In Phase IPS920SD User manual

In-CarEntertainment
Usermanual
IPS920SD

SafetyInformation..............................................2
PanelControls....................................................3
Basicpaneloperation/ejectingdiscs/resetT.........4
RemoteControls(optional)..............................5-6
ButtonTips.........................................................7
RDS(RadioDataSystem)..............................8-10
RDSMenuFunction.....................................11-12
CDFunctions...............................................13-14
USB/SD/MMC/MP3playback.............................15
MP3Playback..................................................16
MP3CharacterSearch.....................................17
MP3Overview..................................................18
ElectricalConnections.................................19-20
InstallationGuide...............................................21
Anti-TheftSystem.............................................22
Troubleshooting................................................23
Specifications..................................................24
Contents
SafetyInformation
DONOTopencoversanddonotrepairyourself.Consultthedealeroranexperiencedtechnicianforhelp.
CAUTION
CDNotes
PlayingadefectiveordustyCDcancausedropoutsinsound.
HoldCDsasillustrated.
touchtheunlabeledside.
attachanyseal,labelordataprotectionsheettoeithersideofadisc.
exposeaCDtodirectsunlightorexcessiveheat.
WipeadirtyCDfromthecenteroutwardwithacleaningcloth.
Neverusesolventssuchasbenzeneoralcohol.
Thisunitcannotplay3-inch(8cm)Cs.
NEVERinserta3-inchCDcontainedintheadapteroranirregularlyshapedCD.
Theunitmaynotbeabletoejectit,resultinginmalfunction.
DONOT
DONOT
DONOT
D
Beforeoperation
Donotraisethevolumeleveltoomuch,asthiswillblockoutsidesounds,makingdrivingdangerous.
Stopthecarbeforeperforminganycomplicatedoperation.
PRECAUTIONS
Useonlyina12-voltDCnegative-groundelectricalsystem.
Disconnectthevehicle'snegativebatteryterminalwhilemountingandconnectingtheunit.
Whenreplacingthefuse,besuretouseonewithanidenticalamperagerating.
Usingafusewithahigheramperageratingmaycauseseriousdamagetotheunit.
DONOTattempttodisassembletheunit.Laserbeamsfromtheopticalpickuparedangeroustotheeyes.
Makesurethatpinsorotherforeignobjectsdonotgetinsidetheunit;theymaycausemalfunctions,
orcreatesafetyhazardssuchaselectricalshockorlaserbeamexposure.
Ifyouhaveparkedthecarforalongtimeinhotorcoldweather,waituntilthetemperature
inthecarbecomesnormalbeforeoperatingtheunit.
Keepthevolumeatalevelatwhichyoucanhearoutsidewarningsounds(hornssirens,etc.).
*InadditiontoordinaryCds,
thisunitcanplaybackCD-RorCD-RW,MP3.
2

PanelControls
PowerOn:Pressanybuttononthepanelexcepttoturnontheunit.
3
PowerON/OFF
Mute
Displayswitch
Radio
Discplay
(whendiscinserted)
Aux-in
Radiopresetscan
Radioautopreset
MP3track/file/
charactersearch
AMS
SEARCH
Rotatetheto
adjustvolumelevel
control
Pushonceormore
TREBLE/
Rotatethe
controltoadjustlevel
toselect
VOLUME/BASS/
BALANCE/FADER,
MP3track/file/character
search
Pushformorethan2seconds
toaccessMENUfunction Radiopreset
Pressfor0.5secondstoapresetstation.
Holdformorethan2secondstostorestation.
listento
AM2AM1
FM3
FM2FM1
BANDSWITCH
Radiotune
Tofastsearchwithin
atrack/skiptonext
orprevioustrack
Remotesensor
PanelOpen
Traffic
Announcements
Identification
AlternativeFrequency
REGON/OFF
ProgramType
USB-drive
(whenUSBinserted)
MEM-card
(whenSD/MMCinserted)
SD/MMCcardslot
USBconnector
SRC
DISP
AMS 123456
PWR BAND AFTA PTY
VOL
DN
UP
DNUPINTRPTRDMTOP USB

Pressthetoopenthepanelandpresstoejectthedisc.
DiscEject
RESETHOLE
Note:
PressingtheRESETholewillerase
theclocksettingandstoredstations.
Basicpaneloperation/ejectingdiscs/reset
Discslot:insertadiscforplaybackhere.
Panelstatusindicator:
Lightsupwhenyouslidethepaneldown;
Flasheswhenyouremovethepanel.
4

SEARCH
MUTE
SEL
MENU
RDMRPTINT
/TOP
DISP
4
3
21
65
VOL
BAND
SRC
AMS
RemoteControls(optional)
Displayswitch
PowerOn:Pressanybuttonontheremotecontroltoturnontheunit.
RadioTune
Poweron/off
Mute
MP3track/file/character
search FM1
FM2
FM3
Bandswitch
MP3track/file/character
search
RadioAutoPreset
AMS
SEARCH
DiscPlayback
RadioPreset
1 6
Volume
AF/REG PTY
TA
AlternativeFrequency
ProgramType
Traffic
Announcements
Identification
REGON/OFF
AM1
AM2
Introplay(10sec)
TrackRepeatPlay
TrackRandomPlay
MP3track-10down
MP3track+10up
Presstoselect VOLUME/BASS/
TREBLE/BALANCE/FADER,
useVolumebuttontoadjustlevel
Pressformorethan2seconds
toaccessMENUfunction
PressbrieflyforPlay/Pausefunction
Pressformorethan2secondsifyou
wanttostartplaybackfromthebeginning
ofthefirsttrackofyourdisc.
Tofastsearchwithin
atrack/skiptonext
orprevioustrack
Pressto
apresetstation,
Holdformore
than2seconds
tostoreastation.
listento
5
RadioPresetscan
Radio
Discplay
(whendiscinserted)
Aux-in
USB-drive
(whenUSBinserted)
MEM-card
(whenSD/MMCinserted)
CDCchanger(optional)

2.Insertthebutton-typelithiumbatterywiththe
markfacingupward. (+) Insertthebatteryholderintothe
remotecontrol.
1.Pulloutthebatteryholderwhilepressingthestopper.
Replacingthelithiumbatteryofremotecontrolunit.
(CR2025)
RemoteControls
Storethebatteryinplacewherechildrencannotreach.
Ifachildaccidentallyswallowsthebattery,consultadoctorimmediately.
Donotrecharge,short,disassembleorheatthebatteryordisposeitin afire.
Doinganyofthesethingsmaycausethebatterytogiveoffheat,crackor
startafire.
Donotleavethebatterywithothermetallicmaterials.
Doingthismaycausethebatterytogiveoffheat,crackorstartafire.
Whenthrowingawayorsavingthebattery,wrapitintapeandinsulate;
otherwise,thebatterymaystarttogiveoffheat,crackorstartafire.
Donotpokethebatterywithtweezersorsimilartools.
Doingthismaycausethebatterytogiveoffheat,crackorstartafire.
WARNING:
*Whentheoperationrangeofthecardremotecontrol
becomesshortordoesnotfunctionproperly,replace
thelithiumbatterywithanewone.Makesurethe
batterypolarityreplacementiscorrect.
6

DISP
AMS
SettingTheClockTime
DiscLoad/Eject
:presstoflipdownthepanel.
Insertthediscintotheslot.
Load
ButtonTips
Eject :Presstoflipdownthepanel.
Presstoejectthedisc.
ViewingClockTimeDuringRadio/DiscPlayback
Pressbrieflytoscanthepresetstationfor5secondseach.Holdformorethan2seconds,the6
strongestavailablestationwillbeautomaticallysavedinthememoryofpresetbuttons.
AMS:AutoMemoryStore
Radio:Tofinetunetheradio,pressorbriefly.
Tosearchthestationautomatically,pressorformorethan0.5.seconds
DiscPlayback: Trackskip:pressbrieflytogotothenextorprevioustrack.
Trackseek:pressformorethan0.5secondstoseektheforwardorprevioustrack.
PressDISP,timedisplays.Pressagainformorethan2seconds,timedisplayblinks.
Rotatethecontrolclockwisetosetthehoursorcounterclockwisetosettheminutes,
pressDISPagaintoexittheclocksetting.
PressDISP(onceforRadiomodeortwiceforothermodes),displayshowstheclocktimeafter5seconds.
7
DISP
VOL
DN
UP

8
RDS (RadioDataSystem)
RDSserviceavailabilityvarieswitharea.PleasenotethatiftheRDSsignalisnotavailablesameofthefollowingfunctionsmaynotwork.
WhenreceivingaRDSstation,theCT(ClockTime)serviceautomaticallyadjuststhetime.
NOCTwilldisplayinareaswhereCTserviceisnotavailable.
CT(ClockTime)Service
RDSBasics
AF(AlternativeFrequency)Whentheradiosignalstrengthispoor,enablingtheAFfunctionwillallowtheunittoautomatically
PI(programidentification)asthecurrentstationbutwithstrongersignalstrength.
searchfor
anotherstationwiththesame
Thenameofstationwillbedisplayinsteadoffrequency.PS(ProgramServicename)
AFMode:
Remark:
PresstheAFbuttonforlessthan1secondtoswitchAFmodeonandoff.
AFon:AFfunctionisactivated.
AFoff:AFfunctionisdisabled.
TheAFindicatorontheLCDwillflashuntilRDSinformationisreceived.IfRDS
servicesarenotavailableinyourareathenturntheAFmodeoff.
REGMode:PresstheAFbuttonformorethan1secondtoswitchREGmodeonandoff.
REGon:AFfunctionwillimplementtheregionalcode(ofthePI)andonlystations
inthecurrentregioncanbetunedautomatically.
REGoff:AFfunctionwillignoretheregionalcode(ofthePI)andstationsin
theotherregionscanalsobetunedautomatically.

TrafficAnnouncements
SomeRDSFMstations
providetrafficinformation. TP(TrafficProgramIdentification) Broadcastingoftrafficinformation TA(TrafficAnnouncementsIdentification) Radioannouncementsontrafficconditions
TAMode: PresstheTAbuttontoturnonandtheTAfunction.
WhentheTAmodeisturnedon,theTAindicatorwillbedisplayed.
Whentrafficannouncementsarereceived,theunitwilltemporarilyswitchtothetunermode
(regardlessofthecurrentmode)andbeginbtheannouncementatvolume
level20(ifthecurrentvolumelevelisbelow20).Afterthetrafficannouncementisover,itwill
returntothepreviousmodeandvolumelevel.WhenTAisturnedon,SEEK,SCAN,AMS
functioncanonlybereceivedorsavedwhentrafficprogramidentification(TP)codeisreceived.
roadcasting
RDS
WhenEONdataisreceived,theEONindicatorlightsandtheTAandAFfunctionsareenhanced.
TA:
AF: Trafficinformationcanbereceivedfromthecurrentstationorstationsinothernetworks. ThefrequencylistofpresetRDSstationsisupdatedbyEONdata.EONenablestheradiotomakefulleruseofRDSinformation.
ItconstantlyupdatestheAFlistofpresetstations,includingtheonthatiscurrentlytunedin.Ifyoupresetastationaroundthe
areaatyourhome,youwilllaterbeabletoreceivethesamestationatanalternativefrequency,oranyotherstationservingthe
sameprogram,EONalsokeepstrackoflocallyavailableTPstationsforquickreception.
EON(EnhancedOtherNetworks)
9

10
RDS
PTYReception(ProgramType)
RDSFMstationsprovideaprogramtypeidentificationsignal.
Example:news,rock,info,sport,etc. PressPTYoncetoentertheMUSICtypeor
pressPTYtwicetoentertheSPEECHtype.
Thenusetoselectthedesired
programtype.
function —⑥
PTYTypePreset
PRESETNO.MUSICTYPESPEECHTYPE
POPM
ROCKM
EASYM
LIGHTM
CLASSICS
OTHERM
JAZZM
COUNTRY
NATIONALM
OLDIESM
FOLKM
NEWS
AFFAIRS
INFO
SPORT
EDUCATE
DRAMA
CULTLURE
SCIENCE
VARIED
WEATHER
FINANCE
CHILDREN
SOCIAL
RELIGION
PHONEIN
TRAVEL
LEISURE
DOCUMENT
1
2
3
4
5
6
PTYMode: pressthePTYbuttontoturnontheProgramTypereception,
thepreviousPTYisshown.PressthePTYbuttononce
againtoentertheMUSICtypeorpresstwicetoenter
theSPEECHtype,thenusebuttonstoselect—⑥
thedesiredprogramtype.TheselectedPTYtypeis
shownandsearchingstartsifnootherfunctionis
selectedfor2seconds.Ifthereisnocorresponding
programtype,NOPTYisshownandtheunitwill
returntonormalmode.

11
MenuFunction
TAmode:RotatetherotarycontroltochooseTAALARMorTASEEK.IftheTA(trafficAnnouncements)functionisturnedonandthereis
notrafficidentificationcodereceivedinthespecifiedtimethennoTA/TPwillbedisplay.
TAALARMmode :Alarmisturnedon. TASEEKmode:TASEEKisautomaticallyactivated.
MASKmode:
Rotatethe
tochooseMASKDPI
orMASKALLmode.
control
Insomecases,theAFfunctionmaybeinfluencedbysomeinterference,examplesaresignalswith
strongfieldbutwithouttheRDSdata.Forthisreason,theunithastwooptionstoavoidtheabove
interference.
OnlyAFwhichhasdifferentprogramidentificationismasked.
MASKDPImode:
MASKALLmode:
TheAFwhichhasdifferentprogramidentificationandNORDS
signalwithhighfieldstrengthismasked.
RETUNEmode:
Rotatethecontrolto
chooseRETUNE-S
orRETUNE-L
oristimelengthselectionoftheTASEEKretuneinterval.
short,TASEEKretuneintervalis45seconds.
long,TASEEKretuneintervalis180seconds.
RemarkmodefunctionsforTAduringTASEEKmodeonly.
RETUNE-SRETUNE-L
RETUNE-S:
RETUNE-L:
:RETUNE
VOL
DN
UP
VOL
DN
UP
Pressformorethan2secondstoenterthemenumode,theneachpresschangesthemodeasfollows:
therotaryvolumecontrol
TAmodeMASKmodeRETUNEmodeDSPmodeLOUDON/OFF
LOCAL/DXmode STEREO/MONOmode SEEK1/2mode
(onlyintunermode)(onlyinFMmode)(onlyintunermode) BEEPON/OFF
WOOFON/OFF ESPmode
MULTON/OFF
(CD12s,Mp345s)≥≥

12
MenuFunction
LOCAL/DXmode:Rotatethecontroltochoosetunersensitivitylocalordistant.
STEREO/MONOmode:RotatethecontroltochooseFMstereoormono.
SEEK1/2mode: Rotatethecontroltochooseradioseekmode1or2.
SEEK1: searchingstationwillstopwhennextstationisreceived.
SEEK2: searchingstationwillstopwhenorbuttonisreleasedandnextstationisreceived.
POPROCKCLASSICFLATDSPOFF
DSPmode:RotatethetochooseDSPsoundeffect:control
LOUDmode:Rotatethecontroltochooseloudnessonoroff.
WOOFON/OFF: Rotatethecontroltoturnthesubwooferpreoutsonoroff.
VOL
DN
UP
BEEPON/OFFmode:Rotatethecontroltochoosebuttonbeepsoundonoroff.
ESP:12/45s
MULTON/OFF: MultiSessionON/OFF.(MultisessionOFF:mixedcd,ONEsessionCD;MultisessionON:Mixed,Extra,multisessionCD)
ESP12:SelectedasCD-ESPtime12seconds.
ESP45:SelectedasCD-ESPtime45seconds.

CDFunctions
PAUSE
-Duringplayback,presstopause/freezepictureontheTVscreen.
-Thesoundwillbemuted.
-Display""intheTVscreen,displayandblink""intheLCDscreen.PAUSEPAUSE
Pressagaintocontinueplayback. ontheremotecontrol
onthepanel
/TOP
1
INTRO(ForCDOnly)
Youcanplaythebeginningofeverytrackfor10secondsinsequence.
1.Duringplayback,pressonce.
2.Pressagaintoselectthecurrenttrack.
INT
INT Onthepanel
INT
2
ontheremotecontrol
DISCSFORPLAYBACK
ThissetcanplayalldigitalaudioCD,videofinaliseddigitalaudioCD-Recordable(CDR)discsandMP3-CD.CD,
1.Pressonceormoretoon.
2.Presstoopenthepanel,insertaCDwiththeprintedsidefacingupward.
3.Pushthepanelbackintoplace.
-DisplayshowsLOADfollowedbythetotaltrackandplayingtime.
Elapsedtimeisshownduringdiscplayback.
-NODISCorBADDISCorERROR-1,2,3willbedisplayedifno
discisinsertedorerrorfoundinCDoperation.
13
PWR
1
TOP
2
INT

4
RDM
3
RPT
CDFunctions(continued)
Randomtrackplayback(ForCDOnly)
Youcanplayallthetracksinrandomorder.
1.Duringplayback,pressonceormore.
2.Pressagaintoselectnormalplayback.
RDM
RDM Onthepanel
RDM
4
ontheremotecontrol
Toselectadesiredtrack
-Pressoronthepanelrepeatedly.
untilthedesiredtrackappearsonthedisplay.
-Ifplaybackisstopped,presstostartplayback.
Fastforward/backwardduringplayback
-Pressandholdoronthepanel()tofastbackwardor
forwardskipduringplayback. orpressorontheremotecontrol
-Duringthefastforwardorbackwardoperation,thevolumewillbemuted.
Onthepanel
ontheremotecontrol
Onthepanel
REPEAT
1.Duringplayback,pressonceormore.RPT
RPTNote:Ifyoudonotselecton,thesystemwillplayyourentiredisc/programcontinuously.
Youcanplaythecurrenttrack,theprogramorthewholediscrepeatedly.
RPT
3
ontheremotecontrol
14

15
USB/SD/MMCNotes
USBfunctions(flashmemorytype)MP3musicplay
(1)SD/MMCcardsupport
(2)USBflashmemory2in1(SD/MMC)support
(3)Fat12/fat16/fat32ispossible
-fat12/16(dir:200support,file:500support)
-fat32(dir:200support,file:500support)
(4)Filename:32byte/dirname:32byte/
(5)Tag(id3tagver2.0)
-title/artist/album:32bytesupport
(6)Multicardreadernotsupport
(7)USB1.1support
USB2.0support(itcannotsupportUSB2.0speed.Just,
tagname:32byte
getbesamespeedwithUSB1.1)
USB/SD/MMCMP3playback
4
1.LoadingSD/MMCCard
InserttheSD/MMCcardintotheslot,withthefrontsideatright.
TheunitwillplaythemusicautomaticallyandtheLCDwillshowMEM-CARD.
2.TakeoutSD/MMCCard
PushSRCbuttonandswitchtononMEM-CARDmode,
slightlypresstheSD/MMCcardandremovethecardwhenitpopsout.
3.LoadingUSBequipment
Opentherubbercap,inserttheUSBintotheconnectorandtheunitplaythemusic
intheUSBdeviceautomatically,andtheLCDwillshowUSB-DRIV.
4.TakeoutUSBequipment
PushtheSRCbuttonandswitchtononUSB-DRIVmode,
thentakeouttheUSBdevice,closetherubbercap.

16
WhileplayinganM3disc/USB/SD/MMC-MP3musicfile,thefolder/filenameand(Songtitle,Album
andArtist)canacrosstheLCD.(PresstheBANDshowID3information)
PID3tag
scrollbuttonto
Elapsedplayingtime&TracknumberFoldername&numberFilename&numberSongtitleAlbumtitleArtistname
PressAMStwiceto
select"FILESCH"mode.
Press toenter,thecontrol
Rotatethecontrolto selectfolder.
M3FilesearchP
M3TracksearchP
PressAMStoselect"TRACKSCH"mode.
PressthecontrolandLCDdisplaywillshow"001".
Ifthedesiredtracknumberislessthan100then
rotatethecontroltoselectthefirstdigitandpressthecontrolonceagain,
therotatethecontroltosetthetenthdigitofthetracknumber.
Pressthecontrolagainformorethan0.5secondstoplaythetrack.
Ifthedesiredtracknumberismorethan100,
Rotatethecontroltoselectthehundredthdigitandpressthecontroltoconfirm,
Rotatethecontroltoselectthetenthdigitandpressthecontroltoconfirm,
Rotatethecontroltoselectthefirstdigitandpressthecontroltoconfirm,
Pressthecontrolagaintoplaythetrack.
VOL
DN
UP
AMS
MP3Playback
IFyoujustwanttoplaysongsfromthisfolder,presstheknob
formorethan0.5secondstoplaythefirsttrackofthefolder.
IFyouwanttoplayadesiredtrackinthefolder,presstheknob
androtatetoselectthetrackyouwant.
Presstheknobagaintoplaythetrack.
*Ifthetracknumberyouenteris
beyondthemaximumfilenumber
thenthelastsongwillbeplayed.

17
MP3CharacterSearch
PressAMSbuttonthreetimestoselect"CHARSCH"mode.
Pressthecontroland"A"isdisplayed.
Ifyoupressthecontrolformorethan0.5seconds,atrackbeginningwiththeletter"A"willbeplayed.
Ifyouwanttoselectatracknamebeginningwithadifferentletter.rotatethecontroltoselectaletter,then
pressthecontroltoconfirm.
Then"A"flashesatthenextplace,select2andothercharacterofthedesiredtracknameasstepsabove.
nd
Pressthecontrolmorethan0.5secondstoplayyourdesiredtrack.
Example:tosearchcharacter"ECHO".
VOL
DN
UP
AMS

18
NoteoncreatingyourownCD-RsorCD-RWscontainingMP3files
Howtogetmusicfiles
Eitherdownloadlegalmusicfilesfromtheinternettoyourcomputerharddiscorcreatethemfromyourownaudio
ans.Forthis,insertanaudioCDintoyourcomputerCD-RWdriveandconvertthemusicusinganappropriateencoding
software.
CD
asrippedandrecorded.
Toenjoyhighqualitymusic,werecommendconvertingMP3fileswithasamplingfrequencyof44.1kHzandafixedbitrateof128kbps.
DONOTstoremorethan447MP3filesperdisc.
ForISO9660-compliantformat,themaximumallowabledepthofnestedfoldersis8,includingtherootdirectory(folder).
WhenCD-Rdiscsareused,thisunitwillonlyplaybackdiscsthathavebeenfinalised.
MakesurethatwhenMP3CD-RorCD-RWisburnedthatitisformattedasadatadiscandNOTasanaudiodisc.
Itisnotrecommendedtowritenon-MP3filesorunrelatedfoldersalongwithMP3filesonthediscotherwiseitmaytakelongertime
tostartplayingthedisc.
WithsomeCD-RorCD-RWmedia,datamaynotbeproperlywrittendependingontheirmanufacturingquality.
Inthiscase,datamaynotbereproducedcorrectly.HighqualityCD-RorCD-RWdiscarerecommended.
supportID3tagVersion1.XXand2.XX,upto16characterscanbedisplayedforthetitleofthesong,AlbumandtheArtist.
Notethattheunitmaynotplaytracks
"MP3"technologyaudiolayer3)reducesthedigitaldataofanaudioCDsignificantlywhilemaintainingCD-likesoundquality.
MP3isamusiccompressiontechnology,audiolayer3)reducesthedigitaldataofanaudioCDsignificantlywhilemaintainingCD-likesoundquality.
ThisproductallowsplaybackofMP3filesonCD-ROMCD-RorCD-RWdiscs.
TheunitcanreadM3fileswritteninaformatcompliantwithISO9660.howeveritdoesnotsupportM3datawrittenbypacketwriting.
TheunitcannotreadanM3filethathasafileextensionotherthan".mp3".
Ifyouplayanon-M3filethathasthe".mp3"extension,youmayhearsomenoise.
Inthismanual,werefertowhatarecalled"M3file"and"folder"inPCterminologyas"track"and"Album"respectively.
Themaximumnumberofdirectoryis128,themaximumnumberofMP3filesperdiscis447.
Theunitmaynotplaytracksintheorderoftracknumbers.
Theunitsupportmulti-sessiondiscswithMIXEDandEXTRAformats,butplaystheMP3tracksispriority.
MIXEDformat:discstructurefirstisMP3data,secondisaudiodata.
EXTRAformat:discstructurefirstisaudiodata,secondisMP3data.
TheunitsupportsallMPEGbitratesincludingfreeformatforMPEG1audiolayer3,allMPEGbitratesexcept8kbpsandfreeformatforMPEG2audiolayer3.
Theunitsupport32/44.1/48kHzsamplingrateforMPEG1audiolayer3,32/44.1/48kHzand16/22.05/24kHzsamplingrateforMPEG2audiolayer3,and
44.1kHz
(MPEG MP3(MPEG
PP
P
P
P
samplingrateforVBR(VariableBitRate).
NoteonM3P
MP3Overview

19
WiringDiagram
Fuse15A
Aux-in
L(White)
R(Red)
ElectricalConnections
Connector
RearLine-out(Gray)
R(Red)
L(White)
Antenna
AUDIOOUT
Amplifier
Pink
GroundLead
Ignitionkey
+12VDCWhenON/ACC
LeftSpeaker
(Front) LeftSpeaker
(Rear)
RightSpeaker
(Front)
White/
Black
Stripe White
Gray/
Black
Stripe
Green/
Black
Stripe
Gray Green
Purple/
Black
Stripe
Purple
Black
Tocarbattery(+)
Continuous+12VDC
Yellow
Red
Blue Motor/ElectricAntennarelaycontrolLead
AmplifierrelaycontrolLead
ISOConnector
Black
R(Red)
L(White)
FrontLine-out(Brown)
RightSpeaker
()Rear
Originalwiring
Modifiedwiring
Red
Yellow Yellow
Red
Red
YellowYellow
Red
ForsomeVW/AudiorOpel(Vauxhall)
carmodels,youmayneedtomodify
wiringofthesuppliedpowercordas
illustrated,orelsethememoryofthe
unitmaybelostafteryoupoweroff.
Contactyourauthorizedcardealer
beforeinstallingthisunit.
TelephoneMute(activelowlogiclevel)
Subwooferout
(Green) Amplifier
Amplifier

20
1.IfyourcarisequippedwiththeISOconnector,thenconnecttheISOconnectorsasillustrated.
2.ForconnectionswithouttheISOconnectors,checkthewiringinthevehiclecarefully
Cuttheconnector,connectthecoloredleadsofthepowercordtothecarbattery,
beforeconnecting,incorrectconnection
maycauseseriousdamagetothisunit. asshowninthecolourcodetablebelowfor
speakerandpowercableconnections.IfyouvehicledoesnothaveastandardISOconnectorthenpleaseaskyoursupplyingdealer
foranISOwiringadaptor
UsingtheISOConnector
ConnectorConnector
Telephone-mute/pink
Battery12V(+)/yellow
AutoAntenna/blue
ACC+/red
Ground/black
RearRight(+)---Purple
RearRight(-)---Purple/BlackStripe
FrontRight(+)---Gray
FrontRight(-)---Gray/BlackStripe
FrontLeft(+)---White
FrontLeft((-)---White/BlackStripe
RearLeft(+)---Green
RearLeft(-)---Green/BlackStripe
ElectricalConnections
