iLive IKB333S User manual
Play/Pause/
Memory/Clock/
Speakerphone
Press to play or pause in
Bluetooth mode.
Press to browse through
preset stations in Radio mode.
Press and hold to begin saving
a station as a preset. With
the power o, press to begin
setting the clock.
Press to answer or end a
phone call.
Features & Controls
Wireless Under Cabinet, Bluetooth, Radio Music System
User’s Guide for Model IKB333S v1625-01
Power
Plug the included AC/DC power adapter into the DC
POWER INPUT on the unit and an AC power outlet to
power the unit.
Battery Backup
The battery backup is intended for short power
outages only. The unit’s primary functions cannot
run o of the battery backup alone.
Requires 2 AAA-size batteries (not included).
Pair Indicator Microphone
Volume +/-
Press to adjust the volume up
or down.
Alarm
Press to begin
setting the alarm.
Tune +/-
Press to tune the radio.
Press and hold to search for
the next available station.
Timer
Press to begin
setting the timer.
Source
Press to switch
between Bluetooth
and Radio mode.
Power
Press to turn the
unit on or o.
Pair
Press to begin pairing
a Bluetooth device.
Light/Dimmer
Press to turn the under
cabinet light on.
Press and hold to
dim the display.
FCC WARNINGS
Warning: Changes or modications to this unit not expressly approved by the party responsible for
compliance could void the user’s authority to operate the equipment.
NOTE: This equipment has been tested and found to comply with the limits for a Class B digital device,
pursuant to Part 15 of the FCC Rules. These limits are designed to provide reasonable protection against
harmful interference in a residential installation. This equipment generates, uses, and can radiate radio
frequency energy and, if not installed and used in accordance with the instructions, may cause harmful
interference to radio communications. However, there is no guarantee that interference will not occur in a
particular installation. If this equipment does cause harmful interference to radio or television reception,
which can be determined by turning the equipment off and on, the user is encouraged to try to correct the
interference by one or more of the following measures:
• Reorient or relocate the receiving antenna.
• Increase the separation between the equipment and receiver.
• Connect the equipment into an outlet on a circuit different from that to which the receiver is connected.
• Consult the dealer or an experienced radio/TV technician for help.
ADDITIONAL WARNINGS AND PRECAUTIONS
• CAUTION: TO PREVENT ELECTRIC SHOCK, MATCH WIDE BLADE OF PLUG TO WIDE
SLOT, FULLY INSERT.
• Mains plug is used as disconnect device and it should remain readily operable during intended use. In
order to disconnect the apparatus from the mains completely, the mains plug should be disconnected
form the mains socket outlet completely.
• WARNING: Shock hazard - Do Not Open.
• Caution and marking information is located at the rear or bottom of the apparatus.
• Objects lled with liquids, such as vases, shall not be placed on the apparatus.
• WARNING: To reduce the risk of re or electric shock, do not expose this apparatus to rain, moisture,
dripping, or splashing.
• CAUTION: Use of controls or adjustments or performance of procedures other than those specied
may result in hazardous radiation exposure.
• WARNING: Changes or modications to this unit not expressly approved by the party responsible for
compliance could void the user’s authority to operate the equipment.
• CAUTION: Danger of explosion if battery is incorrectly replaced. Replace only with the same or
equivalent type.
• Battery shall not be exposed to excessive heat such as sunshine, re or the like.
• Keep new and used batteries away from children. If the battery compartment does not close securely,
stop using the product and keep it away from children.
• If you think batteries might have been swallowed or placed inside any part of the body, seek immediate
medical attention.
• Do not mix old and new batteries.
• Completely replace all old batteries with new ones.
• Do not mix alkaline, standard (carbon-zinc), or rechargeable (ni-cad, ni-mh, etc) batteries.
• Batteries should be recycled or disposed of as per state and local guidelines.
• WARNING: This product may contain chemicals known to the State of California to cause birth defects,
or other reproductive harm (California Prop 65). Wash hands after handling.
• This product meets and complies with all Federal regulations.
Tuning the FM Radio
1. Press the Power button to turn the under cabinet music system on.
2. Press the Source button to switch to FM Radio Mode.
3. Press the Tune button to tune the radio.
4. Hold down the Tune button to scan for the next available station.
Radio
Saving and Tuning Preset Radio Stations
1. Tune to the desired station.
2. Press and hold the Play/Pause/Memory/Clock button.
3. Preset number will appear on the display.
4. Press the Tune buttons to adjust to the desired preset number.
5. Press the Play/Pause/Memory/Clock button to save the current radio
station to the selected preset.
6. Press the Play/Pause/Memory/Clock button to cycle through preset radio
stations.
Radio Reception
Adjust the position of the FM Antenna to improve FM radio reception.
Setting the Alarm
1. With the power OFF, press and hold the Alarm button. The hour on the
display will begin blinking.
2. Press the Tune buttons to adjust the hour.
3. Press the Alarm button. The minutes on the display will begin blinking.
4. Press the Tune buttons to adjust the minutes.
5. Press the Alarm Set button.
6. Press the Source button to select the alarm source: Radio or Buzzer.
Refer to the Radio section for more information on tuning the radio.
7. Press the Alarm button.
8. To turn the alarm OFF, press the Power button.
9. To cancel the alarm before the alarm has sounded, press the Alarm button.
Alarm
Setting the Clock
1. With the power o, press the Play/Pause/Memory/Clock button. The hour
on the display will begin blinking.
2. Press the Tune buttons to adjust the hour.
3. Press the Play/Pause/Memory/Clock button again to adjust the minutes
The minutes on the display will begin blinking.
4. Press the Tune buttons to adjust the minutes.
5. Press the Play/Pause/Memory/Clock button to nish setting the time.
Clock & Sleep Timer
Mounting Under a Cabinet Bluetooth
Pairing a Bluetooth Device for the First Time
1. Power the unit ON and press the Source button to switch to Bluetooth
mode. The Pairing Indicator will begin slowly ashing blue.
2. Press the Pair button. The Pairing Indicator will begin quickly ashing
blue. When pairing, remain within 3 feet of the unit.
3. Using the controls on your Bluetooth device to select IKB333 in your
Bluetooth settings to pair. If your device requests a password, enter the
default password 0 0 0 0 . You may need to refer to the user’s manual for your
specic device for instructions on pairing and connecting Bluetooth devices.
4. When successfully paired and connected, the Pairing Indicator will display
a solid blue light.
After initial pairing, the unit will stay paired unless unpaired manually by
the user or erased due to a reset of the device. If your device should become
unpaired or you nd it is unable to connect, repeat the above steps or press the
Pair button to start the pairing process pairing again.
Playing Audio Wirelessly
1. Use the native controls on the connected Bluetooth Device to select a track.
2. To play or pause the selected track, use the native controls on the
connected Bluetooth Device or the Play/Pause/Memory/Clock button on
the unit.
3. Audio played through the connected Bluetooth device will now be heard
through the speakers.
Setting the Timer
1. Press the Timer button, the display will begin ashing.
2. Press and hold the Tune buttons to adjust the timer in increments of
10 min. Ex. 180,170 or 0. Short press the Tune buttons to adjust the timer in
increments/decrements of 1 min.
3. After the set time has expired the under cabinet music system will sound an
alarm through the speaker.
4. To cancel the alarm after it has sounded, press the Power button.
5. To cancel the timer before the alarm has sounded, press and hold the Timer
button until the display reads 000 and the timer light is no longer lit.
Using the Speakerphone
1. When a call is received, a ringtone will sound through the unit.
2. Press the button to accept the call, or accept the call using the controls
on the connected phone.
3. The incoming call received through the device will now be heard through
the speaker.
4. To end the call, press the button or end the call using the controls on the
connected device.
To download this User’s Guide in English, Spanish, or French, or to get answers to frequently asked questions, visit
the support section at: www.iLiveElectronics.com
Para descargar este Manual del Usuario en inglés, español y francés, o para obtener respuestas a preguntas
frecuentes, visite la sección de apoyo en: www.iLiveElectronics.com
Pour télécharger ce guide de l’utilisateur en anglais, espagnol ou français, ou pour obtenir des réponses à des
questions fréquemment posées, consultez la rubrique d’assistance sur: www.iLiveElectronics.com
For Warranty Information and the most up-to-date version of this User’s Guide, go to www.iLiveElectronics.com
Customer Service: 1-888-999-4215 | Email Support: [email protected] | Email Parts: [email protected]
Copyright © 2016 Digital Products International (DPI, Inc.) All other trademarks appearing herein are the property
of their respective owners. Specications are subject to change without notice.
International Support
Protect for Today
Sustain for Tomorrow
Made
Green
Use and follow the instructions on the included Mounting Template when
attaching to the underside of your cabinet.
