Impulse Ru500 User manual

RU500

12P

UPRIGHT BIKE

Table Of Contents

Read all precautions and instructions in this manual before using this

equipment.

! CAUTION

Important Safety information -------------------------------------------------------------------- 3

Warm Up Exercises ---------------------------------------------------------------------------------- 4

Parts List ----------------------------------------------------------------------------------------------- 5

Exploded View --------------------------------------------------------------------------------------- 7

Usage And Maintenance -------------------------------------------------------------------------- 9

Console Panel Functions ------------------------------------------------------------------------- 10

Troubleshooting Guide -------------------------------------------------------------------------- 15

─ 3 ─

Important Safety Instructions

Warning

The safety of the product can be maintained only if it is examined regularly for

damage and wear. See preventive maintenance section for details.

1. Keep the area around the product clear of any obstructions, including

walls and furniture. Provide at least three feet of clearance behind

the unit.

2. Do not use the product outdoors, near swimming pools, or in areas of

high humidity.

3. Do not allow other people to interfere in any way with the user or

equipment during workout.

4. Supervise closely any children or disabled persons using the product.

Save these instructions for future reference

1. Always follow the console instructions for proper operation.

2. Do not reach into, or underneath, the unit; and do not tip the unit on its

side during operation.

3. Never insert objects into any opening of the Bike. If any object fall into

this equipment, carefully retrieve it while the unit is not in use. If the

object can't be reached, please contact customer services.

4. Never place any containers filled with liquids on the unit, except in

the accessory tray or water bottle holder. Containers should be covered

with lids.

5. Wear shoes with rubber or high-traction soles. Do not wear shoes with

high heels, leather shoes, slippers, or spikes. Make sure no sharp stuff is

embedded in the soles.

6. Do not use the bike with bare feet.

7. Keep all loose clothing, shoelaces, and towels away from moving parts.

8. Take extra caution when stepping on or off the bike.

9. Never face backward while using the bike.

Location

Operation

─ 4 ─

War m Up Exercises

EXERCISE GUIDELINES

WARNING! Before beginning this or any exercise program, you should consult your

physician. This is especially important for individuals over the age of 35 or individuals

with pre-existing health problems.

Warming up prepares the body for the exercise by increasing circulation, supplying more

oxygen to the muscles and raising body temperature. Begin each workout with 5 to 10

minutes of stretching and light exercise to warm up. The photos on this page show

several forms of basic stretching you may perform before your workouts. In order to

achieve an adequate warm-up, perform each stretch three times.

TOE TOUCH STRETCH

Stand, bending your knees slightly and slowly bend forward

from your hips. Allow your back and shoulders to relax as you

reach down toward your toes as far as possible. Hold for 15

counts, then relax. This will stretch your hamstrings, back of

knees, and back.

HAMSTRING STRETCH

Sit with one leg extended. Bring the sole of the opposite foot

toward you and rest it against the inner thigh of your

extended leg. Reach toward your toes as far as possible. Hold

for 15 counts, then relax. This will stretch your hamstrings,

lower back, and groin.

CALF/ACHILLES STRETCH

With one leg in front of the other, reach forward and place

your hands against a wall. Keep your back leg straight and

your back foot flat on the floor. Bend your front leg, lean

forward and move your hips toward the wall. Hold for 15

counts, then relax. To cause further stretching of the Achilles

tendon, bend your back leg as well. This will stretch your

calves, Achilles tendons, and ankles.

QUADRICEPS STRETCH

With one hand against a wall for balance, reach back and

grasp one foot with your other hand. Bring your heel as close

to your buttocks as possible. Hold for 15 counts, then relax.

This will stretch your quadriceps and hip muscles.

INNER THIGH STRETCH

Sit with the soles of your feet together and your knees

outward. Pull your feet toward your groin area as far as

possible. Hold for 15 counts, then relax. This will stretch your

quadriceps and hip muscles.

─ 5 ─

Par ts List

Item No. Description QTY Item No. Description QTY

1 Main Frame 1 23 Lock Nut 2

2 Upright Frame 1 24 Screw 13

3 Front Base 1 25 Hex Nut 1

4 Rear Base 1 27 Leveler Foot 4

5 Seat Post 1 28 Bearing 2

6 Handlebar 1 29 Shaft 1

7 Console Bracket 1 30 Ring-Shield 2

8 Front Base Cover 1 31 Belt Pulley 1

9 Rear Base Cover 1 32 Socket Head Shoulder Screw 6

10 Left Cover 1 33 Lock Nut 4

11 Right Cover 1 34 Left Crank 1

12 Top Cover 1 35 Right Crank 1

13 Crank Ring 2 36 Hexagon Bolt with Flange 2

14 Water Bottle Holder 1 37 Plug For Crank 2

15 Cup Holder Bracket 1 38 Left Pedal 1

16 Tightening Nut 1 39 Right Pedal 1

17 Plastic Sleeve 1 40 Bearing 2

18 Seat 1 41 Ring-Shield 1

19 Pull-Pin 1 42 Poly-V Belt 1

20 PU Wheel 2 43 Tightener 1

21 Button Head Screw 2 44 Hex Nut 1

22 Washer 14 45 Washer 5

─ 6 ─

Par ts List

Item No. Description QTY Item No. Description QTY

46 Tension Spring 1 E3 Display Cabinet 1

47 Hex Head Bolt 1 E4 Circuit Board Frame 1

49 Screw 12 E5 Support Pillar 4

50 Hex Head Bolt 8 E6 Screw 4

51 U Nut 8 E7 Screw 11

52 Hex Nut 5 E8 Front Scarf 1

54 Bearing End Cover 2 E9 Rear Scarf 1

56 Spacer 1 E13 Hex Head Bolt 5

57 Screw 8 E14 Assy,Hand Pulse 2

58 Washer 8 E17 PCB 1

61 Spring Washer 8 E18 Hand Pulse Circuitry Board 1

62 Spring Washer 8 E19 Hand Pulse Cable To Console 1

63 Spring Washer 4 E20 Upper Harness 1

64 Screw 10 E21 Hand Pulse Cable 2

65 Washer 2 E22 Wireless Receiver 1

66 Socket Head Shoulder Screw 2 E24 SBM 1

67 Socket Head Shoulder Screw 7 E25 Magnet Cord 3

73 Ring-Shield 1 E26 Console Overlay 1

75 Screw 6 E30 Consollor PCB 1

76 Cover 1 E31 Hybird 1

E1 Console Top Cover 1 E32 Console Cable 1

E2 Console Bottom Cover 1

─ 7 ─

Exploded View

─ 8 ─

Exploded View

─ 9 ─

Usage And Maintenance

Instruction

1. Max. User Weight is 160 Kg.

2. When moving the machine, grasp the Rear Base, you can move it by the PU Wheel.

3. When using the machine, you must ensure it stand steadily on the ground. If it

isn't steady, you must adjust the Leveler Foot.

4. You can adjust the height of the seat by the Pull-Pin.

5. When adjusting the resistance, you can also use the rapid button, the "-" is down,

the "+" is up.

Maintenance

1. Tighten the pedals every 3 months.

2. If the Bolts and Screws have the trend of losing, please lock them timely.

Leveler Foot

Contact

Heartrate

─ 10 ─

Console Panel Functions

─ 11 ─

Console Panel Functions

CONSOLE PANEL FUNCTION

1. DISTANCE WINDOW

Indicates Kilometers or Miles traveled in 0.01 increments up to 9.99 and 0.1

increments starting at 10.0 (Range 0.01---999).

2. WATT WINDOW

Indicates user's current power ( Watt).

3. CALORIE WINDOW

Indicates estimated calories burned, based on user's weight, speed, resistance,

and time.

4. HEART RATE WINDOW

Indicates user's current heart rate (BPM).

5. TIME WINDOW

Indicates elapsed time after press Start in minutes and seconds (0-99minutes,

0-59seconds).

6. RESISTANCE WINDOW

Indicates workout in degree of Resistance L1—L20 in 1 increments.

7. SPEED WINDOW

Indicates workout laps per minute on pedal.

8. DOT MATRIX

8.1 Indicates ENTER WEIGHT KGS (or Lbs) when turn on power.

8.2 Indicates message when enter value.

8.3 Indicates workout curve in Program mode.

CONSOLE BUTTONS

1. START

This button is used to start the current program.

2. STOP

This button is used to stop the current program.

3. + and -

These buttons are used to adjust the degree of Resistance of the

machine during workout.

These buttons are also used to adjust the values when setting up your workout.

4. TARGET

This button is used to cycle through to the desired programs (time countdown,

calories countdown, distance countdown mode).

─ 12 ─

Console Panel Functions

5. ENTER

This button is used to enter value of program mode.

6. MANUAL ONE TOUCH

This button is used to select workout "manual mode".

7. FAT BURN ONE TOUCH

This button is used to select workout "fat burn mode".

8. RANDOM ONE TOUCH

This button is used to select workout "random mode".

9. CARDIO ONE TOUCH

This button is used to select workout "cardio mode".

10. HEART RATE ONE TOUCH

This button is used to select workout "heart rate mode".

11. USER ONE TOUCH

This button is used to select workout "user mode".

CONSOLE OPERATION

1. QUICK START / MANUAL MODE

1.1 Start the pedal

1.2 Indicates "ENTER WEIGHT KGS" in dot matrix, "68" will flash in degree of

Resistance window. Use level of Resistance + or – button to adjust user's weight.

1.3 Press "ENTER", indicates "PRESS START OR SELECT PROGRAM" in dot matrix.

(1) If press START button through manual mode;

(2) If press FAT BURN button through fat burn mode;

(3) If press RANDOM button through random mode;

(4) If press CARDIO button through cardio mode;

(5) If press HEART RATE button through heart rate mode;

(6) If press USER button through user mode.

1.4 If press TARGET button to cycle through to time countdown, distance

countdown, calories countdown mode.

1.5 If press STOP button will be reset.

─ 13 ─

Console Panel Functions

2. PROGRAM MODE

2.1 TIME COUNTDOWN MODE

Press TARGET button to cycle through time countdown mode After enter weight.

(1) Indicates TIME COUNTDOWN in dot matrix, Time window will be flash 30:00,

Use level + or – button to adjust value;

(2) Indicates ENTER TIME in dot matrix after 5 seconds;

(3) Indicates PRESS START in dot matrix after press ENTER button.

2.2 DISTANCE COUNTDOWN MODE

Press TARGET button to cycle through distance countdown mode after enter weight.

(1) Indicates DISTANCE COUNTDOWN in dot matrix, Distance window will be flash

"0.00", Use level + or – button to adjust value;

(2) Indicates ENTER DISTANCE in dot matrix after 5 seconds;

(3) Indicates PRESS START in dot matrix after press ENTER button.

2.3 CALORIES COUNTDOWN MODE

Press TARGET button to cycle through calories countdown mode after enter weight.

(1) Indicates CALORIES COUNTDOWN in dot matrix, Distance window will be flash

"000", Use level + or – button to adjust value;

(2) Indicates ENTER CALORIES in dot matrix after 5 seconds;

(3) Indicates PRESS START in dot matrix after press ENTER button.

2.4 PROGRAM

2.4.1 FAT BURN

Press FAT BURN button

(1) Indicates FAT BURN MODE in dot matrix, Time window will flash "30:00”. Use

level + or – button to adjust value;

(2) Indicates workout curve in dot matrix after 5 seconds;

(3) Indicates ENTER TIME in dot matrix after 5 seconds;

(4) Indicates PRESS START in dot matrix after press ENTER button.

2.4.2 RANDOM

Press RANDOM button

(1) Indicates RANDOM MODE in dot matrix, Time window will flash "30:00”. Use

level + or – button to adjust value;

(2) Indicates workout curve in dot matrix after 5 seconds;

─ 14 ─

Console Panel Functions

(3) Indicates ENTER TIME in dot matrix after 5 seconds;

(4) Indicates PRESS START in dot matrix after press ENTER button.

2.4.3 CARDIO

Press CARDIO button

(1) Indicates CADIO MODE in dot matrix, Time window will flash "30:00”. Use

level + or – button to adjust value;

(2) Indicates workout curve in dot matrix after 5 seconds;

(3) Indicates ENTER TIME in dot matrix after 5 seconds;

(4) Indicates PRESS START in dot matrix after press ENTER button.

2.4.4 HEART RATE

User must wear chest belt when through HEART RATE mode

HR1: Target pulse is 65% of Max. pulse;

HR2: Target pulse is 75% of Max. pulse;

HR3: Target pulse is 85% of Max. pulse.

2.4.4.1 HR1

Press HEART RATE button to cycle through HR1, HR2, HR3

(1) Indicates HEART RATE 1 in dot matrix, Time window will flash "30:00”. Use

level + or – button to adjust value;

(2) Indicates ENTER TIME in dot matrix after 5 seconds;

(3) Indicates ENTER AGE in dot matrix after press ENTER button, Pulse window

will show target pulse;

(4) Indicates PRESS START after press ENTER button.

2.4.4.2 HR2-HR3

Press HEART RATE button to cycle through HR2, HR3, the same as HR1.

2.4.5 USER

Press USER button

(1) Indicates USER PROGRAM in dot matrix, Time window will flash "30:00”.

Use level + or – button to adjust value;

(2) Indicates workout curve after 5 seconds;

(3) Indicates ENTER TIME after 5 seconds;

(4) Indicates ENTER RESISTANCE in dot matrix after press ENTER button, Level

window will be flash;

(5) First segment will be flash, Using level + or – button to adjust value;

(6) Press ENTER through next segment;

(7) Finished 20 segments, Indicates PRESS START after press ENTER button.

─ 15 ─

Troubleshooting Guide

Malfunction Probable Cause Corrective Action

Belt transmitter electrodes are not

wet enough to pick up accurate

heart rate readings.

Wet the belt transmitter electrodes.

Belt transmitter electrodes are not

laying flat against the skin.

Ensure the belt transmitter

electrodes are laying flat against the

skin.

Belt transmitter needs cleaning. Wash the belt transmitter with mild

soap and water.

Belt transmitter is not within 3 feet

(one meter) of the heart rate

receiver.

Make sure the chest strap

transmitter is within three feet (one

meter) of the heart rate receiver.

Chest strap battery is depleted.

Contact Customer Support Services

for instructions on how to have the

chest strap replaced.
