iLive IHP610B User manual

USER’S GUIDE
V:0842-0727-10
For the most up-to-date version of this User’s Guide, go to www.ilive.net
IHP610B
Home Music System for iPhone and iPod

iLive2
• WARNING:Lithium batteries, like all rechargeable
batteries are recyclable and should be recycled or
disposed of in normal household waste. Contact your
local government for disposal or recycling practices in
your area. They should never be incinerated since they
might explode.
• WARNING: Shock hazard - Do Not Open.
• AVIS: RISQUE DE CHOC ÉLECTRIQUE - NE PAS
OUVRIR
Mains plug is used as disconnect device and it should
remain readily operable during intended use. In order
to disconnect the apparatus from the mains completely,
the mains plug should be disconnected from the mains
socket outlet completely.
La prise du secteur est utilisé pour déconnecter le
système.
La prise du secteur ne doit pas être obstruée ou doit être
facilement accessible pendant son utilisation. Pour être
complètement déconnecté de l’alimentation d’entrée, la
prise doit être débranchée du secteur.
Do not mix old and new batteries.
Do not mix alkaline, standard (carbon-zinc), or
rechargeable (ni-cad, ni-mh, etc) batteries.
No mezcle baterías viejas y nuevas.
No mezcle baterías alcalinas, estándar (carbono-zinc) o
recargables (ni-cad, ni-mh, etc.).
• CAUTION: TO PREVENT ELECTRIC SHOCK,
MATCH WIDE BLADE OF PLUG TO WIDE SLOT,
FULLY INSERT.
• WARNING:To reduce the risk of re or electric shock,
do not expose this apparatus to rain or moisture.
• AveRTIssemeNT: Pour réduire le risque d’incendie
ou de choc électrique, ne pas exposer cet appareil sous la
pluie et l’humidité.
• CAUTION: Use of any controls or adjustments or
performance of procedures other than those herein
specied may result in hazardous radiation exposure.
• WARNING: Changes or modications to this unit
not expressly approved by the party responsible for
compliance could void the user’s authority to operate the
equipment.
• WARNING: Do not place the unit on top of any soft,
porous, or sensitive surfaces to avoid damaging the
surface. Use a protective barrier between the unit and
surface to protect the surface.
• WARNING: Use of this unit near uorescent lighting
may cause interference regarding use of the remote. If
the unit is displaying erratic behavior move away from
any uorescent lighting, as it may be the cause.
• CAUTION:Danger of explosion if battery is incorrectly
replaced. Replace only with the same or equivalent type.
• PRÉCAUTION: Danger d’explosion si les piles sont
remplacées de façon incorrect. Remplacer les piles
seulement par le même type de pile ou l’équivalent.
• WARNING: There is a danger of explosion if you
attempt to charge standard Alkaline batteries in the unit.
Only use rechargeable NiMH batteries.
• WARNING: The remote control’s button cell battery
contains mercury. Do not put in the trash, instead recycle
or dispose of as hazardous waste
Warnings and Precautions
The lightning ash with arrowhead symbol, within
an equilateral triangle, is intended to alert the user
to the presence of uninsulated "dangerous voltage"
within the product's enclosure that may be of
sufcient magnitude to constitute a risk of electric
shock to persons.
WARNING: TO REDUCE THE RISK OF
ELECTRIC SHOCK, DO NOT REMOVE
COVER (OR BACK). NO USER-
SERVICEABLE PARTS INSIDE. REFER
SERVICING TO QUALIFIED SERVICE
PERSONNEL.
ATTENTION
RISQUE D' ÉLECTROCUTION
NE PAS OUVRIR
CAUTION
RISK OF ELECTRIC SHOCK
DO NOT OPEN
The exclamation point within an equilateral triangle
is intended to alert the user to the presence of
important operating and maintenance (servicing)
instructions in the literature accompanying the
appliance.
This product utilizes a Class 1 laser to read
Compact Discs. This laser Compact Disc Player is
equipped with safety switches to avoid exposure
when the CD door is open and the safety interlocks
are defeated. Invisible laser radiation is present
when the CD Player’s lid is open and the system’s
interlock has failed or been defeated. It is very
important that you avoid direct exposure to the
laser beam at all times. Please do not attempt to
defeat or bypass the safety switches.

Customer Support: 1-888-999-4215 iLive 3
13. Unplug this apparatus during lightning storms or when
unused for long periods of time.
14. Refer all servicing to qualied service personnel.
Servicing is required when the apparatus has been
damaged in any way, such as power-supply cord or
plug is damaged, liquid has been spilled or objects
have fallen into the apparatus, the apparatus has been
exposed to rain or moisture, does not operate normally,
or has been dropped.
WARNING: Changes or modications to this unit not expressly
approved by the party responsible for compliance could void the user’s
authority to operate the equipment.
NOTE: This equipment has been tested and found to comply with
the limits for a Class B digital device, pursuant to Part 15 of the FCC
Rules. These limits are designed to provide reasonable protection
against harmful interference in a residential installation. This
equipment generates, uses, and can radiate radio frequency energy and,
if not installed and used in accordance with the instructions, may cause
harmful interference to radio communications. However, there is no
guarantee that interference will not occur in a particular installation. If
this equipment does cause harmful interference to radio or television
reception, which can be determined by turning the equipment off and
on, the user is encouraged to try to correct the interference by one or
more of the following measures:
• Reorient or relocate the receiving antenna.
• Increase the separation between the equipment and receiver.
• Connect the equipment into an outlet on a circuit different from
that to which the receiver is connected.
• Consult the dealer or an experienced radio/TV technician for help.
• The apparatus shall not be exposed to dripping or splashing and
that no objects lled with liquids, such as vases, shall be placed on
apparatus.
L’appareil ne doit pas être exposé aux écoulements ou aux
éclaboussures et aucun objet ne contenant de liquide, tel qu’un vase,
ne doit être placé sur l’objet.
• Main plug is used as disconnect device and it should remain readily
operable during intended use. In order to disconnect the apparatus
from the mains completely, the mains plug should be disconnected
form the mains socket outlet completely.
La prise du secteur ne doit pas être obstruée ou doit être facilement
accessible pendant son utilisation. Pour être complètement
déconnecté de l’alimentation d’entrée, la prise doit être débranchée
du secteur.
• Battery shall not be exposed to excessive heat such as sunshine, re
or the like.
Les piles ne doivent pas être exposées à de forte chaleur, tel qu’à la
lumière du soleil, au feu ou autres choses de semblable.
• Caution marking is located at the rear or back of the apparatus.
Attention marquage est situé à l’arrière ou à l’arrière de l’appareil
• The marking information is located at the rear or back of apparatus.
Les informations de marquage est situé à l’arrière ou à l’arrière de
l’appareil.
FCC Warnings
Additional Warnings
1. Read these Instructions.
2. Keep these Instructions.
3. Heed all Warnings.
4. Follow all instructions.
5. Do not use this apparatus near water.
6. Clean only with a dry cloth.
7. Do not block any ventilation openings. Install in
accordance with the manufacturer’s instructions.
8. Do not install near any heat sources such as radiators,
heat registers, stoves, or other apparatus (including
ampliers) that produce heat.
9. Do not defeat the safety purpose of the polarized or
grounding - type plug. A polarized plug has two blades
with one wider than the other. A grounding type plug
has two blades and a third grounding prong. The wide
blade or the third prong are provided for your safety.
When the provided plug does not t into your outlet,
consult an electrician for replacement of the obsolete
outlet.
10. Protect the power cord from being walked on or
pinched particularly at plugs, convenience receptacles,
and the point where they exit from the apparatus.
11. Only use attachments/accessories specied by the
manufacturer.
12.
Important Safety Instructions
This symbol indicates that this product
incorporates double insulation between
hazardous mains voltage and user
accessible parts.
Use only with a cart, stand, tripod,
bracket, or table specied by the
manufacturer, or sold with the apparatus.
When a cart is used, use caution when
moving the cart/apparatus combination to
avoid injury from tip-over.

iLive4
• Works with iPhone
• Made for iPod
• Plays and charges docked iPhone
and iPod
• CD player: CD, CD-R/RW
• FM stereo radio
• Station memory presets (10 FM)
• LCD display with amber backlight
• Digital clock
• Stereo speakers
• 3.5mm audio input
• Composite video output
• Remote control: requires 1,
CR2025, battery (included)
• Last user setting
• Digital volume control
• Preset EQ
• On/o timer
• DC power input: requires an AC/DC
power adapter (included)
• Remote control: requires 1,
CR2025, battery (included)
• AC/DC power adapter
• Docking brackets for iPhone and
iPod
Home Music System for iPhone and iPod
Features
Included

Customer Support: 1-888-999-4215 iLive 5
TABLE OF CONTENTS
Warnings and Precautions . . . . . . . . . . . 2
Important Safety Instructions . . . . . . . . . . 3
• FCC Warnings
• Additional Warnings
Home Music System for iPhone and iPod . . . . . . . 4
• Features
• Included
Introduction . . . . . . . . . . . . . . 6
Setup . . . . . . . . . . . . . . . . 8
• Power
• Battery Power
Clock and Sleep Timer . . . . . . . . . . . . 9
• Setting the Clock
• Using the Sleep Timer
Timer . . . . . . . . . . . . . . . . 10
• Setting the Timer
• Activating or Deactivating the Timer
iPod and iPhone . . . . . . . . . . . . . 11
• Docking an iPod and iPhone
• Playing an iPod and iPhone
CD . . . . . . . . . . . . . . . . . 12
• Loading a CD
• Playing a CD
• Programming a CD
• Cancelling a Programmed CD
FM Radio . . . . . . . . . . . . . . . 13
• Tuning the FM Radio
• Saving an FM Radio Station
• Playing a Saved Radio Station
Video Output . . . . . . . . . . . . . . 14
• Using the Video Output
3.5mm Audio Input . . . . . . . . . . . . . 15
• Using the 3.5mm Audio Input
Company Information . . . . . . . . . . . . 16
• International Support
• Contact Information

iLive6
Introduction
OPEN/CLOSE
Press to open or close
the CD door.
SLEEP
Press repeatedly to set
the sleep timer or turn
the sleep timer o.
TIMER
Press to view, set, and
activate or deactivate
the timer.
SKIP/SEARCH
TUNE (+/-)/TIME(+/-)
Press to skip between
tracks on a docked iPod,
iPhone, or loaded CD.
Press and hold to search
through an individual
track.
Press to tune the FM
radio.
Press to adjust the time
when setting the clock
or timer.
POWER
Press to power the
music system o or on.
EQ
Press to adjust the
preset EQ to Rock,
Classic, Jazz, Pop, or
Normal.
FM WIRE ANTENNA
COMPOSITE VIDEO
OUTPUT
STOP
Press to stop a CD
during play.
CLK SET/MEM
Press to set the clock
or save a radio station.
Press to program a CD.
REPEAT/MEM-
Press to repeat the
current track or an
entire album/playlist.
Press to cycle through
saved radio stations.
PLAY/PAUSE/MEM+
Press to play or pause a
docked iPhone or iPod
or a loaded CD.
Press the cycle through
saved radio stations.
SOURCE
Press to switch to radio,
CD, Aux, or iPod modes.
iPod
Press to switch to iPod
mode.
VOLUME
Turn to adjust the
volume.
DOCK for iPhone and
iPod
3.5MM AUDIO INPUT
DC POWER INPUT

Customer Support: 1-888-999-4215 iLive 7
POWER
Pres to power the music
system o or on.
iPod
Press to switch to iPod
mode.
DISPLAY
Press to view the time
when in radio mode.
MENU/PROG/MEM
Press to cycle through
menus on a docked
iPhone or iPod.
Press to program a CD.
Press to save a radio
station as a preset.
CLK SET
Press and hold to set
the clock.
CHAPTER/ALBUM/
PLAYLIST
Press to skip between
chapters, albums, and
playlists on a docked
iPhone or iPod.
REPEAT/M-
Press to repeat the
current track or an
entire album/playlist.
Press to cycle through
saved radio stations.
SLEEP
Press repeatedly to set
the sleep timer or turn
the sleep timer o.
SOURCE
Press to switch to radio,
CD, Aux, or iPod modes.
MUTE
Press to mute the
volume.
SKIP/SEARCH
Press to skip between
tracks on a docked iPod,
iPhone, or loaded CD.
Press and hold to search
through an individual
track.
Press to tune the FM
radio.
Press to adjust the time
when setting the clock
or timer.
MENU/SELECT
Press to navigate the
menu on a docked
iPhone or iPod and
make selections.
EQ
Press to adjust the
preset EQ to Rock,
Classic, Jazz, Pop, or
Normal.
VOLUME
Press to adjust the
volume.
STOP
Press to stop a CD
during play.
PLAY/PAUSE/M+
Press to play or pause a
docked iPhone or iPod
or a loaded CD.
Press the cycle through
saved radio stations.
TIMER
Press to view, set, and
activate or deactivate
the timer.
SHUFFLE
Press to play tracks in
a random order from a
docked iPhone or iPod.

iLive8
Plug the included AC/DC power
adapter into the DC POWER INPUT on
the music system and an AC power
outlet to power the music system.
Requires 1, CR2025, battery (pre-
installed).
Power
Battery Power
LITHIUM BATTERY
CR 2025
3V
CR2025
PUSH
OPEN
LITHIUM BATTERY
CR 2025
3V
CR2025
PUSH
OPEN
Setup

Customer Support: 1-888-999-4215 iLive 9
1. Press the POWER button to turn
the music system o.
2. Press and hold the CLK SET/MEM
button on the music system.
“12 Hr” will appear on the display.
3. Press the SKIP/SEARCH buttons to
switch between 12 and 24 hour.
4. Press the CLK SET/MEM button to
select 12 or 24 hour.
The hour will begin to blink on the
display.
5. Press the SKIP/SEARCH buttons to
adjust the hour.
An “AM” indicator will appear on the
display when the time is set to the
AM. A “PM” indicator will appear on
the display when the time is set to
the PM.
6. Press the CLK SET/MEM button to
set the adjusted hour.
The minute will begin to blink on the
display.
7. Press the SKIP/SEARCH buttons to
adjust the minute.
8. Press the CLK SET/MEM button to
nish setting the clock.
1. Press the POWER button to turn
the music system on.
2. While listening to music in iPod
mode, radio mode, aux mode, or
CD mode, press the SLEEP button
repeatedly to set the sleep timer to
the desired time.
3. After the selected time has
expired, the music system will
automatically power o.
Setting the Clock Using the Sleep Timer
Clock and Sleep Timer

iLive10
Timer
1. Press the POWER button to turn
the music system o.
2. Press the TIMER button.
The current timer settings will
appear on the display.
3. Press and hold the TIMER button
while the timer settings are on the
display.
The “On Timer” hour will begin to
blink. “On Timer” refers to the time
that the music system will power on.
4. Press the SKIP/SEARCH buttons to
adjust the “On Timer” hour. Press
the TIMER button.
The “On Timer” minute will begin to
blink.
5. Press the SKIP/SEARCH buttons to
adjust the “On Timer” minute. Press
the TIMER button.
The “O Timer” hour will begin to
blink. “O Timer” refers to the time
that the music system will power o.
6. Press the SKIP/SEARCH buttons to
adjust the “O Timer” hour. Press
the TIMER button.
The “O Timer” minute will begin to
blink.
7. Press the SKIP/SEARCH buttons to
adjust the “O Timer” minute. Press
the TIMER button to nish setting
the timer.
8. Follow the instructions for
Activation or Deactivating the
Timer.
1. Press the POWER button to turn
the music system o.
2. Press and hold the TIMER button.
“TIMER” will appear on the display,
indicating the timer is activated.
3. To deactivate the timer, press and
hold the TIMER button again until
“TIMER” on the display disappears.
Setting the Timer Activating or Deactivating the Timer

Customer Support: 1-888-999-4215 iLive 11
iPod and iPhone
Docking an iPod and iPhone
Playing an iPod and iPhone
1. Follow the instructions for Docking
an iPod and iPhone.
2. Press the POWER button to power
on the music system.
3. Press the iPod button to switch to
iPod/iPhone mode.
“iPod” and an iPod icon will appear
on the display.
4. Press the PLAY/PAUSE button
to begin playing music from the
docked iPhone or iPod.
1. Locate the numbered bracket that
ts the iPhone/iPod model that will
be docked.
Each included bracket has a number
on it, indicating which iPhone/iPod
model that bracket is compatible
with. See the separate bracket chart
page to identify which bracket is
needed.
2. Push the face of the dock to open
the dock for iPhone and iPod.
3. Snap the bracket into place over
the iPhone/iPod connector in the
dock for iPhone/iPod.
4. Connect the iPhone or iPod to
the connector inside the Dock for
iPhone/iPod.
When the tower speaker is plugged
in, using AC power, the docked
iPhone or iPod will charge.

iLive12
1. Press the OPEN/CLOSE button
on the top of the music system to
open the CD door.
2. Load a CD into the music system,
label side facing up.
3. Close the CD door.
1. Follow the instructions for Loading
a CD.
2. Press the POWER button to power
the music system on.
3. Press the SOURCE button to
switch to CD mode.
The track number will appear on the
display, to the right of the time, when
the music system is in CD mode.
4. Press the PLAY/PAUSE button to
begin playing the loaded CD.
1. Follow the instructions for Playing
a CD.
2. Press the STOP button.
The loaded CD must be stopped to
create a program.
3. Press the MENU/PROG./MEM
button on the remote.
“PROG” and a number, indicating
the order in which the next selected
track will play, will appear on the
display.
4. Press the SKIP/SEARCH buttons to
select a track.
5. Press the MENU/PROG./MEM
button on the remote to save the
selected track to the program.
6. Repeat steps 4 and 5 to program
up to 20 tracks to play in the order
they were selected.
1. After programming the CD, press
the STOP button twice to cancel
the program.
Loading a CD
Playing a CD
Programming a CD
Cancelling a Programmed CD
CD

Customer Support: 1-888-999-4215 iLive 13
1. Press the POWER button to power
the music system on.
2. Press the SOURCE button to
switch to FM radio mode.
“Radio” will appear on the display.
3. Press the TUNE +/- buttons to tune
the FM radio.
Adjust the position of the FM wire
antenna to improve FM radio
reception.
1. Follow the instructions for Tuning
the FM Radio and Saving an FM
Radio Station.
2. Press the MEM± or M± buttons to
cycle through saved radio stations.
1. Follow the instructions for Tuning
the FM Radio.
2. Press the TUNE +/- buttons to tune
the FM radio to the desired station.
3. Press and hold CLK SET/MEM
button on the music system or the
MENU/PROG./MEM button on the
remote.
A preset number (P01) will appear on
the display, indicating which preset
the current station will be saved to.
4. Press the TUNE +/- buttons to
adjust the preset number (P01 -
P10).
5. Once the desired preset is selected,
press the CLK SET/MEM button
on the music system or the MENU/
PROG./MEM button on the remote
to save the current FM radio
station to the selected preset.
Tuning the FM Radio
Playing a Saved Radio Station
Saving an FM Radio Station
FM Radio

iLive14
Video Output
The COMPOSITE VIDEO OUTPUT
will only output video from a docked
iPhone or iPod with video capabilities.
Requires a composite RCA video cable
(not included).
1. Follow the instructions for Docking
an iPod or iPhone and Playing an
iPod or iPhone.
2. Check your iPod or iPhone video
settings to make sure “TV OUT” is
set to “ON” or “ASK”.
3. Connect a composite RCA video
cable to the COMPOSITE VIDEO
OUTPUT on the music system
and a composite video input on a
television.
4. Adjust the connected television
to the input setting used when
connecting the two devices.
5. Video played through the docked
iPod or iPhone will now be output
to the connected TV.
Using the Video Output

Customer Support: 1-888-999-4215 iLive 15
3.5mm Audio Input
Requires a 3.5mm audio cable (not
included).
1. Connect a 3.5mm audio cable to
the 3.5MM AUDIO INPUT on the
music system and the headphone
jack or 3.5mm audio output on an
MP3 player or other audio source.
2. Press the POWER button to power
on the music system.
3. Press the SOURCE button to
switch to AUX mode.
4. Use the native controls on the
connected MP3 player or other
audio source to control the music
played through the music system.
Using the 3.5mm Audio Input

Copyright © 2010 Digital Products International (DPI, Inc.) | All other trademarks appearing herein are the property of their respective
owners. Specications are subject to change without notice
International Support Contact Information
Company Information
To download this User’s Guide in
English, Spanish, or French, visit the
support section at www.ilive.net.
Para transferir esta guía de usuario
en inglés, español, o francés, visite la
sección de la ayuda en www.ilive.net.
Pour télécharger ce guide de
l’utilisateur en anglais, espagnol, ou
français, visitez la section de soutien
chez www.ilive.net.
Phone: [phone]
Email: [e-mail]
Parts Email: par[email protected]
Website: www.ilive.net
