Impact Test Equipment Harvard Trip BA710 User manual

User Guide
User Guide
Harvard Trip Balance
BA710
Impact Test Equipment Ltd
www.impact-test.co.uk & www.impact-test.com

Impact Test Equipment Ltd.
Building 21 Stevenston Ind. Est.
Stevenston
Ayrshire
KA20 3LR
T: 01294 602626
F: 01294 461168
E: [email protected]
Test Equipment Web Site
www.impact-test.co.uk
Test Sieves & Accessories Web Site
www.impact-test.com

2
INTRODUCTION
This manual covers Installation, Operation and Maintenance for the Harvard
Trip balances: . To ensure proper
operation of the Balance, please read this manual completely.
DESCRIPTION
The Harvard Trip Balance Series are precision weighing instruments,
designed to provide years of service with virtually no maintenance. Harvard Trip
Balances employ a two-pan design based on the classic Roberval balance
principle. They have the additional advantages of magnetic damping, beams with
sliding weights and two styles of weighing platforms.
Two-pan Balances of this type are commonly used for comparative weighing to
determine the difference in mass between two objects rather than their absolute
value. BA710 is a double side beam model for
higher capacity weighing. Maximum Balance capacity for all Harvard Trip Balances
is 2kg/5lbs. The Platforms used on the Balances are 6" diameter stainless-steel
plates.
Harvard Trip Balance Model BA710.

3
UNPACKING AND ASSEMBLY INSTRUCTIONS
Harvard Trip Balances are shipped as follows:
•Completely assembled Balance
•Instruction manual
•Warranty card
Your new precision Balance has been packed in a carton specifically designed to
protect it during shipment. Follow these instructions and your Balance will be
operational in just a few minutes. Carefully unpack and verify that all items are on
hand.
1. Remove the Balance from the carton by pulling on the cardboard inserts.
2. Remove cardboard inserts from Balance.
3. Remove the two round rubber beam retainers from between the Base and
Platform End Loops. All packing material should be retained if you anticipate
INSTALLATION
Place the Balance on a reasonably flat, level surface away from sources of
vibration and drafts. Move the sliding weight (Poise) all the way to the left facing
the front of the Balance. On Model BA710, slide the tare weight (Poise) all the
way to the left. This will result in the Balance being very nearly at zero.
OPERATION
Zeroing the Balance
To set the Balance exactly at zero, adjust the knurled Zero Adjust Knob which is
located at the right end of the Beam. It is advisable to check the zero balance
periodically because foreign material may accumulate on the Platform or the
Beams. This can produce a slight change in the zero balance position. In
addition, whenever the Balance is moved, the zero balance must be rechecked.
Any appreciable change in the inclination of the working surface will affect
accuracy.
The Base of each Balance is leveled on a surface plate at the factory and will rest
evenly on any perfectly flat surface. The Balance may rock slightly if the working
surface is not absolutely flat. This should be eliminated by shimming under the
Base. Be sure to adjust the zero balance after leveling.

4
Weighing
Once the zero balance has been checked, proceed as follows:
1. Place the unknown mass on the left Platform.
2. Move the large Poise on the lower Beam to the right until it reaches the first
notch which will cause the right Platform to drop.
3. Move the large Poise back one notch, which will allow the right Platform to
rise again.
4. Move the small Poise on the upper Beam to the right until the Balance is
brought into equilibrium.
5. To determine the weight of the unknown mass, add the amounts indicated
on the two Beams.
If the capacity on the Balance exceeds the Beam capacity, additional masses are
necessary to take advantage of the full capacity.
To weigh masses which exceed the Beam capacity, proceed as follows:
1. Place additional masses on the right Platform to compensate for the excess
weight of the unknown mass.
2. Adjust the Poises on the Beams to bring the Balance into equilibrium.
3. To determine the weight of the unknown mass, add the weight (s) on the
right Platform to the amounts indicated on the two Beams.
Use of the Tare Poise (Model BA710)
For those models which are equipped with the Tare Beam assembly, a patented
Tare Poise can be used to tare off containers which weigh less than 200 grams.
With the container on the left Platform, slide the Tare Poise to a position on the
Tare Beam which indicates approximate balance. Rotate the Poise in either
direction to position it precisely on the Tare Beam to counterbalance the
container on the left hand Platform.
When not in use, the Tare Poise is to be moved all the way to the left of the Tare
Beam. The Spring inside the Tare Poise should also be pushed to its left most
position in order to obtain zero balance.

5
Specific Gravity Determination
A Clamp and Rod Support, is an accessory used to
elevate the Balance for suspending a specimen in water. The rod is inserted into
the 1/2 inch recess on the underside of the Base. By means of a fine wire or
thread, the specimen is attached to the Check Pin which connects the Platform
Loop to the Check Rod. The procedure for weighing a suspended specimen is
the same as that for weighing an unknown mass on the Platform.
CARE AND MAINTENANCE
The following practices will assure that your Balance will give you years of
satisfactory and trouble-free service.
When the Balance is not in use, remove any mass or weights from the Platforms.
Move one of the Poises from zero so that the Balance is not in equilibrium. This
will stop the Balance from oscillating and prevent unnecessary wear.
Use and store the Balance in places free of vibration. Never lubricate the scale
bearings. The Bearings in these Balances are high grade polished agate V-
blocks and the knife edges are hardened, precision-ground steel. This type of
Bearing works most efficiently when clean and dry.
Keep the Balance clean at all times, being particularly careful not to let dirt
accumulate in the vicinity of the Bearings. If the Bearings should become dirty, try
to clean them using an air syringe. ABalance Cover is
recommended to keep the Balance clean when not in use.
Cleaning Magnet Faces
In general, most foreign matter may be easily removed by an air syringe. If the
Damper Vane still does not move freely, proceed as follows:
1. CAREFULLY turn the Balance on its side.
2. Remove the four (4) screws that mount the Magnet Case to the underside of
the Base.
3. Remove the Magnet Case.
4. Clean the Magnet faces by pressing a piece of adhesive-backed tape
against them.
5. Reinstall the Magnet Case.

6
SPECIFICATIONS
MODEL N/A BA710
Capacity (g/lb) 2000 2000 2000
Weigh beam capacity x readability 10g x 0.1g 10g x 0.1g 10g x 0.1g
200g x 10g 200g x 10g
Tare range -------- -------- 225g
Platform size (in/cm) 6/15.2 dia.
Platform type Plate
Dimensions (W x H x D) (in/cm) 14 x 9.5 x7 / 35.5 x 24.1 x 17.8
Net weight (lb/kg) 4.7 / 2.1
Shipping weight (lb/kg) 5 / 2.3
PARTS INFORMATION
If you require replacement parts or would like to purchase accessories, please call
Impact Test Equipment - www.impact-test.co.uk
ACCESSORIES
Description
Polypropylene footed scoop,
(12" x 6" x 2.75" deep) and Counterweight
Specific gravity rod and clamp
Weight set, Metric, 1000 gram x 1 gram
Balance Cover, silver metallic vinyl plastic,
16" x 9.5" x 7"
N/A

7
LIMITED WARRANTY
Products are warranted against defects in materials and workmanship
from the date of delivery through the duration of the warranty period. During the
warranty period the supplier will repair, or, at its option, replace any component(s)
that proves to be defective at no charge, provided that the product is returned,
freight prepaid, to the supplier.
This warranty does not apply if the product has been damaged by accident or
misuse, exposed to radioactive or corrosive materials, has foreign material
penetrating to the inside of the product, or as a result of service or modification
by other than the manuafcturer. In lieu of a properly returned warranty registration,
the warranty period shall begin on the date of shipment to the authorized
dealer. No other express or implied warranty is given by the manufacturer and they
shall not be liable for any consequential damages.
