Illuminated Mirrors Diamond X Large Operation manual

Large &Aura
Mirrors
Illuminated Mirrors
The UK’s Largest LED Mirror Supplier to Trade and Retail
www.illuminated-mirrors.uk.com
Installation
& User Guide

2Instruction manual Large & Aura Range of Bathroom Mirrors
Large Bathroom Mirrors
and Aura Range
Installation & User Guide
Thank you for purchasing our illuminated mirror(s).
To avoid product damage or personal injuries, carefully read,
understand, and follow all the Instructions in this installation
guide before installing the product.
Save this manual for future reference.
IP44
Sensor
Shaver socket
Illuminated
RGB
Infrared

3Instruction manualLarge & Aura Range of Bathroom Mirrors
WARNING!
To avoid the risk of electrocution,
please turn o the electricity supply mains
before commencing the installation.

Instruction manual Large & Aura Range of Bathroom Mirrors
4
CONTENT
IMPORTANT INFORMATION
Installation
1 Positioning
2 Installation
Operation
1 On/O Infrared Sensor
2 Shaver Socket
3 Ambient Lighting
4 RGB Colour Change Lighting
5 Bluetooth Audio
FAQs

5
Instruction manualLarge & Aura Range of Bathroom Mirrors
IMPORTANT INFORMATION
This product should only be installed by a fully qualied
electrician in accordance with the current IEE wiring regulations
(UK) or the equivalent national wiring regulation outside of the
UK. This light tting is a Class I product and therefore must be
earthed. Always switch o the electricity supply at the mains
before and during installation of this product.
1. This product is IP44 rated so can be safety tted in Zones 2
and 3. Position the mirror in a suitable location with at least
15cm clearance between the proximity sensor and the
nearest surface and according to the zonal diagram show
below, ensuring that the domestic electrical mains supply is
within reach of the electrical entry point of the product.
60 cm
60 cm
Radius
60 cm
225 cm 75 cm
75 cm
75 cm
60 cm 60 cm

Instruction manual Large & Aura Range of Bathroom Mirrors6
INSTALLATION
2. Carefully unpack the mirror and lay it on a clean at protected
surface. Unscrew the electrical components housing box (a) to
reveal the terminal block (b).
The size and position of the back box will vary dependent on the
model you have purchased.
Measure and note the distance between the four mounting slots.
ab

7Instruction manualLarge & Aura Range of Bathroom Mirrors
With at least 15cm between the proximity sensor and the nearest
surface (c), decide on the location of the mirror and using a level
mark the hole locations on the wall (d).
Using an appropriate drill bit for your wall, drill the four mounting
holes and t wall plugs (e). The plugs supplied with the mirror are
suitable for brick walls only. If in doubt please consult your local
DIY store for advice on alternative suitable xings. Fix the
mounting screws to the wall ensuring that they are left
protruding enough to mount the mirror (f).
15cm 15cm
15cm
Free zone
cd
ef

Instruction manual Large & Aura Range of Bathroom Mirrors8
Pull the power cord through the rubber entry grommet on the
side of the electrical components housing box and connect to
the terminal block.
Reattach the housing box. And carefully hang the mirror on the
four protruding mounting screws.
Live
Earth
Natural

9Instruction manualLarge & Aura Range of Bathroom Mirrors
Operating Instructions:
1. On/O Infrared Sensor
All our Mirrors include an infrared on/o Sensor located on the
bottom of the frame, simply wave your hand across the sensor and
it will instantly power up the lights and demister pad. Repeat the
action to turn the light and demister pad o. On some mirrors
tted with Ambient under-lighting the sensor position will be on
the side of the mirror frame.
2. Shaver Socket
Shaver Mirrors include a 240 Volt shaver socket for the use of
electric shavers and toothbrushes. The shaver socket includes its
own on/o rocker switch which works separately from the lights
and demister pad.
3. Ambient Lighting
Please note that the ambient single colour or white lighting turns
ON and OFF on the actuation of the proximity sensor along with
the main mirror lights and the mirror demister.
4. Bluetooth Audio
To activate the internal Bluetooth Audio System simply turn on
the Shaver Socket/Bluetooth switch. You will hear an activation
tone coming from your cabinet speakers.
For Bluetooth operation, the internal Audio System will
automatically become available for your device to pair to,
appearing as Diamond X on your mobile’s Bluetooth available
devices list. Depending on your portable device and your settings,
subsequent pairing will be automatic.
For Auxiliary Input operation, simply connect your portable
device via its auxiliary output socked or headphone socket to
the cabinets Auxiliary input socket using a stereo Auxiliary cable
(not provided).

5. RGB Colour Change Lighting
Simply point you remote towards the small black sensor located
on either the bottom or side of the mirror frame. Select you Static
Colour option from the keypad. The brightness of the light can be
adjusted in steps by pressing the top left two UP and DOWN
control buttons. The ON - OFF function will only operate if the
main mirror lights are turned on using the remote sensor as
described in Section 1.
There are four MODE buttons giving the eects described in the
table show below. To operate these simply point your remote
towards the black sensor and select the required function and
click once. The speed of the transitions can be increased or
decreased by pressing the UP or DOWN buttons. Simply select a
static colour to cancel the function.
MODE DESCRIPTION
FLASH Flashes between 7 Colours
STROBE Strobes the chosen Static Colour
FADE Fades the Static Colour, On and O.
SMOOTH Fades between Red, Green and Blue.
SMOOTH
FADE
STROBE
FLASH
ONOFF
WBGR
ONOFF DOWN UP
SMOOTH
FADE
STROBE
FLASH
WhiteBlueGreenRed
Light
Green Dark
Blue
Orange
PinkCyan
Dark
Yellow
Purple
Light
Blue
Yellow
Magenta
Sky
Blue
Light
Yellow
Static Colours
Eects
Light Brightness &
Eects Speed
UP - DOWN
Instruction manual Large & Aura Range of Bathroom Mirrors10

FAQs
1. What is a LED Mirror?
A LED Mirror uses Energy Saving LED light bulbs. They are
Waterproof Rated IP44 for use in bathrooms and include clever
technology like, Infra-Red on/o sensors, Anti-Mist demister
pads and a shaver socket.
2. On/O Infrared Sensor?
All our LED Mirrors include Infra-Red on/o Sensor, simply wave
your hand to the sensor and it will instantly powers up the lights
and demister pad. You need to wave your hand 3-6 inches away
to On/O your mirror cabinet.
3. Where is the sensor located?
The sensor is located on the bottom of the mirror and not on the
front of the glass.
4. Can I isolate the sensor so the led's come on with my
bathroom lighting?
Yes this can easily be done by a qualied electrician by
bypassing the Infra-Red switch as shown below:
11Instruction manualLarge & Aura Range of Bathroom Mirrors
Infra-Red
SWITCH
INPUT
OUTPUT
LED
CONVERTER
INPUT OUTPUT
Wired For IR Sensor
Infra-Red
SWITCH
INPUT
OUTPUT
LED
CONVERTER
INPUT OUTPUT
IR Sensor Bypassed

5. How do I activate the demister pad?
The demister pad works automatically when the lights are
turned on and o.
6. Is the mirror tinted glass?
No, the mirror is perfectly clear reective mirror glass.
7. Is the mirror CE & ROHS certied?
Yes!
