Imax B6 Ultimate User manual

B6 Ultimate
Professional Balance Charger/Discharger
SkyRC Technology Co., Ltd. 2010 Version 1.0
Printed in China 2010
All specifications and figures are subject to change without notice.

TABLE OF CONTENTS
Congratulations on your choice of theiMAX digital intelligent charger from SKYRC
TechnologyCo., Ltd. You are now the owner of a compact charger with battery management and
integral balancer.
The unit is simple to use, but the operation of a sophisticated automatic charger such as the iMAX
does require some knowledge on the part of the user. These operating instructions are
designed to ensure that you quickly become familiar with its functions.
It is therefore important that you read right through the Operating Instructions, Warning and Safety
Notes before you attempt to use your new automatic charger for the first time. Wehope you have
many years of pleasure and success with your new battery charger.
IMAX employs the circuit that features outputpower of 200 watts. It cancharge or
discharge up 18 cells of NiCd/NiMH or 6 series of Lithium batteries with maximum current of 10A.
has an individual cell voltage balancer, so itdoes not requiredany balancer separately
when charging Lithium batteries (LiPo/LiIon/LiFe) for voltage balancing.
The fan cooling system is so smart and efficiently. The fan speed is controlled by internal temperature
sensor.
Please BE SURE to read these instructions and Warning and Safety Notes before you use the charger
for the first time.
It can be dangerous to mis-handle batteries and battery chargers, as there is always a risk of batteries
catching fire and exploding.
B6 Ultimate
B6
Ultimate
B6 Ultimate
B6 Ultimate
01 02
INTRODUCTION
Introduction...............................................................................................................................................02
Special features........................................................................................................................................05
Warning and safety notes........................................................................................................................09
Program flow chart...................................................................................................................................14
Lithium polymer balance charge program connection diagram.............................................................16
Initial parameter setup (users set up)......................................................................................................18
.................................................................................................21
Charging lithium battery in the charge mode..........................................................................................22
Charging lithium battery in the balance mode........................................................................................23
Charging lithium battery in the fast charge mode...................................................................................24
Charging lithium battery in the s mode ........................ ..........25
Discharging of lithium battery..................................................................................................................26
Charging NiCd/NiMH battery in the charge mode ................................
Discharge of NiCd/NiMH battery............................................................................................................28
............................................
Charging Pb (lead-acid) battery in the charge mode.............................................................................30
Discharging of the Pb battery..................................................................................................................31
Storage data program.............................................................................................................................32
Load data program..................................................................................................................................33
Various information in the program.........................................................................................................34
Warning and error message....................................................................................................................35
Recommended accessories...................................................................................................................36
Conformity declaration.............................................................................................................................37
Specification.............................................................................................................................................40
Commonly used terms.............................................................................................................................41
Warranty and service...............................................................................................................................42
Lithium battery (LiIo/LiPo/LiFe) program
torage ................................................. .....
................................................. 27
Charge/discharge and discharge/charge cycle of NiCd/NiMH battery.... .29
Maximum circuit power chart..................................................................................................................38

INTRODUCTION INTRODUCTION
Please read thisentire operating manual completely and attentivelybefore using this product, as it
covers a widerange of information on operating andsafety. Orplease do use this product incompany
with a specialist!
Contact-less Key
Switch
Temperature
Probe Socket
Ventilation Fan
LCD Screen
Output
Charging
Universal
Balancing Port
Pitch=2.54mm
PC Link Socket
USB Power Supply5V/1A
DC Input 11V~18V
Connection Diagram
03 04
Temperature
Probe Socket

Internal independent lithiumbattery balancer
iMAX employs an individual-cell-voltagebalancer. It isn’t necessary to connect an
external balancer forbalance charging.
Balancing individual cellsbattery discharging
During the processof discharging, iMAX can monitor andbalance each cellof the battery
individually. Errormessage will beindicated and the process will beended automatically if the
voltage of anysingle one cell is abnormal.
Adaptable to varioustype of lithium battery
iMAX is adaptable tovarious types of lithium batteries, such as Li-ion, LiPoand the new
LiFe series ofbatteries.
Fast and storagemode of lithium battery
Purposes to chargeLithium battery varies,‘fast’ charge reduce the duration of charging, whereas
‘store’ state can control the final voltage ofyour battery,so as to store for a long time andprotect
useful time ofthe battery.
Maximum safety
Delta-peak sensitivity: The automatic chargetermination program based on the principle of
the Delta-peak voltagedetection. When the battery's voltage exceeds the threshold, the
process will beterminated automatically.
Automatic charging currentlimit
You can set up the upper limitof the charging current when charging your NiCd orNiMH battery;
it is usefulfor the NiMH battery of lowimpedance and capacity in the 'AUTO'charging mode.
B6 Ultimate
B6 Ultimate
B6 Ultimate
iMAX features the so-called AUTO function that set the feeding current during the process
of charging or discharging. Especially for Lithium batteries, it can prevent the overcharging which may
lead to an explosion due to the user's fault. It can disconnect the circuit automatically and alarm once
detecting any malfunction. All the programs of this product were controlled through two way linkage
and communication, to achieve the maximum safety and minimize the trouble. All the settings can be
configured by users!
B6 Ultimate
Optimized operating software
Set contents
1
2
3
4
5678
Special features
1. iMAX B6Ultimate Charger
2. XHAdaptor
3. Temperature Probe
4. Crocodile ClipCharging Cable
5. 18AWG Wire Charging Cable
6. Charger MonitorProgram Disk
7. USB Cable
8. Plug-in BatteryClamps
05 06
SPECIAL FEATURES SPECIAL FEATURES

SPECIAL FEATURES SPECIAL FEATURES
Capacity limit
The charging capacityis always calculated as the chargingcurrent multiplied by time. If the charging
capacity exceeds thelimit, the process will be terminatedautomatically when you set the maximum
value.
Temperature threshold
The battery’s internalchemical reaction willcause the temperatureof the battery to rise. If the
temperature limit isreached, the process will be terminated.
This function isavailable by connecting temperature probe, whichis included in the package.
Processing time limit:
You can also limit the maximum processtime to avoid any possible defect.
Data store/load
Cyclic charging/discharging
1 to 5cyclic and continuous process of charge>dischargeor discharge>charge is operable for battery
refreshing and balancing to stimulate the battery’s activity.
PC based analysis using USB Communication
The B6 Ultimate is fitted witha mini USB port on theright-hand side of the case; a USB wire can be
connected to this socket in order to link the charger to a PC. program enable you
to view graphs of charge anddischarge curves, with a capacity, voltage, temperature and ampere display,
and individual curves can be individually suppressedor superimposed to allow a visualcomparison of the
data.
USB Power Supply
The USB power supplycan provide 5V, 1Acontinue current. You can power your mobile phone, digital
camera or even yourIPod via the USBpower supply.
PC based analysis using USB
Communication USB Power Supply
07 08
For users convenience,it can store maximum 10 dataof different batteries.You can establish
the data containsprogram setting of the battery tocharge or discharge. These data can be called
back at anytime you need and the processcan be executed without program setting.

These warnings andsafety notes are particularly important. Pleasefollow the instructions for
maximum safety; otherwisethe charger and the battery canbe damaged or at worst it can
cause a fire.
Never leave thecharger unattended when it is connectedto its power supply. Ifany malfunction
is found, TERMINATE THE PROCESS AT ONCE andrefer to the
operation manual.
Keep the chargerwell away fromdust, damp, rain, heat, direct sunshine and vibration.
Never drop it.
The allowable inputvoltage is 11~18V DC
This charger andthe battery should be put ona heat-resistant, noninflammable and
nonconductive surface. Never place them on a car seat,carpet or similar.
Keep all theinflammable volatile materials away from operatingarea.
Make sure youknow the specifications of the batteryto be charged or discharged to ensure it
meets the requirementsof this charger. If theprogram is setup incorrectly,the battery and
charger may bedamaged .It can cause fire orexplosion due to overcharging. This warranty is
not valid forany damage or subsequent damage arisingas a result of a misuse or failure to
observe the proceduresoutlined in this manual.
09 10
Standard Battery Parameters
3.7V/cell 3.6V/cell 3.3V/cell 1.2V/cell 1.2V/cell 2.0V/cell
4.2V/cell 4.1V/cell 3.6V/cell 1.5V/cell 1.5V/cell 2.46V/cell
3.8V/cell 3.7V/cell 3.3V/cell n/a n/a n/a
1C 1C 4C 0.4C1C-2C 1C-2C
3.0V/cell 2.5V/cell 2.0V/cell 0.85V/cell 1.0V/cell 1.75V/cell
Nominal Voltage
Min. Discharge Voltage
LiPo
Max Charge Voltage
Storage Voltage
Allowable Fast Charge
LiIon LiFe NiCd MiMH Pb
Be very carefulto choose the correct voltage for different types of battery otherwiseyou may
cause damage tothe batteries. Incorrect settings could cause the cells to fire or explode.
WARNING AND SAFETY NOTES WARNING AND SAFETY NOTES

Connect the batteryto the terminal of the charger:red is positive and black is
negative. Due tothe difference between resistance of cable and connector, the
charger can notdetect resistance of the battery pack,the essential requirement
for the chargerto work properly is that thecharge lead should be of adequate
conductor cross-section, andhigh quality connectors which are normallygold-
plated should befitted to both ends.
Always refer tothe manual by the battery manufacturerpertaining to charging
methods, recommended chargingcurrent and charging time. Especially, the
Lithium battery shouldbe charged according the charging instructionprovided
by the manufacturerstrictly.
Attention should bepaid to the connection of Lithiumbattery especially.
Do not attemptto disassemble the battery pack arbitrarily.
Please get highlightedthat Lithium battery packs can bewired in parallel and in
series. In theparallel connection, the battery’s capacity is calculated by
multiplying single battery’s capacity bythe number of cells with totalvoltage
stay the same.The voltage’s imbalance may cause fire or explosion .Lithium
battery is recommendedto charge in series.
A batterypack which consists of different types of cells(including different manufacturers)
A batterythat is already fully charged orjust slightly discharged.
Non-rechargeable batteries (Explosionhazard).
Batteries that requirea different charge technique from NiCd, NiMh, LiPoor Gel cell
(Pb, Lead acid).
A faultyor damaged battery.
A batteryfitted with an integral charge circuitor a protection circuit.
Batteries installed ina device or which are electricallylinked to other components.
Batteries that arenot expressly stated by the manufacturerto be suitable for the currents
the charger deliversduring the charge process.
Please bear inmind the following points before commencing charging:
Did you selectthe appropriate program suitable for thetype of battery you are charging?
Did you setup adequate current for charging ordischarging?
Have you checkedthe battery voltage? Lithium battery packscan be wired in parallel and
in series, i.e.a 2 cell pack can be3.7V (in parallel) or 7.4V (inseries).
Have you checkedthat all connections are firm andsecure?
Make sure thereare no intermittent contacts at anypoint in the circuit.
Charging
During charge process,a specific quantity of electrical energyis fed into the battery. The
charge quantity iscalculated by multiplying charge current bycharge time. The maximum
permissible charge currentvaries depending on the battery typeor its performance, and can
be found inthe information by the battery manufacturer. Only batteries that are expressly
stated to becapable of quick-charge are allowed tobe charged at rates higher thanthe
standard charge current.
11 12
Never attempt tocharge or discharge the following types of batteries.
WARNING AND SAFETY NOTES WARNING AND SAFETY NOTES

Continue on nextpage!
WARNING AND SAFETY NOTES
Discharging
The main purposeof discharging is to clean residualcapacity of the battery, or to reduce
the battery’ voltage to adefined level. The same attention should be paidto the discharging
process as charging.The final discharge voltage should be set up correctly to avoid deep-
discharging. Lithium batterycan not be discharged to lowerthan the minimum voltage, or it
will cause arapid loss of capacity or atotal failure. Generally, Lithium batterydoesn’t need
to be discharged.Please pay attention to the minimumvoltage of Lithium battery to protect
the battery.
Some rechargeable batterieshave a memory effect. If they are partly used and recharged
before the wholecharge is accomplished, they remember thisand will only use that part
of their capacitynext time. This is a ‘memory effect’ It is saidthat NiCd and NiMH batteries
are suffering from memory effect. NiCd has more memory effect than NiMH.
Lithium batteries arerecommended to be discharged partially ratherthan fully discharged.
Frequent full dischargingshould be avoided if possible. Instead,
charge the batterymore often or use a batteryof larger capacity. Full capacitycannot be
reached until ithas been subjected to 10 ormore charge cycles. The cyclic process of
charge and dischargewill optimize the capacity of batterypack.
13 14
PROGRAM FLOW CHART

LITHIUM POLYMER BALANCE CHARGE PROGRAM
CONNECTION DIAGRAM
CONNECTING THE BATTERY
Important !!! Before connecting a batteryit is absolutely essential to check one last time that you have set
the parameters correctly.If the settings are incorrect, the battery may be damaged, and could even burst
into flames or explode. To avoid short-circuits between the bananaplugs, always connect the charge leads
to the charger first, and onlythen to the battery. Reverse the sequence when disconnectingthe pack.
IMAX comes with male 4mm Bullet connectors attached tothe power INPUTcables.
These cables are appropriatefor attaching directly tomost high-quality AC-DC power supply units,
such as eFUELmodel PSU20A (13.8V, 20A). Also included are large Terminal Clips with matching
4mm female bullet connectors,for attaching directly to12V car batteries. Itis critically important that
you use either afully charged 13.8 carbattery or a highquality AC-DC power supply in therange of 11V
to18V DC output, withminimum current rating of20A to insure reliable performance.
B6 Ultimate
CONNECTING THE CHARGER
4mm Bullet
Connectors
plugging
to eFUEL power
supply directly
Using terminal
clip attaching to
car battery
PROGRAM FLOW CHART
15 16

This diagram showsthe correct way to connect your battery to theiMAX while charging
in the balancecharge program mode only.
B6 Ultimate
Balance socket:
The balance wire attached to thebattery must be connected to thecharger with the black wire alignedwith
the negative marking. Take care to maintain correct polarity!(Wiring diagram: see below.)
Failure to connect as shown in this diagram will damage this charger.
WARNING:
112233445566
+
S2
+
S3
+
S1
LITHIUM POLYMER BALANCE CHARGE PROGRAM
CONNECTION DIAGRAM
INC
DEC INC
INCDEC
User setup starting screen.
The screen displays the nominal voltageof Lithium battery.There are three
kinds of Lithium battery: LiFe(3.3V), Lilo(3.6V)or LiPo(3.7V). This is very
important so you have to checkthe battery carefully and set itup correctly. If
it is different from correctvalue the battery may be explodedduring charge
process.
B6 Ultimate recognize the cell count of Lithium battery automatically at
the beginning of charge or dischargeprocess to avoid from erroneous settingby
user. But deeply dischargedbattery can be perceived incorrectly. To prevent the
error, you can setthe time term to verify thecell count by the processor. Normally,
10 minutes are enough to perceivethe cell count correctly. For the battery of larger
capacity, you mayextend the time term. But ifyou set the time term toolong for the
battery of smaller capacity, the charge or discharge processcan be finished within
the time term with the erroneouscell count. This may causethe fatal result.
If the processor recognizes the cellcount incorrectly at the beginning ofcharge or
discharge process, you may extend thetime. Otherwise, you had better usewith
the default value.
IMAX
IMAX B6 Ultimate will be operated with thedefault value of the essential user settings when it isconnected
to a 12V battery forthe first time. The screendisplays the following information in sequence and the user
can change the value ofparameter on each screen.
When you are willing toalter the parameter value in the program, press start/enter key to make it
blink then change the value withInc> or <Dec key. The value will be stored bypressing start/enter
key once.
17 18
To avoidshort circuit betweenthe charge lead always connect the charge cable tothe charger
first, then connectthe battery.Reverse the sequence when disconnecting.
Initial parameter setup (Users set up)
INITIAL PARAMETER SETUP (USERS SET UP)

INITIAL PARAMETER SETUP (USERS SET UP) INITIAL PARAMETER SETUP (USERS SET UP)
INCDEC
INCDEC
DEC INC
DEC INC
DEC INC
DEC INC
INCDEC
Terminationof NiMH and NiCd battery.The effective value ranges from 5 to
20mV per cell.If the trigger voltage is sethigher, there is a danger of over
charging the battery;if it is set lower,there is a possibility of premature termi
nation. Please referthe technical specification of the battery. (NiCd default:
12mV, NiMH default: 7mV)
DEC INC
DEC INC
DEC INC
INCDEC
DEC INC
INCDEC
INCDEC
DEC INC
DEC INC DEC INC
INCDEC
DEC INC DEC INC
INCDEC
DEC INC
INCDEC
This program setsthe maximum charge capacity that will be supplied tothe
battery during charge.If the delta-peak voltage is not detected nor the
safety timer expiredby any reason, this feature will automatically stop the
process at theselected capacity value.
The beep soundsat every time pressing the buttons to confirm youraction.
The beep ormelody sounded at various times during operation to alertdif
ferent mode changes.These audible soundscan be turned on or off.
This program monitorsthe voltage of input battery. If the voltage drops
below the valueyou set the operation forcibly terminated to protect the
input battery.
You can adjust the brightness of LCDscreen at the charger.
19 20
The battery ison the cyclic process of charge and discharge canoften
become warm aftercharge or discharge period. The program can insert a
time delay tooccur after each charge and discharge process to allowthe
battery adequate timeto cool down before being subjected to the nextprocess.
The value rangesfrom 1 to 60 minutes.
An optional featureusing temperature probe contacting the surface of battery,
the temperature cut-offcan be onor off. Ifit is on, set the maximumtempera-
ture at whichthe charger should allow battery to reach during charge.Once a
battery reaches thistemperature during charge, the process will be terminated
to protect thebattery.
When you starta charge process, the integral safety timer automatically
starts running atthe same time. This is programmed to prevent overcharge
the battery ifit proves to be faulty, or if the termination circuit cannotdetect
the battery full.The value forthe safety timer should be generous enough to
allow a fullcharge of the battery.
You canset the trickle charge modeon or off. If it is on, the chargerwill automatic
ally supply the trickle chargecurrentto achieve the full chargewithout overheating
the battery after fast chargehas been terminated.

LITHIUM BATTERY (LILO/LIPO/LIFE) PROGRAM
Lithium battery (LiIo/LiPo/LiFe) program
These programs areonly suitable for charging and discharging Lithium batteries witha nominal
voltage of 3.3V, 3.6V and 3.7V per cell. These batteries needto adopt differentcharge technique
that is termedconstant current (CC) and a constant voltage (CV) method.The charge currentvaries
according to thebattery capacity and performance.
CHARGING LITHIUM BATTERYIN THE CHARGE MODE
INC
INC DEC
DEC -
-+
+
Start
Enter
Batt type
Stop ‘>3 seconds’
Start
Enter
Charged
capacity
Number
of
cells
Charging
time
Charging
current
Battery
voltage
The left side of the firstline shows the type of battery you choose.
The value on the left ofthe second line of the charger is current user
set, After setting the current and voltage, press START/ENTER key
for more than 3 seconds tostart the process.(charge current: 0.1-
10.0A, voltage: 3.7-22.2V).
This displays the number of cellsyou set up and the processor
detects. “R” shows the number of cells detected by the charger and
“S” is the number of cellsset by you at the previous screen. If both
numbers are identical you can startcharging by press
START/ENTER button. If not,press BATTTYPE/STOP button to go
back to previous screen to carefullycheck the number of cells of the
battery pack before going ahead.
This screen shows the real-time statusduring charge process. Press
BATT TYPE/STOP keyonce to stop the charge process.
This charging modeis for charging Li-Po/Ion/Fe battery withoutbalance lead.
Charging lithium battery in the charge mode
21 22
The Lithium batteryis charged at a constant
current until itreaches the final charge voltage
of 4.2 Vper cell (B). After this point the voltage
is kept ata constant level, and the residual
charge takes theform of a declining current
curve (C) untilthe cut-off point(D) is reached.
Charge current =C/10. At this point the battery
can be disconnectedfrom the charger, and is
ready for use.
The final voltageof charge process is also very important; it shouldbe precisely matched with the
charged voltage ofthe battery.They are 4.2Vfor LiPo, 4.1V for Lilo, and3.6V for LiFe.The charge
current and nominalvoltage as for cell count set on the chargeprogram must always be correct for
the battery tobe charged.
4.2V
V
A
Ah
ABCD
t
V/A/Ah
When you arewilling to alter the parameter value in the program,press start/enter key to make it
blink then changethe value with Inc> or <Dec key. The value will be stored bypressing start/enter
key once.

CHARGING LITHIUM BATTERY IN THE BALANCE MODE
INC
INC DEC
DEC -
-+
+
Start
Enter
Batt type
Stop ‘>3 seconds’
Start
Enter
Charged
capacity
Number
of
cells
Charging
time
Charging
current
Battery
voltage
The left side of the first line shows the type of battery you choose. The
value on the left of the second line of the charger is current user set, After
setting the current and voltage, press START/ENTER key for morethan 3
seconds to start the process.(charge current: 0.1-10.0A, voltage: 3.7-
22.2V).
This displays the number of cells you set up and the processordetects.
“R” shows the number of cells detected by the charger and “S”is the
number of cells set by you at the previous screen. If both numbers are
identical you can start charging by press START/ENTER button. If not,
press BATTTYPE/STOP buttonto go back to previous screen to carefully
check the number of cells of the battery pack before going ahead.
This screen shows the real-time status during charge process. Press
BATT TYPE/STOP key once to stop the charge process.
This function is for balancingthe voltage of Lithium-polymer battery cells while charging. In the balance
mode, the battery needs tohave a balance lead to connect to the individual balance port of the charger.
And you need to connectthe battery's power lead to the output of charger. Charging in this mode is
different from the normal modes, because the built-in processor monitors voltage of individual celland
control input current fed intoeach cell to equalized voltage of individual cell.
Charging lithium batteryin the balance mode
Charging lithium batteryin the fast charge mode
CHARGING LITHIUM BATTERY IN THE FAST CHARGE MODE
INCINC DECDEC
--++
Start
Enter
Start
Enter
Batt type
Stop ‘>3 seconds’
Current
voltage
battery
Supplied
capacity
Charge
current
Charging
time
Number
of
cells
The value onthe left side of the secondlines sets the charge current.
The value onthe right side of the secondlines sets the battery pack's
voltage. Aftersetting current and voltage, press STAR/ENTER for
more than 3seconds to start the process.
23 24
The charging currentis getting smaller as the processgoes to the near end term of Lithium battery
charging. To finish charging process earlier,this program eliminate certain term of CV process.
Actually, thecharging current willgoes to 1/5 from the initialvalue to end the process while the
normal charging goesto 1/10 during CV term. Thecharging capacity maybe a bit smaller than
normal charging butthe process time will be reduced.
This screen shows the real-time status during charge process. Press
BATT TYPE/STOP key once to stop the charge process.
This displays the number of cells you set up and the processor detects.
“R” shows the number of cells detected by the charger and “S” is the
number of cells set by you at the previous screen. If both numbers are
identical you can start charging by press START/ENTER button. If not,
press BATTTYPE/STOP buttonto go back to previous screen to
carefully check the number of cells of the battery pack before going
ahead.

CHARGING LITHIUM BATTERY IN THE STORAGE MODE
At this screen,you can set up the current and voltage of the battery pack.
Charging and dischargingwill make the batteries come tothe voltage
level of “storage”state.
This screen showsthe real-time status charging. Press BATT
TYPE/STOP key once to stop the charge process.
Number
of
cells
DEC
-
Batt type
Stop
Elapsed
time
INC
+
Charge
or discharge
current
Supplied
capacity
DEC
Start
Enter
-
‘>3 seconds’
INC
+
Current
voltage
battery
Charging lithium batteryin the storage mode
DISCHARGING OF LITHIUM BATTERY
Number
of
cells
DEC
-
Batt type
Stop
elapsed
time
INC
+
Battery
voltage
DEC
Start
Enter
-
‘>3 seconds’
INC
+
Discharged
capacity
The value ofdischarge current on the left can not exceed 1C,and the
value on theright can not be under the voltage recommended bythe
manufacturer to avoiddeep discharging. Press START/ENTER for more
than 3 secondsto start discharging.
This shows thereal-time status of discharging, you can press BATT
TYPE/STOP key to stop discharging.
discharge
current
INC
The processor detectsvoltage of one cell is too low.
The 4th cellwas damaged. Thevalue of voltage may be zeroif disconnection
occurs.
The processor monitorsvoltage of each cell when the battery packs areduring its “storage” and
“discharging” process. Ifvoltage of any cell is abnormal, iMAX will show errormessage
and terminate theprogram forcibly.So if there is battery damage or disconnection, youcan see the
error message andpress INC to know which cell is damaged.
B6 Ultimate
Voltage balancingand monitoring in the discharge process
Discharging of lithium battery
25 26
This is forcharging or discharging Lithium battery not to be usedfor the time being. The program
will determine tocharge or discharge the battery to the certain voltagedepending on the voltage of
the battery atits initial stage. They are different from the type of thebattery, 3.75Vfor LiIo, 3.85V
for LiPo and3.3V for LiFe per cell. If the voltage ofbattery at its initial stage is over the voltage
level to storage,the program will start to discharge.

CHARGING NICD/NIMH BATTERY IN THE CHARGE MODE
DEC
-
Batt type
Stop
Elapsed
time
INC
+
DEC
Start
Enter
-
‘>3 seconds’
INC
+
Charged
capacity
Battery
type Charge
current
Battery
voltage
This program isfor charging of NiCd/NiMH batteries associatedwith R/C
models applications. You can press START/ENTER key to make it blink
and then INCor DEC to change the parametervalue. Press
START/ENTER key to store the value.
This program chargethe battery using the current you set up. Inthe “auto” state, you should set up
the upper limitof the charge current to avoid damage by excessivefeeding current. Some batteries
of low resistanceand capacity can lead to higher current in the“auto” charging mode. But in the
manual mode, itwill charge with the current you set. You can makeit blink inthe current field and
press INC andDEC simultaneously to swap between Auto and ManualMode. NOTE: Allowable fast
charge current: 1C-2C
The screen shows the real-time status. Press BATTTYPE/STOP keyto
end the program. The sound will emitted to indicatesthe end of program.
Charging NiCd/NiMH batteryin the charge mode
DISCHARGE OF NICD/NIMH BATTERY
Discharge of NiCd/NiMHbattery
Discharge
current
The screen indicatesthe discharging state. Youcan press
START/ENTER key to alter discharge current. PressSTART/ENTER
again to storethe value. Press BATTTYPE/STOP key to stop
discharging. The emittedsound alerts the end of discharging.
Battery
type
Battery
voltage
Elapsed
time Discharged
capacity
Batt type
Stop Start
Enter ‘>3 seconds’
DEC INC DEC INC
Set discharge currenton the left and the final voltage on theright. Range
of the dischargecurrent is 0.1-5.0A; range of final voltage is 0.1-25.0V.
Press START/ENTER key formore than 3 seconds to start the program.
-+-+
27 28

CHARGE/DISCHARGE AND DISCHARGE/CHARGE CYCLE OF NICD/NIMH BATTERY
Charge/discharge and discharge/charge cycle of NiCd/NiMH battery
You can set upsequence on theleft and the number of cycleson the
right. Range ofthe cycle number is 1-5.
DEC
-
Batt type
Stop
INC
+
DEC
Start
Enter
-
INC
+
‘>3 seconds’
Press BATT TYPE/STOPkey to stop program, you can press
START/ENTER key to altercharge current. Thesound indicates the
end of program.
Battery
type
Elapsed
time
Battery
voltage
Discharged
or charged
capacity
Discharge
or charge
current
When it approachesto the end, you can seethe capacity of the
battery being chargedor discharged. You can press INC or DEC key
to display resultof each cycle.
Battery
type
DEC
-
Batt type
Stop
Elapsed
time
INC
+
Charge
current
Battery
voltage
DEC
Start
Enter
-
‘>3 seconds’
INC
+
Charged
capacity
Set up thecharge current on the left andnominal voltage on the right.
Range of currentis 0.1-10.0A, the voltage should matchthe battery being
charged. Press START/ENTER key for more than 3seconds to start
charging.
The screen displaysthe real-time discharging status. Press START/
ENTER key toalter discharge current. Press START/ENTER key again
to store theparameter value you set. Press BATT TYPE/STOP key to
end the program.
This program is only suitable for charging Pb lead-acid battery with nominal voltage from 2 to 24V.
Pb lead-acid battery is completely different from NiCd/NiMH battery.These batteries can only
deliver current lower in comparison to their capacity.The same restrictionapplies to the charging
process. Consequently,the optimum charge current can only be 1/10 of the capacity.Pb battery can
not be used for fast-charging, please follow the instructions provided by the battery manufacturer.
Due to the chemistry characteristic of Pb battery,the cut offpoint may be difficult to detectsometimes.
We recommend userto use CAPACITY CUTOFF feature to protect the battery. You can press START/
ENTER key to make it blink and alter the value of parameters using INC or DEC key, press START/
ENTER key to store the value.
Charging Pb (lead-acid)battery in the charge mode
29 30
CHARGING PB (LEAD-ACID) BATTERYIN THE CHARGE MODE

DISCHARGING OF THE PB BATTERY
Discharging of the Pb battery
DEC
-
Batt type
Stop
INC
+
DEC
Start
Enter
-
‘>3 seconds’
INC
+
Set up thedischarge current on the left andnominal voltage on the right.
Range of dischargecurrent is 0.1-5.0A, the voltage shouldmatch the
battery being charged.Press START/ENTER key for more than 3
seconds to startcharging.
The screen displaysthe real-time discharging status. Press
START/ENTER key to alter discharge current. Press START/ENTER key
again to storethe parameter value you set. PressBATT TYPE/STOP key
to end theprogram.
Battery
type
Elapsed
time Discharge
current
Battery
voltage Discharged
capacity
For your convenience,iMAX has a datastorage and load program. It can store ten
batteries data representingthe respective specifications of batteries. You can call back the data
when charging ordischarging without setting up the program again. Press START/ENTER key to
make it blink,and use INC or DEC to set up theparameter.
B6 Ultimate
Storage data program
STORAGE DATA PROGRAM
Voltage Data
number
CapacityType of
battery
Start
Enter Setting of theparameter in the screen will not affect the chargeand
discharge process. Theyjust present thespecification of the battery.
The example isNiMH battery pack, including 12 cells, the capacity is
3000m Ah.
DEC INC DEC
DEC
DEC
-
-
-
INC
INC
INC
+
+
+
Start
Enter
‘>3seconds’
Batt type
stop
Set up thedischarge current and final voltage.
Set up thecharge current in the manual mode, or current limitin the
auto mode. PressINC and DEC key simultaneously to make the
current field blinkto switch the charge mode.
31 32
DEC INC

LOAD DATA PROGRAM
This program isto load the data stored atthe “save data” program. Press START/ENTER key
to make thedata field blink and press INCor DEC for more than 3seconds to load the data.
Start
Enter
Start
Enter
‘>3seconds’
Choose the datanumber you want to call back.The data you
want to callback will be displayed.
Loading the data.
Load data program
VARIOUS INFORMATION IN THE PROGRAM
It comes tothe final voltage when the program ended.
Displayed temperature cut-offfunction is turnon.
The external temperatureis displayed when the temperature
probe is used.
Present input voltage.
You can inquire various information on the LCDscreen during the charging and discharging process.
Press DEC key, the chargerwill display users' setting. You can pressINC key to monitor voltage of
each cell while the battery’s balance lead is connected to the charger.
Displayed safety timeris turn on and duration of time in
minutes.
Displayed capacity cut-offfunction is turnon and the setting
value of capacity.
Various information in the program
The battery isconnected with balance lead, you can check voltage
of each cellin the battery pack.
33 34
C5:4.18 C6:4.15V
C7:0.00 C8:0.00V
Saving the data
DEC INC
DEC
DEC -
-INC
INC +
+
Start
Enter‘>3seconds’
Set up thecharge/ discharge sequence and cycle number.

WARNING AND ERROR MESSAGE
IMAX B6 Ultimate incorporates a various functions of protective and monitoring the system to verify
functions and the stateof its electronics. In any case of occurring error, the screendisplays the cause
of error that isself-explanatory with audible sound.
Incorrect polarity connected.
Battery connection isinterrupted.
Short-circuit of theoutput termination.
Input voltage wrong.
The voltage ofthe battery pack has been selected incorrectly!
The charger hasmalfunctioned for some reason. Seek professional advice.
The voltage is lower than whichis set. Please check the number of cells in the battery pack.
The processor cannotcontrol the feeding current, please repairit.
Wrong connection ofthe connector detected; please check the connector and cable.
Voltage of one cell in the battery pack is too high; please check the voltage of each cell.
Voltage of one cell in the battery pack is too low, please check the voltage of each cell.
The voltage is higher than which isset. Please check the number of cellsin the battery pack.
The internal temperature of the unit goes too high. Cool down the unit.
20A DC
Power Supply
RECOMMENDED ACCESSORIES
HP/PQ Adaptor
XH AdaptorTemperature
Sensor Cable
EH Adaptor
TP/FP Adaptor Dean charging cable Tamiyacharging
cable
TRAXXAS charging
cable
Glow charging cable Bullet charging cable EC3 charging cable Crocodile clip
charging cable
Futaba RX
charging cable
JST/BEC charging
cable
35 36

CONFORMITY DECLARATION
This symbol means that youmust dispose of electrical from the
General household wastewhen it reaches the end ofits useful life.
Take your chargerto your local waste collection pointor recycling centre.
This applies toall countries of the European Union,and to other European
countries with aseparate waste collection system.
IMAX B6 Ultimate satisfyall relevant and mandatory EC directives and .FCC Part 15 SubpartB: 2008
For EC directives:
The product has beentested to meet the following technical standards:
MAXIMUM CIRCUIT POWER CHART
The actual amountof charge current feeding to thebattery is automatically be limited to 200 Watts,
so not toexceed the charger's maximum rated chargingpower.
The maximum dischargepower is approximately 25 Watts.The discharge current delivered to the
charger is limitedby charger's internal thermal sensor formaximum discharge current. If the internal
temperature over 80Celsius, the charger will be cutoff and "TEMPOVER ERR" willshow on the LCD.
In this case,please decrease discharge current.
Please refer followingchart for maximum charging/discharging current.
Maximum circuit powerchart
Battery
Type
37 38
