Ihse Draco 485-BC Specification sheet

Excellence in KVM and Video
Manual
We continue to develop and improve our products, adding new
functions and features on a regular basis, so we want you to always
have the latest manual. For this reason, we do not include a manual
in an electronic or printed form but kindly ask you to download the
latest manual using the following link:
http://www.ihse.de/leadmin/redakteur/pdf/manuals/m485.pdf
Draco vario
Repeater
Quick Setup
Series 485
Quick Setup Quick SetupQuick Setup
3. Technical Support
Prior to contacting support please ensure you have read the quick
setup, the manual, and then installed and set-up your device as
recommended.
3.1 Support Checklist
To efciently handle your request it is necessary to complete our
checklist for support and problem cases.
http://www.ihse.de/leadmin/redakteur/pdf/support/checklist.pdf
Please keep the following information available before you call:
■Company, name, phone number and email
■Type and serial number of the device (see bottom of device)
■Date and number of sales receipt, name of dealer if necessary
■Issue date of the existing manual
■Nature, circumstances and duration of the problem
■Involved components (such as graphic source/CPU, OS, gra-
phic card, monitor, USB-HID/USB 2.0 devices, interconnect
cable) including manufacturer and model number
■Results from any testing you have done
3.2 Shipping Checklist
1. To return your device, contact your dealer to obtain a RMA
number (Return-Material-Authorization).
2. Package your devices carefully, preferably using the original
box. Add all pieces which you received originally.
3. Note your RMA number visibly on your shipment.
Devices that are sent in without a RMA number cannot be
accepted. The shipment will be sent back without being
opened, postage unpaid.
!
IHSE GmbH
Maybachstrasse 11
88094 Oberteuringen
Germany
Phone [phone]
Fax [phone]
Web www.ihse.de
E-Mail [email protected]
Skype ihse.support
Oce hours:
Monday - Thusday 8:00 am to 4:30 pm
Friday 8:00 am to 3:00 pm
Draco vario Repeater Series 485 Draco vario Repeater Series 485Draco vario Repeater Series 485

1 2 4 5 83 7 96
1 2 4 53 761 2 4 53 76
1234 5
12 345
12345
2.3 Status LEDs
Status Draco vario Repeater Module
The Draco vario Repeater module is tted with a multi color LED for
overall status indication and with two further LEDs for indication of
the connection status.
1. System Setup
First time users are recommended to setup the system in
the same room as a test setup. This will allow you to identify
and solve any cabling problems, and experiment with your
system more conveniently.
Please verify that interconnect cables, interfaces, and
handling of the devices comply with the requirements (see
manual Chapter 7, Page 57).
Draco vario Repeater Setup
1. Switch off all devices.
2. Connect the Draco vario Repeater with the interconnect
cable(s).
3. Connect the chassis of the Draco vario Repeater to the
power supply.
4. Power up the system.
To power up the system, the following sequence is
recommended:
Monitor – CON Unit – Draco vario Repeater – CPU Unit –
source.
!
!
Quick Setup Quick SetupQuick Setup
!
Draco vario Repeater Series 485 Draco vario Repeater Series 485Draco vario Repeater Series 485
2. Specifications
2.1 Package Contents
Your extender package contains the following items:
■Draco vario Repeater
■1x (redundancy 2x) 5VDC international power supply unit
per KVM Extender unit (depending on chassis)
■1x (redundancy 2x) country-specic power cord (depending
on chassis)
■Quick Setup
If anything is missing, please contact your dealer.
Module Module
Rear View Rear View
LED 1/2 and 4/5: Connection Status
Pos. LED Status Description
1/4 Failure LED
(green)
Off Connection available
On or
Flashing
Connection failure (ashing
for about 20 s following a
connection failure)
2/5 Status LED
(green)
Flashing No connection via interconnect
cable
on Connection available
LED 3: Device Status
LED color Description
Red Device ready
Blue Link 1 (left connector) available,
Link 2 (right connector) not detected
Green Link 2 (right connector) available,
Link 1 (left connector) not detected
Light
Blue
Link 1 (left connector) and
Link 2 (right connector) available
2.2 System Overview
Repeater Function (optional: Media Conversion)
1. Source (computer, CPU)
2. KVM Extender CPU Unit
3. Interconnect cable (Cat X)
4. Draco vario (Cross) Repeater
5. Interconnect cable (Cat X / ber)
6. KVM Extender CON Unit
7. Console (monitor, keyboard, mouse)
Dual Media Conversion
1. Source (computer, CPU)
2. KVM Extender CPU Unit
3. Interconnect cable (Cat X)
4. Draco vario Cross Repeater #1
5. Interconnect cable (ber)
6. Draco vario Cross Repeater #2
7. Interconnect cable (Cat X)
8. KVM Extender CON Unit
9. Console (monitor, keyboard, mouse)
