Mini LT Power Pack
INSTRUCTIONS
TM

Congratulations on your purchase of the Impact Mini LT Portable Power Pack.
Enjoy the many benets of portable battery power, such as longer shooting
time, shooting on location, and the ability to use both the dedicated Impact
LiteTrek 4.0 Monolight and portable ashes. With a fully charged Power Pack,
you can achieve 650* ashes at full power, and 3500* ashes at the lowest
power setting.
Features
• Powers the Impact LiteTrek 4.0 Monolight and/or portable ash units
• Automatic power on/off prevents battery drainage
• 400W/s using the LiteTrek 4.0 Monolight
• Lightweight and compact size
• Digitally controlled
• Long lasting and reliably built
• Fast battery swap system for extended shoots
• Two power outlets
Contents
• Power Module
• Battery Pack
• Charger
• Leather Shoulder Case with Shoulder Strap
Warning
• Do not attempt to disassemble the Portable Power Pack.
• Unplug from power source when not in use
• Do not allow moisture or liquids to come in contact with the battery pack, charger or cables
• Keep away from heat, re, dust, and ammable oil and gases
• Do not place metal objects near the power outlets
• Do not use damaged cables – replacements are available from your Impact retailer
• Use the appropriate power cables for the intended ash unit
• Never exchange the battery pack in wet or damp conditions
• Charge only with the supplied Impact charger
• Keep out of reach of children
Impact provides optional Flash Cables that connect between the Impact Mini
LT Portable Power Pack and a portable ash unit. See your Impact dealer for
a cable that is compatible with your model of ash.
Impact CZ Canon Flash Cable for LiteTrek system
For Canon®ash heads: 580EXII, 580EX, 550EX, MR-14EX, MT-24EX
Impact CKE Nikon Flash Cable for LiteTrek system
For Nikon® ash heads: SB-800, SB80-DX, SB-900, SB-28
