Ilsintech Multipack-F User manual

All-in-one Preparation kit for the Optical Fiber Field Termination
Read this service manual carefully before using Multipack-F.
Multipack-F
WWW.ILSINTECH.COM
USER MANUAL

This device complies with Part 15 of the FCC Rules. Operation is subject to the following two conditions:
(1) This device may not cause harmful interference, and (2) this device must accept any interference
received, including interference that may cause undesired operation.
Telephone [phone]~11
Homepage www.ilsintech.com
E-mail [e-mail]
Device Type
Notification
A Class Device
(Broadcasting and
communication device,
commercial use)
Users need to understand that this device (A Class) has
obtained EMI (Electromagnetic compatibility) and been
designed to be used in places other than home.

1
TABLE OF CONTENTS
I. NOTES TO USERS 5
II. SPECIFICATIONS AND COMPONENTS 9
1. Specifications 9
2. In the package 10
III. HOW TO USE 13
1. Power Supply 13
2. Battery 15
IV. FEATURES 16
1. Body 16
2. Multipack-F Auto Stripper 18
3. Multipack-F Alcohol dispenser 20
4. Multipack-F Cleaver 21
5. Multipack-F Sleeve Heater 22
6. Multipack-F Optical Power Module 24
V. OPERATION 28
1. Function buttons 28
2. Multipack-F Activation 29

2
3. Inserting optical fiber into the splice sleeve tube. 29
4. Stripping Procedure 30
5. Cleaning Procedure 32
6. Cleaving Optical Fiber 33
7. Placing a sleeve tube into the sleeve heater 34
8. Heating Sleeve Tube 35
VI. MAINTENANCE 38
1. Auto Stripper maintenance 38
2. Cleaver maintenance 39
3. Sleeve Heater maintenance 42
4. Optical Power Modules maintenance 43
VII. MENU 45
1. Main Menu 45
2. Mode Menu 46
3. Sleeve Heater Mode (Ht Mode Menu) 46
4. Stripping Mode (Str Mode Menu) 47
5. Clock Setting 47
6. Checking Program Version (Program Ver) 48

3
7. Sleeve Heater Mode Setting 48
8. Stripping Mode Setting 49
9. Optical Power Meter 49
VIII. MENU OPERATION 50
1. Going to Submenu 50
2. Going Up to Main Menu 50
3. Changing Modes or Preset Values 50
4. Example for Mode Alteration 51
5. Example for Preset Value Alteration 52
IX. WARRANTY PERIOD AND CONTACT 53
1. Warranty Period and Limit of Responsibility 53
2. Before sending the equipment 53
3. For more effective maintenance and repair 54
4. Transport 54
5. Repair 54
PRODUCTS WARRANTY 56

4

5
I. Notes to Users
Multipack-F has been designed to assure an easy and convenient operation in both
indoor and outdoor work conditions; however, users need to carefully read this user
manual prior to operating this machine in order to prevent any accident or damage to the
equipment.
This easy-and-simple-to-use machine contains potential risks of harm’s way or injury.
Therefore, use Multipack-F only after thoroughly understood this user manual.
ILSINTECH Co., Ltd is not liable for any personal injury, physical loss and damage to
equipment caused by inappropriate use or unauthorized modification of the Multipack-F.
Please turn off the power immediately and contact ILSINTECH Co., Ltd if any of
following incident occurs while operating the Multipack-F.
. Fumes, bad odour, strange noise or overheating
. Liquid or foreign substance contaminates the device
. Multipack-F is dropped or damaged
Use only the AC power cord provided by the manufacturer. Using an improper AC
power cord many cause fire, electric shock or equipment damage resulting in
personal injury.
Do not touch electrodes when Multipack-F is turned on; high voltage and heat
generated from the electrodes could cause severe electric shock or burns.
Keep this user manual along with equipment at all times.
Warnings
Warnings

6
Apply correct voltage.
The input AC power of the charger is AC 100-240V and 50-60Hz.
Check the AC power before use. Providing AC power of an inappropriate range can
cause flame, fire, damage on the equipment, or severe injuries, electric shock or
even death. Inappropriate AC output voltage or frequency from AC power is a
common issue. Before connecting AC power cord, measure AC output voltage
using the circuit tester. Inappropriately high voltage or frequency of AC power can
cause flame, fire, damage on the equipment or severe injuries or even death.
Do not excessively pull on, heat or modify the AC power cable. The use of damaged
power cable may cause fire or injury.
Always connect to 3-core AC power cord. Do not use 2-core AC power cord, cable
and plug.
Do not touch AC plug, AC power cord or Multipack-F with a wet hand. It could result
in electric shock.
Do not disassemble AC adapter, battery or the Multipack-F. Transforming or modification
of Multipack-F unit could cause fire, electric shock or injury.
When using an external battery, follow the instructions below;
�
The use of 3rd party or makeshift external battery may cause fumes or damage
to the equipment and, in serious cases, it could result in burn, injury or even
death.
�
Do not discard the battery into a trash incinerator or fire.
�
Do not charge or discharge the battery near a flame or blaze.
�
Do not excessively shake or physically contact the battery.
�
If a battery is not fully charged or green LED is not turned on in six hours,
immediately stop charging and contact I.
Do not place any object on the AC adaptor during charging.
Use charger (MPF-B) exclusively designed for the equipment. The use of other
battery pack may cause fumes, burn, damaged to the unit, injury or even death.
Warnings
Warnings

7
Use the battery charger (MPF-B) which is designed for the unit.
Do not apply different AC power.
Do not make a short circuit of the terminals of the charger(MPF-B). Excessive
current may cause personal injury and equipment damage.
Do not use Multipack-F in an environment in which flammable liquids or hazardous
gas exists. The electric arc of Multipack-F may cause fire or explosion.
Do not clean Multipack-F with compressed air or compressed gas.
Check the condition of belt to see if there is any damage or worn-outs before
transporting the carrier case using the belt. If the carrier case is dropped due to
worn out belt, it could damage the unit or people could get hurt.
If optical fiber fragments come into contact with the eye or skin, it could be
extremely dangerous.
Do not operate Multipack-F near the temperature is over 50℃.
It could result in injury or damage equipment.
The heat oven reaches high temperatures. Be extremely cautious when operating
the oven.
Please keep hands and other objects away from the heater when in use.
The blade of the cleaver is very sharp so to be used carefully to avoid wound on
your hand.
Do not stare in to beam of visual fault locator.
: DO NOT TOUCH : EXTREMELY HOT
: LASER WARNING
Warnings
Warnings

8
Do not touch protection sleeve or tube-heater during heating or immediately after
completion of heating. Their surfaces are very hot and touching these may result in
burn.
Do not place Multipack-F in an uneven surface. The unit may fall, causing personal
injury or equipment damage.
Do not apply shock on Multipack-F, since it is a precision machine. When moving or
storing Multipack-F, use the carrying case which is designed for the equipment. The
carrying case protects the equipment against humidity, vibration and shocks and
prevents damages during its storage and moving.
Use pure ethyl alcohol (96% or greater) to clean the LCD monitor, body, each of the
other unit. Otherwise, blurring, discoloration, damage or performance deterioration
may occur.
Multipack-F requires no lubrication. The use of oil or grease may degrade the
performance and damage the equipment.
Do not store Multipack-F in a place where temperature or humidity is extremely
high. Equipment failure may occur.
The equipment’s technical parts must be examined by a qualified technician or
engineer, otherwise, it cause fire or electric shock. If any problems occur, ask
ILSINTECH for repair and maintenance.
Cautions
Cautions

9
II. Specifications and Components
1. Specifications
Subject
Description
Applicable type of
fibers
0.25mm, 0.9mm, 2.0mm, 3.0mm, 4.0mm, Indoor cable
Applicable type of
connector
SC, FC, ST, LC
Fiber count
Single fiber
Applicable fiber
dimensions
Cladding diameter: 125㎛, Coating diameter: 250, 900㎛
Fiber setting and
cleaved length
8.0mm
Sleeve heating time
30sec(0.9mm fiber), 70sec(Indoor, 3.0mm cable),
80sec(connector)
Applicable protection
sleeve
60mm, micro, Connector Sleeve
Operating condition
Altitude: 0~5,000m above sea level, Temperature: -10℃~50℃,
Humidity: 0~95%, Wind: 15m/s, non-condensing
Storage
Temperature: -40℃~80℃, Humidity: 0~95%
Dimensions
145(W)×137(L)×98(H) mm
Weight
1.2Kg(Include battery)
display
1.4” color LCD monitor
Power supply
DC Lithium polymer battery(DC 14.8V, 4700mAh),
100 ~240V AC Adapter
No. of splice cycles
with battery
Typical 630 Times(0.9mm fiber)
Terminals
USB, External power(DC 12V Available for car cigar jack)

10
2. In the package
Holder
Heater Block
R
Tool Box
Cooling Tray
Allen wrench
Tweezer
Brush
Multipack-F
Charger Set
Work Belt
Carrying Case

11
Standard Package
Option Package
Category
Model
Q’ty
Category
Model
Multipack-F
MPF
1
Cleaver Blade
BI-05
Battery Charger
MPF-B
1
Battery Charger
MPF-B
AC Adapter
LYD1805000
1
Sleeving Clamp
SC-01
Cooling Tray
CT-01
1
Manual Stripper
MS-01
Allen wrench
1.5/2.0/2.5
1set
Holder
80S/S178
Compatible
250,900, IN, 3.0F,
SC/FC/ST/LC
Heater Block R
-
1set
Z1C
Compatible
250,900, IN, 3.0F,
SC/FC/ST/LC
Holder
-
1set(2ea)
Sleeve
S09-C
0.9mm connector,
1.0×2.3×28mm
Tool Box
CA800-2
1
S09
0.9mm cable,
1.0×2.3×45(60)mm
Brush
-
1
S30-C
3.0mm, Indoor connector,
3.5×4.0×32mm
Pincette
-
1
S30
3.0mm, Indoor cable,
3.5×4.0×45(60)mm
User Manual
CD
1
Carrying Case
Work Belt
Soft Case
1

12
1) Preparation for the Operation
Fiber types
0.25 mm
0.9 mm
Fiber
protection
sleeve
Basic
sleeve
Length: 40mm Length: 28mm
Micro
sleeve
Length: 20mm
Length: 25mm
Length: 34mm
Length: 45mm
Fiber holder
Fiber holder
[Standard] (250/900)
Cleave length : 8mm (Fixed)
Fiber holder
[FTTH]
(SOC(Splice-On Connector))
Cleave length : 8mm (Fixed)

13
III. How to Use
1. Power Supply
Always use the battery provided with Multipack-F by the manufacturer.
Connect AC power cord to the charging adapter and then to DC connecting jack for
battery pack, and the red LED on battery (for displaying power) is turned on and it starts
charging. The LED turns green as charging is completed. It takes approximately 3 hours to
charge when fully discharged.
Use only the charger and AC adaptor provided with the equipment.
The battery of Multipack-F (MPF-B) has a protection circuit and function to prevent over
discharge, overcharge and overload. The power is cut off when protective function is
activated.
Battery charging
Charger
The built-in
battery pack
AC Adapter
AC Power Cord

14
The remaining capacity of a battery is indicated at the top right on the screen when
Multipack-F is in use.
Remaining battery level
(Monitor)
Remaining battery level display
(LED)
Remaining battery
percentage
5 bars
5 LED
80 ~100%
4 bars
4 LED
60 ~80%
3 bars
3 LED
40 ~60%
2 bars
2 LED
20 ~40%
1bars
0 bars
1 LED
10 ~20%
1 LED
1 LED flash
Less than 5%
(It should be
charged
immediately.)
Checking remaining battery capacity

15
2. Battery
Use lock button to Install and remove the battery.
Battery installation
Lock button
Battery
Battery

16
IV. Features
Multipack-F is compact, light and convenient. It is recommended to carefully read the
user manual before operation to understand the entire functions of Multipack-F.
1. Body

17
Cleaner
Stripper
Sleeve Heater
Cleaver
LCD Monitor
Control
Auto Chip
Collector
(Option)
Optical Power
Module

18
2. Multipack-F Auto Stripper
1) Features
Multipack-F automatic fiber stripper automatically carries out an accurate stripping of
the coating of single fibers. Featuring excellent tensile force of fiber, the automatic
stripper strips up to 27mm in length without damaging the surface of fiber. Read the
user manual thoroughly to maintain the best performance of the unit.
2) Specifications
Strip Length
27mm
Applicable Optical Fiber Diameter
0.25, 0.9mm
Blade life
More than 100,000 times
Motor life
More than 1,000,000 times
Fiber count
Single type
Tension
More than 3kgf
Heating Time
2.2 sec
Heating Range
130℃
