imex Bullseye 80 User manual

USER MANUAL V1.0

1

2
2
4
1
3
6
5
8
7
9
Secondary line 2
Secondary line 1
Summary line

3
User Manual
Congratulations on the purchase of your Bullseye 80.
Carefully read the Safety Instructions and the User Manual
before using this product.
S
S
Sa
a
af
f
fe
e
et
t
ty
y
y i
i
in
n
ns
s
st
t
tr
r
ru
u
uc
c
ct
t
ti
i
io
o
on
n
ns
s
s
Symbols used
The symbols used in the Safety Instructions have the following meanings:
WARNING:
Indicates a potentially hazardous situation or an unintended use which, if not
avoided, may result in serious injury.
CAUTION:
Indicates a potentially hazardous situation or an unintended use which, if not
avoided, may result in minor injury and/or in appreciable material, financial and
environmental damage.
Important paragraphs which must be adhered to in practice as they enable
the product to be used in a technically correct and efficient manner.
Use of the instrument
Permitted use
·Measuring distances
·Computing functions, e.g. areas and volumes
·Storing measurements
Prohibited use
·Using the instrument without instruction
·Using outside the stated limits
·Deactivation of safety systems and removal of explanatory and hazard labels
·Opening of the equipment by using tools (screwdrivers, etc.), as far as not
specifically permitted for certain cases
·Carrying out modification or conversion of the product
·Use after misappropriation

4
·Use of accessories from other manufacturers without the express approval of
original manufacturer.
·Deliberate or irresponsible behavior on scaffolding, when using ladders, when
measuring near machines which are running, or near parts of machines or
installations which are unprotected
·Aiming directly into the sun
·Deliberate dazzling of third parties; also in the dark
·Inadequate safeguards at the surveying site (e.g. when measuring on roads,
construction sites, etc.)
Limits of use
See section “Technical Data”.
Product is designed for use in areas permanently habitable by humans, do not use
the product in explosion hazardous areas or in aggressive environments.
Areas of responsibility
Responsibilities of the manufacturer of the original equipment: original
manufacturer is responsible for supplying the product, including the User Manual
and original accessories, in a completely safe condition.
Responsibilities of the person in charge of the instrument:
WARNING
The person responsible for the instrument must ensure that equipment is used in
accordance with the instructions. This person is also accountable for the training
of personnel and for the safety of the equipment when in use.
The person in charge of the instrument has the following duties:
·To understand the safety instructions on the product and the instructions in the
User Manual.
·To be familiar with local safety regulations relating to accident prevention.
·To inform Imex immediately if the equipment becomes unsafe.

5
Hazards in use
CAUTION:
Watch out for erroneous distance measurements if the instrument is defective or
if it has been dropped or has been misused or modified.
Precautions:
Carry out periodic test measurements. Particularly after the instrument has been
subject to abnormal use, and before, during and after important measurements.
Make sure the Bullseye 80 optics is kept clean and that there is no mechanical
damage to the bumpers.
CAUTION:
In using the instrument for distance measurements or for positioning moving
objects (e.g. cranes, building equipment, platforms, etc.) unforeseen events may
cause erroneous measurements.
Precautions:
Only use this product as a measuring sensor, not as a control device. Your system
must be configured and operated in such a way, that in case of an erroneous
measurement, malfunction of the device or power failure due to installed safety
measures (e.g. safety limit switch), it is assured that no damage will occur.
WARNING:
Dispose of the product appropriately in accordance with the regulations in force in
your country. Always prevent access to the product by unauthorized personnel.
CAUTION:
Aiming the telescopic viewer directly at the sun or at the reflected laser beam
(reflected off metallic or mirroring surfaces, prisms……) is hazardous to the eyes.
Precautions:
Never aim the telescopic viewer directly at the sun or at highly reflecting surfaces
(metallic or mirroring surfaces, prisms……).

6
Electromagnetic Compatibility（EMC）
The term “electromagnetic compatibility” is taken to mean the capability of the
product to function smoothly in an environment where electromagnetic radiation
and electrostatic discharges are present, and without causing electromagnetic
interference to other equipment.
WARNING:
The Bullseye 80 conforms to the most stringent requirements of the relevant
standards and regulations. Yet, the possibility of it causing interference in other
devices cannot be totally excluded.
WARNING:
Electromagnetic radiation can cause disturbances in other equipment, in
installations (e.g. medical ones such as pacemakers or hearing aids) and in
aircraft. It can also affect humans and animals.
Precautions:
Although this product conforms to the most stringent standards and regulations，
Imex cannot totally exclude the possibility of harm to people and animals.
· Do not use the product near petrol stations, chemical plants, in areas with a
potentially explosive atmosphere and where blasting takes place.
· Do not use the product near medical equipment.
· Do not use the product in airplanes.
· Do not use the product near your body for extended periods.
CAUTION:
Never attempt to repair the product yourself. In case of damage, contact the local
dealership.
Laser classification
The Bullseye 80 produces a visible laser beam which emerges from the front of
the instrument.
It is a Class 2 laser product in accordance with:
· IEC60825-1:2007 (Safety of laser products)
· GB 7247.1-2001 (Safety of laser products)
Laser Class 2/Ⅱproducts:

7
Do not stare into the laser beam or direct it towards other people unnecessarily.
Eye protection is normally afforded by aversion responses including the blink
reflex.
WARNING:
Looking directly into the beam with optical aids (e.g. binoculars, telescopes) can
be hazardous.
Precautions:
Do not look directly into the beam with optical aids.
CAUTION:
Looking into the laser beam may be hazardous to the eyes.
Precautions:
Do not look into the laser beam. Make sure the laser is aimed above or below eye
level (particularly with fixed installations, in machines, etc.).
S
S
St
t
ta
a
ar
r
rt
t
t u
u
up
p
p
Inserting / Replacing Batteries
1 Remove the battery compartment lid.
2 Insert the batteries. Pay attention to correct polarity.
3 Close the battery compartment. When the battery voltage is too low, the
batteries should be replaced as soon as possible.
Batteries should be removed if the device will not be used for a long time
(danger of corrosion).
Use alkaline batteries.
End-piece
The instrument can be adapted for the following measuring situations:
Measure from edge, fold out the positioning bracket until it first locks in place.
Measure from corner, push the positioning bracket lightly to the right to fold it out
fully.
The sensor automatically detects the orientation of the positioning bracket
and adjusts the zero point of the instrument accordingly.

8
Keypad
See figure A.
1ON / Measuring button
2Area / Volume button
3 Pythagoras button
4 Plus (+) / Timer button
5 Minus (-) / Units button
6 Storage button
7 Angle / stake out function button
8 Reference / Illumination button
9Clear / off button
O
O
Op
p
pe
e
er
r
ra
a
at
t
ti
i
io
o
on
n
n
Switch on and off
Switch on the instrument and laser.
Pressing this button for longer switches the instrument off.
The instrument switches off automatically after 3 minutes of inactivity.
Clear button
The last action is cancelled. While making area or volume measurements,
each single measurement can be deleted and remeasured in series.
Refernce setting
The default reference setting is from the rear of the instrument .
Press this button to set the reference the front or the rear . There is a
special beep sound when changing the reference.
When the end-piece is folded out fully, the reference is set. Press key，
the front edge can be set.

9
Display illuminations
Pressing this button for longer switches the illuminations on or off.
Selecting Units
Press this key until the desired unit is displayed.
Optional units:
Length
Area
Volume
0.000 m
0.000 m²
0.000 m³
0.00m
0.00 m²
0.00 m³
0.00 ft
0.00 ft²
0.00 ft³
0.001/16 ftin
0.00 ft²
0.00 ft²
0' 0'' 1/16
0.00 ft²
0.00 ft³
0.0 in
0.00 ft²
0.00 ft²
0 1/16 in
0.00 ft²
0.00 ft³
M
M
Me
e
ea
a
as
s
su
u
ur
r
ri
i
in
n
ng
g
g
Single distance measurement
Press to activate the laser.
Press again to trigger the distance measurement. The result is displayed
immediately.

10
Minimum/ Maximum measurement
This function allows the user to measure the minimum or maximum distance
from a fixed measuring point. It is commonly used to measure room diagonals
(maximum values) or horizontal distances (minimum values).
Press and hold down this button. Then slowly sweep the laser back and
forth and up and down over the desired target point (e.g. into the corner of a
room).
Press to stop continuous measurement. The values for maximum and
minimum distances are shown on the display as well as the last measured value
in the summary line.
F
F
Fu
u
un
n
nc
c
ct
t
ti
i
io
o
on
n
ns
s
s
Arithmetic
The previous measurement (result) adds to the next one.
The previous measurement (result) subtracts to the next one.
Press this button and the result will be shown in the summary line.
The last step will be cancelled.
The parameters that participate in the calculating must have the same
physical significance.
Area
Press this button until this symbol appears on the display.
Press this button to take the first length measurement (e.g. length).
Press it again to take the second length measurement (e.g. width).
The result is shown in the summary row.

11
Volume
Press this button until this symbol appears on the display.
Press this button to take the first length measurement (e.g. length).
Press this button to take the second length measurement (e.g. width).
Press this button to take the third length measurement (e.g. height).
The result is shown in the summary row.
Indirect horizontal distance
Press this button until this symbol appears on the display.
Press this button to measure tilt and distance. The summary line
displays the result as the horizontal distance.
The instrument should be held without a transverse tilt (max. 10°).
Staking out function
A distance can be set and then be used to mark off defined measured lengths.
Input staking out distances:
Press this button until this symbol appears on the display.
Distance flashes on the display.
By using and button, you can adjust the values to suit the desired
stacking out distance. Press key to confirm it.
Press this key to take the stack out measurement.
The display shows required stake out distance in the summary line between the
stake out point and the instrument (refer to the reference).
If the instrument is then moved slowly along the stake out line the displayed
distance decreases. The instrument starts to beep at a distance of 0.1m from the
next stake out point.

12
Indirect measurement
By using Pythagoras’ theorem, the instrument can calculate distances. This
function is helpful, if the distance to measure can not be reached directly.
Make sure you adhere to the prescribed sequence of measurement:
All target points must be in a horizontal or vertical plane.
The best results are achieved when the instrument is rotated about a fixed
point (e.g. with the positioning bracket fully folded out and the instrument
placed on a wall) or the instrument is mounted on a tripod.
The minimum / maximum function can be used. The minimum value must be
used for measurements at right angles to the target; the maximum distance
for all other measurements.
Pythagorean calculation
It is helpful to use a tripod when measuring heights that require the measurement
of two or three measurements.
Single Pythagorean calculation
E.g. measure the height or width of a building.
Press this button until this symbol appears on the display.
Aim at the upper point and trigger the measurement. Then the
value is adopted. Keep the instrument as horizontal as possible.
Press this button to trigger the measurement . Then the value is
adopted. You can also press and hold down this button to trigger
continuous measurement, sweep the laser back and forth and up and down over
the ideal target point.
The result is displayed in the summary line, the partial results in the
secondary line.

13
Double Pythagorean calculation
E.g. using 3 measurements to determine a distance .
Press this button until this symbol appears on the display.
Press this button to trigger the measurement. Then the first value is
adopted.
Press this button to trigger the measurement. Then the second
value is adopted. You can also press and hold down this button to
trigger continuous measurement, sweep the laser back and forth and up and
down over the ideal target point. Press to stop the measurement then the
minimum value is adopted.
Press this button to trigger the measurement. Then the third value
is adopted.
The result is displayed in the summary line, the partial results in the
secondary lines.
Storage of constant / historical storage
Storage of constant
You can store and recall a frequently used value (e.g. height of a room).
Measure the desired distance, press and hold the button until the
device beeps to confirm storage.
Recalling the constant
Press this button once to recall the constant and then press the
button to enter it into your calculation.

14
History storage
Press this button twice and the previous 30 results (measurements or
calculated results) are shown in reverse order.
and buttons can be used for navigation.
Press this button to use the result from the summary line for further
calculations.
Timer
Press and hold down this button to set a 5-second time delay.
By using and button, you can adjust the value until the desired
time delay reached.
Once the key is released with the laser activated, the remaining seconds
until measurement (e.g. 59, 58, 57...) are displayed in a countdown. The last
5 seconds are counted down with a beep. After the last beep the
measurement is taken and the value is displayed.
Tilt sensor calibration
You can calibrate the tilt sensor in the device. Calibration requires two
measurements on a level surface.
Carry out 1st measurement on a level surface. Press to confirm the
measurement.
Rotate the device horizontally through 180°.
Carry out 2th measurement on a level surface. Press to confirm the
measurement.
The tilt sensor is calibrated with the result on the Summary line.

15
Press to confirm the result.
Press to cancel the result. Press twice to exit without saving.
A
A
Ap
p
pp
p
pe
e
en
n
nd
d
di
i
ix
x
x
Message codes
All message codes are displayed with either “Info” or “Error”.
Info
Cause
Remedy
204
Calculation overflow
Repeat procedure
252
Temperature too high
Cool down instrument
253
Temperature too low
Warm up instrument
255
Receiver signal too weak
Use target plate
256
Received signal too strong
Use target plate (grey side)
205
Ranging transfinite
Use in allowed ranging
206
Wrong parameter
When measuring by Pythagoras, the
length of hypotenuse should be greater
than the other two lengths
The parameter calculated must have the
same unit
156
Transverse tilt greater than
10°
Hold the instrument without any
transverse tilt
Error
Cause
Remedy
Err
Hardware error
Switch on/off the device several
times and check if the symbol
still appears. If so please call
your dealer for assistance

16
Technical data
Range (use target plate for longer)
0.05m to 80m
Measuring accuracy up to 80m（in the room）
Typ. : ±1.5mm**
Smallest unit displayed
1 mm
Laser class
Ⅱ
Laser type
620-690 nm, <1 mW
Automatic switch off
3 minutes of inactivity
Display illumination
√
Minimum/ Maximum measurement, Continuous
measurement
√
Addition/Subtraction
√
Pythagoras measurement
√
Area / Volume calculation
√
Timer
√
Staking out function
√
Historical storage
√(99)
Measure range of tilt sensor
360°
Accuracy of tilt sensor
±0.3° ***
Battery life, Type AAA，2×1.5V
up to 5000 measurements
Dimension
122×46×25 mm
Weight
105g
Temperature range:
Storage
Operating
-25℃to +70℃
-10℃to +50℃
** Maximum deviation occurs under unfavorable conditions such as bright sunlight or when measuring to poor
reflecting or very rough surfaces. For distances over 80m –without using a target plate –the maximum deviation
may increase to a maximum of ±10mm.
*** This is the typical value. For the limiting conditions (e.g. limiting temperature), the deviation increases a little.

17
Measuring conditions
Measuring range
As for the measure range limit, please refer to the technical specification.
At night, at dusk and when the target is shadowed the measuring range
without target plate is increased.
Use a target plate to increase the measurement range during daylight or if
the target has a bad reflection.
Measuring Surfaces
Measuring errors can occur when measuring toward colorless liquids (e.g.
water) or dust free glass, styrofoam or similar semi-permeable surfaces.
Aiming at high gloss surfaces deflects the laser beam and measurement
errors can occur.
Against non-reflective and dark surfaces the measuring time can be
increased.
Care
Do not immerse the unit in water. Wipe off dirt with a damp, soft cloth. Do
not use aggressive cleaning agents or solutions. Treat the optical surfaces
with the same care that you would apply to eyeglasses and cameras.
W
W
Wa
a
ar
r
rr
r
ra
a
an
n
nt
t
ty
y
y
Warranty Regulations
1. A two-year warranty is available from the date of purchase.
2. The following conditions are beyond the warranty lists：
* Instrument of which the instrument number is deleted or modified.
* Instrument which is repaired without authorization.
* Instrument with man-made damage or fault caused by improper storage.
3. Warranty card with date of purchase, model, instrument number must be
provided when warranty.

18
Warranty Card
Packing list
Certificate
Name：Hand-Held Laser Distance Meter
Model：Bullseye 80
Testing: Date:
Instrument Model
Serial Number
Date of sales
Sale company
Sale Address
NO.
Name
Quantity
Unit
Remarks
1
Main body
1
pc
2
AAA battery
2
pcs
2
Instrument cap
1
pc
4
Lanyard
1
pc
5
User manual
1
pc

19
Copyright © Imex Group International 2016
www.imexlaseres.com
