,
installation and operation� Keep this document during the entire duration of use of
the device�
1.1 Symbols used
►Instructions
> Reaction, result
[…] Designation of keys, buttons or indications
→Cross-reference
Important note
Non-compliance may result in malfunction or interference�
Information
Supplementary note
2 Safety instructions
2.1 General
These instructions are an integral part of the device� They contain texts and figures
concerning the correct handling of the device and must be read before installation
or use�
Observe the operating instructions� Non-observance of the instructions, operation
which is not in accordance with use as prescribed below, wrong installation or
incorrect handling can seriously affect the safety of operators and machinery�
2.2 Target group
These instructions are intended for authorised persons according to the EMC and
low-voltage directives� The device must only be installed, connected and put into
operation by a qualified electrician�

RFID UHF antennas
4
2.3 Electrical connection
Disconnect the device externally before handling it�
The connection pins may only be supplied with the signals indicated in the
technical data and/or on the device label and only the approved accessories of ifm
may be connected�
2.4 Tampering with the device
In case of malfunctions or uncertainties please contact the manufacturer� Any
tampering with the device can seriously affect the safety of operators and
machinery� This is not permitted and leads to the exclusion of any liability and
warranty claims�
2.5 Environmental conditions
Do not place the device in the vicinity of heatings, do not expose it to direct sunlight
and do not operate it in wet environments� No objects with open flames must be
placed onto the device� Protect the device against moisture, falling water drops and
splashing water� Observe the environmental conditions indicated in the technical
data sheet�
There is a risk of fire in unsuitable environmental conditions�

UK
RFID UHF antennas
5
3 Product description
The ifm RFID antennas consist of several UHF antennas which can meet the
requirements of almost any RFID application� The antennas are divided into three
product lines with regard to their reading range: low-range, mid-range and wide-
range antennas�
3.1 Low-range antennas
With dimensions of 90 x 63 mm the ANT810 / ANT910 low-range antennas have a
high field concentration in the near field and an extremely reduced antenna gain in
the far field� These features ensure that the antennas achieve ranges up to 10 cm
with a typical selectivity of 5 cm�
In addition to the low-range antennas there is the ANT805 ultra-low-range
antenna� The ultra-low-range antenna was designed to read dipole-shaped
tags ("far-field tags") at a very limited distance� This antenna can also activate
loop-shaped tags ("near-field tags") up to 3 cm� The low-range antennas were
developed for larger ranges so that they are in particular suitable for near-field
tags� The antenna allocation according to the reading range and tag shape is
outlined in chapter 3�4�
Figure: ANT805 ultra-low-range antenna,
ANT810 / ANT910 low-range antennas
3.2 Mid-range antennas
The ANT815 / ANT820 / ANT920 mid-range antennas were designed for
applications in the range between near and far field� Special importance was
placed on a compact design to ensure integration into space-limited environments�
With dimensions of 156 x 126 reading ranges of more than 2 m are nevertheless
possible� Mid-range antennas also have an increased selectivity at lower read
distances as compared to conventional antennas� That means the mid-range
antennas are suitable for use in the transition range with different tags�
