In the Swim Automatic Solar Blanket Reel System Operating instructions

In the Swim® Solar/Battery Powered Solar Blanket Reel
Installation / Operation Guide
Please Read, Follow, and Save this Instruction Manual.
In the Swim® Solar/Battery Powered Solar Blanket Reel is recommended for use on rectangular
shaped pools with or without diving boards.
The In the Swim® Solar/Battery Powered Solar Blanket Reel system should only be used for the
intended application.
INTRODUCTION
PBITS001

READ AND FOLLOW ENTIRE INSTRUCTION MANUAL
AND ALL PRECAUTIONS, PRIOR TO INSTALLING,
USING, OR TROUBLESHOOTING THIS EQUIPMENT.
• Read, follow, and save the entire instruction manual .
• Use the system only in the intended manner.
• Remember, solar blankets are not safety covers.
• Remove the solar blanket completely from the pool before using the pool.
• The system is intended to be stationary. It is not designed to be mounted on a caster-
equipped stand.
• Visually inspect the pool prior to retracting or extending the solar blanket. The pool should be
clear of occupants and other items that might conflict with the solar blanket.
• Store the remote control and in a secure location in order to prevent unauthorized operation.
• Do not attempt any technical repairs without proper training or first calling
TechnicalSupportat 1-866-778-POOL(7665).Failure to do so may result in denial of
warrantyclaims.
IMPORTANT SAFETY PRECAUTIONS

Required Tools:
• 5/16 & 7/16 wrenches or sockets
• #2 Phillips screwdriver
• Drill
• 1/4” and 5/32” drill bits
• Flat blade screwdriver
Select the Location
Select a location at one of the narrow ends of the pool. The location must be away from the ladder.
Typical Layout
GETTING STARTED

1) Position the Stands
Position the stands in the selected location at one of the narrow ends of the pool. The stands come
assembled in the middle of the height adjustment range.
Height adjustment
The height of the reel system is adjustable through a wide range. The height of the cross tube can be
changed by moving the hub assemblies to different height settings.
Installation
Drive
Stand
Pool Deck
Level

Adjusting Stand Height
1. Remove the drive and idler stand covers. The covers are each held in place by three screws.
2. Remove bolts that attach motor case to stand. Position motor / gearbox assembly at the desired
height. Insert and tighten bolts.
3. Remove bolts and nuts that attach the idler hub and position hub to match the drive stand hub
location.
4. Reinstall bolts, washers and nuts and tighten.
5. Leave the drive stand cover off. Install the idler stand cover, if desired.
Example- Highest Setting
Example- Lowest Setting

Drive Stand
Idler Stand
Using a 5/16 wrench,
remove (4) mounting
bolts.
Adjust stand height and
reinstall bolts.
Using a 7/16 wrench,
remove (4) mounting
bolts.
Adjust stand height and
reinstall bolts.

2) Installing Cross Tubes
The cross tube assembly is adjustable to accommodate required widths from 17 to 23.5 feet. The cross
tube assembly has three tube sections. Two smaller tubes telescope from each end of the larger
diameter tube.
1. Slide a smaller diameter tube section into each end of the large tube.
2. Insert the drive and idler hubs into the ends of the cross tube assembly.
3. Center the middle tube section between the stands.
Note: The cross tube is adjustable from 17ft to 23.5 ft.
Install the Cross Bolts
This will fasten the three sections of the
cross tube assembly together.
Note: the cross tube sections have
grooves. These grooves are used to
help guide the drill bit during the drilling
process.
On one end of the large diameter tube:
Measure one (1) inch in from the end of
the large tube section and using the
groove as a guide, drill a 1/4” hole.
Insert a 1/4” bolt into the hole to keep
the tubes from moving. Then drill
another 1/4” hole one inch from the end
of the large tube in the guide groove on
the opposite side (180 degrees) from
the first hole. Insert a bolt through both
holes, install a nut, and tighten.
Repeat this process by drilling two more
holes at eleven (11) inches from the
end of the large tube and at 90 degrees
rotation from the first pair of holes.
Perform this process on the other
end of the large tube for a total of
four (4) bolts.

Attaching the cross tube assembly to the hubassemblies.
1. Insert the drive and idler hubs into the cross tube
2. Drill a 5/32 pilot hole through the tube and into the hub approx¾”
3. Insert the screw and tighten

3) Installing battery, solar charger and antenna
Installing the battery
The battery is simply placed inside of the drive side stand on the right hand side (opposite side from the
controller). The connector from the battery is then plugged into the mating connector in the drive side
stand. When properly connected the wire colors will match. The photo below shows a properly connected
and installed battery in the drive side stand. The wiring should be neatly tucked in next to the battery and
below the motor.
Note: Battery, solar charger and antenna may vary from photo.
Proper Battery Installation
Solar Charger installation
The solar charger is shipped with mounting bracket and suction cups installed. This will allow numerous
mounting options. The supplied cord is designed to allow the solar charger to be mounted to the sides or
the top of the drive side stand or it may be mounted remotely away from the stand. The mounting locating
needs to be selected so that the solar charger is exposed to enough sunlight to keep the battery charged.
After selecting a location and mounting the solar charger route the cord to the drive side stand. There is a
hole in the bottom of the two sides to route the cord through. Then simply locate the mating connector
that will be near the battery and connect the two together. Any excessive cord should be neatly coiled
and stored inside of the drive side stand. When routing the cord from the solar charger it must be kept
away from the rotating tubes and hubs.
Showing proper cord routing Showing optional mounting of Showing optional mounting of
and connection of solar charger solar charger to side of drive solar charger to top of drive
cord to drive side stand. side stand. side stand.
Antenna Installation
The wireless antenna is shipped uninstalled, it is simply screwed onto the connector at the top
of the drive side stand.
Showing installed antenna.

4) Test Run
With the cross tube attached, test run the system. (See the OPERATION Section for instructions.)
Ensure the cross tube is securely attached to the hubs and that it runs smoothly without wobble.
In preparation for installing the solar blanket, observe the direction of rotation of the cross tube. Compare
this direction of rotation to the EXTEND and RETRACT buttons on the remote control as well as to the
direction you plan to wrap the solar blanket around the crosstube.
Depending on the desired installation configuration, the operating direction of the reel may be opposite of
the buttons on the remote. To correct this, install the supplied directional matching harness at the motor
connection. This will match motor direction on the remote control to the desired wrap direction of the pool
cover.
Controller Harness
Directional Matching Harness
Plug into the motor harness at
the motor connection.
Motor Assembly

5) Install the covers for the drive and idler stands
Install the drive stand cover. Make sure the motor harness is routed through the slot in the side of the
cover. If the idler stand cover was removed, reinstall it at this time.
6) Attach the solar blanket
Attach solar blanket onto the cross tube in the manner prescribed by the blanket/ blanket strap
manufacturer. Consult your solar blanket retailer for details.
The blanket can wind onto the cross tube either direction.
7) Install tether kit
The tether kit attaches to the leading edge of the solar cover, opposite the end that wraps onto the cross
tube. The tether is used to guide the cover during extension and retraction.
1. Carefully wrap the edge of the cover around the tube (after joining the two 5 ft. pieces). Ensure
the wrap is even and square to the leading edge and center of the cover.
2. Install the supplied (5) clips as shown in the following diagram. Bolt through the cover material, a
hole will need to be made through the blanket. Install clamps evenly, approximately one every
two feet.
3. Snap the guide rope harness to the clamps as shown.

Safety Items prior to operation
Visually inspect the pool prior to retracting or extending the solar blanket.
The pool should be clear of occupants or other items that might conflict with the solar blanket.
When not in use, store the remote control in a secure location in order to prevent
unauthorized operation.
Safety Features
The powered solar blanket reel has operational safety features integrated into a
locking remote control that is designed to prevent unauthorized operation.
Remote Control: The key fob style remote control is used to extend and retract the solar blanket.
This remote control is activated for use only after both buttons (EXT / RET) are depressed
simultaneously and held for 2 seconds. Once activated, the remote control has a built in 5 minute
timer during which time, operation is possible. After five minutes elapses, the remote will deactivate
and operation will cease. To continue operation, the remote must be activated again.
OPERATION
Activate the remote control by pressing simultaneously and holding both the EXT and RET buttons
for 2seconds. Note: Activating the remote starts a 5-minute timer for system operation.
Operate the System
To retract the solar blanket: press and release the RETRACT (RET) button on the remote control.
To stop retraction: press and release the RETRACT (RET) button again. Note: Retraction will also
stop automatically after 90 seconds.
It may be necessary to guide the blanket as it coils onto the reel. This can be done by grasping
the edge of the solar blanket or using the tether.
To extend the solar blanket: press and release the EXTEND (EXT) button on the remote control.
To stop extending the blanket: press and release the EXTEND (EXT) buttonagain.
Note: Extension will also stop automatically after 90seconds.
It will be necessary to guide the blanket across the pool as it uncoils from the reel. This can be
done by grasping the edge of the solar blanket or using thetether.

In the event of a loss of power, a manual override isprovided.
1) Remove the cover of the drive stand
2) Unplug the motor harness at the motor connector.
3) Remove the cover of the idler stand.
4) Use a ¾-inch wrench or socket to turn the reel in the desireddirection.
MANUAL OVERRIDE
Use a ¾ Inch
Wrench

Maintenance and Troubleshooting
Stands and tubes
The stands and tubes are designed to be weather resistant and maintenance free. The hubs are
made of a special material that does not require lubrication. The stands are specially coated to
resist the elements and may be cleaned using a mild soap and water solution. The use of a
pressure washer is to be avoided due to the battery and other components inside of the drive
stand.
Battery
The battery located in the drive side stand must be kept charged for proper operation. The solar
charger must receive adequate sunlight to keep the battery charged. The battery powered
components located inside of the drive side stand are weather resistant, they are not immersion
proof. The battery and battery powered components and solar charger may be cleaned using a
damp rag. Under no circumstances should the battery, solar charger or battery powered
components be cleaned by using high pressure spray from a hose or pressure washer.
Seasonal storage
Prior to long periods of inactivity the battery should be removed from the stand, and stored where
it cannot freeze. It should be stored away from excessive heat and flame. It may then be
necessary for it to receive charge from the solar panel prior to it having enough charge to properly
operate.
Remote (Fob)
The remote control (Fob) is weather resistant. It contains a button type battery (CR 2032). The
battery may require replacement at some time. This battery (CR 2032) is available at most retail
outlets that sell batteries. When replacing the battery be sure to install with correct polarity and
remove any protective sticker or film that may be on the battery.
No operation
If the system fails to operate, first check and verify that you are doing the TWO button press
for TWO seconds prior to attempting operation. (See operation instructions for this.)
Then check the following items:
• Check/charge the main battery in the drive side stand, the solar panel may not be getting
sufficient sun for proper charging so check to verify the solar panel location.
• Check the fuse in the fuse holder at the battery connector. The fuse is an ATO 7.5 AMP.
• Check/replace the battery in the remote (Fob)
• Check the wiring inside of the drive side stand for corrosion and or loose wiring
• After following the above checks if trouble persists call technical assistance at
866-778-7665

© 2009 TouchTronics, Inc. All Rights Reserved. TouchTronics, the TouchTronics logo, and other TouchTronics marks are owned by
TouchTronics and may be registered. TouchTronics assumes no responsibility for any errors that may appear in this manual. Information
contained herein is subject to change without notice.
FCC Compliance and Advisory Statement. This hardware device complies with Part 15 of the FCC Rules. Operation is subject to the
following two conditions: 1) this device may not cause harmful interference, and 2) this device must accept any interference received,
including interference that may cause undesired operation. This equipment has been tested and found to comply with the limits for a Class
B digital device, pursuant to Part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful
interference in a residential installation. This equipment generates, uses, and can radiate radio frequency energy and, if not installed or
used in accordance with the instructions, may cause harmful interference to radio communications. However, there is no guarantee that
interference will not occur in a particular installation. If this equipment does cause harmful interference to radio or television reception,
which can be determined by turning the equipment off and on, the user is encouraged to try to correct the interference by one or more of the
following measures: 1) reorient or relocate the receiving antenna; 2) increase the separation between the equipment and the receiver 3)
connect the equipment to an outlet on a circuit different from that to which the receiver is connected; 4) consult the dealer or an
experienced radio/TV technician for help. Any changes or modifications not expressly approved by the party responsible for compliance
could void the user’s authority to operate the equipment. Where shielded interface cables have been provided with the product or specified
additional components or accessories elsewhere defined to be used with the installation of the product, they must be used in order to ensure
compliance with FCC regulations.
Canadian DOC Statement. This digital device does not exceed the Class B limits for radio noise emissions from digital apparatus
specified in the interference-causing equipment standard entitled “Digital Apparatus,” ICES-003 of the Department of Communications.
This device complies with RSS-210 of Industry Canada. Operation is subject to the following two conditions: 1) this device may not
cause interference, and 2) this device must accept any interference, including interference that may cause undesired operation of thedevice.
© 2009 TouchTronics, Inc. Tous droits réservés. TouchTronics, le logo TouchTronics et les autres marques TouchTronics sont la
propriété exclusive de TouchTronics et sont susceptibles d’être des marques déposées. Toutes les autres marques sont la propriété
exclusive de leurs détenteurs respectifs. TouchTronics décline toute responsabilité en cas d’erreurs dans ce manuel. Les informations
énoncées dans le présent document peuvent faire l’objet de modifications sans avis préalable.
Déclaration FCC. Cet équipement a été testé et déclaré conforme à la section 15 du règlement de la FCC. Son fonctionnement est soumis
aux conditions suivantes: 1) l’équipement concerné ne doit pas causer d’interférences dangereuses, et 2) il doit accepter toute interférence
reçue, y compris les interférences risquant d’engendrer un fonctionnement indésirable. Cet équipement a été testé et déclaré conforme aux
limitations prévues dans le cadre de la catégorie B des appareils numériques défini par la section 15 du règlement de la FCC. Ces
limitations sont stipulées aux fins de garantir une protection raisonnable contre les interférences gênantes en installation résidentielle. Cet
équipement génère, utilise et diffuse des ondes radio, et s’il n’est pas installé ni utilisé en conformité avec les instructions dont il fait
l’objet, peut causer des interférences gênantes avec les communications radio. Cependant, nous ne pouvons vous garantir qu’une
interférence ne se produira pas dans une installation particulière. Si cet équipement produit des interférences graves lors de réceptions
radio ou télévisées qui peuvent être détectées en allumant et en éteignant l’équipement, vous êtes invités à les supprimer de plusieurs
manières: 1) Réorienter ou déplacer l’antenne de réception; 2) Augmenter la distance séparant l’équipement et le récepteur 3) Connecter
l’équipement à un circuit différent de celui auquel le récepteur est connecté; 4) Contacter votre revendeur ou un technicien radio/TV
qualifié. Toutes modifications ou tous changements effectués sans l’accord exprès de la partie responsable de la conformité aux normes
pourraient contraindre l’utilisateur à ne plus utiliser son équipement. Afin d’assurer la conformité avec les règlements FCC, les câbles
d’interface blindés fournis avec le produit doivent être utilisés, ainsi que tout autres composants ou accessoires également spécifiés, lors de
l’installation du produit.
Déclaration du Ministère des Communications Canadien. Cet appareil numérique est conforme aux limitations concernant l’émission
d’interférences radio par des appareils numériques de catégorie B, telles que stipulées dans le cadre de la norme Appareils numériques
ICES-003 édictée par le Ministère canadien de l’industrie.
Cet équipement a été déclaré conforme à la norme RSS-210 édictée par le Ministère canadien de l’industrie. Son fonctionnement est
soumis aux conditions suivantes: 1) l’équipement concerné ne doit pas causer d’interférences, et 2) il doit accepter toute interférence reçue,
y compris les interférences risquant d’engendrer un fonctionnement indésirable.
FCC Statement

DAYS CORPORATION
LIMITED WARRANTY, REPLACEMENT PARTS & RETURNS POLICY
LIMITED WARRANTY Effective January 1, 2016 Days Corporation (“Days”) warrants to the original purchaser of system
components (the “Products”), for a period of three (3) years from the original sale date or date of dealer installation, whichever is earlier
(“Limited Warranty Period”), that the Products shall be free from defects in material and workmanship. Days’ sole obligation under this
warranty is, at its election, to repair, replace or make appropriate adjustments concerning the Products where Days’ inspection discloses
any such defects in the Products occurring in normal usage within the limited warranty period. Days will, at its option, repair or replace
such part at no expense to you (provided, however, that you will be responsible for all shipping or transportation costs in connection with
transporting this unit to and from Days). Only warranty claims with prior authorization from Days will be recognized; all other claims are
invalid and will be denied. This warranty does not apply to abuse, misuse, neglect, negligence, error of operations or to purposeful or
accidental damage or damage due to “act of God” such as wind or rain damage, flood, lightning or other natural or similar occurrences. The
limited warranty coverage applies only to the Products and no other apparatus or property to which the Products are affixed or attached.
The limited warranty is not transferable. THE FOREGOING WARRANTY IS IN LIEU OF AND EXCLUDES ALL OTHER WARRANTIES NOT
EXPRESSLY SET FORTH HEREIN, WHETHER EXPRESS OR IMPLIED BY OPERATION OF LAW OR OTHERWISE, AND DAYS EXPRESSLY EXCLUDES
ANY IMPLIED WARRANTIES, INCLUDING ANY IMPLIED WARRANTY OF MERCHANTABILITY OR FITNESS FOR PURPOSE OR USE. Days is not
responsible for removal or installation costs. UNDER NO CIRCUMSTANCES SHALL DAYS’ LIABILITY FOR ANY DEFECT IN THE PRODUCTS,
WHETHER BASED ON CONTRACT, TORT, WARRANTY, STRICT LIABILITY, OR ANY OTHER THEORY, EXCEED THE PURCHASE PRICE OF THE
DEFECTIVE PRODUCTS, AND DAYS SHALL HAVE NO LIABILITY FOR CONSEQUENTIAL, SPECIAL, INCIDENTAL, INDIRECT, EXEMPLARY OR
PUNITIVE DAMAGES OF ANY KIND WHATSOEVER. This limited warranty provides the limited purchaser of the Products with specific legal
rights. The original purchaser of the Products may also have other rights that vary from state to state.
APPLICABILITY OF LIMITED WARRANTY TO REPLACEMENT PARTS. The terms and conditions of the Limited
Warranty shall apply to any replacement parts provided to the original purchaser by Days in connection with any warranty claim. Any
replacement part is warranted for the balance of the Limited Warranty Period or ninety (90) days from the date of shipment of the
replacement part, whichever is longer. No markup will be paid by Days for warranty parts.
RETURNS POLICY. This returns policy applies to all Products returned to Days from the original purchaser during the Limited
Warranty Period. Prior authorization is required before any Product may be returned to Days. A Return Authorization Number is required
for Days’ acceptance of returned Products. Warranty claims submitted without proof of the original purchase date are not covered by this
Warranty and will be denied. Parts credit (if applicable) will be sent after Days tests the Product and validates the warranty claim.
Please direct all questions concerning the Limited Warranty to: Days
Corporation
Warranty Claims
P.O. Box 668
Elkhart, IN 46515
Telephone: [phone]
Facsimile: 1-574- 266-6083
Rev. 12-2015
WARRANTY
