IMC HAND SANITISING STATION F63/250 User manual

IS760 ECN 4749 - May 2020
HAND SANITISING STATION
INSTALLATION AND USER MANUAL
PLEASE LEAVE WITH OPERATOR
HAND SANITISING STATION –F63/250

INDEX
INPORTANT INFORMATION
1
Guarantee
1
Delivery
1
DIMENTIONS
2
SPECIFICATION
2
PRODUCT FEATURES
3
INSTALLATION
4
Procedure
Location
4
4
Commissioning
5
Emptying / Refilling
6
Cleaning
6
SPARE PARTS
Spare Parts List
Ordering Spear Parts
6
6
6

HAND SANITISING STATION 1
INPORTANT INFORMATION
Read these instruction carefully. This manual outlines the installation, operation
procedures relevant to this unit.
WARNING
The unit should be used under adult supervision
Guarantee
The Hand Sanitising Station unit is guaranteed by Lincat-IMC for 1 year from the
date of purchase from Lincat-IMC, or from one of its stockists, dealers or
distributors. The guarantee is limited tothe replacement of faulty parts or products
and excludes any consequential loss or expense incurred by purchaser. Defects
which arise from faulty installation, inadequate maintenance, incorrect use or fair
wear and tear are not covered by the guarantee.
The guarantee applies in this form to installations within the United Kingdom.
Please observe these instructions carefully. Keep this manual for future reference
The manufacturer disclaims any liability for incidental, or consequential damages.
Attendance is based on reasonable access to the appliance to allow the
authorised technician to carry out the warranty work.
Delivery
The packaged unit contains:
IMC HAND SANITISING STATION:
Fully Assembled Hand Sanitising Station
Pump cover panel (removable)
Rear upstand
A4 click frame fitted
1
Instruction Booklet
1
Please note this unit is not supplied with Sanitiser.
Please notify LINCAT-IMC on the day of receipt if anything is missing or
damaged.
UK: 01522 875555
Check that the correct machine has been supplied. The data plate is located on
the rear of the unit.

HAND SANITISING STATION 2
1294
250
375
920
14
99
369
350
A4
DIMENSIONS
SPECIFICATION
Sanitiser container compatible
5 litres
Net Weight
12.2kg

HAND SANITISING STATION 3
CARRY HANDLES
UPSTAND WITH
A4 CLICK FRAME
FOOT PUMP
SANITISER FAUCET
PRODUCT FEATURES

HAND SANITISING STATION 2
INSTALLATION
These Instructions contain important information designed to help the user obtain
the maximum benefit from their investment.
Please read them carefully before starting work and consult with your
distributor/supplier in the event of any queries.
Be sure to leave this Instruction Manual with the user after installation of the
machine is complete, or in a safe location.
Procedure
WARNING
The following table shows the weight and the minimum quantity of
people required to lift the unit:
Net Weight
Quantity of People
F63/250
12.2kg
1
Before use; remove all packaging and ensure that the unit is checked over for
damage, any damage must be reported to the carrier or distributor/supplier
immediately.
Remove any protective plastic coating on the unit.
Location
The Hand Sanitising Station is only suitable for use where there is no risk for the
unit to be adversely affected by its surrounding environment.
The unit must be stationed on a flat surface capable of safely supporting the units
weight when fully laden with sanitiser.
The unit is fitted with a handles on the side to assist when moving.

HAND SANITISING STATION 5
Commissioning
Remove the rear panel by unscrewing the black knob on the back of the unit, tilt
the panel backwards and pull upwards away from the unit at an upward angle.
This will enable the operator to gain access to the suction hose and place a
suitable containers inside the unit.
Once the rear panel has been removed, fit the suction hose pipe into the sanitiser
container. Place the container on to the inner base panel. Note the suction tube
is suitable for 5 litre containers.
The rear panel can now be refitted. Note there are two securing brackets through
the back panel. These can be used to secure the back panel and the unit if being
left unattended.
To prime the pump remove the pump cover panel. To do this lift upwards and
away from the unit. Depress the foot pump several times until sanitiser is seen
coming out of the dispense spout.
Once all of the above steps have completed the pump cover panel can now be
refitted, your station should now be ready for operation.
Note the pump cover is required to restricts the volume of sanitiser dispensed per
operation. This should only be removed to prime the unit with sanitiser.

HAND SANITISING STATION 2
Emptying / Refilling
Once the unit has completed its total number of operations, the sanitiser container
will need replacing or refilled.
To replace the sanitiser container, follow the steps outlined in the commissioning
section.
Cleaning
Clean the externals of the unit as required; using a damp cloth and an appropriate
cleaning product.
DO NOT USE CLEANING MATERIALS CONTAINING ABRASIVES OR
BLEACHES.
SPARE PARTS
PART NUMBER
DESCRIPTION
WP02
FOOT PUMP
A21_044
SECURING KNOB
CF01
A4 CLICK FRAME
Ordering Spare Parts
In the event that spare parts or accessories need to be ordered, please always
quote the SERIES AND SERIAL NUMBER of the machine. This is to be found on
the rating plate located near the supply cable if applicable or at the rear of the
appliance.
For help with the installation, maintenance and use of your Lincat - IMC
equipment, please contact our service department:
UK: 01522 875520
For non-UK customers, please contact your local Lincat dealer
All service work, other than routine cleaning should be carried out by one of our
authorised service agents. We cannot accept responsibility for work carried out
by other persons.
To ensure your service enquiry is handled as efficiently as possible, please tell
us:
Brief details of the problem
Product code
All available on serial plate
Type number
Serial number
Lincat reserve the right to carry out any work under warranty, given reasonable
access to the appliance, during normal working hours, Monday to Friday, 08:30
to 17:00.
