INDE PLASTIK IP 190 User manual

IP 190 Se ling M chine
- 1-
Instruction M nu l
IP 190 Se ling M chine
INDE PLASTIK Betriebsges. mbH
Industriestrasse 16
52457 Aldenhoven
Tel.: [phone]
Fax: [phone]
Email: [email protected]

IP 190 Se ling M chine
- 2-
Contents:
1. Introduction ...............................................................................................................3
2. S fety inform tion ....................................................................................................3
3. Description of the individu l p rts..........................................................................4
4. Prep r tion for use ...................................................................................................8
5. Oper tion ...................................................................................................................9
6. Cle ning the se ling surf ce .................................................................................10
7. Consum bles / Rep irs / Service ddress............................................................11
8. W rr nty...................................................................................................................11
9. Technic l d t .........................................................................................................12

IP 190 Se ling M chine
- 3-
1. Introduction
The machine is used to manually seal all kinds of trays made from CPET, PP, PS and
OPS with different kinds of film. Fusing and sealing can be carried out in one operation.
atching sealing frames are available for various container shapes.
Read these instructions carefully before using the sealing machine.
Use the sealing machine only for its intended purpose as described in this manual.
2. S fety inform tion
The device complies with the essential health and safety requirements. Nevertheless,
dangerous situations can occur. Follow all safety precautions given in this manual!
Ignoring these instructions may lead to serious risks to health or even life-threatening
injuries!
The following safety symbols are used in this manual:
W rning - d ngerous electric l volt ge
W rning – hot surf ce
The symbol indic tes the potenti l for injury or loss of life.
The symbol indic tes h z rd to property nd / or environment l
d m ge.
This symbol indic tes import nt f cts.
Danger
Attention

IP 190 Se ling M chine
- 4-
3. Description of the individu l p rts
Over ll view
ains switch
Heating control light
Temperature setting control

IP 190 Se ling M chine
- 5-
Fuse
Film roll support bracket
Sealing surface
Cutter
Sealing frame

IP 190 Se ling M chine
- 6-
Film retaining bracket
ains cable
Film roll
Air vents
Tensioning spring

IP 190 Se ling M chine
- 7-
4. Prep r tion for use
Before using the sealing machine carry out the following preparatory steps:
Inserting the film roll
Insert the film as shown in the picture, (the film is unwound from the top).
ake sure that the film is fed under the bracket. The film retaining bracket prevents the
film from slipping out after the automatic cutting operation which takes place during
sealing.
Film retaining bracket
When feeding the film under the br cket be c reful to void touching
the cutter..
Setting up the se ler
Install the machine in a suitable location. This must allow sufficient space for unres-
tricted operation.
M ke sure th t the m ins c ble does not p ss over he ted
surf ces.
Connecting to the m ins
Plug the power cable into the mains (230 V).
The connection must be vi fused socket outlet.
Danger
Danger
Danger

IP 190 Se ling M chine
- 8-
5. Oper tion
Step 1: Turn on the device using the mains witch. The light in the mains
switch is illuminated.
Step 2: Set the temperature setting control to the required temperature. It
should be 140°C for PP and PET trays and 90°C for PS trays (The
orange light goes off whenever the selected temperature is rea-
ched.)
When switching on initially small amounts of steam may be emitted
for a short while; these are not harmful and burn off residual pro-
duction fats.
Step 3: Fill the tray with the selected food and put it into the sealing frame.
Step 4: Hold the film as shown in the illustration and pull the film over the
tray. Ensure that the film overlaps the edges of the tray.
When pulling out the film be careful not to touch the sealing surface.
When pulling out the film be careful not to touch the cutter.
Danger

IP 190 Se ling M chine
- 9-
Step 5: Grasp the top handle with both hands as shown in the illustration
and, applying light pressure, press the sealing surface down until it
rests on the film-covered tray.
The sealing process takes about 1 to 3 seconds.
After sealing is complete lift the upper handle with both hands back
to the starting position. (Do not let go of the handle.)
Do not allow the sealing process to extend beyond about 3 seconds
maximum.
Do not touch any other areas except the handle on the top of the
machine. In particular, the areas around the upper and front air vents
and the side surfaces of the top of the machine can become very
hot.
Step 6: Now remove the sealed tray.
Each unit is factory tested for functionality. While it is being
transported it may become misaligned. Check the seal quality before
giving customers the first sealed food trays.
Attention

IP 190 Se ling M chine
- 10 -
Information on changing the film roll
Turn off the mains switch and allow the sealing machine to cool
before replacing the film roll.
When changing the film roll do not touch the cutter.
6. Cle ning the se ling surf ce
The sealing surface should be cleaned only with water to which a commercially availa-
ble detergent can be added. Use a sponge or soft cloth for cleaning.
Unplug the mains lead before beginning any cleaning.
Allow the machine to cool down before beginning any cleaning.
Danger

IP 190 Se ling M chine
- 11 -
7. Consum bles / Rep irs / Service ddress
We recommend that you use only original consumable materials from INDE PLASTIC
(trays and films). Only then we can guarantee optimum sealing results.
We assume no liability for damage caused by using supplies other than the manufactu-
rer’s consumables.
Do not make any repairs to the sealer. Please contact the service
address provided in case of malfunctions
To order consumables and in the event of any necessary repairs or for further informa-
tion please contact us at the following service address:
INDE PLASTIK Betriebsges. mbH
Industriestrasse 16
52457 Aldenhoven
Tel.: [phone]
Fax: [phone]
Email: [email protected]
You can find out more information on our products at www.indeplastik.de
www.indeplastik.de
8. W rr nty
The warranty period is six months after the commissioning of the machine.
We assume no liability for damage caused by incorrect or improper use.
Danger

IP 190 Se ling M chine
- 12 -
9. Technic l d t
Technic l d t :
Sealing surface: 225 x 180 mm
Roll width: 190 mm max
Roll diameter: approx 180 mm
Power supply voltage: 230 Volt
Power consumption: 550 W
Fuse: 3 A
Net weight: 9 kg
