Operating manual
Baby scale
KERN MBA
Typ TMBA-B
Version 1.0
2020-12
GB
TMBA_B-BAPS-d-2010

2TMBA_B-BAPS-e-2010
GB
KERN MBA
Version 1.02020-12
Operating manual
Baby scale
Contents
1Technical data................................................................................................ 4
2Declaration of conformity ............................................................................. 5
3Appliance overview ....................................................................................... 6
3.1 Dimensions ............................................................................................................................... 7
3.2 Overview of display.................................................................................................................. 7
3.3 Keyboard overview................................................................................................................... 9
4Basic Information (General)........................................................................ 10
4.1 Intended use ........................................................................................................................... 10
4.2 Improper Use / Contraindications......................................................................................... 11
4.3 Warranty.................................................................................................................................. 11
4.4 Monitoring of Test Resources............................................................................................... 12
5Basic Safety Precautions............................................................................ 13
5.1 Pay attention to the instructions in the Operation Manual................................................ 13
5.2 Preparing for use.................................................................................................................... 13
6Transport and storage................................................................................. 14
6.1 Testing upon acceptance ...................................................................................................... 14
6.2 Packaging / return transport ................................................................................................. 14
7Unpacking, Setup and Commissioning ..................................................... 15
7.1 Installation Site, Location of Use.......................................................................................... 15
7.2 Unpacking ............................................................................................................................... 15
7.3 Scope of delivery.................................................................................................................... 15
7.4 Installation............................................................................................................................... 16
7.5 Battery operation.................................................................................................................... 16
7.6 Mains connection (option)..................................................................................................... 19
7.7 Optional equipment mains adapters.................................................................................... 19
7.8 Initial Commissioning ............................................................................................................ 19
8Operation...................................................................................................... 19
8.1 Weighing ................................................................................................................................. 19
8.2 Taring....................................................................................................................................... 20
8.3 Hold function (Standstill function) ....................................................................................... 21
8.4 Auto off (Automatic switch-off function) ............................................................................. 22
8.5 Using the optional equipment height measuring rod MBA-A01........................................ 23
8.6 Using the optional equipment WIFI interface YMI-A01 (TMBA-A02-A) ............................. 24
8.6.1 Printing function........................................................................................................................ 25
8.6.2 Remote commands .................................................................................................................. 25
9Menu ............................................................................................................. 26
9.1 Navigation in the menu.......................................................................................................... 26
9.2 Menu overview........................................................................................................................ 27
10 Error reports................................................................................................. 28

TMBA_B-BAPS-e-2010 3
11 Servicing, maintenance, disposal .............................................................. 29
11.1 Cleaning .................................................................................................................................. 29
11.2 Cleaning / disinfecting........................................................................................................... 29
11.3 Sterilisation............................................................................................................................. 29
11.4 Servicing, maintenance ......................................................................................................... 29
11.5 Disposal................................................................................................................................... 29
12 Instant help................................................................................................... 30
13 Adjustment................................................................................................... 31
14 Equipment (optional)................................................................................... 33

4TMBA_B-BAPS-e-2010
1 Technical data
KERN MBA 10K-3M
Item no./ Type TMBA 15K-3M-B
Weighing range (max) 15 kg
Readability (d) 0.005 kg
Reproducibility 0.005 kg
Linearity 0.005 kg
Display LCD with 25mm high digits
Recommended adjustment
weight, not added (class) 15 kg
(M1)
Stabilization time (typical) 3 sec.
Warm-up time 10 min
Operating temperature 10° C …. + 40° C
Storage and Transport
Environment -10 to +60°C, and 30% to 90% relative humidity
Atmospheric pressure: 700-1060 hPa
Humidity of air max. 80 % (not condensing)
Atmospheric pressure (kPa) 70kpa-106kpa
Input Voltage 100 V - 240 V, 50 / 60 Hz
Output Voltage
power supply DC 12V/500mA
Battery use
6 x 1,5 V AA
battery working period:
without WiFi installed: 50 hours
Auto Off can be adjusted after "30, 60, 180" sec. or "Off" without load
change
Dimensions fully mounted
(W x D x H) mm 890 x 470 x 175
Baby weighing pan
(B x D x H) mm 600 x 260
Weight kg (net) 4.6
Height measuring rod,
optional MBA-A01, Measuring range 40 – 80 cm
WIFI WIFI interface
as factory option

TMBA_B-BAPS-e-2010 5
2 Declaration of conformity
The current EC/EU Conformity declaration can be found online in:
www.kern-sohn.com/ce

6TMBA_B-BAPS-e-2010
3 Appliance overview
1. Height measuring rod (optional)
2. Baby weighing pan
3. Keyboard
4. LED
5. Bubble level
6. Mains connection
7. Rubber feet (height adjustable)
8. Battery compartment / adjustment switch inside
9. WIFI compartment

TMBA_B-BAPS-e-2010 7
3.1 Dimensions
3.2 Overview of display
Display Designation Description
GROSS Gross weight display Illuminated when gross weight of the
baby is displayed
NET Net weight display Illuminated when net weight of the baby
is displayed
Illuminated after weighing scale was
tared
TARE Taring display Illuminated after weighing scale was
tared
Zeroing display Should the balance not display exactly
zero despite empty scale pan, press the
button. Your balance will be set to
zero after a short standby time.

8TMBA_B-BAPS-e-2010
Stability display Scales are in a steady state
W1 – W2 Display weighing range Illuminated, when the load is within the
displayed range
HOLD HOLD function Is displayed with active Hold function
Rechargeable battery
symbol
Lights when the voltage drops below the
prescribed minimum.
Lights when the rechargeable battery
capacity is almost exhausted.
Illuminated when the rechargeable
battery is fully charged.

TMBA_B-BAPS-e-2010 9
3.3 Keyboard overview
Button Designation Function
ON/OFF-button Turn on/off
For numeric entry:
•Decimal point further to the right
In menu:
•Confirm selection
HOLD button Hold function
For numeric entry:
•Decimal point further to the left
TARE-key/
Zeroing key
•Tare balance
•Weighing scale will be reset to „0.0“kg.
For numeric entry:
•Reduce numeric value
In menu:
•Call up menu
•Select menu items
PRINT button Printout the weighing value
For numeric entry:
•Increase numerical value
In menu:
•Select menu items

10 TMBA_B-BAPS-e-2010
4 Basic Information (General)
4.1 Intended use
These balances serve as a means of determining the weight of babies in medical
treatment rooms (hospitals or Doctor practices). The frequently used function of the
baby scale is recognising, preventing and controlling illnesses.
The WIFI interface allows the measured results to be transmitted wirelessly to a PC.
Scales fitted with a serial interface may only be
connected to
appliances in compliance with Directive EN60601-1.
To prevent babies lying on the weighing pan from falling off the
scale, they must be watched all the time. Please observe note on
weighing pan!

TMBA_B-BAPS-e-2010 11
4.2 Improper Use / Contraindications
Do not use these scales for dynamic weighing processes.
Do not leave permanent load on the weighing pan. This may
damage the measuring system.
Impacts and overloading exceeding the stated maximum load
(max) of the weighing plate, minus a possibly existing tare load,
must be strictly avoided. This could cause damage to the
balance.
Never operate balance in explosive environment. The serial
version is not explosion protected. It should be noted that a
flammable mixture of anaesthetics and oxygen or laughing gas
may occur.
The structure of the balance may not be modified. This may lead
to incorrect weighing results, safety-related faults and destruction
of the balance.
The balance may only be used according to the described
conditions. Other areas of use must be released by KERN in
writing.
If the balance is not used for a longer time, take out the batteries
and store them separately. Leaking battery liquid could damage
the balance.
The scale is for weighing baby only. Any person with weight over
15 kg, do not step on the scale.
Improper use of optional height meter MBA-A01:
The structure of the height measuring rod may not be modified.
This may result in incorrect measuring results, safety-related
defects as well as destruction.
The height
measuring rod may only be used according to the
described conditions. Other areas of use must be released by
KERN in writing. More details in the instruction manuals of the
height meter.
4.3 Warranty
Warranty claims shall be voided in case of
Our conditions in the operation manual are ignored
The appliance is used outside the described uses
The appliance is modified or opened
Mechanical damage and damage caused by media, liquids,
Natural wear and tear
The appliance is improperly set up or incorrectly electrically connected
The measuring system is overloaded
Dropping the balance

12 TMBA_B-BAPS-e-2010
4.4 Monitoring of Test Resources
In the framework of quality assurance the measuring-related weighing properties of
the balance and, if applicable, the testing weight, must be checked regularly. The
responsible user must define a suitable interval as well as type and scope of this test.
Information is available on KERN’s home page (www.kern-sohn.com) with regard to
the monitoring of balance test substances and the test weights required for this. In
KERN’s accredited DKD calibration laboratory test weights and balances may be
calibrated (return to the national standard) fast and at moderate cost.
For balances with height measuring rods, we recommend a metrological examination
of the accuracy of the height measuring rod, however, this is not mandatory as the
determination of human body height involves rather large, intrinsic inaccuracies.

TMBA_B-BAPS-e-2010 13
5 Basic Safety Precautions
5.1 Pay attention to the instructions in the Operation Manual
Carefully read this operation manual before
setup and commissioning, even if you are
already familiar with KERN balances.
5.2 Preparing for use
•Check the balance for damage before any use
•Maintenance and re-verification
The baby scale must be serviced and re-verified at regular intervals. (see
chapter 12.4)
•Do not use the device on slippery surfaces or in rooms susceptible to
vibrations
•The balance must be levelled during installation
•If possible, the product must be transported in its original packaging when
transporting. If this is not possible, ensure that the product is protected from
damage.

14 TMBA_B-BAPS-e-2010
6 Transport and storage
6.1 Testing upon acceptance
When receiving the appliance, please check packaging immediately, and the
appliance itself when unpacking for possible visible damage.
6.2 Packaging / return transport
Keep all parts of the original packaging for a possibly required
return.
Only use original packaging for returning.
Prior to dispatch disconnect all cables and remove loose/mobile
parts.
Reattach possibly supplied transport securing devices.
Secure all parts such as the weighing pan, power unit etc. against
shifting and damage.

TMBA_B-BAPS-e-2010 15
7 Unpacking, Setup and Commissioning
7.1 Installation Site, Location of Use
The balances are designed in a way that reliable weighing results are achieved in
common conditions of use. You will work accurately and fast, if you select the right
location for your balance.
On the installation site observe the following:
Place scales on a stable, even surface
Avoid extreme heat as well as temperature fluctuation caused by installing next to
a radiator or in the direct sunlight;
Protect the balance against direct draughts due to open windows and doors;
Avoid jarring during weighing;
Protect the balance against high humidity, vapours and dust;
Do not expose the device to extreme dampness for longer periods of time. Non-
permitted condensation (condensation of air humidity on the appliance) may occur
if a cold appliance is taken to a considerably warmer environment. In this case,
acclimatize the disconnected appliance for ca. 2 hours at room temperature.
Avoid static charge of the balance and of the person to be weighed.
Avoid contact with water.
Major display deviations (incorrect weighing results) may be experienced should
electromagnetic fields (e.g. due to mobile phones or radio equipment), static
electricity accumulations or instable power supply occur. In that case, the location
must be changed.
7.2 Unpacking
Take the balance out of their packaging and place it at the intended position. When
using the power pack, ensure that the power cable does not produce a risk of
stumbling.
7.3 Scope of delivery
Balance
Batteries 6x1.5 V AA
Operating manual

16 TMBA_B-BAPS-e-2010
7.4 Installation
Carefully remove the balance from the packaging, remove plastic cover and setup
balance at the intended workstation.
Levelling
Level balance with foot screws until the air bubble of the
water balance is in the prescribed circle.
7.5 Battery operation
The balance offers also the possibility to be operated with 6x AA-batteries.
Open the battery cover (see fig.) at the lower side of the display unit and insert the
batteries according to the example shown below. Lock again the battery
compartment cover. If the batteries are empty, in the balance display appears the
symbol . Change batteries. To save the battery, the balance switches
automatically off (see chap.11.6 Auto off).

TMBA_B-BAPS-e-2010 17
If the batteries are run down,to turn off, press the button and immediately
change the batteries.
If the balance is not used for a longer time, take out the batteries and store them
separately. Leaking battery liquid could damage the balance.
Capacity of batteries exhausted.
Batteries will soon be flat.
Batteries completely loaded
If the balance is not used for a longer time, take out the batteries and
store them separately. Leaking battery liquid could damage the
balance.

18 TMBA_B-BAPS-e-2010
Insert batteries:
Remove the battery
compartment lid on the lower
side of the balance
Connect the battery block with
batteries to the contact of the
housing and insert into the
battery compartment.
Fix it using the battery
compartment lid.

TMBA_B-BAPS-e-2010 19
7.6 Mains connection (option)
Power is supplied by the external power unit which also serves to isolate the mains
supply from the scale. The stated voltage value must be the same as the local
voltage.
Only approved genuine KERN power supply units may be used in compliance with
Directive EN 60601-1.
7.7 Optional equipment mains adapters
Available mains adapters (optional)
•YKA-43
•YKA-44
7.8 Initial Commissioning
In order to obtain exact results with the electronic balances, your balance must have
reached the operating temperature (see warming up time chap.1). During this
warming up time the balance must be connected to the power supply (mains,
accumulator or battery) and be switched on.
The accuracy of the balance depends on the local acceleration of gravity.
The value of gravity acceleration is shown on the type plate.
8 Operation
8.1 Weighing
Start balance by pressing .
The balance carries out a self-test.
The scales are ready for operation as soon as the weight display
for “0.000 kg” has appeared.
However, you can reset the weighing scale to zero by pressing
the key.
Put baby in the centre of the weighing pan.
Wait for the stability display , then read the weighing
result.
If the baby is heavier than the max. weighing range, the display
shows "oL" (=overload) and a beep sounds.

20 TMBA_B-BAPS-e-2010
8.2 Taring
The tare weight of any preloads can be deducted by pressing a button so that the
actual weight of the baby is displayed in subsequent weighings.
(example)
Put object (such as towel or padding) on the weighing pan.
Wait for stability display .
Press , the zero display appears.
(example)
Put baby on the weighing pan.
Wait until the stability display appears, then read the
weighing result. “NET” is shown at the bottom on the left.
When the balance is unloaded the saved taring value is
displayed with negative sign.
To delete the stored tare value, unload the balance and press
.
