Illuminated Mirrors DiamondX Operation manual

IP65 rated
Water Proof
Mirrors
Illuminated Mirrors
The UK’s Largest LED Mirror Supplier to Trade and Retail
www.illuminated-mirrors.uk.com
Installation
& User Guide

2Instruction manual IP65 rated Water Proof Mirrors
IP65 rated Water Proof Mirrors
Installation & User Guide
Thank you for purchasing our illuminated mirror(s).
To avoid product damage or personal injuries, carefully read,
understand, and follow all the Instructions in this installation
guide before installing the product.
Save this manual for future reference.
IP65
IR Sensor
Water Proof
Frosted Glass
Illuminated
LED
Demist
Infrared

3Instruction manualIP65 rated Water Proof Mirrors
WARNING!
To avoid the risk of electrocution,
please turn o the electricity supply mains
before commencing the installation.
We recommend this item gets tted by
a qualied electrician

Instruction manual IP65 rated Water Proof Mirrors
4
CONTENT
IMPORTANT INFORMATION
INSTALLATION
OPERATING INSTRUCTIONS
FAQs

5
Instruction manualIP65 rated Water Proof Mirrors
IMPORTANT INFORMATION
1. This product should only be installed by a fully qualied
electrician in accordance with the current IEE wiring regulations
(UK) or the equivalent national wiring regulation outside of the
UK. This light tting is a Class I product and therefore must be
earthed. Always switch o the electricity supply at the mains
before and during installation of this product.
This product is IP65 rated so can be safely tted in Zones 1, 2
and 3.
60 cm
60 cm
Radius
60 cm
225 cm 75 cm
75 cm
75 cm
60 cm 60 cm

Instruction manual IP65 rated Water Proof Mirrors6
INSTALLATION
2. Your mirror consists of two parts, the Mirror and the mounting
back plate, as shown below.
3. For recessed mounting, begin by marking out the position of
your mirror (a) and create a wall cavity (b) to match the back
plate dimensions. Also mark out the position of the mains cable
hole and install your mains cable at this point
IR Sensor
Mirror
Mirror rear box
Locators
Main cable
entry hole
Back plate
LED Illuminating
frosted glass areas
Solid wall Solid wall
a
b
Wall cavity to match
mirror back plate
dimension Сable
entry hole

7Instruction manualIP65 rated Water Proof Mirrors
4. For both wall and recess mounting, mark out the position of
the four frame mounting holes (e). Using an appropriate drill bit
for your wall, drill the four mounting holes and t wall plugs
where required (f). The plugs supplied with the mirror are suitable
for brick walls only. If in doubt please consult your local DIY store
for advice on alternative suitable xings.
5. Connect your mirror’s power lead to the mains supply (g)
e
f
Solid wall
Live Earth Neutral
Rear box
with Mirror on Concealed
back plate
g

Instruction manual IP65 rated Water Proof Mirrors8
6. Slot the mirror onto the frame using the four locating screws (h)
7. Optional. Although not essential, for a better nish you can
apply a silicon sealant (not supplied) around the perimeter of the
mirror (i). Your mirror is now ready to use.
h
Solid wall
Silicone sealant
i

9Instruction manualIP65 rated Water Proof Mirrors
Operating Instructions:
All waterproof IP65 rated cabinets include an inferred on/o sensor
located on the front of the mirror. Simply wave your hand across the
sensor and it will instantly power up the light. Repeat the action to
turn o the lights. This action also turns the demister pad on/o
simultaneously.

Instruction manual IP65 rated Water Proof Mirrors10
FAQs
1. How does the sensor work?
You need to wave your hand 3-6 inches away to
activate/deactivate.
2. Where is the sensor located?
The sensor is located on the front of the glass.
3. Does the demister pad demist the whole face of the mirror?
Yes, the whole mirror face will demist.
4. How do I activate/deactivate the demister pad?
The demister pad works automatically when the lights are
turned on and o.
5. How do I know if the demister pad is on?
The mirror front will heat up and demist.
