Iluminarc Ilumiline 36 IP Optic RGB User manual

Ilumiline 36 IP Optic Series
User Manual
•Ilumiline 36 IP Optic VW
•Ilumiline 36 IP Optic RGB

Edition Notes
Ilumiline 36 IP Optic (RGB or VW) User Manual Rev. 8
Edition Notes
The Ilumiline 36 IP Optic Series User Manual Rev. 8 covers the description, safety precautions,
installation, programming, operation, and maintenance of the
Ilumiline 36 IP Optic
(RGB or VW). ILUMINARC released this edition of the Ilumiline 36 IP Optic Series User
Manual Rev. 8 in April 2018.
Trademarks
The ILUMINARC logo, the ILUMINARC
name and all other trademarks in this document
related to services or products by ILUMINARC
are trademarks owned or licensed by
ILUMINARC, its affiliates or subsidiaries. Any other product names, logos, b
rands, company
names,
trademarks featured or referred to within this document are the property of their
respective trademark holders.
Copyright Notice
The entire content of this document, except where applicable and unless otherwise noted, is
solely owned by ILUMINARC, a wholly owned trademark of Chauvet & Sons, LLC.
© Copyright 2018 ILUMINARC.
All rights reserved.
Electronically published by ILUMINARC in the United States of America.
Manual Usage
ILUMINARC
authorizes its customers to download and print this manual for professional
information purposes only. ILUMINARC expressly prohibits the u
sage, copy, storage,
distribution, modification,
or printing of this manual or its content for any other purpose
without its written consent.
Document Printing
For better results, print this document in color, on letter size paper (8.5 x 11 inches), double
sided. If using A4 paper (210 x 297 mm), configure your printer to scale the content of this
document to A4 paper.
Intended Audience
Any person in charge of installing, operating, and/or maintaining the
Ilumiline 36 IP Optic
(RGB or VW)
should read the Guide that shipped with it and this manual in their entirety
before installing, operating, or maintaining this product.
Disclaimer
ILUMINARC
believes that the information contained in this manual is accurate in all respects.
However, ILUMINARC
assumes no responsibility for any error or omissions in this document.
ILUMINARC
reserves the right to revise this document and to make changes from time to time
in the content hereof without obligation of ILUMINARC
to notify any person or company of
such revision or changes. This does not constitute in any way a commitment by ILUMINARC
to make such changes. ILUMINARC
may issue a revision of this manual or a new edition of it
to incorporate such changes.
Document Revision
The Ilumiline 36 IP Optic Series User Manual Rev. 8 supersedes all previous versions of this
manual. Please discard any older versions of this manual you may have, whether in printed or
electronic format, and replace them with this version.

Table of Contents
Ilumiline 36 IP Optic (RGB or VW) User Manual Rev. 8 I
Table of Contents
1. Introduction ...................................................................................................1
What Is In the Box........................................................................................................ 1
Unpacking Instructions................................................................................................. 1
Text Conventions ......................................................................................................... 1
Safety Notes................................................................................................................. 2
Personal Safety...................................................................................................................2
Mounting and Installation.....................................................................................................2
Power and Wiring................................................................................................................2
Operation.............................................................................................................................2
2. Product Description......................................................................................3
Common Features........................................................................................................ 3
VW Features........................................................................................................................3
RGB Features......................................................................................................................3
Options................................................................................................................................3
Product Overview......................................................................................................... 4
Product Dimensions ..................................................................................................... 5
3. Installation.....................................................................................................6
AC Power ..................................................................................................................... 6
Power Consumption............................................................................................................6
AC Plug ...............................................................................................................................6
Power Wiring.......................................................................................................................6
DMX Linking................................................................................................................. 7
DMX Modes.........................................................................................................................7
Signal Wiring .......................................................................................................................8
Protocol Connectivity...........................................................................................................8
Controllers.................................................................................................................... 9
DMX Controller....................................................................................................................9
ILUMICON.........................................................................................................................10
Ilumicode...........................................................................................................................11
Mounting..................................................................................................................... 12
Orientation.........................................................................................................................12
Installation.........................................................................................................................12
Procedure..........................................................................................................................12
4. Operation.....................................................................................................13
Ilumicode.................................................................................................................... 13
Ilumicode Panel Description..............................................................................................13
Menu Map .................................................................................................................. 13
VW Functions Menu Map ..................................................................................................13
RGB Functions Menu Map ................................................................................................14
Programming.............................................................................................................. 14
DMX Personality................................................................................................................14
DMX Starting Address.......................................................................................................14
Static Colors......................................................................................................................15
Dimmer..............................................................................................................................15
Color..................................................................................................................................15
Whites Setting ...................................................................................................................16
Reset to Factory Settings..................................................................................................16
DMX Values ............................................................................................................... 17
ARC 1................................................................................................................................17
ARC 1 + D.........................................................................................................................17
ARC FULL.........................................................................................................................17
SPECIAL 1 ........................................................................................................................18
VW.....................................................................................................................................18
VW + D..............................................................................................................................18
SOLID................................................................................................................................18

Table of Contents
II Ilumiline 36 IP Optic (RGB or VW) User Manual Rev. 8
5. Technical Information................................................................................. 19
Product Maintenance ................................................................................................. 19
Product Repairs.......................................................................................................... 19
Troubleshooting Guide............................................................................................... 20
Photometrics .............................................................................................................. 21
LED Disclaimer........................................................................................................... 23
LED Life.............................................................................................................................23
LED Binning.......................................................................................................................23
Color Rendering Index (CRI).............................................................................................23
Returns Procedure..................................................................................................... 24
Claims......................................................................................................................... 25
Technical Specifications VW Products....................................................................... 26
Technical Specifications RGB Products..................................................................... 27

Introduction
Ilumiline 36 IP Optic (RGB or VW) User Manual Rev. 8 1
1. Introduction
This icon
indicates useful,
although non-
critical information.
This icon
indicates
important
installation or
configuration information.
Failure to comply with this
information may prevent
the product from
functioning correctly.
This icon
indicates critical
installation,
configuration, or operation
information. Failure to
comply with this
information may render
the product partially or
completely inoperative,
damage third-party
equipment, or cause harm
to the user
The term “DMX”
used throughout
this document
refers to the USITT
DMX512-A transmission
protocol.
What Is In the Box
•One Ilumiline 36 IP Optic (VW or RGB)
•Warranty Card
•Quick Reference Guide
Unpacking Instructions
Immediately upon receiving a product from ILUMINARC, carefully unpack the carton. Check
the contents of the box to ensure that all parts are present and that they are in good condition. If
any part appears damaged from shipping, or if the carton shows signs of mishandling, see the
Claims section in the Technical Information chapter.
Text Conventions
Convention Meaning
1~512
A range of values in the text
50/60
A set of mutually exclusive values in the text
“ILUMICON UM”
The name of another publication or manual
<SET>
A button on the product’s control panel
Settings
A product function or a menu option
MENU > Settings
A sequence of menu options
1~10
A range of menu values from which to choose in a menu
Yes/No
A set of two mutually exclusive menu options in a menu
ON
A unique value to enter or select in a menu

Introduction
2 Ilumiline 36 IP Optic (RGB or VW) User Manual Rev. 8
There are no user
serviceable parts
inside this
product. Any reference to
servicing you may find
from now on in this User
Manual will only apply to
properly certified
ILUMINARC technicians.
Do not open the housing
or attempt any repairs
unless you are certified to
do so.
Please refer to all
applicable local
codes and
regulations for the proper
installation of this product.
Keep this manual
for future
consultation. If
you sell this product to
another user, make sure
that they also receive this
manual.
In the unlikely
event that your
Ilumiline 36 IP
Optic (RGB or VW) may
require service, please
contact ILUMINARC
Technical Support.
Safety Notes
Please read all the following safety notes carefully because they include important information
on how to install, use, and maintain this product safely.
Personal Safety
•Avoid direct eye exposure to the light source while the product is on.
•Always disconnect this product from its power source before servicing.
•Always connect this product to a grounded circuit to avoid the risk of electrocution.
•Do not touch this product’s housing when operating because it may be very hot.
Mounting and Installation
•DO NOT submerge this product (IP66). Regular outdoor operation is fine.
•CAUTION: When transferring product from extreme temperature environments, (e.g.
cold truck to warm humid ballroom) condensation may form on the internal electronics
of the product. To avoid causing a failure, allow product to fully acclimate to the
surrounding environment before connecting it to power.
•Make sure there are no flammable materials close to this product while operating.
•When hanging this product, always secure it to a fastening device using a safety cable.
Power and Wiring
•Always make sure that you are connecting this product to the proper voltage, as per the
specifications in this manual or on the product’s sticker.
•Never connect this product to a dimmer pack.
•Make sure that the power input cable is not cracked, crimped, or damaged.
•Never disconnect this product by pulling or tugging on the power input cable.
Operation
•The maximum ambient temperature is 104° F (40° C). Do not operate this product at a
higher temperature.
•In case of a serious operating problem, stop using this product immediately!

Product Description
Ilumiline 36 IP Optic (RGB or VW) User Manual Rev. 8 3
2. Product Description
The Ilumiline 36 IP Optic Series User Manual includes two products:
•Ilumiline 36 IP Optic VW
•Ilumiline 36 IP Optic RGB
These products are available with 60° x 10° optics. The Ilumiline 36 IP Optic, both the RGB
and the VW, consist of a stainless steel body containing a power supply, control unit, impact
resistant glass cover, and 36 LEDs.
Common Features
•Remotely addressable DMX-512 LED linear wash light
•IP66 ingress protection
•IP66 stainless steel gland nuts for cable entry
•Extruded aluminum housing
•Five distinct dimming curves
•Integrated Cooling Enhancement™
•Gore™ valve controlled humidity
•Ilumicode compatible
VW Features
•Operating modes:
1-channel: Dimmer
2-channel: Warm white, cool white control
3-channel: Warm white, cool white, dimmer
•High power 1 W (350 mA) warm white and cool white LEDs
•Static color temperature control with or without a DMX controller
•SpectraWhite™ mixing with or without DMX controller
•Installed (non-changeable) optical system:
60°x10°lenses -Product order code: 12036006
RGB Features
•Operating modes:
1-channel: Dimmer
3-channel: RGB control
4-channel: RGB, dimmer
7-channel: RGB, dimmer, color macro, strobe, dimmer speed
•High power 1 W (350 mA) RGB LEDs
•RGB color mixing with or without DMX controller
•Installed (non-changeable) optical system:
60°x10°lenses -Product order code: 12036005
Options
•Ilumicode addresser (required for product configuration)
•The RDM2go, which includes a built in ilumicode addresser along with many other useful
features is now available.
•The Ilumicoode addresser is required for product configuration (sold separately).

Product Description
4 Ilumiline 36 IP Optic (RGB or VW) User Manual Rev. 8
Product Overview
Safety Loop
Power In
Signal In/Out
Gore™ Valve
Mounting
Brackets
Mounting
Brackets

Product Description
Ilumiline 36 IP Optic (RGB or VW) User Manual Rev. 8 5
Product Dimensions

Operation
6 Ilumiline 36 IP Optic (RGB or VW) User Manual Rev. 8
3. Installation
Always connect
the Ilumiline 36
IP Optic (RGB or
VW) to a protected circuit
with an appropriate
electrical ground to avoid
the risk of electrocution or
fire.
Never connect
the Ilumiline 36 IP
Optic (RGB or
VW) to a rheostat
(variable resistor) or
dimmer circuit, even if the
rheostat or dimmer
channel serves only as a
0 to 100% switch.
Make sure to
connect the
Ilumiline 36 IP
Optic (RGB or VW) to a
power line with the proper
voltage and frequency, as
per the specifications in
this manual or on the
product’s sticker.
The listed
current rating
indicates the
maximum current draw
during normal operation.
If you choose to
bury the power or
signal distribution
boxes, make sure that
they are IP66 rated or
greater.
AC Power
The Ilumiline 36 IP Optic (RGB or VW) has an auto-ranging power supply that can work with
an input voltage range of 100~240 VAC, 50/60 Hz.
Make sure that you are connecting this product to the proper voltage, as per the specifications in
this manual or on the product’s sticker.
Power Consumption
To determine the power requirements for the Ilumiline 36 IP Optic (RGB or VW), see
the label affixed to the side of the product. Alternatively, you may refer to the
specifications chart in the Technical Information chapter of this manual.
The listed current rating indicates the maximum current draw during normal operation.
AC Plug
The Ilumiline 36 IP Optic (RGB or VW) comes with a bare-ended power input cord
for hardwire installation. Use the table and the illustration below to wire a plug.
Connection Wire (US) Screw Color (US) Wire (Europe) IP66 Pin
AC Live
Black
Yellow or Brass
Brown
1
AC Neutral
White
Silver or Gray
Blue
2
AC Ground
Green/Yellow
Green
Green/Yellow
3
Power Wiring
You can connect the bare-ended IP66 rated AC power cable from the product to an
IP66 rated power connector or IP66 rated junction box.
If using junction boxes, make sure to use IP66 rated conduit for surface installations.

Operation
Ilumiline 36 IP Optic (RGB or VW) User Manual Rev. 8 7
The Ilumiline 36
IP Optic (RGB or
VW) must be
linked using
DMX cable in a daisy
chain (serial) fashion. To
comply with the EIA-485
standard, no more than
32 products should be
connected on one daisy
chain without using a
DMX optically-isolated
splitter. Doing otherwise
may result in deterioration
of the digital DMX signal.
USITT
recommends
limiting the total
length of the DMX cable
(from the first
product/controller to the
last product) to 300 ~ 455
m (985 ~ 1,500 ft).
Disconnect the
product from the
AC power before
opening it.
DMX Linking
You may link the Ilumiline 36 IP Optic (RGB or VW) to a DMX controller using a standard
DMX serial connection. If using other DMX products compatible with the Ilumiline 36 IP Optic
(RGB or VW), you can control each individually with a single DMX controller.
If you are not familiar with the DMX standard, or if you need information about the DMX cables
needed to link the Ilumiline 36 IP Optic (RGB or VW) to a DMX controller, you may download
the DMX Primer document from the ILUMINARC Web site at www.iluminarc.com.
DMX Modes
The Ilumiline 36 IP Optic (RGB or VW) uses the standard DMX data connection for all
its DMX personalities. Refer to the Introduction chapter for a brief description of these
modes. Refer to the Operation chapter to learn how to configure the Ilumiline 36 IP
Optic (RGB or VW) to work in these modes. The DMX Values section will provide you
with detailed information regarding the DMX modes.
VW
DMX Mode DMX Address
VW
511
VW + D
510
SOLID
512
RGB
DMX Mode DMX Address DMX Mode DMX Address
ARC FULL
506
SOLID
512
ARC1
510
SPECIAL1
507
ARC1+D
509

Operation
8 Ilumiline 36 IP Optic (RGB or VW) User Manual Rev. 8
The signal cable
must match or
exceed the
electrical
characteristics of the
Belden 9841 cable for
EIA RS-485 applications.
You may also use CAT5,
5e, or CAT6 LAN cable.
Signal Wiring
To provide signal for the Ilumiline 36 IP Optic (RGB or VW), you can connect the bare-
ended IP66 rated signal cable from the product to two IP66 rated signal connectors
(DMX in and DMX Out), or use an IP66 rated junction box and conduit.
Protocol Connectivity
The Ilumiline 36 IP Optic (RGB or VW) uses USITT DMX 512 protocol. The
procedure below illustrates the recommended connection method.

Operation
Ilumiline 36 IP Optic (RGB or VW) User Manual Rev. 8 9
If you have not
configured the
DMX starting
address and
DMX mode for each
product, they will all use
their default values. This
means that all products
will operate in unison.
Controllers
Each product in the Ilumiline 36 IP Optic Series can operate with a standard DMX controller, or
the Ilumicode addresser. The sections below provide information on how to connect these
products to the corresponding controllers. The instructions to operate these products with each of
the above controllers are in the Operation chapter of this manual.
DMX Controller
The Ilumiline 36 IP Optic (RGB or VW) can work with a standard DMX controller. The
channel assignments will depend on the chosen personality (see the corresponding Menu Map
on pages 13 and 14) and the DMX address assigned to each product (see Programming on
page 14).
The figure below illustrates how to connect the DMX controller to the Ilumiline 36 IP Optic
(RGB or VW).

Operation
10 Ilumiline 36 IP Optic (RGB or VW) User Manual Rev. 8
Refer to the
Operation chapter
of the ILUMICON
User Manual to
learn how to enable the
Ilumiline 36 IP Optic RGB
to operate with the
ILUMICON controller.
ILUMICON
The Ilumiline 36 IP Optic RGB can also work with the ILUMICON controller instead of a
standard DMX controller. Please refer to the ILUMICON User Manual to learn how to use this
controller with the Ilumiline 36 IP Optic RGB.
The figure below illustrates how to connect the ILUMICON controller to the Ilumiline 36 IP
Optic RGB.

Operation
Ilumiline 36 IP Optic (RGB or VW) User Manual Rev. 8 11
The RDM2go,
which includes a
built in ilumicode
addresser along with
many other useful
features is now available.
To assign
individual DMX
addresses to
each product,
you must connect the
Ilumicode to each
product, individually.
ILUMINARC
suggests that you
connect no more
than 20 products
in this mode and keep the
total distance to less than
60 m (197 ft). Otherwise,
you might need to use an
optically isolated signal
amplifier.
Ilumicode
The Ilumiline 36 IP Optic (RGB or VW) uses the Ilumicode for configuration purposes. The
diagram below shows how to connect the Ilumicode to this product. This connection will
control multiple products at the same time, all having the same DMX address.
The Ilumicode must be used to configure this product. The Ilumicode can be purchased
separately through your ILUMINARC sales representative.

Operation
12 Ilumiline 36 IP Optic (RGB or VW) User Manual Rev. 8
Make sure to
mount this
product away
from any flammable
material as indicated in
the Safety Notes.
Mounting
Before mounting this product, read and follow the safety recommendations indicated in the
Safety Notes section.
Orientation
Always mount this product in any safe position making sure there is adequate room for
ventilation, configuration, and maintenance.
Installation
The Ilumiline 36 IP Optic (RGB or VW) comes with two adjustable brackets with
3mm slot openings to mount the product on any firm, non-flammable surface. Once
mounted the angle of the product can also be adjusted and locked into place.
ILUMINARC recommends following the general guidelines below when mounting
the Ilumiline 36 IP Optic (RGB or VW).
•When selecting an installation location, consider ease of access to the product for
operation, programming adjustments, and routine maintenance.
•Make sure the product’s mounting location can support its weight. Please see the
Technical Specifications section of this manual for the weight requirement of this
product.
Procedure
The Ilumiline 36 IP Optic (RGB or VW) comes with two adjustable brackets with
3mm slot openings to mount the product on any firm, non-flammable surface. These
feet also serve as floor or wall mount supports. You will have to use two mounting
points per product.

Operation
Ilumiline 36 IP Optic (RGB or VW) User Manual Rev. 8 13
4. Operation
When you scroll
through the
menu options,
you will see
many of them that do not
correspond with this menu
map. Skip them, as they
do not work with the VW
output products.
Ilumicode
The Ilumiline 36 IP Optic (RGB or VW) needs an external controller, the Ilumicode addresser,
to change its configuration.
Ilumicode Panel Description
Menu Map
The products in the Ilumiline 36 IP Optic Series have distinct menu maps based on the colors
they produce, whether RGB or VW. The Ilumicode includes the functions for both types of
products.
VW Functions Menu Map
(Ilumiline 36 IP Optic VW)
This menu map shows you which parameters of the Ilumicode controller correspond to
the Ilumiline 36 IP Optic VW product.
Main Level Programming Levels Description
DMX 001~512 N/A Sets the DMX starting address
PERSON
VW
N/A
3-channel: SpectraWhite control
VW+D
4-channel: SpectraWhite control + dimmer
SOLID
1-channel: dimmer
DIMMER
OFF
N/A
Dimmer work in linear mode
DIM 1
Dimmer works in non-linear mode, from fast to
slow.
DIM 2
DIM 3
DIM 4
STATIC COOL 0~255 Configures the static color and effect
WARM
Button Function
<MENU>
Exits from the current menu or function
<ENTER>
Enables the currently displayed menu or sets the
currently selected value into the selected function
<UP>
Navigates upwards through the menu list and increases
the numeric value when in a function
<DOWN>
Navigates downwards through the menu list and
decreases the numeric value when in a function
<POWER>
Turns the unit on. The unit will turn off automatically
after 30 seconds of inactivity.

Operation
14 Ilumiline 36 IP Optic (RGB or VW) User Manual Rev. 8
When you scroll
through the
menu options,
you will see
many of them that do not
correspond with the menu
map. Skip them, as they
do not work with the RGB
only output products.
RGB Functions Menu Map
(Ilumiline 36 IP Optic RGB)
Main Level
Programming Levels
Description
DMX 001~512 N/A Sets the DMX starting address
PERSON
ARC1
N/A
3-channel: RGB control
ARC1+D
4-channel: RGB control + dimmer
ARC FULL
7-channel: RGB control, dimmer, color macro, strobe,
dimmer speed
REMOTE
Allows using the ILUMICON unit
SOLID
1-channel: dimmer
CALIB
WHITE (1~11) RED
GREN
BLUE 0~255
Determines the white balance for the color macros
RGBTOW Determines the white balance when RGBTOW is
active
DIMMER
OFF
N/A
Dimmer works in linear mode
DIM 1
Dimmer works in non-linear mode, from fast to slow.
DIM 2
DIM 3
DIM 4
STATIC
RED
0~255 Configures the static color and effect
GREN
BLUE
STRB
SETTINGS COLOR
OFF
Maximum output, unbalanced white
RGBTOW White output is as per CALIB > RGBTOW settings
UC
Output matches that of product’s previous versions
RESET
NO/YES
Resets unit to factory default settings
Programming
Carry out all the programming procedures indicated below from the control panel. Refer to the
Menu Map above to learn how the menu options relate to each other.
Use <ENTER> and <MENU> to change levels in the Menu Map,moving right and left
respectively. Use <UP> and <DOWN> to move vertically within the Menu Map.
DMX Personality
1. Go to PERS and select any DMX personality.
2. Make sure to rearrange the DMX addresses of all products in the current DMX
universe to avoid address overlapping.
DMX Starting Address
1. Go to DMX.
2. Select a starting DMX address (001~512).

Operation
Ilumiline 36 IP Optic (RGB or VW) User Manual Rev. 8 15
DIM1 is the
fastest dimmer
curve and DIM4 is
the slowest.
Static Colors
(Ilumiline 36 IP Optic RGB, only)
1. Go to STATIC.
2. Select a color or effect (Red, Green, Blue, or Strobe).
3. Select a color value (000~255) or a strobe frequency (0~20).
(Ilumiline 36 IP Optic VW, only)
1. Go to STATIC.
2. Select a color or effect (Cool or Warm).
3. Select a color value (000~255).
Dimmer
This setting gives the user four different options to simulate the dimming curve of an
incandescent lighting product.
1. Go to DIMMER.
2. Select a dimmer curve (OFF or DIM1~4).
Procedure:
DIMMER
Description
OFF
Dimmer curve is linear with fader
DIM1
Non-linear (fastest)
DIM2
Non-linear (fast)
DIM3
Non-linear (slow)
DIM4
Non-linear (slowest)
Color
1. Go to SETTINGS > COLOR.
2. Select the color method (OFF, RGB TO W, UC).
Procedure:
OFF
When the RGB faders are all set to “255”, the output is maximum.
RGB TO W
When the RGB faders are all set to “255”, the output is the selected White color (see
Whites Setting).
UC
When the RGB faders are all set to “255”, the output matches the same color output of
previous versions of this product.

Operation
16 Ilumiline 36 IP Optic (RGB or VW) User Manual Rev. 8
Whites Setting
(Ilumiline 36 IP Optic RGB, only)
1. Go to CALIB.
2. Select a white color (WHITE 1~11) or RGB TO W.
3. Select an RGB color (Red, Green, or Blue).
4. Configure the color value (0~255).
5. Repeat steps 3 and 4 for the other RGB colors to obtain a white color.
6. Repeat steps 2 to 5 for the other white colors.
Resetto Factory Settings
1. Go to SETTINGS > RESET.
2. Select an option (YES/NO).
