IFM AC3227 User manual

Operating instructions
AS-i SmartLine FO repeater
AC3227
80272533/00 01/2018
UK

2
Contents
1 Preliminary note���������������������������������������������������������������������������������������������������3
2 Safety instructions �����������������������������������������������������������������������������������������������3
2�1 Symbols used ������������������������������������������������������������������������������������������������3
3 Functions and features ����������������������������������������������������������������������������������������4
4 Operating and display elements ��������������������������������������������������������������������������4
5 Installation������������������������������������������������������������������������������������������������������������5
5�1 Installation of the device ��������������������������������������������������������������������������������5
5�2 Remove device����������������������������������������������������������������������������������������������5
6 Connections���������������������������������������������������������������������������������������������������������6
6�1 Electrical connection �������������������������������������������������������������������������������������6
6�2 Optical fibre connection ���������������������������������������������������������������������������������7
7 Terminal connection���������������������������������������������������������������������������������������������7
8 Operation / LEDs �������������������������������������������������������������������������������������������������8
9 Example of an AS-i topology �������������������������������������������������������������������������������8
10 Maintenance, repair, disposal����������������������������������������������������������������������������8
10�1 Maintenance ������������������������������������������������������������������������������������������������8
10�2 Cleaning the housing surface ����������������������������������������������������������������������8
10�3 Disposal�������������������������������������������������������������������������������������������������������8

3
UK
1 Preliminary note
Technical data, approvals, accessories and further information at
www�ifm�com�
2 Safety instructions
• Read this document before setting up the product and keep it during the entire
service life�
• The product must be suitable for the corresponding applications and
environmental conditions without any restrictions�
• Only use the product for its intended purpose (→ Functions and features).
• If the operating instructions or the technical data are not adhered to, personal
injury and/or damage to property may occur�
• The manufacturer assumes no liability or warranty for any consequences
caused by tampering with the product or incorrect use by the operator�
• Installation, electrical connection, set-up, operation and maintenance of the
product must be carried out by qualified personnel authorised by the machine
operator�
• The plant operator is responsible for the safety of the plant in which the device
is installed�
• If the device is not used as intended by the manufacturer, the protection
supported by the device may be impaired�
• Protect units and cables against damage�
2.1 Symbols used
►Instructions
→Cross-reference
Important note
Non-compliance may result in malfunction or interference�
Information
Supplementary note�

4
3 Functions and features
The AS-i FO repeater is used to extend the cable of an AS-i network� The
incoming data of repeater 1 is processed and transmitted to repeater 2 via a fibre
optic cable� The data of repeater 2 is also processed and sent to repeater 1� A
system consists of two AS-i FO repeaters�
• Electrical separation of the incoming AS-i line from the outgoing AS-i line
• Additional AS-i power supply required
• Connection via supplied COMBICON connectors
• Use of a standard fibre optic cable with ST connector
4 Operating and display elements
4
1
LE
D
2
Rx
Tx
3
1� COMBICON connector with cage clamps
2� Panel for labelling
3� Connection fibre optic cable with ST connector
4� DIN rail adapter

5
UK
5 Installation
5.1 Installation of the device
►Mount the device on a 35 mm DIN rail�
►Leave enough space between the device and the top and bottom of the control
cabinet to enable air circulation and to avoid excessive heating�
►Take into account the internal heating of all devices when mounting several
devices side by side and observe the environmental conditions for every
device�
5.2 Remove device

6
6 Connections
6.1 Electrical connection
Connect the incoming AS-i line 1 to terminals A+ and A- of repeater 1 and the
outgoing AS-i line 2 to terminals A+ and A- of repeater 2�
Rx
Rx
Tx
Tx
AS-i Line 1 AS-i Line 2
An additional AS-i power supply is required for the outgoing AS-i line�
If the AS-i FO repeater 1 is at the cable end of an AS-i line and the cable length is
> 100 m, the AS-i bus must be terminated with a link between T1 and T2� A link is
supplied�
The AS-i bus termination is used to improve the signal quality and to extend the
AS-i network cable� Only one AS-i bus termination may be used per AS-i segment�
Activate the termination and check the signal quality of the AS-i network via the
diagnostic possibilities of the master (e.g. telegram error).

7
UK
6.2 Optical fibre connection
►Connect fibre optic cable�
►Connect Rx of repeater 1 to Tx of repeater 2,
connect Rx of repeater 2 to Tx of repeater 1�
Permissible fibre optic cable types
- Fibre optic cable 50/125 µm with ST connector (recommended up to 500 m)
- Fibre optic cable 62�5/125 µm with ST connector (do not use at distances
below 200 m)
►Observe permissible bending radii of the fibre optic cable manufacturers�
Calculation of the achievable distances for data transmission
→ifm fibre optic calculator in the download area�
7 Terminal connection
A+ A- A+ A-
Line AS-i
T1 T2
Line Termination
Rx
Tx
A+: AS-i +
A-: AS-i -
A+: AS-i +
A-: AS-i -

8
8 Operation / LEDs
Tx
Rx
PWR
TERM
LED PWR green: AS-i voltage ok
LED TERM yellow: termination active
LED Rx green: optical input, receive data
LED Tx green: optical output, send data
9 Example of an AS-i topology
MPS S
RT
AS-i flat cable
100...200 m
S
AS-i fibre optic cable
e.g. 1500 m
AS-i flat cable
100...200 m
R
S
S
PS
M = master / PS = power supply / S = slave / R = repeater /
T = termination (terminating resistor for cable length > 100 m)
10 Maintenance, repair, disposal
10.1 Maintenance
The device is maintenance-free�
10.2 Cleaning the housing surface
►Disconnect the device�
►Clean the device from dirt using a soft, chemically untreated and dry cloth�
Micro-fibre cloths without chemical additives are recommended�
10.3 Disposal
►Dispose of the device in accordance with the national environmental
regulations�

9
UK
