Impex CB-202 User manual

NOTE:
Please read all instructions
carefully before using this
product
Table of Contents
Safety Notice
Hardware Pack
Assembly Instruction
Parts List
Warranty
Ordering Parts
Model
CB 202
Retain This
Manual for
Reference
06-29-07
OWNER'S
MANUAL
COMPETITOR BENCH
CB-202
IMPEX®INC.
14777 DON JULIAN RD., CITY OF INDUSTRY, CA 91746
Tel: [phone] Fax: [phone]
www.impex-fitness.com
[email protected]

TABLE OF CONTENTS
BEFORE YOU BEGIN...................................................................................... 1
IMPORTANT SAFETY NOTICE....................................................................... 2
HARDWARE PACK ……….....…....................................................................... 4
ASSEMBLY INSTRUCTIONS........................................................................... 5
EXPLODED DIAGRAM.........................................................................………. 9
PARTS LIST…………………………………………………………………………. 10
WARRANTY.................................................................................................… 11
ORDERING PARTS......................................................................................... 11
BEFORE YOU BEGIN
Thank you for selecting the Competitor Bench CB-202 by IMPEX®INC. For
your safety and benefit, read this manual carefully before using the machine.
As a manufacturer, we are committed to provide you complete customer
satisfaction. If you have any questions, or find there are missing or damaged
parts, we guarantee you complete satisfaction through direct assistance from
our factory. To avoid unnecessary delays, please call our TOLL-FREE
customer service number. Our Customer Service Agents will provide
immediate assistance to you.
1
Toll-Free Customer Service Number
1-800-999-8899
Mon. - Fri. 9 a.m. - 5 p.m. PST
www.impex-fitness.com
[email protected]m

IMPORTANT SAFETY NOTICE
PRECAUTIONS
This exercise machine is built for optimum safety. However, certain precautions apply
whenever you operate a piece of exercise equipment. Be sure to read the entire manual
before you assemble or operate your machine. In particular, note the following safety
precautions:
1. Keep children and pets away from the machine at all times. DO NOT
leave children unattended in the same room with the machine.
2. Only one person at a time should use the machine.
3. If the user experiences dizziness, nausea, chest pain, or any other abnormal
symptoms, STOP the workout at once. CONSULT A PHYSICIAN IMMEDIATELY.
4. Position the machine on a clear, leveled surface. DO NOT use the machine
near water or outdoors.
5. Keep hands away from all moving parts.
6. Always wear appropriate workout clothing when exercising. DO NOT wear
robes or other clothing that could become caught in the machine. Running
or aerobic shoes are also required when using the machine.
7. Use the machine only for its intended use as described in this manual. DO
NOT use attachments not recommended by the manufacturer.
8. Do not place any sharp object around the machine.
9. Disabled person should not use the machine without a qualified person or
physician in attendance.
10. Before using the machine to exercise, always do stretching exercises to
properly warm up.
11. Never operate the machine if the machine is not functioning properly.
12. A spotter is recommended during exercise.
CARE AND MAINTENANCE
1. Inspect and tighten all parts before using the machine.
2. The machine can be cleaned using a damp cloth and mild non-abrasive detergent.
DO NOT use solvents.
3. Maximum weight capacity on the uprights: 200 lbs.
4. Maximum user’s weight: 250 lbs.
5. Maximum weight capacity on the leg developer: 100 lbs.
WARNING: BEFORE BEGINNING ANY EXERCISE PROGRAM, CONSULT YOUR
PHYSICIAN. THIS IS ESPECIALLY IMPORTANT FOR INDIVIDUALS OVER THE
AGE OF 35 OR PERSONS WITH PRE-EXISTING HEALTH PROBLEMS. READ
ALL INSTRUCTIONS BEFORE USING ANY FITNESS EQUIPMENT. IMPEX INC.
ASSUMES NO RESPONSIBILITY FOR PERSONAL INJURY OR PROPERTY
DAMAGE SUSTAINED BY OR THROUGH THE USE OF THIS PRODUCT.
SAVE THESE INSTRUCTIONS.
2

WRANING LABEL REPLACEMENT
The warning label shown here have been placed on the Cross Brace. If the label is missing or illegible,
please call customer service at 1-800-888-8899 for replacements. Apply the label in the location shown.
3

Hardware Pack
NOTE: The following parts are not drawn to scale. Please use your own ruler or scale to measure the size.
4

ASSEMBLY INSTRUCTION
Tools Required Assembling the Machine: Two Adjustable Wrenches.
NOTE: It is strongly recommended two or more people assembling this machine to
avoid possible injury.
STEP 1 (See Diagram 1)
A.) Connect the two Upright Beams (#1) by a Cross Brace (#2) in the mid-span.
B.) Secure each end of Cross Brace to each Upright Beam with two M10 x 2 ½” Hex Bolts
(#20), one Bracket (#12), two Ø ¾” Washers (#30), and two M10 Aircraft Nuts (#32).
C.) Insert the Backrest Adjustment Bar (#10) through the selected holes on the Upright
Beams to obtain desired incline position. DIAGRAM 1
5

STEP 2 (See Diagram 2)
A.) Attach the Front Support (#5) to the Main Seat Support (#3). Secure it with one M8 x 1
5/8” Carriage Bolt (#22), Ø 5/8” Washer (#29), and M8 Aircraft Nut (#31). Do not tighten
the Nut and Bolt yet.
B.) Attach the other end of Main Seat Support to the Cross Brace (#2). Secure it with two
M10 x 2 1/8” Hex Bolts (#21), one Bracket (#12), two Ø ¾” Washers (#30), and two
M10 Aircraft Nuts (#32).
C.)Attach the Diagonal Support (#4) to the Main Seat Support. Secure it with one M8 x 1
¾” Carriage Bolt (#23), Ø 5/8” Washer (#29), and M8 Aircraft Nut (#31).
D.)Attach the other end of Diagonal Support to the Front Support. Secure it with one M8 x
2 1/8” Hex Bolt (#27), Ø 5/8” Washer (#29), and M8 Aircraft Nut (#31).
E.) Securely tighten all Nuts and Bolts. DIAGRAM 2
6

STEP 3 (See Diagram 3)
A.) Attach the side-holes on the two Backrest Supports (#7) to the pivot on the Main
Seat Support (#3). Place the other end of the Backrest Supports rest against the
Backrest Adjustment Bar (#10).
B.) Attach the Backrest Board (#9) to the Backrest Supports (#7). Secure it with four M6
x 1 3/8” Hex Bolts (#25) and Ø ½” Washers (#28).
C.)Place the Seat Pad (#8) onto the Main Seat Support. Secure it with four M6 x 5/8”
Hex Bolts (#26) and Ø ½” Washers (#28).
DIAGRAM 3
7

STEP 4 (See Diagram 4)
A.) Attach the Leg Developer (#6) to the open bracket on the Front Support (#5).
Secure it with one M10 x 2 3/8” Hex Bolt (#24), Ø ¾” Washer (#30), and M10
Aircraft Nut (#32).
B.) Insert two Foam Tubes (#11) half way through the holes on the Leg Developer.
C.)Push four Foam Rolls (#14) onto the Foam Tubes.
DIAGRAM 4
8

9

PARTS LIST
KEY NO. DESCRIPTION Q’ty
1 Upright Beam 2
2 Cross Brace 1
3 Main Seat Support 1
4 Diagonal Support 1
5 Front Support 1
6 Leg Developer 1
7 Backrest Support 2
8 Seat Pad 1
9 Backrest Board 1
10 Backrest Adjustment Bar 1
11 Foam Tube 2
12 Bracket 3
13 Ø ¾” End Cap 4
14 Foam Roll 4
15 1 ½” Square End Cap 3
16 Ø 1” End Cap 3
17 Rubber Bumper 1
18 Spring Clip 1
19 ¾” Square End Cap 2
20 M10 x 2 ½” Hex Bolt 4
21 M10 x 2 1/8” Hex Bolt 2
22 M8 x 1 5/8” Carriage Bolt 1
23 M8 x 1 ¾” Carriage Bolt 1
24 M10 x 2 3/8” Hex Bolt 1
25 M6 x 1 3/8” Hex Bolt 4
26 M6 x 5/8” Hex Bolt 4
27 M8 x 2 1/8” Hex Bolt 1
28 Ø ½” Washer 8
29 Ø 5/8” Washer 3
30 Ø ¾” Washer 7
31 M8 Aircraft Nut 3
32 M10 Aircraft Nut 7
10

IMPEX®INC.
LIMITED WARRANTY
IMPEX Inc. ("IMPEX®") warrants this product to be free from defects in workmanship and material, under
normal use and service conditions, for a period of two years on the Frame from the date of purchase. This
warranty extends only to the original purchaser. IMPEX's obligation under this Warranty is limited to replacing
or repairing, at IMPEX's option.
All returns must be pre-authorized by IMPEX. Pre-authorization may be obtained by calling IMPEX Customer
Service Department at 1-800-999-8899. All freights on products returned to IMPEX must be prepaid by the
customer. This warranty does not extend to any product or damage to a product caused by or attributable to
freight damage, abuse, misuse, improper or abnormal usage or repairs not provided by an IMPEX authorized
service center or for products used for commercial or rental purposes. No other warranty beyond that
specifically set forth above is authorized by IMPEX.
IMPEX is not responsible or liable for indirect, special or consequential damages arising out of or in
connection with the use or performance of the product or other damages with respect to any economic loss,
loss of property, loss of revenues or profits, loss of enjoyments or use, costs of removal, installation or other
consequential damages or whatsoever natures. Some states do not allow the exclusion or limitation of
incidental or consequential damages. Accordingly, the above limitation may not apply to you.
The warranty extended hereunder is in lieu of any and all other warranties and any implied warranties of
merchantability or fitness for a particular purpose is limited in its scope and duration to the terms set forth
herein. Some states do not allow limitations on how long an implied warranty lasts. Accordingly, the above
limitation may not apply to you.
This warranty gives you specific legal right. You may also have other rights which vary from state to state.
Register on-line at www.impex-fitness.com
IMPEX®INC.
14777 Don Julian
City of Industry, CA 91746
ORDERING REPLACEMENT PARTS
Replacement parts can be ordered by calling our Customer Service Department toll-free at 1-800-999-8899
during our regular business hours: Monday through Friday, 9 am until 5 pm Pacific standard time.
[e-mail]
When ordering replacement parts, always give the following information.
1. Model
2. Description of Parts
3. Part Number
4. Date of Purchase
11
