iLive IS809B User manual

IS809B
Wireless Music System with Dock for iPod
TABLE OF CONTENTS
Warnings and Precautions....................................................................... 2
Important Safety Instructions.................................................................. 3
In the Box & Features............................................................................. 4
Powering the Unit ................................................................................... 5
Backup Batteries for the Unit ................................................................. 5
Powering the Speakers & Changing the Remote Battery ....................... 6
Pairing Speakers with the Unit ............................................................... 7
Docking an iPod & Playing an iPod ....................................................... 8
Setting the Clock..................................................................................... 8
Setting the Timer & Setting the Sleep Timer .......................................... 9
Using the Auxiliary Input........................................................................ 9
Locations of Controls & Definitions................................................10-15
Parts & Service Information ................................................................. 16

2
Warnings and Precautions
WARNING: Use of this unit near uorescent lighting may cause interference regarding use of the remote.
If the unit is displaying erratic behavior move away from any uorescent lighting, as it may be the cause.
WARNING: To prevent re or shock hazards, do not expose this unit to rain or moisture.
Do not mix old and new batteries.
Do not mix alkaline, standard (carbon-zinc), or rechargeable (ni-cad, ni-mh, etc) batteries.
WARNING: The remote control’s button cell battery contains mercury. Do not put in the trash, instead
recycle or dispose of as hazardous waste
CAUTION: Danger of explosion if battery is incorrectly replaced. Replace only with the same or
equivalent type.
PRÉCAUTION: Danger d’explosion si les piles sont remplacées de façon incorrect. Remplacer les piles
seulement par le même type de pile ou l’équivalent.
WARNING: Changes or modications to this unit not expressly approved by the party responsible for
compliance could void the user’s authority to operate the equipment.
NOTE: This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to Part 15
of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residential
installation. This equipment generates, uses, and can radiate radio frequency energy and, if not installed and used in
accordance with the instructions, may cause harmful interference to radio communications. However, there is no guarantee
that interference will not occur in a particular installation. If this equipment does cause harmful interference to radio or
television reception, which can be determined by turning the equipment off and on, the user is encouraged to try to correct
the interference by one or more of the following measures:
• Reorient or relocate the receiving antenna.
• Increase the separation between the equipment and receiver.
• Connect the equipment into an outlet on a circuit different from that to which the receiver is connected.
• Consult the dealer or an experienced radio/TV technician for help.
This symbol, located on back or
bottom of the unit, is intended to alert
the user to the presence of uninsulated
“dangerous voltage” within the
product’s enclosure that may be of
sufcient magnitude to constitute a
risk of electric shock to persons.
This symbol, located on back or
bottom of the unit, is intended to alert
the user to the presence of important
operating and maintenance (servicing)
instructions in the literature
accompanying the appliance.
CAUTION: TO PREVENT ELECTRIC SHOCK, MATCH WIDE BLADE OF PLUG TO WIDE SLOT,
FULLY INSERT.
To reduce the risk of electric shock, do not remove cover (or back). There are no user-serviceable parts
inside. Please refer any servicing to qualied service personnel.

3
Important Safety Instructions
1. Read Instructions - All the safety and operating
instruction should be read before the product is
operated.
2. Retain Instructions - The safety and operating
instruction should be retained for future reference.
3. Heed Warnings - All warning on the product and
in the operating instructions should be adhered to.
4. Follow instructions - All operating and use
instructions should be followed.
5. Cleaning - Unplug this product from the wall
outlet before cleaning. Do not use liquid cleaners
or aerosol cleaners. Clean only with a dry cloth.
6. Attachments - Do not use attachments not
recommended by the product manufacturer as they
may cause hazards.
7. Water and Moisture - Do not use this product
near water - for example, near a bath tub, wash
bowl, kitchen sink, or laundry tub; in a wet
basement, or near a swimming pool, and the like.
The apparatus shall not be exposed to dripping or
splashing and that no objects lled with liquids,
such as vases, shall be placed on apparatus.
L’appareil ne doit pas être exposê aux écoulements
ou aux éclaboussures et aucun objet ne contenant
de liquide, tel qu’un vase, ne doit être placé sur
l’objet.
8. Accessories - Do not place this product on an
unstable cart, stand tripod, bracket, or table. The
product may fall, causing serious injury to a child
or adult, and serious damage to the product. Use
only with a cart, stand, tripod, bracket, or table
recommended by the manufacturer, or sold with
the product. Any mounting of the product should
follow the manufacturer’s instructions, and should
use a mounting accessory recommended by the
manufacturer.
9. Use only with the cart, stand, tripod, bracket, or
table specied by the manufacturer, or sold with
the apparatus. When a cart is used, use caution
when moving the cart/apparatus combination to
avoid injury from tip-over.
See gure:
10. Ventilation - Slots and openings in the cabinet
are provided for ventilation and to ensure reliable
operation of the product and to protect it from
overheating, and these openings must not be
blocked or covered. The openings should never be
blocked by placing the product on a bed, sofa, rug,
or other similar surface. This product should not be
placed in a built-in installation such as a bookcase
or rack unless proper ventilation is provided or the
manufacturer’s instruction have been adhered to.
11. Power Sources - This product should be operated
only from the type of power source indicated on
the marking label. If you are not sure of the type of
power supply to your home, consult your product
dealer or local power company. For products
intended to operate from battery power, or other
sources, refer to the operating instruction.
12. Grounding or Polarization - This product may
be equipped with a polarized alternating-current
line plug (a plug having one blade wider than the
other). This plug will t into the power outlet only
one way. This is a safety feature. If you are unable
to insert the plug fully into the outlet, try reversing
the plug. If the plug should still fail to t, contact
your electrician to replace your obsolete outlet. Do
not defeat the safety purpose of the polarizes plug.
Alternate Warnings - This product is equipped
with a three-wire grounding-type plug, a plug
having a third (grounding) pin. This plug will only
t into a grounding-type power outlet. This is a
safety feature. If you are unable to insert the plug
into the outlet, contact your electrician to replace
your obsolete outlet. Do not defeat the safety
purpose of the grounding-type plug.
13. Power-Cord Protection - Power supply cords
should be routed so that they are not likely to be
walked on or pinched by items placed upon or
against them, paying particular attention to cords
at plugs, convenience receptacles, and point where
they exit from the product.
14. Protective Attachment Plug - The product is
equipped with an attachment plug having overload
protection. This is a safety feature. See Instruction
Manual for replacement or resetting of protective
device. If replacement of the plug is required, be
sure the service technician has used a replacement
plug specied by the manufacturer that has the
same overload protection as the original plug.
15. Outdoor Antenna Grounding - If an outside
antenna is connected to the receiver, be sure the
antenna system is grounded so as to provide some
protection against voltage surges and built-up static
charges. Article 810 of the National Electrical
Code, ANSI/NFPA 70, provides information
with regard to proper grounding of the mast and
supporting structure, grounding of the mast and
supporting structure, grounding of the lead-in wire
to an antenna-discharge unit, size of grounding
conductors, location of antenna-discharge
unit, connection to grounding electrodes, and
requirements for the grounding electrode.
See gure:
16. Lightning - For added protection for this product
during a lightning storm, or when it is left
unattended and unused for long periods of time,
unplug it from the wall outlet and disconnect the
antenna or cable system. This will prevent damage
to the product due to lightning and power-line
surges.
17. Power Lines - An outside antenna system should
not be located in the vicinity of overhead power
lines or other electric light or power circuits, or
where it can fall into such power lines or circuits.
When installing an outside antenna system,
extreme care should be taken to keep from
touching such power lines or circuits as contact
with them might be fatal.
18. Overloading - Do not overload wall outlets,
extension cords, or integral convenience
receptacles as this can result in a risk of re or
electric shock.
19. Object and Liquid Entry - Never push objects of
any kind into this product through openings as they
may touch dangerous voltage points or short-out
parts that could result in a re or electric shock.
Never spill liquid of any kind on the product.
20. Servicing - Do not attempt to service this product
yourself as opening or removing covers may
expose you to dangerous voltage or other hazards.
Refer all servicing to qualied service personnel.
21. Damage Requiring Service - Unplug this product
from the wall outlet and refer servicing to qualied
service personnel under the following conditions:
a) When the power-supply cord or plug is
damaged,
b) If liquid has been spilled, or objects have fallen
into the product,
c) If the product has been exposed to rain, water
or moisture.
d) If the product does not operate normally by
following the operating instructions. Adjust only
those controls that are covered by the operating
instructions as an improper adjustment of other
controls may result in damage and will often
require extensive work by a qualied technician to
restore the product to its normal operation.
e) If the product has been dropped or damaged in
any way, and
f) When the product exhibits a distinct change in
performance - this indicates a need for service.
22. Replacement Parts - When replacement parts are
required, be sure the service technician has used
replacement parts specied by the manufacturer
or have the same characteristics as the original
part. Unauthorized substitutions may result in re,
electric shock, or other hazards.
23. Safety Check - Upon completion of any service or
repairs to this product, ask the service technician
to perform safety checks to determine that the
product is in proper operating condition.
24. Wall or Ceiling Mounting - The product
should be mounted to a wall or ceiling only as
recommended by the manufacturer.
25. Heat - The product should be situated away from
heat sources such as radiators, heat registers,
stoves, or other products (including ampliers)
that produce heat. Battery shall not be exposed to
excessive heat such as sunshine, re, or the like.
Les piles ne doivent pas être exposées à de forte
chaleur, tel qu’à la lumière du soleil, au feu ou
autres choses de semblable.
26. Main plug is used as disconnect device and it
should remain readily operable during intended
use. In order to disconnect the apparatus from
the mains completely, the mains plug should
be disconnected from the mains socket outlet
completely.
La prise du secteur ne doit pas être obstruée
ou doit être facilement accessible pendant son
utilisation. Pour être complètement déconnecté
de l’alimentation d’entrée, la prise doit être
débranchée du secteur.
27. Excessive sound pressure from earphones and
headphones can cause hearing loss.
Des pressions acoustiques excessives provenant
d’écouteurs ou de casques peuvent provoquer des
pertes de l’audition.
28. To prevent re or shock hazard, do not use this
plug with an extension cord, receptacle or other
outlet unless the blades can be fully inserted to
prevent blade exposure.
2 9 . Symbol is used to indicate that a
specic component shall be replaced
only by the component specied in that
documentation for safety reasons.
30. This symbol indicates that this product
incorporates double insulation.
31. Caution marking is located at the bottom of
apparatus.
Les précautions d’emploi sont inscrites en bas de
l’appareil.
32. The marking information is located at the bottom
of apparatus.
Les marquages sont inscrits en bas de l’appareil.

4
In the Box
Features
IS809B•
Remote control•
Docking brackets for iPod•
Documentation•
Dock plays and charges iPod•
Wireless speakers•
Supports multiple speakers•
Advanced hi- sound with Channel Purity®•
Remote•
Digital volume control•
Pairing button•
Left, right, or mono selections•
Weather resistant•
Digital 2.4GHz ISM wireless transmitter•
LCD display with white backlight•
Digital clock•
Play/pause, skip up/down functions for iPod•
On/Off, mute, function and pairing controls•
Independent volume settings for each speaker•
Transmission range: 200ft line of sight, 90ft indoors•
Auxiliary input for iPod shufe and other audio devices•
AC power: built-in AC cord•
DC power: requires 6 D batteries per speaker, not included•
Includes: remote control, docking brackets for iPod•

5
Powering the Unit
Backup Batteries for the Unit
AC Power Cord
Plug the included AC cord into a standard AC outlet (120V~60Hz)
Backup Battery Compartment (Requires 2 AAA batteries, not included)
Note: The Backup Battery Compartment will only backup the unit’s time for a short period. The
unit cannot function on the backup batteries alone.

6
Changing the Remote Battery
Powering the Speakers
Battery Power (Requires 2 AAA batteries, not included)
AC Power Cord
Plug the included AC cord into a standard AC outlet (120V~60Hz)
Battery Power (Requires 6 D batteries, not included)

7
Press theStep 1: Power Button on the unit to turn the unit on.
Press theStep 2: Power Button on the speakers to turn the speakers on.
Press and hold theStep 3: Pair Button on the unit until the Link Indicator
begins blinking.
Press and hold theStep 4: Pair Button on the speakers until the Link Indicator
begins blinking.
TheStep 5: Link Indicator will shine solid on both the unit and speaker once
they are paired together.
Transmission range: 200ft line of sight, 90ft indoors
Pairing Speakers with the Unit

8
Docking an iPod
Locate the numbered bracket that ts the iPod that will be docked.Step 1:
Each included Bracket has a number on it, indicating which iPod •
model that bracket is compatible with. See the separate bracket chart
page to identify which bracket is needed.
Snap the bracket into place over theStep 2: iPod Connector in the dock.
Connect the iPod to theStep 3: iPod Connector inside the dock.
When the unit is plugged in, using AC power, the docked iPod will •
charge. If the unit is running on batteries, DC power, the docked iPod
will not charge.
Playing an iPod
Press theStep 1: Power Button to turn the unit on.
Press theStep 2: Source Button to switch to iPod mode.
Press theStep 3: Play/Pause Button to play or pause the docked iPod.
Setting the Clock
Press and hold theStep 1: Time Set Button.
While holding theStep 2: Time Set Button, press the Skip/Search Buttons to
adjust the hour and minute.
Release theStep 3: Time Set Button to set the adjusted time.

9
Setting the Timer
Press and hold theStep 1: Timer Button.
While holding theStep 2: Timer Button, press the Skip/Search Buttons to
adjust the hour and minute.
Release theStep 3: Timer Button to set the adjusted time.
Press theStep 4: Power Button to turn the unit off.
Press theStep 5: Timer Button to activate the timer.
“Timer On” will appear on the LCD display.•
After the set time is reached, the unit will power on.
Setting the Sleep Timer
Press theStep 1: Sleep Button consecutively to adjust the sleep timer between
60 and 10 minutes, in 10 minute increments.
When the set time has expired, the unit will power off.
Using the Auxiliary Input
Step 1: Connect a mini-phono 3.5mm cable (not included) to the Auxiliary
Input on the unit and the audio output on an MP3 player.
Step 2: Turn the unit on by pressing the Power Button.
Step 3: Press the Source Button to switch the unit to Aux Mode.
Step 4: Audio played through the connected MP3 player will now be heard
through the unit.

10
Locations of Controls & Denitions
iPod Connector1.
Use the Dock Connector to connect an iPod to the unit.
Source Button2.
Press the Source Button to switch between iPod and Auxiliary Modes.
Link Indicator3.
A solid light indicates that the unit is not searching for nearby wireless speakers.
A blinking light indicates that the unit is attempting to link up with nearby wireless
speakers.
Power Button4.
Press the Power Button to turn the unit off and on.
Note: The wireless speakers need to be powered off separately.
Timer Button5.
Press and hold the Timer Button to set the timer.
Play/Pause Button6.
In iPod Mode, press the Play/Pause Button to play or pause a docked iPod.
Skip/Search Buttons7.
In iPod Mode, press the Skip/Search Buttons to skip between songs on a docked iPod.
In iPod Mode, press and hold the Skip/Search Buttons to search through an individual
song.
1
38
2
4
5
6
7
10
11
9

11
Locations of Controls & Denitions
Dimmer Button8.
Press the Dimmer Button consecutively to adjust between low, medium, and high LCD
display brightness’.
Time Set Button9.
Press and hold the Time Set Button to set the units clock.
Sleep Button10.
Press the Timer Button consecutively to set the sleep timer between 60 and 10 minutes
(in 10 minute increments).
LCD Display11.
Auxiliary Input12.
Use the Auxiliary Input to connect an audio source (MP3 player) to the unit.
Pair Button13.
Press and hold the Pair Button to have the unit search for nearby wireless speakers.
Backup Battery Compartment (Requires 2 AAA batteries, not included)14.
Note: The Backup Battery Compartment will only backup the unit’s time for a short
period. The unit cannot function on the backup batteries alone.
12
13
14

12
Locations of Controls
16
17
15
20
19
18
21

13
Control Denitions
Volume Dial15.
Turn the Volume Dial to adjust the volume of the speaker.
Left/Right/Mono Button16.
Turn the Left/Right/Mono Button to switch between left, right, and mono speaker modes.
Battery Compartment (Requires 6 D batteries, not included)17.
AC Power Cord18.
Use the AC Power Cord to power the speakers as an alternative to using battery power.
Power Button19.
Press the Power Button to turn the speakers on and off.
Pair Button20.
Press and hold the Pair Button to have the speaker search for a nearby unit to link to.
Link Indicator21.
A solid light indicates that the unit is not searching for nearby wireless speakers.
A blinking light indicates that the unit is attempting to link up with nearby wireless
speakers.

14
Locations of Controls
22
23
25
27
31
32
29
28
26
24 30

15
Control Denitions
Power Button22.
Press the Power Button to turn the unit off and on.
Source Button23.
Press the Source Button to switch between iPod and Auxiliary Modes.
Repeat Button24.
Press the Repeat Button to activate the repeat options on a docked iPod.
Skip/Search Buttons25.
In iPod Mode, press the Skip/Search Buttons to skip between songs on a docked iPod.
In iPod Mode, press and hold the Skip/Search Buttons to search through an individual
song.
Random Button26.
Press the Random Button to activate the shuffle options on a docked iPod.
Treble Buttons27.
Press the Treble Buttons to adjust the level of treble output from the speakers.
Bass Buttons28.
Press the Bass Buttons to adjust the level of bass output from the speakers.
Mute Button29.
Press the Mute Button to mute the volume of the unit.
Play/Pause Button30.
Press the Play/Pause Button to play or pause a docked iPod.
Volume Buttons31.
Press the Volume Buttons to adjust the volume of the unit.
Battery Compartment (Requires 2 AAA batteries, not included)32.

© 2009 Digital Products International (DPI, Inc.)
All other trademarks appearing herein are the property of their respective owners.
Service Information
Address: 2116 Carr Street, St. Louis MO, 63106
Phone: [phone]
Fax: [phone]
Email: [email protected]
Website: www.ilive.net
Version: v. 010509
Parts Information
Address: 2116 Carr Street, St. Louis MO, 63106
Phone: [phone]
Fax: [phone]
Email: [email protected]
To download this Instruction Manual in English, Spanish, or French visit the Support
section at www.ilive.net.
Para descargar este manual de instrucción en inglés, español, o francés visite la sección
de la ayuda en www.ilive.net.
Pour télécharger ce manuel d’instruction en anglais, espagnol, ou le Français visitez la
section de soutien à www.ilive.net.
