iLive BI100B User manual

1
BI100B User GuideCustomer Helpline Number: 0844 481 5000
BI100B
User Guide
iPod Handbag

2BI100B User Guide 3
BI100B User GuideCustomer Helpline Number: 0844 481 5000
Congratulations on purchasing this iPod Handbag. You can now listen to FM radio, your iPod,
or any other external device, through your iPod Handbag’s stereo speakers.
Please read the warning section on page 9 carefully before using your iPod Handbag.
Your iPod Handbag
Set up
Everyday use
Troubleshooting
Maintenance
Warnings
Technical specifications
Contents
Welcome
01
02
03
04
05
06
07
Need something else?
There are a wide range of accessories and
other products that can be ordered direct to
your door from ASDA. For more information
see www.asda.com
• 1.5v (C) batteries (x6)
• 3.5mm line in cable
You may also need
iPod Handbag
You should have
AC power cable

5
BI100B User GuideCustomer Helpline Number: 0844 481 5000
4BI100B User Guide
Your iPod Handbag
01
Power indicator
AC Power Input
Tuning dial
Power ON/OFF
Battery
compartment
Volume
Line input
Source selector
Adjustable
dock dial
02
Set up
Setting up your iPod Handbag
1 Plug the power cable into the AC IN
socket in the rear of your iPod Handbag.
2 Plug into a standard three pin wall
socket and switch the power on at
the wall.
Battery Power
When you’re away from a power source
you can use batteries to power your iPod
handbag as described below.
1 Remove the rear battery panel.
2 Insert 6 C size batteries (not included)
as shown.
3 Replace the rear battery panel.
Telescopic FM
antenna
AC 230V~/50Hz
1
2

6BI100B User Guide 7
BI100B User GuideCustomer Helpline Number: 0844 481 5000
Everyday use
Using the FM radio
Turn your iPod Handbag on using the
ON/OFF switch.
1 Select FM by using the SOURCE
SELECTOR switch on the top of your
iPod Handbag.
2 You can select the desired frequency by
turning the radio TUNING wheel on the
right panel of the unit.
3 Turn the wheel clockwise for lower
frequencies and anti-clockwise for
higher frequencies.
Using the telescopic aerial
For improved reception use the telescopic
aerial on the top of your handbag. The
aerial extends up and down but does not
move side to side. Under no circumstances
try to bend the aerial as this will damage
your iPod Handbag.
Note:
You can select the desired volume using
the VOLUME wheel on the left side panel.
Turn clockwise to turn the volume up, or
anti-clockwise to turn it down.
Volume
Playing your iPod
You can play your iPod through your
iPod Handbag. Connect your iPod to the
cradle on the front of the unit. To do this,
twist the ADJUSTABLE DOCK DIAL to
select the model of iPod you are docking.
iPod models and memory sizes that are not
listed on the ADJUSTABLE DOCK DIAL can
be connected by adjusting the dial to the
depth that fits the iPod best.
1 Select ON to turn the unit on.
3 Select iPod on the SOURCE SELECT
SWITCH to switch the unit to iPod mode.
4 The iPod will automatically begin playing
through the unit. Controls on the iPod
can be used to select songs and play
music as you would normally.
Note:
Charging your iPod
While the power is on, the unit will
automatically charge your iPod.
Connecting an external device
You can connect an external device to your iPod Handbag using 3.5mm line-in cable
(not included), as shown below. This will allow the device to play through your music system’s
speakers. You will need to purchase a line-in cable (for more information see www.asda.com).
Use the SOURCE SELECTOR switch to select LINE IN. Once the device is connected
you can control playback as you would usually.
You can turn the VOLUME WHEEL on the iPod Handbag to increase or reduce the volume.
External device
03

8BI100B User Guide 9
BI100B User GuideCustomer Helpline Number: 0844 481 5000
Warnings
This product was designed and manufactured
to meet strict quality and safety standards.
There are, however, some operation
precautions that you should be aware of:
• Read all warnings.
• Follow all instructions.
• Check the mains voltage stated on
the mains adaptor rating plate
corresponds to the local electricity
supply, if it doesn’t, return the product
to the store where you bought it.
• Unwind and straighten the adaptor
cord before use.
• Place the product on a firm and
level surface.
• Turn off the appliance during
thunder storms.
• To completely disconnect this product
from the mains, disconnect the plug from
the wall socket outlet. The mains plug is
used to completely interrupt the power
supply to the unit and must be easily
operable by the user.
• Remove the adaptor from the outlet,
when the product is unused for a long
period of time and during thunderstorms.
• Clean only with a dry cloth, unplug
the outlet before cleaning. Do not
use aggressive cleaners as these will
damage the surface.
• Only use attachments/accessories
specified by the manufacturers.
• Do not locate the appliance in the
vicinity of a heat source or in direct
sunlight. Do not place a naked flame
source on or near this product.
• Do not attempt to open the cabinet
or remove any covers. If the power
adapter or its lead becomes damaged,
it must be replaced with an adapter
of the same type and rating.
• Repairs must only be performed by
the manufacturer or its service agent
or similarly qualified person.
• Do not immerse the main unit,
the power adapter or any accessories
in water or any other liquid.
• Do not expose this product to
dripping or splashing or stand
any vessel containing liquid on
or near this product.
CAUTION
RISK OF ELECTRIC SHOCK
DO NOT OPEN
CAUTION: TO REDUCE THE RISK OF ELECTRIC SHOCK, DO NOT
REMOVE COVER (OR BACK). NO USER SERVICEABLE PARTS INSIDE.
REFER SERVICING TO QUALIFIED SERVICE PERSONNEL.
Troubleshooting
Problem What to do
No power Check that the power is switched on at the wall.
Check if the power cord is properly connected to the power outlet.
No sound Check that the volume control is NOT at minimum setting.
Radio channel
reception is poor
Adjust the antenna location and position to obtain the best signal reception.
Tune to the correct radio channel frequency.
Function disturbed If none of the above solutions work, try switching off and unplugging your music system,
leaving it for two minutes and then switching it back on again.
Need extra help?
Don’t worry we’re just the other end of the
phone. If you’re experiencing problems using
your new product, before returning it to the
retailer just call 0844 481 5000.
Monday - Friday 9am - 8pm, Saturday 9am - 5pm
Sunday 11am - 4pm. Calls charged at local rates.
Loving your new ASDA iPod Handbag? ASDA has
a wide variety of electrical and other products that
are available either instore or online.
For more information visit your local store
or find us online at www.asda.com
Need something else?
04
Maintenance
1 Do not use harsh or abrasive cleaning
agents or solvents.
2 Do not attempt to disassemble
your product.
3 Do not paint your product.
4 Do not drop, throw or try to bend
your product.
5 Do not expose your product to open
flames or lit tobacco products.
05
06

10 BI100B User Guide 11
BI100B User GuideCustomer Helpline Number: 0844 481 5000
28 day no quibble refund
If you’re not delighted by your product, simply bring it back within 28 days for a no quibble refund.
Don’t forget to include all of the item’s original components (for example remote control or power
cable) and packaging along with your receipt or other proof of purchase.
Free 1 year guarantee
All our electrical items are covered by a full 1 year ASDA guarantee from the day you buy it. In the
unlikely event that your product is faulty or you are simply struggling to set it up, don’t worry, here’s
what you should do:
1 First call our Customer Helpline as they may
be able to help you with the problem.
2 If the problem can’t be resolved, you will
receive a reference number.
3 Take the reference number along with the
item, all its components and your receipt
to your nearest store for a full refund.
This does not affect your statutory rights.
Customer Helpline
0844 481 5000
Monday - Friday 9am - 8pm, Saturday 9am - 5pm
Sunday 11am - 4pm. Calls charged at local rates.
© 2010 Digital Products International (DPI, Inc.) | All other trademarks appearing herein are the property of
their respective owners. Specifications are subject to change without notice
Technical specifications
Input Voltage AC 230V ,DC9V
DC Battery size “C” x 6
Rating of speaker 8 OHM / 3W FM (MHz) 87.5 - 108 MHz
Standby power consumption <2w
07

© 2010 Digital Products International (DPI, Inc.) | All other trademarks appearing herein are
the property of their respective owners. Specifications are subject to change without notice
This symbol on the product or in the instructions means that your electrical and
electronic equipment should be disposed at the end of its life separately from your
household waste. There are separate collection systems for recycling in the EU.
For more information, please contact the local authority or your retailer where you
purchased the product.
