impro IMPROX SUPAGATE SGI911-1-1-GB-XX User manual

MODEL NUMBER: SGI911-1-1-GB-XX
IMPROXSUPAGATE
ImproX SupaGate 4-Channel Controller
INSTALLATION MANUAL
SPECIFICATIONS
Working Environment .................
The SupaGate is designed to work in an
indoor or protected outdoor environment
similar to IP20. The SupaGate is, therefore,
NOT sealed against water.
Passive Frequency......................
125 kHz.
RF Frequency...............................
433.92 MHz.
Security ........................................
ImproX DCT, Dynamic Code Transmission
Technology.
Input Voltage................................
10 V DC to 14 V DC.
Power Requirements
Current (mA)
Power (W)
Input Voltage 12 V DC,
1 Antenna Reader, all
Relays OFF............................
60
0.72
Input Voltage 12 V DC,
1 Antenna Reader, all
Relays ON..............................
220
2.64
Relays
Relay Output..........................
4 Relays, each with NO, COM and NC
contacts.
Relay Contact Ratings ...........
10 A at 28 V DC,
5 A at 220 V AC.
Installer Interfaces
LED Indicators
7-Segment Display.........
2 Displays, Red (externally visible).
Push-buttons..........................
4 Push-buttons (externally accessible).

SGI300-0-0-GB-08
April 2008
Page 2
INSTALLATION INFORMATION
Accessories
Find the following when unpacking the SupaGate Controller:
A SupaGate housed in a Black tinted, Polycarbonate Plastic Cabinet. The
SupaGate consists of a 2-piece Top Cover and a Base.
CAUTION: DO NOT use the Metal-oxide Varistors (25 Vrms, 500 A, 77 V max
clamping) with mains power applications.
Four Metal-Oxide Varistors, 25 Vrms, 500 A, 77 V max clamping.
Four Black tinted, Polycarbonate Plastic Standoffs.
Two Brass Wood Screws (3.50 mm x 25 mm).
Two Wall Plugs (7 mm).
An extra Serial Number Label.
General
Remember the following when installing the SupaGate:
Read Range
CAUTION: The SupaGate is susceptible to excessive RF interference, reducing
the range. Always site test the SupaGate, prior to installation, in its
installation location for optimum RF read range.
The SupaGate has a tested RF read range of between 10 m to 30 m
(11 yd to 33 yd) when used with the ImproX QT (XQT904-1-1-GB-XX).
The passive read range varies from between 25 mm to 76 mm (1 in to 3 in)
depending on the Antenna Reader and Tag used.
Antenna Reader Distance
The ideal cable distance between the SupaGate and its Antenna Reader ranges
between 2 m to 16 m (7 ft to 53 ft). Achieve this by using good quality screened,
twisted pair cable.
Distance between Antenna Readers from DIFFERENT SupaGates
To avoid mutual interference, install the Antenna Readers alongside each other at least
500 mm (20 in) apart.
Default Relay Selection
For passive Tags presented to Antenna Reader 1, Relay 1 is automatically
selected.
When using the Normal (4-Digit) PIN-code, if you enter the PIN-code on Antenna
Reader 1, Relay 1 is automatically selected.
Buttons 1 to 4 on the ImproX (QT) Quad Transmitter activate Relays 1 to 4 on the
SupaGate Controller. If only Buttons 1 and 2 are pressed during the “Add RF
Tags” procedure then only those Buttons will activate the relevant Relays. Buttons
3 and 4 will have no action. Any combination is available. See Figure 1 for Button
locations.

SGI300-0-0-GB-08
April 2008
Page 3
Figure 1: Button Configuration for ImproX (QT) Quad Transmitter
Programmed in “Dynamic Code Transmission Mode”
The ImproX (QT) Quad Transmitter has its own passive Tag, separate from the
transmitted codes. Presenting the ImproX (QT) Quad Transmitter passive Tag to
Antenna Reader 1 drives Relay 1.
Relay 1
Relay 2
Relay 3
Relay 4
Quad Transmitter
Button 1
Button 2
Button 3
Button 4
Passive Tag
Antenna
Reader 1
-
-
-
4-Digit PIN-code
Antenna
Reader 1
-
-
-
5-Digit PIN-code
(Antenna Reader 1)
PIN XXXX1
PIN XXXX2
PIN XXXX3
PIN XXXX4
Request to Exit
(RTE) Input
RTE Door 1
RTE Door 2
-
-
Table 1: Relay Allocation Summary
Arc Suppression
Snubber devices are recommended for EMF Flyback and Arc Suppression when
driving an inductive load with the Relay, see Figure 2.
Figure 2: EMF Flyback and Arc Suppression

SGI300-0-0-GB-08
April 2008
Page 4
MOUNTING THE SUPAGATE
CAUTION: DO NOT mount the Controller on or close to a metal surface.
CAUTION: Mount the SupaGate in a suitable indoor location, or protected
outdoor location. Mounting the SupaGate in a location unprotected
against rain will damage the SupaGate Controller.
CAUTION: Make certain that you mount the Controller on a vibration-free
surface.
NOTE: If you intend mounting the SupaGate on a damp wall, use the supplied
standoffs to position the SupaGate away from the wall.
NOTE: Test the SupaGate, in the proposed installation location before mounting in
position, ensuring the read range meets your needs.
For best performance, position the Controller for clear line-of-sight in the direction of the
movement. The antenna should be in the vertical plane.
In Figure 3, a Tag moving along Motion 1 will be in line-of-sight of the antenna
throughout the 10 m distance from first detection to the Controller. However, a Tag
moving along Motion 02 will move out of line-of-sight of the antenna once it reaches
Point A in Figure 3.
Figure 3: Line of Sight Communication

SGI300-0-0-GB-08
April 2008
Page 5
1. After removing the SupaGate from its packaging, straighten the flexible Antenna,
this ensures an improved RF read range.
2. Position the SupaGate in clear line-of-sight, preferably 1.50 m to 2 m (5 ft to 6 ft)
above the ground, in the direction of movement, with the Antenna vertical.
3. Secure the Cabinet to the mounting surface, using two suitable screws and wall
plugs (supplied) nuts and bolts or rivets.
CONNECTING THE SUPAGATE
Figure 4 shows the layout of the SupaGate.
Figure 4: SupaGate Layout

SGI300-0-0-GB-08
April 2008
Page 6
Figure 5 shows a typical connection diagram for the SupaGate.
Figure 5: Typical SupaGate Electrical Connections

SGI300-0-0-GB-08
April 2008
Page 7
USER INFORMATION
Mode and Action
7-Segment Display LED
Displays
Display
Duration
POWER-UP
2 seconds
then enters
Run Mode
RUN MODE
Reading Tags
Rotates in
a circular
manner
Unknown Tag
2 seconds
Tag Found
Displays the Tag
Memory Location
(01-99)
2 seconds
PROGRAMMING MODE
Adding Passive Tags
1. In Run Mode press the “ADD” Push-
button for less than 1 second.
2. Press the “TENS” and “UNITS” Push-
buttons until the desired Tag Location is
shown.
3. Present the Passive Tag to the Antenna
Reader.
4. Press “ADD” to return to Run Mode.
NOTES:
Each new Tag Code received will display
the Location at which it is being added.
If the Tag already exists, it will be deleted
and re-added in the same location.
1 second
Displays the first free
Location (01-99)
2 seconds
Displays the Passive
Tag (Card) number as
follows:
Blank Space

SGI300-0-0-GB-08
April 2008
Page 8
Mode and Action
7-Segment Display LED
Displays
Display
Duration
Adding RF Tags
1. In Run Mode press the “ADD” Push-
button for less than 1 second.
2. Press the “TENS” and “UNITS” Push-
buttons until the desired Tag Location is
shown.
3. Press only the Buttons on the ImproX
(QT) Quad Transmitter that are required
to be allowed.
4. Press “ADD” to return to Run Mode.
NOTES:
Each new Tag Code received will display
the Location at which it is being added.
If the Tag already exists, it will be
deleted and re-added in the same
location.
1 second
Displays the first free
Location (01-99)
2 seconds
Displays the Button
Number as follows:
Adding Normal (4-Digit) PIN-codes
1. In Run Mode press the “ADD” Push-
button for less than 1 second.
2. Press the “TENS” and “UNITS” Push-
buttons until the desired Tag Location is
shown.
3. Enter your 4-digit PIN-code on the
Keypad Antenna Reader, followed by the
“#”Key on the Keypad Antenna Reader.
4. Press “ADD” to return to Run Mode.
NOTE: Ensure you enter the complete 4-
digit code, followed by the “#”Key to
gain entry.
1 second
Displays the first free
Location (01-99)
2 seconds
Displays the PIN-code
as follows:
Blank Space

SGI300-0-0-GB-08
April 2008
Page 9
Mode and Action
7-Segment Display LED
Displays
Display
Duration
Adding Special (5-Digit) PIN-codes
The PIN-code entered activates only the
Relay specified as the 5th digit of the PIN-
code.
1. In Run Mode press the “ADD” Push-
button for less than 1 second.
2. Press the “TENS” and “UNITS” Push-
buttons until the desired Tag Location is
shown.
3. Enter your 4-digit PIN-code on the
Keypad Antenna Reader, followed by a
1-digit reference to the Relay you want to
activate. Press the “#”Key on the
Keypad Antenna Reader to complete the
entry.
4. Press “ADD” to return to Run Mode.
NOTE: Ensure you enter the complete
5-digit code, followed by the “#”Key
to gain entry.
1 second
Displays the first free
Location (01-99)
2 seconds
Displays the PIN-code
as follows:
Deleting Tags or PIN-codes
1. In Run Mode press the “DELETE” Push-
button.
2. Press the “TENS” and “UNITS” Push-
buttons until the desired Tag Location is
shown.
3. Press “DELETE” to delete the desired
Location.
4. Specify more Locations to be deleted, or
press “DELETE” to return to Run Mode.
1 second
2 seconds
Bulk Delete
1. Power down the SupaGate.
2. Power up the SupaGate while
simultaneously pressing the “ADD” and
“DELETE” Push-buttons.
3. “??” is displayed, after 2 seconds all is
deleted and “dE” is displayed.

SGI300-0-0-GB-08
April 2008
Page 10
Mode and Action
7-Segment Display LED
Displays
Display
Duration
Replacing Lost Tags
1. Delete the lost Tag from its Tag
Location. (See the “Deleting Tags”
section).
2. Add the new Tag to the abovementioned
Tag Location. (See the relevant “Adding
Tags” section).
Displays the first free
Location
(01-99)
2 seconds
Displays selected Tag
Memory Location
Set Relay Durations
1. In Run Mode press the “ADD” Push-
button for longer than 1 second.
2. Press the “TENS” and “UNITS” Push-
buttons to specify the duration of Relay 1
in seconds (00 = Toggled Mode).
NOTE: The factory default setting is 01.
1 second
Displays the Relay
Drive Time in seconds
(01–99 seconds)
1. Press the “ADD” Push-button for less
than 1 second.
2. Press the “TENS” and “UNITS” Push-
buttons to specify the duration of Relay 2
in seconds (00 = Toggled Mode).
NOTE: The factory default setting is 01.
1 second
Displays the Relay
Drive Time in seconds
(01–99 seconds)
1. Press the “ADD” Push-button for less
than 1 second.
2. Press the “TENS” and “UNITS” Push-
buttons to specify the duration of Relay 3
in seconds (00 = Toggled Mode).
NOTE: The factory default setting is 01.
1 second
Displays the Relay
Drive Time in seconds
(01–99 seconds)
1. Press the “ADD” Push-button for less
than 1 second.
2. Press the “TENS” and “UNITS” Push-
buttons to specify the duration of Relay 4
in seconds (00 = Toggled Mode).
NOTE: The factory default setting is 01.
1 second
Displays the Relay
Drive Time in seconds
(01–99 seconds)
3. Press “ADD” for less than 1 second to go
back to Run Mode.

SGI300-0-0-GB-08
April 2008
Page 11
COMPLICATED CONCEPTS
If the Tag + PIN-code function is required, then register a Tag at Antenna Reader
1 and a 5-digit PIN-code specifying Relay 2. Relays 1 and 2 can then be wired in
series. Appropriate Relay durations need to be chosen.
If the incorrect PIN-code is entered 3 times in succession, the Keypad locks for 20
seconds. During this period the RF System remains operational.
If you select Button 1 on the ImproX (QT) Quad Transmitter to activate Relay 1,
presenting the ImproX (QT) Quad Transmitters passive Tag to Antenna Reader 1
automatically activates Relay 1. This will only utilize 1 of your 99 Locations.
Blank Space

SGI300-0-0-GB-08
April 2008
Page 12
TAG LOCATIONS
Document all Tag owners at their respective Tag Memory Locations (in the SupaGate)
using Table 2. This list provides an easy reference when you need to delete Tags from
the SupaGate.
Owner
Relay or PIN-code
Owner
Relay or PIN-code
1
2
3
4
5/R
1
2
3
4
5/R
01
27
02
28
03
29
04
30
05
31
06
32
07
33
08
34
09
35
10
36
11
37
12
38
13
39
14
40
15
41
16
42
17
43
18
44
19
45
20
46
21
47
22
48
23
49
24
50
25
51
26
52

SGI300-0-0-GB-08
April 2008
Page 13
Owner
Relay or PIN-code
Owner
Relay or PIN-code
1
2
3
4
5/R
1
2
3
4
5/R
53
77
54
78
55
79
56
80
57
81
58
82
59
83
60
84
61
85
62
86
63
87
64
88
65
89
66
90
67
91
68
92
69
93
70
94
71
95
72
96
73
97
74
98
75
99
76
Table 2: Tag Location Table
Blank Space

SGI300-0-0-GB-08
April 2008
Page 14
GUARANTEE OR WARRANTY
CAUTION: We reserve the right to nullify the products guarantee or warranty
where you have not properly installed the Metal-oxide Varistors.
This product conforms to our Guarantee or Warranty details placed on our Web Site to
read further please go to www.impro.net.
USER NOTES

SGI300-0-0-GB-08
April 2008
Page 15
USER NOTES

SGI300-0-0-GB-08
April 2008
Page 16
This manual is applicable to the ImproX SupaGate 4-Channel Controller,
SGI911-1-1-GB-01.
(The last two digits of the stock code indicate the issue status of the product).
SGI300-0-0-GB-08
Issue 09
Apr 2008
ImproX SupaGate\English Manuals\LATEST
ISSUE\XSupGate-insm-en-09.docx
