Airswitch Installation Instructions
Model : ASC

READ THIS INSTURCTION MANUAL CAREFULLY
BEFORE INSTALLING AND USING THIS PRODUCT.
PLEASE KEEP THESE INSTRUCTIONS HANDY FOR
FUTURE REFERENCE
IMPORTANT
Always operate the product from a power source of the same
voltage, frequency and rating as what is indicated on the product
identification label. You can find this label on the bottom of the
airswitch.
Do NOT operate this product if the power cord is damaged, or
the product appears damaged in any manner.
Do NOT immerse or expose any part of this product in any
liquid, or expose the electrical part to any moisture, or located
the electrical part near basins or other vessels containing water
or other liquid.
INSTALLATION AND USAGE
This product contains four components, including:
Button (in silver chrome finish)
Spare button cover in alternative finish (white)
Air tube
Airswitch including cord and three-pin plug
To change the colour of the bellows button and surround, grasp
the body of the bellows and pull the surround (outer ring) from
the bellows body. The button assembly can then be removed
from the bellows body, remove and replace with the preferred
colour and reassemble into the bellows body.
To install the button, drill a 33mm hole into the work surface or
sink, at the preferred position of the working bench. Remove
the back nut and the washer first, then fit the button through the
hole. Fits the large washer back on, then the back nut, hand
tighten only.
Mount the airswitch adjacent to the product to be controlled in a
dry location vertically. Then connect the airswitch and the
button with the air tube provided.
Plug the airswitch into an AC power point (ensuring the power
point is grounded properly). This power point should be of the
same voltage, frequency and Rating with that on the product
identification label. Make sure the AC power point is
switched off.
Plug the product to be controlled into the airwitch 3-pin socket.
Turn on the AC power point. Press the button to control (turn
on / off) the product.
This product is under 1 year return to base warranty.
