Ikelite 4077.67 Specification sheet

Base with Left Quick Release Handle for DL and FL
Housings
Product # 4077.67
Base with Dual Quick Release Handles for DL and FL
Housings
Product # 4077.68

2
About this Product
Thank you for your purchase of Ikelite equipment. Please read this
instruction manual completely before attempting to operate or dive
with this product.
Important Information
»The Base with Quick Release Handle(s) is designed primarily
for DL and FL housings, but can be attached to any Ikelite
housing using the hardware included.
»An Anti-rotational Pad is included when attaching the Base to
a Non-Ikelite housing with a single 1/4-20 mount.
»A 1/4-20 threaded mouting point is located in the center of the
Base to allow attachment to a Tripod.

3
Included in the Box
Qty. 2 - # 0212.16 1/4” Nylon Washer
Qty. 4 - # 0245.2 3/8” Nylon Washer
Qty. 2 - # 0212.12 1/4” Shoulder Washer for 12-24 Screw
Qty. 2 - # 0212.14 1/4” Shoulder Washer for 1/4-20 Screw
Qty. 2 - # 0213.38 1/4-20 x 3/8” Screw
Qty. 1 - # 0220.2 1/4-20 x 5/8” Screw
Qty. 2 - # 0333.6 12-24 x 1/2” Screw
Qty. 1 - # 0945.18 Hex Key
# 0399.02 Spacer
# 0399.03 Anti-rotation Pad
Base # 4077.66
Qty. 2 - # 0219.5 3/8-16 Hex Nut
# 4077.01 Left Handle
with Extension
# 4077.02 Right Handle
with Extension (NOT
included with # 4077.67)

4
Contents
About this Product 2
Important Information 2
Included in the Box 3
Attach Base to DL or FL Housing 5
Attach Base to Compact Housing with 3/8-16 Bolts 6
Attach Base to Compact Housing with Threaded Mounts 7
Attach Base to ULTRAcompact Housing with Threaded Mounts 8
Attach Base to Non-Ikelite Housing with 1/4-20 Threaded Mount 10
Limited Warranty 11
Contact Us 12

5
Attach Base to DL or FL Housing
1. Determine the correct thread type for your housing mounts. ALL
white housings use 1/4-20 x 3/8” screws. Most clear and older
housings use 12-24 x 1/2” screws. 1/4-20 screws will not thread into
a smaller 12-24 size mount.
CAUTION: Using the incorrect screws could damage your housing
mounts.
2. Once the correct screws have been selected, place your Ikelite
DSLR housing upside down on a at surface or on your lap.
3. Line up the 3/8” tray holes with the housing mounts. If the tray is
positioned properly, the Quick Release Buttons will be extending
toward the rear of the housing.
4. Place a shoulder washer in the holes corresponding to the housing
mount holes, with the small end of each washer facing down.
5. With your free hand, insert and rotate the correct screws clockwise
until threaded into the housing mounts. Finish tightening the base
to the housing using a athead screwdriver. DO NOT overtighten.
IKELITE
Quick Release Button
1/4-20 x 3/8” Screw1/4” Shoulder Washer 1/4-20

6
Attach Base to Compact Housing with 3/8-16 Bolts
1. Place your Ikelite Compact Housing upside down on a at surface
or on your lap.
2. Peel protective lm off # 0399.02 Spacer to expose adhesive. Place
Spacer over Housing Mounting Bolts with adhesive side facing up.
Protective Backing
(peel off before use)
3. Line up the base holes with the 3/8” housing bolts. If the tray is
positioned properly, the Quick Release Buttons will be extending
toward the rear of the housing.
Quick Release Button
3/8-16 Hex Nut3/8” Nylon Washer

7
4. Slide Tray into position over the Spacer and press rmly for a
couple seconds. This will allow the Spacer to cling to the base.
5. With your free hand, slide the 3/8” nylon washers over the Housing
Mounting Bolts and tighten base using both 3/8-16 Hex Jam Nuts.
Finish tightening the base to the housing using a 9/16” open end or
socket wrench. DO NOT overtighten.
Attach Base to Compact Housing with Threaded Mounts
1. Determine the correct thread type for your housing mounts. ALL
white housings use 1/4-20 x 3/8” screws. Most clear and older
housings use 12-24 x 1/2” screws. 1/4-20 screws will not thread into
a smaller 12-24 size mount.
CAUTION: Using the incorrect screws could damage your housing
mounts.
2. Once the correct screws have been selected, place your Ikelite
Compact Housing upside down on a at surface or on your lap.
Quick Release Button
1/4-20 x 3/8” Screw
1/4” Shoulder Washer

8
3. Line up the 3/8” tray holes with the housing mounts. If the base is
positioned properly, the Quick Release Buttons will be extending
toward the rear of the housing.
4. Place a shoulder washer in the holes corresponding to the housing
mount holes, with the small end of each washer facing down.
5. With your free hand, insert and rotate the correct screws clockwise
until threaded into the housing mounts. Finish tightening the base
to the housing using a athead screwdriver. DO NOT overtigthen.
Attach Base to ULTRAcompact Housing with Threaded Mounts
1. Determine the correct thread type for your housing mounts. ALL
white housings use 1/4-20 x 3/8” screws. ALL clear and older
housings use 12-24 x 1/2” screws. 1/4-20 screws will not thread into
a smaller 12-24 size mount.
CAUTION: Using the incorrect screws could damage your housing
mounts.
2. Once the correct screws have been selected, place your Ikelite
ULTRAcompact Housing upside down on a at surface or on your
lap.

9
3. Line up the 3/8” tray holes with the housing mounts. If the Base is
positioned properly, the Quick Release Buttons will be extending
toward the rear of the housing.
Quick Release Button
1/4-20 x 3/8” Screw
1/4” Shoulder Washer
4. Place two shoulder washers in the holes corresponding to the
housing mount holes, with the small end of each washer facing
down.
5. With your free hand, insert and rotate the correct screws clockwise
until threaded into the housing mounts. Finish tightening the base
to the housing using a athead screwdriver. DO NOT overtighten.

10
Attach Base to Non-Ikelite Housing with 1/4-20 Threaded Mount
Protective Backing
(peel off before use)
1. Remove the protective backing from the Anti-rotational Pad.
2. Line up the pad hole with the larger non-threaded center base hole
and place the adhesive side down on the base.
3. Line up center base hole with the housing mount hole. If the base is
positioned properly, the Quick Release Buttons will be extending
toward the rear of the housing.
Quick Release Button
1/4-20 x 5/8” Screw
1/4” Nylon Washer

11
4. With your free hand, insert and rotate the 1/4-20 X 5/8” screw
clockwise until threaded into the housing mount. Finish tightening
the base rmly to the housing using a athead screwdriver. DO
NOT overtighten.
Note: Since the housing base is designed for Ikelite Housings, any
excessive pressure applied to either side of a Non-Ikelite housing
may cause slight rotation or movement of the housing on the base.
Also, make sure the screw does not bottom out on the housing
bottom causing damage. Additional nylon washers should be used
if necessary.
Limited Warranty
This Ikelite product is warranted against any manufacturing defects for
a period of one (1) year from the original date of purchase. To obtain
warranty service, the product must be returned to Ikelite postage paid.
Ikelite will, at its sole discretion, repair or replace such products, and
will return to customer postage paid. All other claims of any nature
are not covered. Except as mentioned above, no other warranty
expressed or implied applies to this Ikelite product.
