IgniteNet GLinq GL-I-1GE-1C User manual

– 1 –
Quick Start Guide
1. Unpack and Check Contents
GL-I-1GE-1C
Indoor GE to G.hn Coax Bridge AP
12 VDC Power Supply
QSG will be posted to the Web
Wall Mounting Kit
2. Mount the Bridge AP
a. Mounting on a Wall
In the required location, mark and drill two holes spaced 57
mm apart in the wall for M4 wall anchors.
Note: For a wood wall, drilling holes and using wall anchors
is not required.
Mount the unit on the wall and secure it in place using two
M4 x20 tapping screws.
b. Mounting on a Desktop
Attach the included four rubber feet to the base of the
bridge AP and place the bridge AP on the desktop.
2
1
1
2
1
11
1
1
3. Connect Power
The bridge AP can receive power from one of two different power
sources:
◆The supplied DC power adapter to the DC power jack.
◆Power over Coaxial cable (PoC) to the F-type coaxial connector
(from another IgniteNet GLinq only).
a. DC Power Jack
Plug the DC power supply into a suitable power mains
outlet.
Insert the DC power supply DIN connector into the bridge
AP’s DC power jack.
Note: When power is supplied to the DC jack and the DC
switch is set to ON, the F-type coaxial connector functions as
a 12 VDC PoC power source.
b. PoC Power
Warning:
Before connecting a coaxial cable
with power to the bridge AP, ensure the PoC DC
switches are in the OFF position on both the PoC
source bridge AP and the PoC receive bridge AP.
Caution:
To prevent damage when physically connecting a
coaxial cable, follow the instructions in step: 7. Connect
Coaxial Cable
Using the DC jack, connect power to the bridge AP that is to
supply coaxial cable power.
On both the power source and receive bridge APs connect a
coaxial cable. Refer to step: 7. Connect Coaxial Cable of this
guide on how to connect coaxial cable connectors.
2
1
2
2
13
1
2
Gigabit Ethernet to Coax bridge
GLinq GL-I-1GE-1C
www.ignitenet.com

Quick Start Guide
– 2 –
On the bridge AP that is to supply power, slide the PoC DC
switch to the ON position.
4. Verify Bridge AP Operation
Verify basic switch operation by checking the system LEDs.
When operating normally, the Power LED should be on
green, and the WiFi, Eth and G.hn LEDs should be on or
blinking green.
5. Connect an Ethernet Cable
Connect Category 5e or better cable to the RJ-45 port.
As the connection is made, check the Ethernet port status
LED to be sure the link is valid:
◆On Green — Port has a valid link.
◆Blinking Green — Indicates network activity.
6. Connect a Coaxial Cable
3
1
1
1
2
1
2
1
2
Caution: Damage may occur if an F-type cable connector
on the GLinq is overtightened. Do not tighten a connector
more than the maximum torque rating of 168 N-cm (16 lb-
in).
Note: Use only threaded male F-type compression coaxial
cable connectors to connect coaxial cable between the
bridge APs.
Note: It is NOT recommended to use Flex F or push-on
connectors. Always use standard threaded male F-
connectors.
Screw a male coaxial cable connector onto the bridge AP F-
type coaxial connector until it is finger tight. If you are using
a specialized torque wrench, tighten the connector to the
maximum specified torque of:
◆168 N-cm or 16 lb-in
As the connection is made, check the G.hn port status LED to
be sure the link is valid:
◆On Green — Port has a valid link.
◆Blinking Green — Indicates network activity.
7.Verify AP Operation
Power LED, cloud status, gateway status –
◆power connected (on)
◆no power connected (off)
WiFi–
◆radio enabled (on)
◆radio disabled (off)
◆link activity (blinking)
Ethernet –
◆plugged wire (on)
◆unplugged wire (off)
◆link activity (blinking)
G.hn –
◆coaxial cable connected (on)
◆coaxial cable disconnected (off)
◆link activity (blinking)
1
2
1
2
3
4
1
2
3
4

Quick Start Guide
– 3 –
8. Complete the Device Configuration
a. Manage the AP with the IgniteNet Cloud Controller
Go to https://cloud.ignitenet.com to register your AP. Log in and
select Devices from the menu. Click Add Device and enter the AP
serial number and MAC address to register the AP with your cloud
network. (The serial number and MAC address can be found on the
product packaging or label.)
b. Manage the AP in Stand-Alone Mode (Optional)
To access the web interface, connect a PC directly to the AP’s Eth RJ-
45 port. In a web browser, enter the AP’s default management IP
address of 192.168.1.20 to access the web login page.
If you select to manage the AP in stand-alone mode, use the web
interface to manually make your configuration changes.
For more information on AP configuration in stand-alone mode,
refer to the HeliOS User Manual, which can be downloaded from:
https://support.ignitenet.com
Note: To reset the Bridge AP to factory default settings,
press and hold down the AP’s Reset button for 5 seconds. A
quick press of the Reset button reboots the AP.
Log in to the web interface
using the default settings:
◆Login Name — root
◆Password — admin123

– 4 –
Safety and Regulatory Information
FCC Class B
This equipment has been tested and found to comply with the limits for
a Class B digital device, pursuant to Part 15 of the FCC Rules. These limits
are designed to provide reasonable protection against harmful
interference in a residential installation. This equipment generates, uses
and can radiate radio frequency energy and, if not installed and used in
accordance with the instructions, may cause harmful interference to
radio communications. However, there is no guarantee that interference
will not occur in a particular installation. If this equipment does cause
harmful interference to radio or television reception, which can be
determined by turning the equipment off and on, the user is
encouraged to try to correct the interference by one of the following
measures:
◆ Reorient or relocate the receiving antenna
◆ Increase the separation between the equipment and receiver
◆ Connect the equipment into an outlet on a circuit different from
that to which the receiver is connected
◆ Consult the dealer or an experienced radio/TV technician for help
FCC Caution: Any changes or modifications not expressly approved by
the party responsible for compliance could void the user’s authority to
operate this equipment.
This device complies with Part 15 of the FCC Rules. Operation is subject
to the following two conditions: (1) This device may not cause harmful
interference, and (2) this device must accept any interference received,
including interference that may cause undesired operation.
For product available in the USA/Canada market, only channel 1–11 can
be operated. Selection of other channels is not possible.
Quick Start Guide
IMPORTANT NOTE:
FCC Radiation Exposure Statement:
This equipment complies with FCC radiation exposure limits set forth for
an uncontrolled environment. This equipment should be installed and
operated with minimum distance 20 cm between the radiator and your
body.
Industry Canada
This device complies with Industry Canada license-exempt RSS
standard(s). Operation is subject to the following two conditions: (1) this
device may not cause interference, and (2) this device must accept any
interference, including interference that may cause undesired operation
of the device.
Le présent appareil est conforme aux CNR d'Industrie Canada
applicables aux appareils radio exempts de licence. L'exploitation est
autorisée aux deux conditions suivantes : (1) l'appareil ne doit pas
produire de brouillage, et (2) l'utilisateur de l'appareil doit accepter tout
brouillage radioélectrique subi, même si le brouillage est susceptible
d'en compromettre le fonctionnement.
For product available in the USA/Canada market, only channel 1~11 can
be operated. Selection of other channels is not possible.
Pour les produits disponibles aux États-Unis / Canada du marché, seul le
canal 1 à 11 peuvent être exploités. Sélection d'autres canaux n'est pas
possible.
CE Mark
CE Mark Declaration of Conformance for EMI and Safety (EEC)
This information technology equipment complies with the requirements
of the Council Directive 2014/30/EC on the Approximation of the laws
of the Member States relating to Electromagnetic Compatibility and
2014/35/EC for electrical equipment used within certain voltage limits.
For the evaluation of the compliance with these Directives, the following
standards were applied:

Quick Start Guide
– 5 –
IMPORTANT NOTE:
IC Radiation Exposure Statement:
This equipment complies with IC RSS-102 radiation exposure limits set
forth for an uncontrolled environment. This equipment should be
installed and operated with minimum distance 28 cm between the
radiator and your body.
Cet équipement est conforme aux limites d'exposition aux
rayonnements IC établies pour un environnement non contrôlé. Cet
équipement doit être installé et utilisé avec un minimum de 28 cm de
distance entre la source de rayonnement et votre corps.
CE Statement
This equipment complies with EU radiation exposure limits set forth for
an uncontrolled environment. This equipment should be installed and
operated with minimum distance 20 cm between the radiator and your
body.
All operational modes:
2.4 GHz: 802.11b, 802.11g, 802.11n (HT20), 802.11n (HT40)
The frequency and maximum transmitted power limit in EU are listed as
below:
2412-2472 MHz: 20 dBm
Europe - EU Declaration of Conformity
Hereby, IgniteNet Inc. declares that the radio equipment type: Indoor
Gigabit Ethernet to G.hn Coax. Bridge AP w/PoC GL-I-1GE-1C is in
compliance with Directive 2014/53/EU.
The full text of the EU declaration of conformity is available at the
following Internet address:
www.ignitenet.com -> support.
CZCYCHBGBEAT
FIESELEEDKDE
ITISIEHUHRFR
NLMTLVLULTLI
SISEROPTPLNO
UKTRSK
NCC Statement (Taiwan)
低功率電波輻射性電機管理辦法
第十二條 經型式認證合格之低功率射頻電機，非經許可，公司、商號
或使用者均不得擅自變更頻率、加大功率或變更原設計之特性及功
能。
第十四條 低功率射頻電機之使用不得影響飛航安全及干擾合法通信；
經發現有干擾現象時，應立即停用，並改善至無干擾時方得繼續使
用。前項合法通信，指依電信法規定作業之無線電通信。低功率射頻
電機須忍
受合法通信或工業、科學及醫療用電波輻射性電機設備之干擾。
Warnings and Cautionary Messages
Warning: This product does not contain any serviceable user
parts.
Warning: Installation and removal of the unit must be carried
out by qualified personnel only.
Warning: The F-type Coaxial Connector can conduct up to 2.5
amperes of DC currentif power is supplied to the unit and its DC
switch is in the ON position.
Warning: If applying DC voltage to a coaxial cable using the
GLinq, you must ensure that all connected devices are capable
of sustaining a DC voltage applied to their coaxial input without
damage.
Caution: Wear an anti-static wrist strap or take other suitable
measures to prevent electrostatic discharge when handling this
equipment.
Caution: Do not plug a phone jack connector in the RJ-45
port. This may damage this device.
Caution: Use only twisted-pair cables with RJ-45 connectors
that conform to FCC standards.

Quick Start Guide
– 6 –
Hardware Specifications
Chassis
131 x 100 x 26 mm (35.16 x 3.94 x 1.02 in)Size (WxDxH)
277 g (0.61 lb)Weight
Operating: 0° C to 50° C (32 F to 122° F)Temperature
Storage: -40° C to 70° C (-40° F to 158° F)
Operating: 5% to 90% (non-condensing)Humidity
Network Ports ◆One 1000BASE-T RJ-45 PoE port
◆One 2 Gbps G.hn F-type Coaxial
Connector
Power, Wireless 2.4 GHz, Ethernet, G.hnStatus LEDs
Power
12 – 54 VDC, 1.0 ADC Input Power
Coaxial Cable Input
Power 12 VDC, 1.0 A
Maximum Coaxial
Cable Output
Current
2.5 A
Power Consumption 6.5 W maximum
Standards
Ethernet
Wireless
G.hn Coax.
IEEE 802.3ab 1000BASE-T
IEEE 802.11b/g/n 2.4 GHz with 2x2 MIMO
ITU-T G.hn G.9960, G9961 bandplan: 25 MHz,
50 MHz, 100 MHz, 200 MHz (max. 2 Gbps)
Regulatory Compliance
Radio Frequencies 2412–2472 (FCC, IC, CE, AU, MIC, NCC, SRRC)
Immunity EN 55024:2010
IEC 61000-4-2/3/4/5/6/8/11
Manufacturer Accton Technology Corporation
1, Creation 3rd Rd., Hsinchu Science Park,
Hsinchu 30077,
Taiwan, R.O.C
E102018-KS-R01
150200002019X
