Noise Reduction Stereo Earphones
with Hands-free Microphone
Instruction Manual
i910
www.i-luv.com

V10M10_IM_EN_04242008
- 1 -

V10M10_IM_EN_04242008
- 2 -
INTRODUCTION
Active Noise Reduction Stereo Earphones
with Hands-free Microphone
Thank you for purchasing the i910 from iLuv. This headset has
been designed for enhanced reduction of outside noise to
remove distractions and help you concentrate on the music you
love. Please keep this manual in a safe place for future reference.
•Highly effective noise-canceling circuitry enhances audio
sound quality in noisy environments
•Built with high-performance speakers for extended
frequency range and lower distortion
•Fully-closed ear pieces deliver maximum sound and
efficiency

V10M10_IM_EN_04242008
- 3 -
1
2 3 4
5
6
GETTING STARTED
Location of Controls
1. Clothing Clip 4. ANR Switch
2. CALL/ANSWER Button 5. Microphone
3. MUTE Button 6. Battery Compartment

V10M10_IM_EN_04242008
- 4 -
GETTING STARTED
Installing the battery
1. Remove the battery door.
2. Insert one (1) AAA battery in the battery compartment as
shown in the illustration.
3. Replace the battery door.
Attaching the audio cable
1. The iPhone/iPod audio cable is included, connect the
2.5mm (small diameter) plug to the i910, and connect the
3.5mm (big diameter) plug to your iPhone or iPod.
2. The hands-free microphone and CALL/ANSWER button
will not function when the i910 is connected to your iPod.
Wearing the headset
•These earphones are designed to be worn comfortably in
the ears.
•Gently place the left and right earphone in each ear as
marked (L and R).

V10M10_IM_EN_04242008
- 5 -
OPERATIONAL INSTRUCTIONS
Using the Active Noise Reduction (ANR)
1. Turn the ANR switch to the ON position.
2. When the earphones are not in use or you do not need
the ANR feature, turn the ANR switch to the OFF position
to conserve the battery.
Using the Mute Feature
While listening to music, you can momentarily disable the sound
by holding the MUTE button. When the MUTE button is released,
music will be heard again. The Mute feature also disables ANR.
Using the Hands-Free Microphone
•When connected to the iPhone with the correct cable, you
may answer a call using the CALL/ANSWER button or
using the controls on your phone.
•During a call, the music will not be heard in the earphones
and the in-line microphone allows you to have hands-free
conversations.
•When a call is complete, press the CALL/ANSWER
button to return to music.
•The CALL/ANSWER button may provide other functions.
Refer to your phone’s instruction guide for details of using
a hands-free accessory.

V10M10_IM_EN_04242008
- 6 -
TROUBLESHOOTING GUIDE
1. I can still hear outside noises when ANR is activated.
•This is normal. In fact, no ANR headset in the market can
completely delete the noises. It only reduces a certain
amount of noises. This headset is capable of a maximum
-15dB of active noise reduction.
•Be sure that a “AAA” battery is installed to use the Active
Noise Reduction feature.
2. There is no sound.
•Make sure the volume is turned up on your iPhone, iPod
or other audio device.

V10M10_IM_EN_04242008
- 7 -
USER SAFETY GUIDE
INSTRUCTIONS ON ENVIRONMENT PROTECTION
Do not dispose of this product in the usual household garbage at
the end of its life cycle; bring it to a collection point for the
recycling of electrical and electronic appliances.
This symbol on the product means the instructions
for use or the packaging will inform about the
methods of disposal. The materials are recyclable
as mentioned in its marking. By recycling, material
recycling, and other forms of re-utilization of old appliances, you
make an important contribution to the protection of the
environment. Please inquire at your local community
administration for an authorized disposal location.
Important Safety Instructions
1. Read instructions – All safety and operating instructions
should be read before the appliance is operated.
2. Retain instructions – The safety and operating instructions
should be retained in a secure place for future reference.
3. Heed warnings – All warnings on the appliance and in the
operating instructions should be observed.
4. Follow instructions – All operating and use instructions
should be followed.
5. Water and moisture – The appliance should not be used
near water (bathtub, kitchen sink, laundry tub, pool, etc.).
6. Heat – The appliance should be situated away from heat

V10M10_IM_EN_04242008
- 8 -
USER SAFETY GUIDE
Important Safety Instructions-Continued
sources such as radiators, heat registers, stoves, or other
appliances (including amplifiers) that produce heat.
7. Power sources – The appliance should be connected to a
power supply only of the type described in the operating
instructions or as marked on the appliance.
8. Cleaning – The appliance should be cleaned with a dry cloth.
9. Objects and liquids entry – Care should be taken so that
objects do not fall and liquids are not spilled into the device’s
openings.
10.Servicing – The user should not attempt to service the
appliance beyond that described in the user's operating
instructions. All other servicing should be referred to qualified
service professional.
FCC Notice (USA)
This device complies with Part 15 of the FCC Rules. Operation is
subject to the following two conditions: (1) this device may not
cause harmful interference, and (2) this device must accept any
interference received, including interference that may cause
undesired operation. Refer to 47 CFR Sec. 15.19.
This equipment has been tested and found to comply with the
limits for a Class B digital device, pursuant to Part 15 of the FCC
Rules. These limits are designed to provide reasonable
protection against harmful interference in a residential installation.
This equipment generates, uses, and can radiate radio
frequency energy and, if not installed and used in accordance
with the instructions, may cause harmful interference to radio

V10M10_IM_EN_04242008
- 9 -
USER SAFETY GUIDE
FCC Notice (USA)-Continued
communications, which can be determined by turning the
equipment off and on, the user is encouraged to try to correct the
interference by one or more of the following measures:
•Reorient or relocate the receiving antenna.
•Increase the separation between the equipment and receiver.
•Connect the equipment into an outlet on a circuit different
from that to which the receiver is connected.
•Consult the dealer or an experienced radio/TV technician for
help.
NOTE: Changes or modifications not expressly approved by
the party responsible for compliance could void the user’s
authority to operate the equipment. Refer to 47 CFR Sec.
15.21.
Industry Canada Notice to Canadian Users
Operation is subject to the following two conditions: (1) this
device may not cause harmful interference, and (2) this device
must accept any interference received, including interference
that may cause undesired operation of the device. Refer to IC
RSS 210 Sec. 5.11. The term “IC” before the certification or
registration number only means that the registration was
performed based on a Declaration of Conformity and that
Industry Canada technical specifications were met. It does not
imply that Industry Canada (IC) approved this equipment. Refer
to Self-Marking 6(f) and RSP 100 Sec. 4.

V10M10_IM_EN_04242008
- 10 -
USER SAFETY GUIDE
Additional Safety Instructions
•When not in use, keep your device in a safe place where it
will not be bent or crushed.
•Keep this device away from children. Some small and
detachable parts might be swallowed by children and result in
harm to them.
About Electromagnetic Interference (EMI)
This device is designed and manufactured not to exceed the
exposure limit for radio frequency energy, which is set by the
Federal Communications Commission of the U.S government.
The term “EMI” is short for the electromagnetic interference
caused by the electromagnetic field generated by electronic
devices. In fact, most electrical appliances and devices emit
electric and magnetic fields, and most of modern electronic
devices are susceptible to the EMI if they are inadequately
shielded or designed.
•If you use any personal medical device, such as a pacemaker,
please consult the manufacture of your medical device to
determine if it is adequately shielded from EMI. Your
physician might assist you in obtaining this information.
•Please turn off this device if you are instructed to do so,
especially on an airplane or in a hospital.
•Please keep away from medical instruments in a hospital or
medical unit while using this device.

V10M10_IM_EN_04242008
- 11 -
USER SAFETY GUIDE
IMPORTANT NOTES ON HEARING
Your hearing is very important to you and to us. We strongly
recommend you to follow the guideline below in order to prevent
possible damage to or loss of hearing.
Hearing experts caution that listening to loud sounds can
damage hearing over time. With continuous listening to loud
sounds, hearing adapts and will give the impression that volume
has reduced. What seems normal may, in fact, be harmful. To
guard against this before hearing adapts, set the volume at a low
level and slowly increase the volume level until sound can be
heard comfortably and clearly without distortion. Damage to
hearing is accumulative and is irreversible. Ringing or discomfort
in the ears indicates that the volume is too loud. Once a
comfortable listening level has been established, do not increase
the volume level further.
Cautions
•If you experience a ringing sound in your ear, lower the
volume or discontinue the use of this product.
•Do not use the headphones while driving or cycling. Because
this product reduces the external noises, you might not be
able to hear the warning sounds, such as an automobile horn,
and might result in the traffic accident. Additionally, listening
to headphones while driving is illegal in many places

V10M10_IM_EN_04242008
- 12 -
FEATURES & SPECIFICATIONS
Features
•Ideal for digital devices – iPhone / iPod / MD / MP3 / CD
players
•Noise canceling function On/Off switch
•Up to 30 hours of noise reduction with 1 AAA battery
•Self mute (monitor) feature for conversations or public
announcements
•Switch between call and music easily on your iPhone with
a one-touch button
•Features an in-line microphone for convenient hands-free
phone conversations
Specifications
•Driver Unit
oDiameter: 9mm
oMagnet: NdFeB
•Frequency Response: 20Hz – 20kHz
•Sensitivity: 105dB ± 3dB
•Noise reduction level: -15dB (Max)
•Ear tips
oEar tips (3 sets)
o3 layer ear tips (1 set)
•Cables
oAudio cable for iPhone and music devices
2.5mm (4 tips) to 3.5mm (4 tips)
30 inch -length / “I”-type / Gold-plated
•Power Source: 1 x “AAA” battery (Not Included)

iLuv is a trademark of jWIN Electronics Corp. Features and specifications are
subject to change without prior notification. IPod and iPhone are a trademarks
of Apple Inc. iPod and iPhone not included in this package.
© 2008 jWIN Electronics Corp. All rights reserved. No portion of this printed
material or product enclosed herewith including design, shape and graphics,
may be reproduced or transmitted in any form without the expressed written
consent of jWIN Electronics Corp. by any means, electronic or mechanical,
including photocopying, recording or the use of an information storage and
retrieval system. Any unauthorized distribution or reproduction of this printed
material or product, or any portion thereof, will be prosecuted to the fullest
possible extent of the law.
Printed in China
TEL: [phone]
FAX: [phone]
website: www.i-Luv.com
