Sunlighten Signature III User manual

E1x Floor
G1x Left Wall H1x Back Wall I1x Right Wall J1x Front Wall with Glass door
F1x Roof
2x
16x 24x 3
6x
A1x B1x C
1x
4
D1x Bench
ASSEMBLY INSTRUCTIONSUS ASSEMBLY INSTRUCTIONS SIGNATURE III
1sunlighten.com 1sunlighten.com

1.1 Attach the feet pegs with supplied Allen
wrench and bolts to the underside of floor .
1.2 Cut the zip ties holding the floor grate.
The fabric will adhere to the Velcro on the
underside of the grate.
TIP: One side of the fabric adheres better
NOTE: Make sure the floor panel is on a surface
that is perfectly level and relatively smooth. Failure to
do so can cause the door to not close all the way in
the later steps.
2 E
A
You will want two or more people to assemble your sauna.
Unpack each wall segment from the shipping material. Stage each
wall segment in the room you will be assembling the unit.
STEP 1
Place the back wall on the back of the floor panel .
Be sure you have two people assisting with this step.
This is the side with the sauna information label
on the bottom edge.
STEP 2
PRE-STEPS
A
2
4
1.1
1.2
HE
* Failure to do so will void your sauna's warranty
and customer will assume liability for any electrical
damages to the sauna itself or the residence/
business in which the sauna is installed.
See USER MANUAL or spec sheet for additional
specs.
120V, 2250 W. Dedicated 20 A circuit,*
without GFCI or AFCI, and NEMA 5-20 power
socket. 10 ft cord exists from back left of roof.
NOTE: Before you begin installing the walls, be sure you
have at least:
• 6 in between the back of the sauna and the outlet wall.
• 12 in gap from the top of the sauna to the ceiling.
• Place the sauna next to the wall power outlet to ensure
you have access to the wall power socket outlet to cut
the power to the unit if required.
In this step, make sure one person is holding the wall
while the other helps balance it and press it in place.
E
E
E
H
sunlighten.com
2sunlighten.com

STEP 3
As you insert each wall segment, you will insert the
U-clips in the pre-drilled holes in the corner.
This will keep the walls sealed together.
The front wall will be inserted next. Be careful
of the glass door and panel as you insert the wall.
Place right wall on the right side of floor panel .
This wall panel should sit flush once properly seated.
Make sure no gaps are visible in the corner of the two
walls as you insert it. It should be inserted flush.
STEP 4
J
I E
3
3
I
J
1sunlighten.com 3sunlighten.com

STEP 5
Once all the U-clips have been inserted in the
corners, the next step will be to place the roof
on top. Make sure the side the main power cord
receptacle faces the back.
After securing the U-clip , the left wall will
be the last to be inserted. Make sure it is flush and
no gaps are showing in the corners.
NOTE: If you ever have trouble getting a U-clip
to slide in, this can be resolved by tapping it with
a hammer.
STEP 6
3 G
3
3
3
F
G
F
1sunlighten.com 4sunlighten.com

STEP 7
Please make all connections on roof of sauna as
illustrated. To do this, you will first need to remove
the dust cover by removing many screws.
removing many screws.
Before the bench is placed, make
sure the heater frames are taken out to
allow the bench to be placed on its
support.
Left Wall Heaters
Back Wall Heaters Right Wall Heaters
Control Panel
Front Heater
D
D
heater frame
NOTE: The right wall of the sauna includes wire
connections underneath which will lead into
the floor panel (see illustration 7.2 below).
7.2 Connect floor
heaters
The floor heaters will need to be connected to the right
wall wires.The diagram to the left shows where the
connection is made. You will need to remove the floor
grate and a small hatch covering the harness.
E
1
sunlighten.com
5sunlighten.com
Blaupunkt Receiver/
Sound Therapy Receiver

STEP 8
With the bench installed, the heater panel
frames can be inserted back into their
respective walls.
The door handles come with the hard-
ware and can easily be screwed right in.
A second person should hold the handle
while the other screws the bolts in
with the Allen wrench. The dust
cover should also be replaced.
CONGRATULATIONS, your sauna is now ready to enjoy!
If you have any questions, please call
Sunlighten Customer Support at 877.292.0020.
C
1
4
heater frame
09082023
