iLive IHTB059B User manual

5.1 Home Theater System with Bluetooth
User’s Guide for Model IHTB059B v2572-01
For the most up-to-date version of this User’s Guide, go to www.iliveelectronics.com
IHTB059B-2572-01-IB.indd 1 17/08/2020 3:00:28 PM

2
Important Safety Instructions
• ReadtheseInstructions.
• KeeptheseInstructions.
• HeedallWarnings.
• Followallinstructions.
• Donotusethisapparatusnearwater.
• Cleanonlywithadrycloth.
• Donotblockanyventilationopenings.Installinaccordance
withthemanufacturer’sinstructions.
• Donotinstallnearanyheatsourcessuchasradiators,heat
registers,stoves,orotherapparatus(includingampliers)
thatproduceheat.
• Donotdefeatthesafetypurposeofthepolarizedor
grounding-typeplug.Apolarizedplughastwobladeswith
onewiderthantheother.Agroundingtypeplughastwo
bladesandathirdgroundingprong.Thewidebladeorthe
thirdprongareprovidedforyoursafety.Whentheprovided
plugdoesnottintoyouroutlet,consultanelectricianfor
replacementoftheobsoleteoutlet.
• Protectthepowercordfrombeingwalkedonorpinched
particularlyatplugs,conveniencereceptacles,andthepoint
wheretheyexitfromtheapparatus.
• Onlyuseattachments/accessoriesspeciedbythe
manufacturer.
• Unplugthisapparatusduringlightningstormsorwhen
unusedforlongperiodsoftime.
• Referallservicingtoqualiedservicepersonnel.Servicing
isrequiredwhentheapparatushasbeendamagedinany
way,suchaspower-supplycordorplugisdamaged,liquid
hasbeenspilledorobjectshavefallenintotheapparatus,
theapparatushasbeenexposedtorainormoisture,doesnot
operatenormally,orhasbeendropped.
• Useonlywithacart,stand,tripod,bracket,
ortablespeciedbythemanufacturer,or
soldwiththeapparatus.Whenacartis
used,usecautionwhenmovingthecart/
apparatuscombinationtoavoidinjury
fromtip-over.
Safety Instructions & Warnings
FCC Warnings
Warning:Changesormodicationstothisunitnotexpressly
approvedbythepartyresponsibleforcompliancecouldvoidthe
user’sauthoritytooperatetheequipment.
NOTE:Thisequipmenthasbeentestedandfoundtocomply
withthelimitsforaClassBdigitaldevice,pursuanttoPart
15oftheFCCRules.Theselimitsaredesignedtoprovide
reasonableprotectionagainstharmfulinterferenceina
residentialinstallation.Thisequipmentgenerates,uses,andcan
radiateradiofrequencyenergyand,ifnotinstalledandusedin
accordancewiththeinstructions,maycauseharmfulinterference
toradiocommunications.However,thereisnoguaranteethat
interferencewillnotoccurinaparticularinstallation.Ifthis
equipmentdoescauseharmfulinterferencetoradioortelevision
reception,whichcanbedeterminedbyturningtheequipmento
andon,theuserisencouragedtotrytocorrecttheinterference
byoneormoreofthefollowingmeasures:
• Reorientorrelocatethereceivingantenna.
• Increasetheseparationbetweentheequipmentandreceiver.
• Connecttheequipmentintoanoutletonacircuitdierent
fromthattowhichthereceiverisconnected.
• Consultthedealeroranexperiencedradio/TVtechnician
forhelp.
IHTB059B-2572-01-IB.indd 2 17/08/2020 3:00:29 PM

3
Battery Warnings
• WARNING:Donotingestthebattery,ChemicalBurn
Hazard.
• Iftheremotecontrolsuppliedwiththisproductcontainsa
coin/buttoncellbatteryandthecoin/buttoncellbatteryis
swallowed,itcancausesevereinternalburnsinjust2hours
andcanleadtodeath.
• Keepnewandusedbatteriesawayfromchildren.Ifthe
batterycompartmentdoesnotclosesecurely,stopusingthe
productandkeepitawayfromchildren.
• Ifyouthinkbatteriesmighthavebeenswallowedor
placedinsideandpartofthebody,seekimmediatemedical
attention.
• CAUTION:Dangerofexplosionifbatteryisincorrectly
replaced.Replaceonlywiththesameorequivalenttype.
• WARNING:Thereisadangerofexplosionifyouattempt
tochargestandardAlkalinebatteriesintheunit.Onlyuse
rechargeableNiMHbatteries.
• Batteryshallnotbeexposedtoexcessiveheatsuchas
sunshine,reorthelike.
• Donotmixoldandnewbatteries.
• Completelyreplacealloldbatterieswithnewones.
• Donotmixalkaline,standard(carbon-zinc),orrechargeable
(ni-cad,ni-mh,etc)batteries.
• Batteriesshouldberecycledordisposedofasperstateand
localguidelines.
Additional Warnings and Precautions
• CAUTION:TOPREVENTELECTRICSHOCK,MATCH
WIDEBLADEOFPLUGTOWIDESLOT,FULLY
INSERT.
• Mainsplugisusedasdisconnectdeviceanditshouldremain
readilyoperableduringintendeduse.Inordertodisconnect
theapparatusfromthemainscompletely,themainsplug
shouldbedisconnectedfromthemainssocketoutlet
completely.
• CAUTION:Useofcontrolsoradjustmentsorperformance
ofproceduresotherthanthosespeciedmayresultin
hazardousradiationexposure.
• WARNING:Changesormodicationstothisunitnot
expresslyapprovedbythepartyresponsibleforcompliance
couldvoidtheuser’sauthoritytooperatetheequipment.
• WARNING:Useofthisunitnearuorescentlightingmay
causeinterferenceregardinguseoftheremote.Iftheunitis
displayingerraticbehaviormoveawayfromanyuorescent
lighting,asitmaybethecause.
• WARNING:Shockhazard-DoNotOpen.
• Cautionandmarkinginformationislocatedattherearor
bottomoftheapparatus.
• WARNING:Toreducetheriskofreorelectricshock,
donotexposethisapparatustorain,moisture,dripping,or
splashing.
• Objectslledwithliquids,suchasvases,shallnotbeplaced
ontheapparatus.
WARNING:Toreducetheriskofelectric
shock,donotremovecover(orback).No
user-serviceablepartsinside.Referservicing
toqualiedservicepersonnel.
ATTENTION
RISQUE D' ÉLECTROCUTION
NE PAS OUVRIR
CAUTION
RISK OF ELECTRIC SHOCK
DO NOT OPEN
Theexclamationpointwithinanequilateral
triangleisintendedtoalerttheuserto
thepresenceofimportantoperatingand
maintenance(servicing)instructionsinthe
literatureaccompanyingtheappliance.
Thissymbolindicatesthatthisproduct
incorporatesdoubleinsulationbetween
hazardousmainsvoltageanduseraccessible
parts.
Thelightningashwitharrowheadsymbol,
withinanequilateraltriangle,isintendedto
alerttheusertothepresenceofun-insulated
“dangerousvoltage”withintheproduct’s
enclosurethatmaybeofsucientmagnitude
toconstituteariskofelectricshocktopersons.
WARNING : Thisproductcanexposeyou
tochemicalsincludinglead,whichisknown
totheStateofCaliforniatocausecancerand
birthdefectsorotherreproductiveharm.For
moreinformationgotowww.P65Warnings.
ca.gov.This product meets and complies
with required Federal product guidelines.
IHTB059B-2572-01-IB.indd 3 17/08/2020 3:00:29 PM

4
Setup
Features
• Bluetooth Wireless - range 60 ft.
• Voice prompts announce speaker functions
• 6, 5.1 surround sound audio inputs
• 2 stereo audio inputs
Includes
• Subwoofer (main unit)
• 5 wired satellite speakers
• Remote control: requires CR2025 battery (included)
• RCA stereo audio cable
• AC/DC power adapter
IHTB059B-2572-01-IB.indd 4 17/08/2020 3:00:29 PM

5
Connect Satellite Speakers
Connect each speaker wire with the corresponding port on the rear of the
subwoofer. Be sure to match the plugs to the correct port or the speakers
will not function properly.
SPEAKER
OUTPUT
SUB
SR
FR
R
CEN
SL
FL
L
CEN
SL
FR
FL
SR
AUX IN
DC IN
SPEAKER
OUTPUT
SUB
SR
FR
R
CEN
SL
FL
L
CEN
SL
FR
FL
SR
AUX IN
DC IN
Power
Plug the AC/DC power adapter (included) into a standard
wall outlet and the DC power input on the rear of the
subwoofer.
Setup
IHTB059B-2572-01-IB.indd 5 17/08/2020 3:00:30 PM

6
Subwoofer Front View
Orientation
POWER
VOL – VOL +
BASS – BASS +
Volume Dial
Turn to adjust
volume level.
Speaker Status Indicator Light
Power ON Red Light
Bluetooth Pairing Rapid Flashing Blue Light
Bluetooth Connected Solid Blue Light
Aux In Slowly Fading Purple Light
5.1 Surround Sound Mode Solid Purple Light
LED Indicator Light
Power/Source
Press to power ON.
Press and hold to
power OFF.
Press to switch
between Bluetooth,
Aux In, and 5.1
Surround Sound
Modes.
Pair
Press and hold to
begin pairing to a
Bluetooth device.
Bass Dial
Turn to adjust
the bass level.
Remote Receiver
IHTB059B-2572-01-IB.indd 6 17/08/2020 3:00:30 PM

7
Subwoofer Rear View
Stereo Audio Inputs
DC Power Input
Audio Outputs
(to speakers)
SPEAKER
OUTPUT
SUB
SR
FR
R
CEN
SL
FL
L
CEN
SL
FR
FL
SR
AUX IN
DC IN
IHTB059B-2572-01-IB.indd 7 17/08/2020 3:00:30 PM

8
Remote
Functions
Note: When using the remote, be sure to aim at the remote
signal receiver located on the front of the subwoofer.
Remote Batteries
Requires 1 CR2025 battery (pre-installed).
Power
Press to turn
the system ON or OFF.
Mute
Press to mute
the volume.
Aux
Press to switch to Aux In (RCA)
Mode.
5.1CH
Press to switch
to 5.1 Surround Sound Mode.
Press to switch
to Bluetooth Mode.
Skip Back/Fwd
In Bluetooth Mode, press to skip
the selected track.
Pair/Play/Pause
Press and hold to begin pairing to a
Bluetooth device.
Press to play or pause the selected
track (BLUETOOTH).
Center/Sub/Surround
Press to adjust volume for
individual speakers.
Volume-/+
Press to adjust volume for all
speakers.
IHTB059B-2572-01-IB.indd 8 17/08/2020 3:00:31 PM

9
Bluetooth Wireless
Pairing & Playing Audio
1. When the system first powers ON it defaults to Bluetooth Mode and is ready to pair automatically. When pairing,
remain within 3 feet of the Bluetooth device.
2. Using the controls on your Bluetooth device, select IHTB059 in the Bluetooth Settings to pair. If need be, refer to
the user’s manual for your specific device for more information.
3. When successfully paired, a voice will announce,“Bluetooth is connected.”Your Bluetooth device will now be
heard through the speaker.
4. Use the controls on the connected Bluetooth device to select and play audio. Use the subwoofer controls or the
connected Bluetooth device to play, pause, skip, and adjust the volume level.
After initial pairing, the speaker will automatically connect to the last Bluetooth device used whenever it is in
Bluetooth Mode. If your device should become unpaired or you find it is unable to connect, press & hold the Pair
button to enter to Pairing Mode. The blue pairing indicator will flash quickly, a voice will announce, “Bluetooth is
connecting,” and you can then connect to the speaker manually.
IHTB059B-2572-01-IB.indd 9 17/08/2020 3:00:31 PM

10
6 Port 5.1 Surround Sound RCA Inputs (5.1 CH)
If your TV, DVD, or other media player has 6 ports of audio output, use the 6 lower audio inputs on the rear of the
subwoofer for 5.1 surround sound audio.
Requires RCA stereo audio cables (not included).
1. Using an RCA stereo audio cable, connect your media player’s Surround Sound stereo outputs to the to the
Surround Sound inputs on the subwoofer. When connecting the audio cables, match the colored plugs to the
same colored ports.
2. With the unit powered ON, select Surround Sound Mode through the Source button on the subwoofer or
through the 5.1CH button on the remote. A voice prompt and a solid purple light will indicate that Surround
Sound Mode has been selected.
SUB
SR
FR
R
CEN
SL
FL
L
CEN
SL
FR
FL
SR
SPEAKER
OUTPUT
AUX IN
DC IN
Audio Input Audio Channel
FL / FR Front Left / Front Right
SL / SR Surround Left / Surround Right
CEN Center
Audio Inputs
IHTB059B-2572-01-IB.indd 10 17/08/2020 3:00:31 PM

11
2 Port Stereo RCA Inputs (Aux)
If your TV, DVD, or other media player has only 2 ports of audio output, use the top 2 audio inputs (Left/Right
channel) on the rear of the subwoofer for stereo audio.
Requires an RCA stereo audio cable (included).
1. Using an RCA stereo audio cable, connect your media player’s RCA stereo outputs to the to the RCA stereo
inputs on the subwoofer. When connecting the audio cables, match the colored plugs to the same colored ports.
2. With the unit powered ON, select Aux Mode through the Source button on the subwoofer or through the Aux
button on the remote. A voice prompt and a slowly fading purple light will indicate that Aux Mode has been
selected.
SPEAKER
OUTPUT
SUB
SR
FR
R
CEN
SL
FL
L
CEN
SL
FR
FL
SR
AUX IN
DC IN
IHTB059B-2572-01-IB.indd 11 17/08/2020 3:00:31 PM

12
Contact Information
Website: www.iLiveElectronics.com
Email Support: [email protected]
Email Parts: [e-mail]
Phone Support: 1-888-999-4215
Warranty
For Warranty Information and the most up-to-date version of this
User’s Guide, go to: www.iLiveElectronics.com
International Support
To download this User’s Guide in English, Spanish, and French, or to get
answers to frequently asked questions, visit the support section at:
www.iLiveElectronics.com
Para descargar este Manual del Usuario en inglés, español y francés, o para obtener respuestas a preguntas
frecuentes, visite la sección de apoyo en: www.iLiveElectronics.com
Pour télécharger ce guide de l’utilisateur en anglais, espagnol ou français, ou pour obtenir des réponses à des
questions fréquemment posées, consultez la rubrique d’assistance sur: www.iLiveElectronics.com
Copyright © 2020 Digital Products International (DPI, Inc.) All other trademarks appearing herein are the property
of their respective owners. Specifications are subject to change without notice.
Customer Support
Protect for Today
Sustain for Tomorrow
Made
Green
IHTB059B-2572-01-IB.indd 12 17/08/2020 3:00:31 PM
