IMC Networks MediaConverter/1 User manual

800-624-1070
www.imcnetworks.com
Features and Benefits
Modules meet a variety of installation
requirements
Supports Ethernet, Fast Ethernet, and•
Gigabit Ethernet, and up to OC-3 for
mode converters
Available for multi-mode or single-mode•
fiber with ST or SC fiber connectors
Supports very long fiber distances•
A variety of chassis options
Table-top or rackmountable•
1-, 4-, 8- and 12-slot chassis•
12-slot chassis is only 1U high•
AC power•
Maximizes network uptime
Modular, hot-swappable architecture•
reduces operational costs associated
with product installation, upgrades and
maintenance
Eases Troubleshooting
LinkLoss and FiberAlert features assist•
in diagnosing problems on fiber optic
networks
Ethernet-based, Modular Media Converters
MediaConverter Series
The MediaConverter Series is a cost-effective solution for extending the
life of legacy equipment and bringing fiber to the desktop.
Your network is growing and many new access points, workstations,
etc. are required. However, legacy equipment, along with your
existing wiring infrastructure, must work with any new equipment
you implement in your network. When copper-to-fiber, copper-
to-coax or fiber-to-fiber conversions are required, along with
advanced troubleshooting features, our MediaConverter Series is
the perfect solution.
IMC Networks’ MediaConverter Series enables you to easily and
cost-effectively connect one type of media to other dissimilar
media or networking products. This series increases the
functionality and extends the productive life of both your legacy
cabling infrastructure and networking equipment when adding
fiber to your network.
The MediaConverter series includes:
MediaConverter Chassis:
1, 4, 8 and 12-slot varieties•
MediaConverter Modules:
McPIM:•
- One 10 Mbps twisted pair port with an RJ-45 connector
- One 10 Mbps fiber port with ST or SC connector(s)
McLIM:•
- One 100 twisted pair port with an RJ-45 connector
- One 100 Mbps fiber port with ST or SC connector(s)
Switching McLIM TP-TX/FX:•
- One 10/100 twisted pair port with an RJ-45 connector
- One 100 Mbps fiber port with ST or SC connector(s)
- Plug-and-play operation
McGigabit:•
- One 1000 Mbps twisted pair port with an RJ-45 connector
- One 1000 Mbps fiber port with SC connector(s).
- Plug-and-play operation
RoHS Compliant

DS-MediaConverter-0807
Copyright © 2008 IMC Networks. All rights reserved.
The information in this document is subject to
change without notice. IMC Networks assumes
no responsibility for any errors that may appear in
this document. Specific product names may be
trademarks or registered trademarks and are the
property of their respective companies.
IMC Networks
Fiber Consulting Services
For information call:
TEL: [phone]
1-800-624-1070 (US/CAN)
[phone] (Europe)
[email protected]
IMC Networks
Headquarters
19772 Pauling
Foothill Ranch, CA 92610
TEL: [phone]
FAX: [phone]
[email protected]
www.imcnetworks.com
IMC Networks
Europe
Herseltsesteenweg 268
B-3200 Aarschot | Belgium
TEL: [phone]
FAX: [phone]
[email protected]
IMC Networks
Eastern US/Latin America
18840 US Hwy. 19 North Suite 400
Clearwater, FL 33764
TEL: [phone]-8071 (Latin)
FAX: [phone]
[email protected]
Fiber Optics Specifications
For each product listed below in the Ordering Information section, the DISTANCE represents an approximate fiber distance based on industry-standard fiber attenuation specifications. Actual
distances will vary for each installation. For complete power budgets and information on calculating specific distances, visit www.imcnetworks.com/go/fcs or contact IMC Networks Fiber
Consulting Services at 949-465-3000.
*These products have single-strand fiber technology. Deploy in pairs, or connect to another compatible IMC Networks single-strand
fiber product. For more information go to: www.imcnetworks.com/products/SSFX.cfm
Technical Specifications
All MediaConverter Modules
Install in any MediaConverter chassis•
50/125µm or 62.5/125µm multi-mode fiber•
9/125µm single-mode fiber•
Support Half- and Full-Duplex operation•
Include diagnostic LEDs•
Include hot-swappable architecture•
McPIM
10Base-T twisted pair•
10Base-FL fiber•
Includes MDI-II/MDI-X switch•
Features LinkLoss and Pulsing FiberAlert•
McLIM
100Base-TX twisted pair•
100Base-FX or SX fiber•
AutoCross for MDI-II/MDI-X•
Features LinkLoss and FiberAlert•
Features Auto-Negotiation•
McLIM TP-TX/FX
10Base-T twisted pair•
100Base-TX twisted pair•
100Base-FX or SX fiber•
AutoCross for MDI-II/MDI-X•
Features Auto-Negotiation•
Available for single-strand fiber•
McGigabit
1000Base-T twisted pair•
1000Base-LX or SX fiber•
AutoCross for MDI-II/MDI-X•
Available for single-strand fiber•
Chassis
MediaConverter/1
Dimensions: 1.60”H x 4.75”W x 5.20”D
(4.06 x 12.07 x 13.21 cm)
Shipping Weight:
2 lbs (.9 kg)
AC Input Load:
100-240V AC, 50/60Hz, 0.3A
MediaConverter/4
Dimensions: 1.75”H x 8.60”W x 4.73”D
(8.3 x 21.84 x 12.01 cm)
Shipping Weight:
3.5 lbs (1.6 kg)
AC Input Load:
100-240V AC, 50/60Hz, 1.2A
MediaConverter/8
Dimensions: 1.75”H x 17.4”W x 4.70”D
(4.45 x 44.20 x 11.94 cm)
Shipping Weight:
6.25 lbs (2.8 kg)
AC Input Load:
100-240V AC, 50-60Hz, 1.2A
MediaConverter/12
12 slot chassis is only 1U high•
12 slot available with redundant power•
Dimensions /12x: 1.75”H x 17.40”W x 8.76”D
(4.45 x44.20 x 22.25 cm)
Shipping Weight:
11.0 lbs (5 kg)
AC Input Load:
100/240V AC, 50/60Hz, 1.2A
McPIM: TP/FO (10 Mbps Copper to 10 Mbps Fiber)
Part
Number Port Description Fiber Connector Distance
855-12840 TP/FO-MM850 ST 2 km
855-1284 TP/FO-MM850 SC 2 km
855-12842 TP/FO-MM1300 ST 2 km
855-12843 TP/FO-MM1300 SC 2 km
855-12844 TP/FO-SM1310/PLUS ST 40 km
855-12845 TP/FO-SM1310/PLUS SC 40 km
855-12846 TP/FO-SM1310/LONG ST 70 km
855-12847 TP/FO-SM1310/LONG SC 70 km
855-12848 TP/FO-SM1550/LONG ST 80 km
855-12849 TP/FO-SM1550/LONG SC 80 km
855-12850 TP/FO-SM1550/XLONG SC 130 km
McLIM: TX/FX and TX/SX (100 Mbps Copper to 100 Mbps Fiber)
Part
Number Port Description Fiber Connector Distance
855-12662 TX/SX-MM850 ST 2 km
855-12663 TX/SX-MM850 SC 2 km
855-12660 TX/FX-MM1300 ST 2 km
855-12661 TX/FX-MM1300 SC 2 km
855-12664 TX/FX-SM1310/PLUS ST 40 km
855-12665 TX/FX-SM1310/PLUS SC 40 km
855-12668 TX/FX-SM1310/LONG SC 80 km
855-12669 TX/FX-SM1550/LONG SC 80 km
Single-Strand Fiber*
855-12680 TX/SSFX-SM1310 (1550rcv) SC 20 km
855-12681 TX/SSFX-SM1550 (1310rcv) SC 20 km
855-12682 TX/SSFX-SM1310/PLUS (1550rcv) SC 40 km
855-12683 TX/SSFX-SM1550/PLUS (1310rcv) SC 40 km
855-12684 TX/SSFX-SM1310/LONG (1550rcv) SC 60 km
855-12685 TX/SSFX-SM1550/LONG (1310rcv) SC 60 km
Part
Number Port Description Fiber Connector Distance
855-12620 TP-TX/SX-MM850 ST 2 km
855-12621 TP-TX/SX-MM850 SC 2 km
855-12622 TP-TX/FX-MM1300 ST 2 km
855-12623 TP-TX/FX-MM1300 SC 2 km
855-12624 TP-TX/FX-SM1310/PLUS ST 40 km
855-12625 TP-TX/FX-SM1310/PLUS SC 40 km
Single-Strand Fiber*
855-12642 TP-TX/SSFX-SM1310 (1550rcv) SC 20 km
855-12643 TP-TX/SSFX-SM1550 (1310rcv) SC 20 km
855-12644 TP-TX/SSFX-SM1310/PLUS (1550rcv) SC 40 km
855-12645 TP-TX/SSFX-SM1550/PLUS (1310rcv) SC 40 km
McLIM: TP-TX/FX and TP-TX/SX (10 or 100 Mbps Copper to 100 Mbps Fiber)
Part
Number Port Description Fiber Connector Distance
855-12670 TX/SX-MM850 SC 550 m
855-12671 TX/LX-SM1310 SC 15 km
855-12672 TX/LX-SM1310/PLUS SC 40 km
855-12673 TX/LX-SM1550/LONG SC 70 km
Single-Strand Fiber*
855-12674 TX/SSLX-SM1310 (1550rcv) SC 10 km
855-12675 TX/SSLX-SM1550 (1310rcv) SC 10 km
855-12676 TX/SSLX-SM1310/PLUS (1550rcv) SC 40 km
855-12677 TX/SSLX-SM1550/PLUS (1310rcv) SC 40 km
855-12686 TX/SSLX-SM1510/LONG (1570rcv) SC 60 km
855-12687 TX/SSLX-SM1570/LONG (1510rcv) SC 60 km
855-12688 TX/SSLX-SM1510/XLONG (1570rcv) SC 70 km
855-12689 TX/SSLX-SM1570/XLONG (1510rcv) SC 70 km
McGigabit: TX/SX and TX/LX (1000 Mbps Copper to 1000 Mbps Fiber)
Part Number Description # of Slots
851-10901 MediaConverter/1 1
851-10904 MediaConverter/4 4
851-10908 MediaConverter/8 8
851-10912 MediaConverter/12 12
Accessories
806-39040 AC power supply for MediaConverter/12
MediaConverter Chassis
Environmental Specifications for all Module and
Chassis Series
Operating Temperature:
32° to 122°F (0° to +50°C); 5% to 90% (non-condensing),
0 – 10,000 ft. altitude
Storage Temperature:
-13° to +158°F (-25° to +70°C); 5 to 90% (non-condensing)
