ilntegral LED ILDRCVA042 User manual

12V/24V Constant Voltage LED Driver
Non-Dimmable
Installation Guide
Please retain for future reference
ILDRCVA/ V1
Compliant to: EMC EC 2014/30/EU, LVD EC 2014/35/EU
Models
ILDRCVA042 79-89-94 (20W 12VDC)
ILDRCVA041 99-51-39 (40W 12VDC)
ILDRCVA043 84-03-26 (50W 12VDC)
ILDRCVA044 14-89-40 (75W 12VDC)
ILDRCVA045 10-13-70 (100W 12VDC)
ILDRCVA046 12-15-64 (20W 24VDC)
ILDRCVA047 49-56-44 (75W 24VDC)
ILDRCVA048 63-93-49 (100W 24VDC)
Integral-LED.com
Integral Memory plc. London, NW10 0UF, UK.
IP20

Constant Voltage 12V/24V LED Driver
Installation Guide
WARNING
RISK OF ELECTRICAL SHOCK. ALWAYS SWITCH OFF POWER AT THE MAINS BEFORE INSTALLING OR MAINTAINING THIS LED DRIVER
IMPORTANT NOTICE
• This LED driver should be installed according to the instructions in this guide and by a qualied
electrical installer. All electrical work must be completed in accordance with the latest IET
regulations (formally IEE) for the UK and in accordance with all applicable regulations and laws in
the country in which it being installed.
• Always SWITCH OFF the power at the mains when installing, adjusting or maintaining the LED
driver.
• The LED Driver must be installed in indoor dry areas only, avoid any contact with moisture or water
and protect against excessive heat and allow adequate ventilation (operating temperatures: -20C
to + 45 C).
• Observe the correct wiring and polarity for INPUT (primary) (200~240V AC 50Hz/60Hz) and
OUTPUT (secondary) (12V/24V DC). Errors in connecting the device can lead to irreparable
damage or personal injury.
• An electronic protection circuit will switch OFF the power supply internally in case of a short/open
circuit or overload on the 12V/24V output circuit. Once faults are corrected the LED driver will reset
automatically.
• Do NOT dismantle the driver; there are NO user-serviceable parts inside.
• This LED driver is Non-Dimmable – Do NOT install in a dimmable circuit.
FOR THE BEST PERFORMANCE AND TO AVOID ANY DAMAGE TO THE DRIVER
OR CONNECTED DEVICES
• This is a SWITCH MODE 12V/24V DC CONSTANT VOLTAGE LED Driver – It must ONLY be used with
suitable CONSTANT VOLTAGE LED LAMPS or STRIPS. Do NOT use with NON-LED devices. Ensure
a suitable load is connected.
• Connected loads to the 12V/24V OUTPUT should be connected in PARALLEL only.
• To allow for power variation in installations, the connected load wattage should be up to 80%-90%
of wattage of the LED driver. Do NOT overload the LED driver.
• Before mounting the driver, determine a suitable and safe installation position (see Fig 3) and
consider how the driver will be switched ON and OFF.
• To maintain EMC compliance the output cable to LED devices should not exceed 2M in length.
INSTALLING THE LED DRIVER
1. Switch the power OFF at the mains.
2. Unscrew and remove the connector covers.
3. Connect the 12V/24V load wires on the OUTPUT (secondary) side – Ensure the correct polarity.
(see Fig 1).
4. Connect the mains supply wires to the INPUT (primary) side – Ensure the correct polarity.
(see Fig 2).
5. Check connections are secure and that there are no loose strands. Screw down the connector
covers ensuring the outer wire insulation is held under the cord grip.
IP20

Fig 1
OUTPUT(secondary) 12V/24V DC load
Fig 2 INPUT(primary) 200-240V AC (50/60Hz) Supply on 20W/50W/75W
Models:
ILDRCVA041 (40W 12VDC)
ILDRCVA045 (100W 12VDC)
ILDRCVA048 (100W 24VDC)
ILDRCVA042 (20W 12VDC)
ILDRCVA043 (50W 12VDC)
ILDRCVA044
ILDRCVA046
ILDRCVA047
(75W 12VDC)
(20W 24VDC)
(75W 24VDC)
Models:
INPUT
OUTPUT
12V DC
200-240V AC
N
L
INPUT
OUTPUT
24V DC
200-240V AC
N
L
INPUT
OUTPUT
24V DC
200-240V AC
N
L
INPUT220-240V AC (50/60Hz) Supply on 100W
INPUT
OUTPUT
24V DC
220-240V AC
L
N
Blue
Brown
Brown
Blue
6. When the circuit has been safety tested, switch ON power and conrm operation.
7. Once the position and functionality is confirmed. Switch OFF the power at the mains and
mount the LED driver if required using suitable fixings (not supplied).

Model No Input
Voltage
(AC)
Type Input
Current
Output
Voltage
(DC)
Maximum
Output
Current
Max
Power
Rating
IP
Rating
ILDRCVA042 200-240V AC, 50/60Hz
Constant
Voltage
<0.23A 12V DC 1.67A 20W
IP20
ILDRCVA041 200-240V AC, 50Hz <0.30A 12V DC 3.33A 40W
ILDRCVA043 200-240V AC, 50/60Hz <0.30A 12V DC 4.2A 50W
ILDRCVA044 200-240V AC, 50Hz <0.50A 12V DC 6.25A 75W
ILDRCVA045 220-240V AC, 50/60Hz <0.7A 12V DC 8.33A 100W
ILDRCVA046 200-240V AC, 50/60Hz <0.23A 24V DC 0.83A 20W
ILDRCVA047 200-240V AC, 50/60Hz <0.5A 24V DC 3.13A 75W
ILDRCVA048 220-240V AC, 50/60Hz <0.7A 24V DC 4.17A 100W
Model No Ambient
Temp
Max(tc)
Case
Temp
Max(tc)
Recommended Input
Cable Specication Recommended Output Cable Specication
ILDRCVA042
+45° C
80° C H03VVH2-F 2x0.75mm² H03VVH2-F 2x0.75mm²
ILDRCVA041 85° C H03VVH2-F 2x0.75mm² H03VVH2-F 2x0.75mm²
ILDRCVA043 85° C H03VVH2-F 2x0.75mm² H03VVH2-F 2x0.75mm²
ILDRCVA044 80° C H03VVH2-F 2x0.75mm² H03VVH2-F 2x0.75mm²
ILDRCVA045 90° C H03VVH2-F 2x0.75mm² H05VVH2-F 2x1.00mm²
ILDRCVA046 80° C H03VVH2-F 2x0.75mm² H03VVH2-F 2x0.75mm²
ILDRCVA047 80° C H03VVH2-F 2x0.75mm² H03VVH2-F 2x0.75mm²
ILDRCVA048 90° C H03VVH2-F 2x0.75mm² H05VVH2-F 2x1.00mm²
Limited 3 Year Warranty
This LED driver is for indoor use only. Improper installation, abuse or miss-powering of the driver
or failure to use the driver for its intended use will void the warranty. Proof of purchase is required
for all returns. Your statutory rights remain unaected.
Please see www.integral-LED.com/warranty
Questions? Please contact you supplier or see integral-LED.com
SPECIFICATIONS:
Fig 3 Mounting Location
50mm 50mm
50mm 50mm
50mm
50mm
50mm
Integral LED is a division
of Integral Memory plc:
Unit 6, Iron Bridge Close,
Iron Bridge Business Park,
London, NW10 0UF, UK
