Sunny SF-B901B User manual

BELT DRIVE PRO INDOOR
CYCLING BIKE
SF-B901B
USER MANUAL
IMPORTANT! Please retain owner’s manual for maintenance and adjustment
instructions. Your satisfaction is very important to us, PLEASE DO NOT RETURN
UNTIL YOU HAVE CONTACTED US: [email protected] or 1- 877 -
90SUNNY (877-907-8669).

1
IMPORTANT SAFETY INFORMATION
We thank you for choosing our product. To ensure your safety and health, please use
this equipment correctly. It is important to read this entire manual before assembling
and using the equipment. Safe and effective use can only be achieved if the equipment
is assembled, maintained and used properly. It is your responsibility to ensure that all
users of the equipment are informed of all warnings and precautions.
1. Before starting any exercise program, you should consult your physician to
determine if you have any medical or physical conditions that could put your health
and safety at risk, or prevent you from using the equipment properly. Your
physician’s advice is essential if you are taking medication that affects your heart
rate, blood pressure or cholesterol level.
2. Be aware of your body’s signals. Incorrect or excessive exercise can damage your
health. Stop exercising if you experience any of the following symptoms: pain,
tightness in your chest, irregular heartbeat, shortness of breath, lightheadedness,
dizziness or feelings of nausea. If you do experience any of these conditions, you
should consult your physician before continuing with your exercise program.
3. Keep children and pets away from the equipment. The equipment is designed for
adult use only.
4. Use the equipment on a solid, flat level surface with a protective cover for your floor
or carpet. To ensure safety, the equipment should have at least 2 feet (60 CM) of
free space all around it.
5. Ensure that all nuts and bolts are securely tightened before using the equipment.
The safety of the equipment can only be maintained if it is regularly examined for
damage and/or wear and tear.
6. Always use the equipment as indicated. If you find any defective components while
assembling or checking the equipment, or if you hear any unusual noises coming
from the equipment during exercise, discontinue use of the equipment immediately
and do not use until the problem has been rectified.
7. Wear suitable clothing while using the equipment. Avoid wearing loose clothing that
may become entangled in the equipment.
8. Do not place fingers or objects into the moving parts of the equipment.
9. The maximum weight capacity of this unit is 275 pounds (125 KG).
10.The equipment is not suitable for therapeutic use.
11.To avoid bodily injury and/ or damage to the product or property, proper lifting and
moving is required.
12.Your product is intended for use in cool, dry conditions. You should avoid storage in
extreme cold, hot or damp areas as this may lead to corrosion and other related
problems.
13.This equipment is designed for indoor and home use only! It is not intended for
commercial use!
WARNING: This product can expose you to one or more chemicals known to
the State of California to cause cancer and birth defects or reproductive harm.
For more information go to www.P65Warnings.ca.gov.

2
EXPLODED DIAGRAM
1
2
3
4
57
6
3
45
8
7
8
73
4
9
10
11 12 13
80R
80L
5
15 16
17
18
17
19
7
6
20
20
20
21
22
23
24
25
26
27
28
29
30
29
33
32
31
77
78
79
3
4
8
7
8
7
19 17 18
17
16
5

3
INNER EXPLODED DIAGRAM
1
7357
56
49
34
39
40
49
42 73
57
43
76
51
53
52
54
55
58
59
60
54
53
52
51
50
61
62
63
64
65
66
71
70
19
69
68
67
72
16
41
45
46
48
48
47
36
47
75
37
36
36
36
35
74
44
44
38
36
36
58
64
34

4
No.
Description
Spec.
QTY
No.
Description
Spec.
QTY
1
Main Frame
1
41
Screw
M10*16*S6
4
2
Rear Stabilizer
1
42
Right Crank
170“R”9/16
1
3
Nut
M10*H7*S17
4
43
Belt
1
4
Foot pad
M10*30*φ52*49
4
44
Screw
M5*20*Φ8.5
3
5
End Cap
J80*40*1.5
4
45
Wave Washer
1
6
Screw
M10*25*S6
4
46
Outer Belt Cover
1
7
Washer
d10*φ20*2
8
47
Washer
d6*Φ12*1.2
2
8
Screw
M10*15*S6
4
48
Screw
M6*12*Φ12
2
9
Rear Shipping Tube
1
49
C Clip
d20
2
10
Front Shipping Tube
1
50
Nut
M12*1*H19.5*S19
1
11
Allen Wrench
S6
1
51
Washer
d12*φ24*1.5
2
12
Spanner
S14-15-17
1
52
Adjustable Bolt
M8*83*Φ12*5
2
13
Open End Wrench
S13 S15
1
53
Nut
M8*H7.5*S13
2
14
Refer to Part #80
54
Nut
M12*1*H6*S19
2
15
Front Stabilizer
1
55
Inertia Axle
15*162*M12*1*29*29
1
16
Screw
M6*12*S5
3
56
Left Crank
170“L”9/16
1
17
Bearing
608ZZ φ8
4
57
Nut
M10*1.25*H7.5
2
18
Transport Wheel
φ71*φ19*24
2
58
Bearing
6202Z
3
19
Screw
Φ7.8*30*M6*15*S5
3
59
Flywheel
18*460*80*30*55*42*PK
1
20
Adjustment Knob
M16*1.5*16*Φ49
3
60
Spacer
Φ20*Φ15.1*28
1
21
Bushing
F45*F38*153
1
61
Clamp Brake Assembly
1
22
Handlebar Post
1
62
End Cap
φ22*16
1
23
Handlebar
1
63
Nut
M6*H7*S10
1
24
Screw
M10*25*S6
2
64
Brake Pad
2
25
Washer
d10*φ20*1.5
2
65
Screw
M6*38*S5
1
26
Seat
1
66
End Cap
F45*45*24
1
27
Seat Slider
1
67
Nut
M10*H9*S17
1
28
Seat Post
1
68
Brake Clamp Holder
1
29
Bushing
F45*F38*153
2
69
Brake Handle
142*34*46
1
30
End Cap
F38*38*14
1
70
Washer
d10*φ25*1
1
31
Water Bottle Holder
1
71
Tension Control Knob
M10*60*40*50
1
32
Washer
d5*Φ10*1
2
72
Flat Washer
φ11*φ25*4
1
33
Screw
M5*12*Φ8.5
2
73
Crank Cap
Φ25*7
2
34
Bearing
6004-2RS NBK
2
74
Plastic Washer
Φ30*Φ10.1*3
2
35
Plastic Washer
φ6.5*Φ25*6
1
75
End Cap
Φ38*14
1
36
Screw
ST4.8*16*Φ10
9
76
Nut
M12*1.0*H11*S18
1
37
Inner Belt Cover
1
77
Left Nylon Nut
9/16*20*H8*S22
1
38
Front Cover
1
78
Right Nylon Nut
9/16*20*H8*S22
1
39
Middle Axle
φ20*184*43*10.5*
74.5*4-φ10.1*φ105
1
79
Spanner
S8-14-22
1
40
Belt Wheel
Φ204*20*5PK
1
80L/R
Pedal
YH-76X 9/16
2
PARTS LIST

5
HARDWARE PACKAGE
#7 (d10*Φ20*2.0) 4PCS
#6 (M10*25*S6) 4PCS
#25 (d10*Φ20*1.5) 2PCS
#24 (M10*25*S6) 2PCS
S8-14-22
Replacement Parts (U.S. and Canadian Customers only)
Ordering replacement parts checklist:
Please provide the following information in order for us to accurately identify the part(s)
neededThe model number (found on cover of manual)
The product name (found on cover of manual)
The part number found on the Parts List and Exploded Diagram (found near the
front of the manual)

6
ASSEMBLY INSTRUCTIONS
8
78
7
9
10
1
S6
8
7
8
7
7
6
7
6
S6
2
15
1
STEP 1:
Remove Screws (No. 8) using Allen wrench
(No. 11) and discard the Front & Rear
Shipping Tubes (No. 10 & No. 9).
OPTIONAL: You may save these parts:
Screws (No. 8), Washers (No. 7), Front &
Rear Shipping Tubes (No. 10 & No. 9) for
future packaging and transportation of bike.
STEP 2:
Attach the Front & Rear Stabilizers (No. 15 &
No. 2) to the Main Frame (No. 1) using 4
Screws (No. 6) and 4 Washers (No. 7).
Tighten and secure with Allen Wrench (No.
11).

7
20
20
1
80R
80L
S13-15
S15
S8-14-22
78
77
56
42
S22
28
22
20
20
1
STEP 4:
Loosen and remove Adjustment Knobs (No.
20). Insert the Seat and Handlebar Posts (No.
28 &No. 22) into the sleeves located on the
Main Frame (No. 1).Adjust the Seat and
Handlebar Posts (No. 28 & No. 22) to the
desired positions. Re-insert and tighten the
Adjustment Knobs (No. 20) to secure the
posts in place.
STEP 3:
Before you begin, immobilize the crank arms by
turning the tension control knob all the way to
the right. Remove the 2 Nylon Nuts (No. 77 &
78) located on the Pedals (No. 80L/R). (NOTE:
The Left &Right Pedals (No. 80L/R) are
marked Land R.)
Screw the Left Pedal (No. 80L) COUNTER-
CLOCKWISE into the Left Crank Arm (No.
56). Once properly screwed into the place, use
the Wrench (No. 13)to hold the bolt of the
pedal and screw the Left Nylon Nut (No. 77)
CLOCKWISE to the thread end of the Left
Pedal (No. 80L) securely with Spanner (No.
79).
Screw the Right Pedal (No. 80R)
CLOCKWISE into the Right Crank Arm (No.
42). Once properly screwed into the place, use
the Wrench (No. 13)to hold the bolt of the
pedal and screw the Right Nylon Nut (No. 78)
COUNTER-CLOCKWISE to the thread end of
the Right Pedal (No. 80R) securely with
Spanner (No. 79).

8
23
24
25
27
26
20
28
22
31
32
1
#32 d5*Φ10*1 2PCS
#33 M5*12*Φ8.5 2PCS
33
STEP 5:
Loosen and remove the Adjustment Knob
(No. 20). Next, insert the Seat Slider (No.
27) into the Seat Post (No. 28) and adjust it
to the desired position. Re-insert and
tighten Adjustment Knob (No. 20) to
secure the seat slider in place.
Attach the Seat (No. 26) to the Seat Slider
(No. 27), tighten and secure with Spanner
(No. 12).
Attach the Handlebar (No. 23) to the
Handlebar Post (No. 22) using 2 Screws
(No. 24) and 2 Washers (No. 25), tighten
and secure with Allen Wrench (No. 11).
STEP 6:
Remove the preassembled 2 Screws
(No.33) then attach Water Bottle Holder
(No. 31) to Main Frame (No. 1) using the 2
Screws (No. 33) and 2 Washers (No. 32)
that were just removed. Tighten and secure
with Spanner (No. 12).
The assembly is complete!

9
ADJUSTMENT GUIDE
ADJUSTING THE BALANCE:
In order to achieve a smooth and comfortable ride during use, you must
ensure the stability of the bike. If you notice that the bike is unbalanced
you can adjust the foot pads located beneath the front and rear
stabilizers. To do so, use the Spanner (No. 12) to loosen the Nut (No.
3) by turning it clockwise (direction A). With the nut loosened, rotate the
Foot Pad (No. 4) until it sits level with the surface that the bike is on.
When you have finished adjusting the foot pad, re-tighten the Nut (No.
3) by turning it counter-clockwise (direction B) using Spanner (No. 12). If
required, repeat this process to adjust the remaining foot pads.
RESISTANCE & BRAKING:
You may adjust the tension level of the bike by rotating the Tension
Control Knob (No. 71). To increase the level of resistance, rotate the
control knob clockwise,to decrease the level of resistance, rotate the
control knob counter-clockwise.
During an exercise, users may stop the bike immediately by pushing
down on the Brake Handle (No. 69). This is the emergency brake.
ADJUSTING THE HANDLEBAR:
It is important that the handlebar and seat are both set to the correct
height of your body. To adjust the handlebar height, loosen and pull the
Adjustment Knob (No. 20) outward, then slide the Handlebar Post
(No. 22)up or down to the desired height. Once adjusted re-insert and
tighten the Adjustment Knob (No. 20) to secure the handlebar post in
place
TRANSPORTING THE BIKE:
To move the bike, first ensure that the Handlebar (No. 23) is properly
secured. If the handlebar is loose, tighten the Adjustment Knob (No.
20)to secure it. Next, stand at the front of the bike so that you’re directly
in front of the handlebar. Firmly grasp and hold each side of the
handlebar, place one foot on the front stabilizer and tilt the bike towards
you until the transportation wheels on the front stabilizer touch the
ground. With the wheels on the ground, you can transport the bike to the
desired location with ease.
NOTE: When moving the bike, always use caution as unexpected
impact, such as dropping the bike, may cause injury and affect the
bike’s performance.

10
MAINTENANCE INSTRUCTIONS
This is general information for daily, weekly and monthly maintenance to be performed on
your bike.
Version 2.1
Version 1.3
DAILY MAINTENANCE
After each exercise session, wipe down all
the equipment: seat, frame, handlebars. Pay
special attention to the seat post, handlebar
post and belt/chain guard. Sweat is very
corrosive and may cause problems that
require parts replacement later.
1. Get on the bike and engage the drive
train.
2. Pay attention to any vibrations felt
through the pedals. If you feel any
vibrations, you may need to tighten the
pedals, bottom bracket, or adjust the drive
belt/chain tension.
3. Use a wrench to tighten the pedals until
they are secure.
MONTHLY MAINTENANCE
1. Check all hardware is secure, such as: water
bottle holder, flywheel nuts, belt/chain guard
bolts, brake caliper lock nuts and brake
caliper tension rod nuts.
2. Inspect the brake tension rod for signs of
wear such as missing threads. Clean and
lubricate the brake tension rod.
3. Clean and lubricate the seat post, handlebar
post and seat slider. Remove any build up of
foreign material.
WEEKLY MAINTENANCE
1. Inspect moving parts and tighten the
hardware.
2. Inspect pull pin frame fittings, making
sure the fittings are snug. Loose frame
fittings may strip out threads over time
and cause extensive damage.
3. Clean and lubricate pop pin assemblies.
Pull on the pin and spray a small amount
of lubricant onto the shaft.
4. Tighten the seat hardware, making sure
the seat is level and centered.
5. Brush and treat the resistance pads.
Remove any foreign material that may
have collected on the pads. Spray the
pads with silicone lubricant. This helps to
reduce noise from friction between the
pads and the flywheel.
6. Visually inspect the bottom bracket, toe
clips and toe straps. If any of them are
loose or disconnected, attach and tighten.
Version 2.2
