iKey PM-1000 User manual

Part Number: PM-1000 and PM-5K
Drawing Title: MOUNTING INSTRUCTIONS Date: 01.29.02
Sheet:
JKH
Drawing Number: XXXX
Revision: 1.000
ph: [phone]

fx: [phone]
©2002 IKEY,LTD
iKey, ltd.

2621 Ridgepoint Dr. Ste 235

Austin, Texas 78754
1 OF 1
REAR COVER
8-32 TH'D 
STUD
Brackets
Hexnuts
8
1
3
6
13
10
12
7
2
4
5
14
9
11
REAR COVER
Bracket
Bracket
Bracket
Bracket
1. PLACE UNIT IN 7.9"X16.4" CUT PIT
2. PLACE 4 BRACKETS ON EACH SIDE AND HAND TIGHTEN LOCKING HEXNUTS OVER ALL 14 8-32 STUDS
3. TIGHTEN WITH TORQUE WRENCH (18-20 IN.LB.) IN ORDER SHOWN ABOVE
TOP VIEW
SIDE VIEW
16.400"
7.900"
CUTOUT
CUTOUT
