Impex SA GEAR SAG-71 User manual

NOTE:
Please read all instructions
carefully before using this
product
Table of Contents
Safety Notice
Hardware Pack
Assembly Instruction
Parts List
Warranty
Ordering Parts
Model
SAG-71
Retain This
Manual for
Reference
100816
OWNER'S
MANUAL
Deluxe Power Tower
SAG-71
IMPEX®INC.
2801 S. Towne Ave., Pomona, CA 91766
Tel: [phone] Fax: [phone]
www.impex-fitness.com
[email protected]

TABLE OF CONTENTS
BEFORE YOU BEGIN...................................................................................…. 1
IMPORTANT SAFETY NOTICES..................................................................…. 2
HARDWARE IDENTIFIER.....…....................................................................…. 4
ASSEMBLY INSTRUCTIONS........................................................................…. 6
EXPLODED DIAGRAM………………………………………………………………. 11
PARTS LIST...............................................................................................……. 12
WARRANTY.................................................................................................…. 13
ORDERING PARTS.......................................................................................… 13
BEFORE YOU BEGIN
Thank you for selecting the SA GEAR SAG-71 Power Tower by IMPEX®
INC. For your safety and benefit, read this manual carefully before using the
machine. As the manufacturer, we are committed to provide you complete
customer satisfaction. If you have any questions, or find there are missing
or damaged parts, we guarantee you complete satisfaction through direct
assistance from our factory. To avoid unnecessary delays, please call our
TOLL-FREE customer service number. Our Customer Service Agents will
provide immediate assistance to you.
Toll-Free Customer Service Number
1-800-999-8899
Mon. - Fri. 9 a.m. - 5 p.m. PST
www.impex-fitness.com
[email protected]
1

IMPORTANT SAFETY NOTICE
PRECAUTIONS
This exercise machine is built for optimum safety. However, certain precautions apply
whenever you operate a piece of exercise equipment. Be sure to read the entire manual
before you assemble or operate your machine. In particular, note the following safety
precautions:
1. Keep children and pets away from the machine at all times. DO NOT leave
children unattended in the same room with the machine.
2. Only one person at a time should use the machine.
3. If the user experiences dizziness, nausea, chest pain, or any other abnormal
symptoms, STOP the workout at once. CONSULT A PHYSICIAN IMMEDIATELY.
4. Position the machine on a clear, leveled surface. DO NOT use the machine near water
or outdoors.
5. Keep hands and feet away from all moving parts.
6. Always wear appropriate workout clothing when exercising. DO NOT wear robes or
other clothing that could become caught in the machine. Running or aerobic shoes are
also required when using the machine.
7. Use the machine only for its intended use as described in this manual. DO NOT use
attachments not recommended by the manufacturer.
8. Do not place any sharp object around the machine.
9. Disabled person should not use the machine without a qualified person or physician in
attendance.
10. Before using the machine to exercise, always do stretching exercises to properly warm
up.
11. Never operate the machine if the machine is not functioning properly.
12. A spotter is recommended during exercise.
CARE AND MAINTENANCE
1. Lubricate moving parts with WD-40 or light oil periodically.
2. Inspect and tighten all parts before using the machine.
3. The machine can be cleaned using a damp cloth and mild non-abrasive detergent.
DO NOT use solvents.
4. Maximum user’s weight: 300 lbs.
WARNING: BEFORE BEGINNING ANY EXERCISE PROGRAM, CONSULT YOUR
PHYSICIAN. THIS IS ESPECIALLY IMPORTANT FOR INDIVIDUALS OVER THE AGE
OF 35 OR PERSONS WITH PRE-EXISTING HEALTH PROBLEMS. READ ALL
INSTRUCTIONS BEFORE USING ANY FITNESS EQUIPMENT. IMPEX INC. ASSUMES
NO RESPONSIBILITY FOR PERSONAL INJURY OR PROPERTY DAMAGE
SUSTAINED BY OR THROUGH THE USE OF THIS PRODUCT.
SAVE THESE INSTRUCTIONS.
2

WARNING LABEL PLACEMENT
The Warning Label shown here has been placed on the Rear Base Frame. If the label is missing or illegible,
please call customer service at 1-800-999-8899 for replacement. Apply the label in location shown.
3

HARDWARE IDENTIFIER
NOTE: The following parts are not drawn to scale. Please use your own ruler to measure the size.
4

HARDWARE IDENTIFIER
NOTE: The following parts are not drawn to scale. Please use your own ruler to measure the size.
5

ASSEMBLY INSTRUCTION
Tools Required for Assembling the Machine: Two Adjustable Wrenches and Allen
Wrenches.
NOTE: It is strongly recommended that two or more people assemble this machine
to avoid possible injury.
STEP 1 (See Diagram 1)
A.) Do not tighten Nuts and Bolts until instructed to do so.
B.) Attach one Base Frame (#1) to the Rear Base Frame (#10). Secure it with one M10 x
3 1/8” Carriage Bolt (#24), one Ø ¾” Washer (#34), and one M10 Aircraft Nut (#32)
from bottom. Secure it with one M10 x 5/8” Hex Bolt (#30) and one Ø ¾” Washer
(#34) from side.
C.)Attach the Left Rear Support (#8) to the left end of Rear Base Frame. Secure it with
one M10 x 2” Hex Bolt (#27) and one Ø ¾” Washer (#34).
D.)Repeat B & C to install the other Base Frame and the Right Rear Support (#9) to the
Rear Base Frame. DIAGRAM 1
6

STEP 2 (See Diagram 2)
A.) Do not tighten Nuts and Bolts until instructed to do so.
B.) Attach the Left Upright Beam (#2) onto the left Base Frame (#1). Secure it with two
M10 x 3” Hex Bolts (#29), four Ø ¾” Washers (#34), and two M10 Aircraft Nuts (#32).
C.)Attach the bracket on Left Upright Beam to Left Rear Support (#8). Secure it with one
M10 x 2 3/8” Hex Bolt (#28), two Ø ¾” Washers (#34), and one M10 Aircraft Nut (#32).
D.)Repeat B & C to install the Right Upright Beam (#3).
E.) Securely tighten all Nuts and Bolts in Step-1 and Step-2. DIAGRAM 2
7

STEP 3 (See Diagram 3)
A.) Attach the Chin-up Bar (#7) to the two Upper Uprights (#11). Secure them together
with two M10 x 1 5/8” Hex Bolts (#22) and two Ø ¾” Washers (#34).
B.) Cover the Hex Bolts with two Chin-up Covers (#15).
DIAGRAM 3
8

STEP 4 (See Diagram 4)
A.) Attach the two Upper Uprights (#11) onto Left & Right Upright Beam (#2 & #3).
B.) Attach the Left Arm Support (#4) to the left Upper Upright and Left Upright Beam from front.
Attach the Backrest Support Frame (#6) to the left Upper Upright and Left Upright Beam
from Rear.
C.)Secure Backrest Support Frame, the left Upper Upright, Left Upright Beam, and Left Arm
Support together with four M10 x 3 1/8” Hex Bolts (#23), eight Ø ¾” Washers (#34), and
four M10 Aircraft Nuts (#32).
D.)Repeat B &C to install the Right Arm Support (#5).
DIAGRAM 4
9

STEP 5 (See Diagram 5)
A.) Attach the Backrest Board (#13) to the Backrest Support Frame (#6). Secure it
with two M8 x 5/8” Allen Bolts (#25) and two Ø 5/8” Washers (#35).
B.) Attach two Arm Pads (#14) to Left & Right Arm Support (#4 & #5). Secure each
Arm Pad with two M8 x 2 ½” Allen Bolts (#26) and two Ø 5/8” Washers (#35).
C.)Attach four Upright Base Covers (#18) to the base of Left & Right Upright Beam
(#2 & #3). Secure each Cover with one ST3.5 Self Taping Screw (#21).
D.)Use twenty-six Bolt Cover Caps (#20) to cover all Bolts installed.
DIAGRAM 5
10

EXPLODED DIAGRAM
11

PARTS LIST
KEY NO. DESCRIPTION QUANTITY
1 Base Frame 2
2 Left Upright Beam 1
3 Right Upright Beam 1
4 Left Arm Support 1
5 Right Arm Support 1
6 Backrest Support Frame 1
7 Chin-up Bar 1
8 Left Rear Support 1
9 Right Rear Support 1
10 Rear Base Frame 1
11 Upper Upright 2
12 Dip Handle 2
13 Backrest Board 1
14 Arm Pad 2
15 Chin-up Cover 2
16 2 ½” Handle Grip 10
17 Base Frame End Cap 2
18 Upright Base Cover 4
19 Sleeve 2
20 Bolt Cover Cap 26
21 ST3.5 Self Taping Screw 4
22 M10 x 1 5/8” Hex Bolt 2
23 M10 x 3 1/8” Hex Bolt 8
24 M10 x 3 1/8” Carriage Bolt 2
25 M8 x 5/8” Allen Bolt 2
26 M8 x 2 ½” Allen Bolt 4
27 M10 x 2” Hex Bolt 2
28 M10 x 2 3/8” Hex Bolt 2
29 M10 x 3” Hex Bolt 4
30 M10 x 5/8” Hex Bolt 2
31 M6 x 1 5/8” Hex Bolt 2
32 M10 Aircraft Nut 16
33 M6 Aircraft Nut 2
34 Ø ¾” Washer 36
35 Ø 5/8” Washer 6
36 Ø ½” Washer 4
5# Allen Wrench (Tool) 1
12

IMPEX®INC.
LIMITED WARRANTY
IMPEX Inc. ("IMPEX®") warrants this product to be free from defects in workmanship and material,
under normal use and service conditions, for a period of two years on the Frame from the date of
purchase. This warranty extends only to the original purchaser. IMPEX's obligation under this
Warranty is limited to replacing or repairing, at IMPEX's option.
All returns must be pre-authorized by IMPEX. Pre-authorization may be obtained by calling IMPEX
Customer Service Department at 1-800-999-8899. All freights for products return to IMPEX must be
prepaid by the customer. This warranty does not extend to any product or damage to a product caused
by or attributable to freight damage, abuse, misuse, improper or abnormal usage or repairs not provided
by an IMPEX authorized service center or for products used for commercial or rental purposes. No
other warranty beyond that specifically set forth above is authorized by IMPEX.
IMPEX is not responsible or liable for indirect, special or consequential damages arising out of or in
connection with the use or performance of the product or other damages with respect to any economic
loss, loss of property, loss of revenues or profits, loss of enjoyments or use, costs of removal, installation
or other consequential damages or whatsoever natures. Some states do not allow the exclusion or
limitation of incidental or consequential damages. Accordingly, the above limitation may not apply to
you.
The warranty extended hereunder is in lieu of any and all other warranties and any implied warranties of
merchantability or fitness for a particular purpose is limited in its scope and duration to the terms set
forth herein. Some states do not allow limitations on how long an implied warranty lasts. Accordingly,
the above limitation may not apply to you.
This warranty gives you specific legal right. You may also have other rights which vary from state to
state. Register on-line www.impex-fitness.com
IMPEX®INC.
2801 S. Towne Ave.
Pomona, CA 91766
ORDERING REPLACEMENT PARTS
Replacement parts can be ordered by calling our Customer Service Department toll-free at 1-800-999-
8899 during our regular business hours: Monday through Friday, 9 am until 5 pm Pacific standard time.
[email protected]
When ordering replacement parts, always give the following information.
1. Model
2. Description of Parts
3. Part Number
4. Date of Purchase
