iGear RazorBeat iG-1041 User manual
Thank you for choosing our speaker. It is based
on the mainstream low-power portable
Bluetooth version 5.0 program that allows you
to enjoy music anytime, anywhere.
This manual describes the various features of
the product, tips and cautions, please read this
manual carefully before using the product.
Care and maintenance
Keep the device dry. Do not let the device or
battery come in contact with water or water
vapor.
Do not make the equipment, battery to strong
impact or shock, or cause equipment, battery
failure.
Do not place the speaker in too high or too low
temperature area. It may cause device failure.
Do not strike, throw or drop the product .
Do not disassemble the device, otherwise the
device will not be covered by the warranty.
1. INTRODUCTION
1.1 Acknowledgment
1.2 Precautions
Do not use products while driving, so as not to hinder safe
driving.
In medical sites, please comply with the relevant rules or
regulations. Near medical equipment, please turn off
product.
Turn off the device before boarding the plane to avoid
interference with the signals.
Turn off the products in the vicinity of high-precision
electronic devices, or it may cause electronic equipment
failure.
Do not disassemble products and accessories, only
authorized center
Please keep away from magnetic equipment, the radiation
of the product will erase the information stored on the
magnetic device.
Do not use the product in places with high temperature or
flammable gases. (such as a nearby gas station).
Please keep the accessories out of children's reach. do not
allow children to use the product without adult
supervision.
Please comply with relevant laws and regulations when
using this product, and respect others' privacy and legal
rights.
Strictly follow the instructions in this manual when using
the USB charging cable, as this may damage your product.
Do not use the product in the bathroom or other wet
places to avoid any type of liquid damage.
1.3 Safety Tips
Before using the product, please read the information in
this section, and let your children know that information.
For more detailed information, please refer to the safety
instructions and precautions.
The box includes the following item6:
- Bluetooth Soundbar” 1
- USB Charging Cable” 1
- User Manual” 1
- Aux cable” 1
Before using the product for the firs time, charge the
battery. Use 5V USB interface charging cable to charge the
product
Be sure to use 5V output adapter for charging. Do not use
adapter above 5V output as it will damage the product.
Please select the charging adapter strictly in accordance
with the product specifications.
2.1 Equipment Packing List
2.2 Charging
2.3 Specifications
2. OVERVIEW
• Bluetooth name: iGear-RazorBeat
• RMS: 10W (5W x 2)
• Speaker Driver: 2.25” x 2
• Bluetooth frequency: 2402 MHz to 2480 MHz
• Battery Capacity: 15O0mAh
• Battery Charging Power: DC5V/1A
• Working time Up to: 3 hours
• Transmission distance: 10 Meter
(Transmission distance varies due to differences in
environmental factors and Bluetooth cell phone devices)
3.1 Audio Key Function/Interface Function
3. QUICK START
1. Power On/Off, VoI +/-
2. Mode
3. Pre/ Rewind
4. Next/Speed
5. PIay/Pause
6. USBDisk Slot
7. ChargeSlot
8. TF Card
9. AUX
10. Mic
3.2 Charging
1. Please use the 5V/1A charger to charge the device. The
battery life will vary depending on the volume and the
environment.
2. If the speaker is not used for a long time, be sure to
charge at least twice a month as it may protect the
battery and extend the battery life.
* Make sure the output voltage of the charger used is no
more that 5V, otherwise it will damage the product
3.3 Power On and Power Off
3.4 Volume + /- Adjustment
3.5 Bluetooth speaker & devices
Power On: Turn the rotary knob to switch the device on
Power Off: Turn the rotary knob to switch off the device
Volume Adjustment: Rotate the rotary knob left or right to
adjust the volume.
3.5.1 Bluetooth connection
1. To switch to Bluetooth mode, press the "M" key.
2. Go to Bluetooth settings on your device and search for
the name "iGear Razorbeat" then click and connect it.
3.5.2 Bluetooth phone call (Hands Free)
1. When you get a call in Bluetooth mode, press the
Play/Pause key to accept the call.
2. During a call, The volume knob can be used to adjust
the volume output
3. Short press the Play / Pause button to end the call.
4. Double click the Play/Pause key to redial the last
dialed number.
3.5.3 Muslc player
1. Stand-alone Play / Pause , You can Play/Pause music.
2. Press key to switch to the next song, press
key to switch to the previous song.
3.6 External TF Card Audio Player
Insert the SD/TF card with music on it to play your songs
(support FAT32 file system format maximum 32GB).
3.7 FM Mode
1. FM Radio: Short press "M" key to enter the FM radio
mode.
2. Auto Search: Long press the Play/Pause button, it
will search for the available stations and save them
automatically. once the search it will jump to the first saved
station.
3. Once the search is completed, press the or
button to switch between the saved stations. supported
band network is 87.5 - 108MHz.
NOTE: To use the FM radio, please go to open space such as
outdoors, window or balcony, etc. to get clear signal and
avoid interference from the surrounding environment.
3.8 External U disk playback multimedia
features
Under Bluetooth mode, insert the USB drive directly, it
will start playing the music automatically. If the music
does not start playing, please check if the USB drive has
MP3 files as other formats are not supported.
3.9 AUX/Line-In
Using AUX cable: Connect one end of the cable to the AUX
port of the speaker and the other end to the port in
your Mobile/Tablet/Computer/TV.
3.10 TWS Connection
Using TWS mode: Two speakers can be paired at the same
time. turn on both the speakers, both will prompt Welcome
to iGear Music', press "M" button on any speaker for a few
seonds, then they will get paired to each other. Once both
are paired, search for the Bluetooth name 'iGear RazorBeat'
and connect.
WARRANTY METHODS
The definition of RMA products falls into two categories as
described below:
IRMA (In Warranty of Return Merchandise Authorization)
Defect occurs after 30 days of purchase and before the
warranty has expired.
Please following standard procedure of claiming the RMA
Service to assure you our best guarantee and service.
ORMA (Out of Warranty Return Merchandise Authorization)
Defect occurs after the warranty has expired.
We may refuse to provide inspection, repair or replacement
service for products that are out of warranty, and will
charge fees if these services are provided for
out-of-warranty products.
1. RMA
Name of Commodity: RazorBeat
Month and Year of Import: January, 2021
Country Of Origin: PRC
Net Weight: 810 gms
Net Quantity: 1 unit
Dimensions: 420mm X 60.5mm X 61mm
Voltage: DC: 5V
Wattage: 10W
Warranty Period: 1 Year
Imported and Marketed By:
IGear Tech Pvt. Ltd.
204, Sai Corporate Park,
Laxmi Nagar, Off Link Road,
Goregaon West, Mumbai - 400104.
In case of consumer complaints:
Toll free number - 1800 22 8495
Email: [email protected]
(Between 10am to 5pm, Mon- Fri)
