Ikelite 6214.08 Sony DSC-WX80 Owner's manual

Digital Housing
Supplemental Instructions
6214.08 Sony DSC-WX80
Size and Weight
Width ......................5.8 in. (147mm) including controls
Height ....................4.6 in. (117mm) including controls
Depth ......................4.4 in. (112mm) including controls & lens port
Weight ....................1.5 lb (680g)
Buoyancy ................Slightly positive in freshwater

ULTRAcompact
Made in USA
6
7
1
1
3
9
2
8
4 5
2
Parts of the Housing
Front View N/ FF Button
1. Movie Button
2. DISP
3. Shooting Settings
Note: No control is provided for the Mode Switch or Control Wheel. Use the
Movie Button to switch between shooting modes.
4. Set
5. Flash
6. Self-timer
Lanyard
Tray Mounts
7. MENU Button
8. Delete
9. Playback
Back View
Latch
Lens Port
Shutter
Button
Zoom Lever

3
Initial Camera Settings (before placing camera in housing)
- Insert and Format a high capacity SD or SDHC memory card.
- Set Date and Time.
- Set REC Mode to “P” Program Auto.
- Set Still Image Size to “16 M.”
- Set IS to “200.”
- Set White Balance to “WB Auto.”
- Set Focus to “Center AF.”
- Set Metering Mode to “Center.”
- Set Smile Shutter to “ ff.”
- Set Movie Quality to “FH” and Still Image Size to “12M.”
- Set Movie SteadyShot to “ACT.”
- Set AF Illuminator to “ ff.”
- Set Digital Zoom to “ ff.”
- Set Red-Eye Reduction and Blink Alert to “ ff.”
- Set Flash to “ n Always use flash.”
NOTE: If overexposure occurs, use “-” exposure compensation “EV” and/or
back away from your subject and zoom in. When using an AF35 strobe
or manual controller, turn the power down.
External Macro Adaptor 9306.82
Allows attachment of 67mm threaded macro lenses from Inon and
Epoque. N T for use with 67mm threaded wide-angle lenses.
WD-4 Wide-Angle Conversion Dome 6430.4
The removeable WD-4 corrects light refraction underwater,
restoring the camera’s original angle of coverage. Approximately
3/4 of the camera's zoom range can be used with the dome in
place. Slight vignetting may occur at camera’s widest angle setting.
Note: ther wide angle conversion or accessory lenses cannot be used
with this housing.

6214.08_Sony_DSC-WX80_1-0713
AF35 Strobe Package 4035
The AutoFlash AF35 kit is a great compliment, and
an effortless, affordable way to add a flash to your
new Ikelite point and shoot camera system.
Everything you need to get started is in the box.
Just attach it to the bottom of your housing and
start taking pictures!
AF35 AutoFlash kit includes:
AF35 strobe - Flex arm - AutoFlash sensor
Handle with rubber grip - Tray (single or dual)
Mounting hardware.
ikelite
35
AF
ikelite
AUTOFLASH
A full range of accessories is available to support your housing. Please
visit http://www.ikelite.com to see the most current information about
recommended accessories for your housing.
Customer Support
Please read the troubleshooting section of the “Instruction Manual”
before contacting Ikelite.
Ikelite nderwater Systems
50 West 33rd Street
Indianapolis, IN 46208 SA
www.ikelite.com
© 2013 Ikelite Underwater Systems
