Incyt Lyra LX User manual

Remove the VHB protective film on the
underside of the device, and press firmly
against the mounting surface for 30
seconds to maximise adhesion.
Note: VHB adhesive will reach maximum
bonding strength after 24 hours.
For an alternate secure mounting method,
mount the device using a cable tie to the
desired fixture, or connect to keyring as
pictured below:
Safety and compliance
Ensure installation complies with all
relevant local regulations and requirements.
Troubleshooting
Visit incyt.io/support for further installation,
activation and trouble-shooting information.
9
Lyra
Quick Start Guide
Product Overview
Mounting
surface
Cable tie
Keyring
C01E1801A62E98A3 3
4
2
1
10
For help visit incyt by LX
incyt.io/support
Copyright 2020 LX Corporation Pty Ltd.
All rights reserved.
Apple and the Apple Logo are trademarks of Apple
Inc., registered in the U.S. and other countries.
App Store is a service mark of Apple Inc., registered
in the U.S. and other countries.
Google Play and the Google Play logo are
trademarks of Google Inc.
Environmental Sensing Port
(Lyra Sense model only)
LED
Device ID
VHB Tape
1
2
3
4

• Orientation
Lyra may be mounted in any orientation,
however Lyra Sense must be mounted
on a vertical surface to avoid sensor port
blockage as below:
• Temperature
The recommended temperature range
of this device is 5ºC to 50ºC. Use outside
of this range may limit the device
performance and functionality, and may
reduce the battery and operational life of
Logo upright
Environmental
Sensing Port
8
the device. We recommend you carefully
consider these factors when installing.
• Wireless network
This device uses Bluetooth technology for
geo-location and communication with the
Incyt platform. Installing the device in a
location with unobstructed visibility to the
Bluetooth receiver, such as a smartphone
or the LX Antares gateway, will ensure
maximum performance and accuracy of
the device.
• Exposure to Environment
Although this device is rugged, protecting
it from direct sunlight, rain, chemicals,
and dirt will extend its operational life.
The environmental sensing port needs to
be kept clean, dry and unobstructed to
provide accurate sensor readings.
Roughen smooth surfaces using a scouring
pad or steel wool before application. Clean
the mounting surface prior to installation
by removing debris, and wiping using the
alcohol wipe included.
Getting Started
Download the Incyt by LX app on the iOS
AppStore, or Google Play store on your
mobile device.
Create a new account or login with your
existing account.
Follow instructions in the app to pair
your device.
Follow the instructions on the next page
to activate and mount your device.
Device Activation
The device is delivered in a dormant state.
Activate before use by completing the
following steps:
Place the device in range of the Bluetooth
equipped smartphone to be connected
to. Ensure the Incyt app is installed, and
Bluetooth is turned on.
Use the magnet included in the box to
swipe over the LED on the device. The LED
will start pulsing yellow.
Swipe a second time within 5 seconds.
The LED will remain on for 3 second,
indicating successful activation.
Note: If the LED turns ON for 1 second after
the first magnet swipe, the device has
already been activated.
Device Installation and Mounting
Select an appropropriate location to
mount your device. The most important
factors to consider are:
6
7
5
1
2
3
4
